This product contains drivers that work with the
Windows XP,
following operating systems:
Windows 2000, and Windows Me

Before You Begin

Decide which setup mode (Ethernet NIC or USB) you want to use and follow the
installation process for that setup mode.
Local Cable Network Service
Before installing the cable modem, contact your local cable service provider to
check the availability of Internet/Cable network access. Read this Quick Installation
Guide thoroughly before attempting to install the cable modem.
Check Your Package Contents
These are the items included with your DCM-201 purchase:
D-Link Cable Modem DCM-201
CD-ROM (containing USB Drivers, Manual,
and Warranty)
Ethernet (CAT5 UTP/Straight Through) Cable
Device Stand
USB Cable
12V DC, 1.25A Power Adapter
If any of the above items are missing, please contact your reseller.
©2003 D-Link Systems, Inc. All rights reserved. Trademarks or registered trademarks are the property of their respective holders. Software and
specifications subject to change without notice. DCM-201.05052003
DCM-201
D-Link Cable Modem
1
