Operator's Guide
This guide contains selected information on how to use the
printer and frequently used features of the printer.
See the User's Guide (online manual) for detailed instructions
on using the printer.
Home Screen Operations ....................................... 2
Getting Ready to Print ............................................. 4
Printing CAD Drawings ........................................... 6
Printing Banners ........................................................ 8
Printing at Non-Standard Sizes ............................ 10
Print from an Upload) .............................................. 13
(SC-T5400M Series) ................................................... 14

Advertisement

Table of Contents
loading

Related Manuals for Epson SC-T5400 SERIES

Summary of Contents for Epson SC-T5400 SERIES

  • Page 1: Table Of Contents

    Operator’s Guide This guide contains selected information on how to use the printer and frequently used features of the printer. See the User’s Guide (online manual) for detailed instructions on using the printer. Home Screen Operations ........2 Getting Ready to Print ..........4 Printing CAD Drawings ...........

  • Page 2: Home Screen Operations

    Home Screen Operations Approx. remaining levels of The network connection status consumables The icon changes according to the connection method. While the printer is connected, is blue and indicates As the ink is consumed or the maintenance box the signal strength. becomes full, the corresponding bar becomes shorter.
  • Page 3 The home screen is displayed when the printer is turned on. These pages show the available operations on the home screen. The number of notices The number of notices, such as ink low warnings, is displayed on the icon. Touch this icon… A list of the notices that require your action is displayed.

  • Page 4: Getting Ready To Print

    Getting Ready to Print Check the Paper Loading Load the Paper Following the Positions On-Screen Instructions Touch Paper Setting. Roll Paper Select one of the paper sources. Cut Sheet (1 sheet) A4 to the maximum print width One sheet at a time Touch See Guide to see the detailed on-screen instructions.
  • Page 5 Paper Size Promptly select the settings because the paper will start being fed if the screen is not used for 90 seconds. Epson Special Paper Select the paper name printed on the paper package. Non-Epson Paper Select one of the following.

  • Page 6: Printing Cad Drawings

    Printing CAD Drawings Click Custom Properties. Using the Printer Driver This method is best suited to printing CAD drawings, such as appearance view of buildings, at high quality. The printer driver screen is displayed. Select CAD/Line Drawing at Printer Settings tab.
  • Page 7 Settings - Page Margins option - Oversize Click Plot. Select plotter in Printer/plotter. Select the plotter name as shown below according to your model. SC-T5400 Series: HP DesignJet 750C C3196A SC-T5400M Series: HP DesignJet 750C C3196A SC-T3400 Series: HP DesignJet 750C C3195A...

  • Page 8: Printing Banners

    Printing Banners Fitting the Original to the Roll Steps to print a banner Paper Width Create the original in the application Fitting the short side of Original the original to the roll paper width. Fitting the long side of the original to the roll Select the enlargement method paper width.
  • Page 9 These pages explain how to enlarge and print an original created at a standard size for a banner. Fitting the Original to the Output Specifying the Size Size Output size Output size Original Original Select Output Size - Fit to Output Size, and then select the Select Output Size - Specify Size, and then select the output output size.

  • Page 10: Printing At Non-Standard Sizes

    Printing at Non-Standard Sizes Steps to print a non-standard size Register and Select the Paper Size Register and select the paper size in the application Windows Start the application, click the File menu, and then click Print. On the Printer Settings tab, click Custom Paper Size...
  • Page 11 These pages explain how to create and print an original with a non- standard size, such as a banner or square shape. Create the Original Create the original using the application. Start the application, and then click Page Setup. Enlarge and Print the Original If Page Setup is not displayed due to the application, select Print.

  • Page 12: Printing By Installing A Usb Flash Memory

    Printing by Installing a USB Flash Memory Select one file to print. You can print JPEG files or TIFF files saved on a USB flash memory by installing it on the printer. When printing TIFF Install the USB flash memory in which the data to be printed is saved onto the printer.

  • Page 13: Other Printing (Wi-Fi Direct Printing/Print From An Upload)

    Other Printing (Wi-Fi Direct Printing/Print from an Upload) Printing by connecting with Wi-Fi Print from an Upload using Web Direct Config (SC-T5400M Series) Use Wi-Fi Direct to connect your device to the printer when Using Web Config to print from an upload, allows you to you are outside the office and cannot connect to the printer print from a computer that does not have the printer driver over a wired or wireless connection.

  • Page 14: Loading An Original For Copying/Scanning (Sc-T5400M Series)

    Loading an Original for Copying/ This section explains an overview of loading an Scanning (SC-T5400M Series) original to copy and scan. Supported Sizes and Types of Loading the Original while Viewing Originals the Guide Size of original Touch Copy or Scan. Width of original: 148 mm to 914 mm (36 inches) Length of original: 148 mm to 30,480 mm (1,200 inches)* 1 sheet only...

  • Page 15: Procedure For Copying (Sc-T5400M Series)

    Procedure for Copying This section explains the procedure for copying after the original is (SC-T5400M Series) loaded. Touch the Copy button to start scanning the Load the original. original. U “Loading an Original for Copying/ Scanning (SC-T5400M Series)” on page 14 Do the settings for copying.

  • Page 16: Procedure For Scanning (Sc-T5400M Series)

    Procedure for Scanning (SC-T5400M Series) Load the original. You can scan documents and CAD drawings, make them into image data, and then save the data or send it via email. U “Loading an Original for Copying/ Scanning (SC-T5400M Series)” on page 14 Specify the destination or where you want to save the data.
  • Page 17 There are 3 ways that you can save or send the data of scanned images. Touch the Save button to start scanning the You can register setting values that are often used in copying and original. scanning as presets. Select Presets on each settings screen, and then touch Save as Preset.
  • Page 18 MEMO...
  • Page 19 Epson printer. Epson is not responsible for any use of this information as applied to other printers. Neither Seiko Epson Corporation nor its affiliates shall be liable to the purchaser of this product or third parties for damages, losses, costs, or expenses incurred by the purchaser or third parties as a result of accident, misuse, or abuse of this product or unauthorized modifications, repairs, or alterations to this product, or (excluding the U.S.) failure to strictly comply with Seiko Epson Corporation‘s operating and maintenance instructions.
  • Page 20 From the home screen, touch Settings - Maintenance - Print Head Cleaning. Lines appear on the scanned The glass surface of the scanner is dirty. See the User’s Guide (online manual) for how to or copied document. clean the glass surface. CMP0158-01 EN ©2018 Seiko Epson Corporation. All rights reserved.
