This product can be set up using
any current web browser, i.e.,
Internet Explorer 6.0, Netscape
Navigator 6.2.3.
Before You Begin
1. If you purchased this router to share your high-speed Internet connection with other
computers, you must have either an Ethernet-based Cable or DSL modem with an
established Internet account from an Internet Service Provider (ISP).
2. It's best to use the same computer that is connected to your modem for configuring
the DI-754 Multimode Wireless Router. The DI-754 acts as a DHCP Server by
default and will assign all the necessary IP address information on your network.
See Appendix at the end of this Quick Installation Guide or the Manual on the
CD-ROM for setting each network adapter to automatically obtain an IP
address.
Check Your Package Contents
If any of the above items are missing, please contact your reseller.
©2002 D-Link Systems, Inc. All rights reserved. Trademarks or registered trademarks are the property of their respective holders. Software and
specifications subject to change without notice. DI-754.09252002
DI-754 Multimode Wireless Router
CD-ROM (containing Manual and Warranty)
Ethernet (CAT5 UTP/Straight Through) Cable
5V DC, 3A Power Adapter
DI-754
5GHz Multimode
Wireless Router
Using a power
supply with a
different voltage rating
will damage and void
the warranty for this
product.
Advertisement
Related Manuals for D-Link DI-754
Summary of Contents for D-Link DI-754
-
Page 1: Before You Begin
5V DC, 3A Power Adapter If any of the above items are missing, please contact your reseller. ©2002 D-Link Systems, Inc. All rights reserved. Trademarks or registered trademarks are the property of their respective holders. Software and specifications subject to change without notice. DI-754.09252002... - Page 2 First, connect the power adapter to the receptor at the back panel of the DI-754 and then plug the other end of the power adapter to a wall outlet or power strip. The Power LED will turn ON to indicate proper operation.
-
Page 3: Restart Your Computer
When a D-Link AirPlus DWL-650+ Wireless Cardbus Adapter is inserted into the Expansion Slot on the back of the DI-754, computers equipped with 802.11b wireless adapters will be able to connect to the DI-754. The DWL-650+ AirPlus Wireless Cardbus Adapter and the DWL-520+ AirPlus Wireless PCI Adapter will be able to connect out of the box with the router using their default wireless settings. - Page 4 Connecting Additional Computers To The DI-754 Using additional Ethernet (CAT5 UTP) cables, connect your Ethernet-equipped computers to the remaining Ethernet LAN ports on the back panel of the DI-754 M1 LED – a solid light indicates that the DI-754 is M2 LED –...
-
Page 5: Using The Setup Wizard
Using The Setup Wizard Insert the DI-754 CD-ROM The Install Screen will appear. Click Configure DI-754 If the logon screen does not automatically appear, please follow the step shown below. If the logon screen does appear, proceed to the next screen. - Page 6 The Setup Wizard (continued) Once you have logged in, the Home screen will appear. Click Run Wizard You will see the following screens Click Next Step 1 - Set up your new password. You have the option to establish a password.
- Page 7 The Setup Wizard (continued) Step 2 Choose your time zone. You will be prompted to select your time zone for your router Click Next Step 3 – Select your Internet Connection. prompted to select the type of Internet connection for your router. Select one of these settings...
- Page 8 The Setup Wizard (continued) If you selected Dynamic IP Address, this screen will appear: Click the “Clone MAC Address” button to automatically copy the MAC address of the network adapter in your computer. You can also manually type in the MAC address.
- Page 9 The Setup Wizard (continued) If your ISP uses PPPoE (Point-to-Point Protocol over Ethernet), and this option is selected, then this screen will appear: Please be sure to remove any existing PPPoE client software installed on your computers. Enter in the username and password provided to you by your ISP.
- Page 10 Click Next If you enable encryption on the DI-754 make sure to also enable encryption on all 802.11a wireless clients or wireless connection will not be established The following steps are required if you have added the DWL-650+ Wireless Cardbus adapter in the Expansion Slot on the DI-754.
- Page 11 Click Next If you enable encryption on the DI-754 make sure to also enable encryption on all 802.11b wireless clients or wireless connection will not be established Your Setup is Complete! Click...
- Page 12 Continued... Click Close You will be returned to the Home tab. Test your Internet connection. Click Exit Then relaunch your Web browser (i.e., Internet Explorer or Netscape Navigator), to link to your favorite Web site to test your Internet connection. For additional settings or information, select HELP or refer to the...
- Page 13 APPENDIX To connect to the DI-754, make sure the network adapter in your computer is configured properly. Here’s how to configure the network adapter to obtain an IP address automatically for the DI-754 5GHz Multimode Wireless Router. Microsoft Windows XP: Go to Start >...
- Page 14 Apple Macintosh OS X: Go to the Apple Menu Click on Network and Select System Preferences Select Built-in Ethernet in the Show pull-down menu Select Using DHCP in the Configure pull- down menu Click on Apply Now The IP address information, the Subnet Mask, the Router’s IP address and the Ethernet adapter address will appear...
- Page 15 NOTES...
-
Page 16: Technical Support
Technical Support You can find the most recent software and user documentation on the D-Link website. D-Link provides free technical support for customers within the United States for the duration of the warranty period on this product. U.S. customers can contact D-Link technical support through our web site or by phone.
