- Page 1 20810 Sockeye Pl #200 Bend, OR 97701 Support and Sales Questions: Tel: (866) 977-6688 Monday to Friday 9AM to 5PM Pacific Time English Manual V2.0 or email support@evogimbals.com Pour le French Manual, rendez-vous sur EVOGimbals.com EVOGimbals.com Para el manual de español, vaya a EVOGimbals.com...
-
Page 2: Table Of Contents
CONTENTS Important Message Overview Getting Started Operating Modes Inverted Mode Micro USB Connection Camera Charging & Video Out Startup & Calibration Specifications Notes Warranty... -
Page 3: Important Message
IMPORTANT MESSAGE IMPORTANT MESSAGE Thank you for choosing EVO Gimbals as your camera stabilization solution! We know that buying a new Thumb Screw product can be very exciting and we are sure that you probably can not wait to use your new gimbal! Before (on back) you start PLEASE read this manual and become familiar with your gimbal’s components and operating modes. -
Page 4: Overview
GETTING STARTED Action Camera (not included) UNPACK THE EVO GP-PRO Thumbscrew Thank you for choosing EVO Gimbals! Before you begin please be sure to unpack your GP-PRO and Tilt Motor review your contents list! Camera Mounting Bracket Your EVO GP-PRO should be packed with the following items:... - Page 5 Mode Button for 2 seconds to engage the your camera and into the camera Mode Button motors. charging port at the base of the tilt motor. Once powerd on, The EVO GP-PRO starts up in Pan Follow Mode. See page 7 for details on the other modes.
-
Page 6: Operating Modes
INVERTED MODE The EVO GP-PRO enters Pan Follow Mode (PF) by default each time when powered on. Switch into Lock Mode (LM) by single pressing the Mode Button. Double press the Mode Button to enter Full Follow Mode (FF). Single press the Mode Button to exit Full Follow mode to the previous Lock or Pan Follow mode. -
Page 7: Micro Usb Connection
FIRMWARE & SOFTWARE UPDATES There are 3 GoPro accessory cables included in the Connect the EVO GP-PRO to your computer via Micro USB cable for the firmware upgrade and calibration. box. Two are Mini USB cables and one is a USB-C cable. -
Page 8: Startup & Calibration
STARTUP & CALIBRATION STARTUP & CALIBRATION STARTUP CALIBRATION SIX-SIDED CALIBRATION If you find during normal use that your camera’s pitch or roll angle begins to drift or deviate then you need to first try restarting your gimbal. Simply power off your gimbal and set it down on a flat non-moving surface. -
Page 9: Specifications
SPECIFICATIONS NOTES 95mm 31mm MAX CAMERA DIMENSIONS Height: 42.7mm Width: 31mm Stabilization Accuracy: ±0.01° Follow Accuracy: ±0.2° Pan Axis Range: -135° to +135° Tilt Axis Range: -90° to +180° (Inverted) Roll Axis Range: -45° to +45° Tilt Axis Control Speed: Min 1°/s Max 50°/s Pan Axis Control Speed: Min 1°/s Max 80°/s... -
Page 10: Warranty
DAMAGES FOR BREACH OF ANY EXPRESS OR IMPLIED WARRANTY ON THIS PRODUCT. Labor: For a period of one (1) year from the original date of purchase of the product (“Labor Warranty”), EVO Gimbals will, at its option, repair or replace with new or refurbished product, product determined to be defective. If EVO Gimbals elects DURATION OF IMPLIED WARRANTIES: EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW, ANY IMPLIED to replace the product after this Labor Warranty has expired but while the Parts Warranty below is still in effect, it will do so...
