WASH MOVING HEAD
M37W15RGBW
USER MANUAL
For safety, please read this user manual carefully before initial use.
Event Lighting reserves the right to revise the manual at any time. Information and specifications within this manual are subject to
change without notice. Event Lighting assumes no liability or responsibility for any errors or omissions. Please consult Event Lighting
for any clarification or information regarding this item.
www.event-lighting.com.au
V1.1
Advertisement
Table of Contents
Related Manuals for Event Lighting M37W15RGBW
Summary of Contents for Event Lighting M37W15RGBW
- Page 1 For safety, please read this user manual carefully before initial use. Event Lighting reserves the right to revise the manual at any time. Information and specifications within this manual are subject to change without notice. Event Lighting assumes no liability or responsibility for any errors or omissions. Please consult Event Lighting for any clarification or information regarding this item.
-
Page 2: Safety Instructions
Safety Instructions WARNING • Do not open this device, there is no user-serviceable parts inside. Risk of electric shock. • Do not look at the light source when the device is on. • CAUTION: This unit's housing may be hot during and after operation. •... - Page 3 Product appearance, LUX chart, Dimensions Project lens Head Base Display Foot stand Operation button Handle Wireless indicator 10. Mic 11. Left Button 12. Battery Indicator 13. Enter Button 14. Down Button 15. Up Button 16. Right Button 17. Ethernet Out 18.
-
Page 4: Menu Operation
Menu operation Description of icons in the menu CONNECT LIGHT INFOMATION PROGRAM Menu Default setting shadowed. Mark with ①can be basic reloaded, ② be program reloaded, ③can be private reloaded. DMX Address① DMX address setting Wireless① Wireless Enabled Max Temperature① 80~139℃, 90℃... - Page 5 Brand Show① ON/OFF Show brand or not Key Lock① ON/OFF Key lock on/off Language① En/简/繁/Fr/Sp Language Select Users User Mode① Standard Standard mode Extended Extended mode Basic-8bit Basic mode-8bit Basic-16bit Basic mode-16bit User User program mode Edit User③ Max Channel = XX Edit users mode PAN = CH01 Calibration③...
-
Page 6: Dmx Chart
DMX Chart Channel Name Function Pan Coarse Pan fine Pan Fine Tilt Tilt Coarse Tilt fine Tilt Fine Movement Fastest to slowest Speed Normal Movement Movement With Blackout Function Normal Shutter Functions Pulse-effect Forward Shutter Pulse-effect Reverse Function Random Strobe Normal Shutter Functions Close Strobe Rate (slow to fast) - Page 7 CTC Function Colour Temperature Correction 2000K->2700K White 3200K White 4200K White 5600K White 8000K Forward Spin Rainbow Effect (Slow->Fast) Reverse Spin Rainbow Effect (Slow->Fast) Continuous & Color Bounce Virtual Color Black Green Blue White Red=0, Green->up, Blue=full, White=0 Red=0, Green=full, Blue->down, White=0 Red->up, Green=full, Blue=0,White=0 Red=full, Green->down, Blue=0,White=0 Red=full, Green=0,Blue->up, White=0...
- Page 8 Pattern control Pattern Picture Effect Speed Pattern Effect Slow-> Fast Pattern Direct access to Pattern of LED 1&LED 2 Byte 1 Bit 0 Bit0=Led1 Red Switch Bit 1 Bit1=Led1 Green Switch Bit 2 Bit2=Led1 Blue Switch Bit 3 Bit3=Led1 White Switch Bit 4 Bit4=Led2 Red Switch Bit 5...
- Page 9 Pattern Direct access to Pattern of LED 35&LED 36 Byte 18 Pattern Direct access to Pattern of LED 37 Byte 19 Led Off Red Pixel 1 Led On Led Off Green Pixel Led On Led Off Blue Pixel 1 Led On Led Off White Pixel 1 Led On...
-
Page 10: More Functions
More functions RDM. RDM stands for “Remote Device Management”, with this function, users can realize remote control of the device, such as remotely changing DMX address, reverse pan/tilt setting, check a lot of useful information such as temperature, power consumption, fan speed. Etc. Every single device has a unique RDM code programmed at manufacture to distinguish from each other.
