WARNING:
The Model 8630 Room Pressure Monitor must be wired to 24 VAC only. Wiring the unit to
110 VAC will cause serious damage to the unit and void the warranty.
The pressure sensor must be mounted through the wall between the controlled space (isolation
room) and referenced space (ante room / hallway).
These installation instructions guide the installer through the installation of the TSI Model 8630 PresSura
Room Pressure Monitor. Please read these instructions thoroughly before beginning installation.
This product is classified by Underwriters Laboratories, Inc.
firestop systems. See UL fire resistance directory.
Figure 1: Typical Installation
_____________________
TSI and TSI logo are registered trademarks of TSI Incorporated.
PresSura is a trademark of TSI Incorporated.
MODEL 8630 PRESSURA
ROOM PRESSURE MONITOR
INSTALLATION INSTRUCTIONS
for use in through-penetration
®
Component List
Part Number
Qty
800243
1
800248
1
800244
1
or
800245
1
800420
1
800414
1
1901057
2
2923020
1
™
Description
Pressure sensor
Sensor cable
8630-SM Room pressure
monitor
8630-PM Room pressure
monitor
Transformer
Transformer cable
Intumescent ring
Fire sealant
™
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for TSI Incorporated PRESSURA 8630
Summary of Contents for TSI Incorporated PRESSURA 8630
- Page 1 8630-SM Room pressure monitor 800245 8630-PM Room pressure monitor 800420 Transformer 800414 Transformer cable 1901057 Intumescent ring 2923020 Fire sealant Figure 1: Typical Installation _____________________ TSI and TSI logo are registered trademarks of TSI Incorporated. PresSura is a trademark of TSI Incorporated.
- Page 2 Pressure Sensor Installation Figure 2: Pressure Sensor Orientation and Mounting Template 2. The pressure sensor must be orientated WARNING: 800243 pressure sensor must on the wall as shown in Figure 2. be mounted through the wall between the Looking at the mounted sensor, sensor controlled space (isolation room) and hole is on the left (2¼”) and wire hole is referenced space (hallway), exactly as shown...
- Page 3 6. From the side of the wall the sensor will be 8. Wire the pressure sensor per Figure 7. Run mounted, slide the sensor tube through the sensor cable to the room pressure monitor wall. Mark the tube where it is flush with 4”...
- Page 4 Transformer Installation WARNING Make sure no power is applied until all wiring is complete. Follow all applicable electrical codes, and have qualified personnel install the transformer. Note: Each system must be installed with supplied Figure 5: Transformer Installation transformer. If TSI transformer is discarded and a central transformer is installed, a separate...
- Page 5 Pressure Monitor Installation Pressure Monitor Rough-in 1. Select the mounting location of the pressure monitor. The construction plans normally show the mounting location. If no location is specified, then the unit is typically installed as shown in Figure 1. Alternate mounting locations are nurse’s station, other staff areas, etc. 2.
- Page 6 Figure 7: Wiring Diagram If you need assistance installing the system, call TSI at (800) 874-2811. TSI Incorporated – Visit our website www.tsi.com for more information. Tel: +1 800 874 2811 India...
