  • Page 1 SURFTAB P10 SURFTAB BREEZE 7.0 QUAD LTE OPERATING INSTRUCTIONS OPERATING INSTRUCTIONS...

  • Page 2: Table Of Contents

    CONTENT Welcome ……………………………………………………………………………… 4 Intended use ………………………………………………………………………… 4 Explanation of Safety Symbols and Keywords …………………… 5 General Safety Information ………………………………………………… 5 Technical speci ications ………………………………………………………… 11 Technical speci ications of the device Technical speci ications of the power adapter Package contents ………………………………………………………………… 12 Controls &...
  • Page 3 16. Launching the Internet browser/ Entering an Internet address 24 Sending and receiving e-mails with the Surftab …………………… 24 Setting up the app Receiving e-mails Sending e-mails 18. Downloading and installing apps from the Play Store ………… 26 19. Uninstalling apps ………………………………………………………………… 27 20.

  • Page 4: Welcome

    Welcome We hope you enjoy your new Surftab breeze 7.0 quad LTE. The online operating instructions, the enclosed Quick Start Guide and the additional brochure "Product Safety and Legal Information" are direct components of the product. Please read all three documents carefully before you turn on your device. They contain important information about device safety, usage and disposal.

  • Page 5: Explanation Of Safety Symbols And Keywords

    3. Explanation of Safety Symbols and Keywords This booklet uses the following safety symbols and keywords: WARNING Indicates possible danger to life and/or danger of severe, irreversible injuries CAUTION Follow instructions to avoid injuries and material damage NOTICE Follow instructions to avoid material damage ADVICE Additional information about using the device 4.
  • Page 6 Risk of electric shock or electrocution and/or fire hazard from unsafe connections Make sure the power cord is not bent, crimped, or damaged in any other way. ■ Never use the power cord or plug if they are damaged. ■ Only use the included power adapter and only connect it to a suitable ■...
  • Page 7 Risk of multiple injuries due to reduced attentiveness Safety is the top priority while driving. For this reason, it is prohibited to ■ use the device while operating a motor vehicle. Always be aware of your immediate surroundings to avoid putting yourself ■...
  • Page 8 CAUTION Risk of fire or explosion when using non-approved chargers and power adapters Only use the included power adapter or an equivalent power adapter to ■ charge the battery. If the power adapter is defective, only exchange it for an equivalent power ■...
  • Page 9 Risk of impairment to the musculoskeletal system and supporting tissue from use over longer periods of time Repetitive movements (e.g., use of keyboard/touch screen or playing ■ games for an extended period of time) may result in pain in the hands, arms, shoulders, neck and shoulder region, and in other parts of the body.
  • Page 10 Use the device in a dust-free environment. ■ Magnetic ields may cause the device to malfunction and/or the battery to ■ discharge. To prevent possible damage to your device: Do not charge your device on standard USB ports such as those found on ■...

  • Page 11: Technical Speci Ications

    5. Technical specifications Technical specifications of the device Processor (CPU): MT8735M Processor, up to 1,0 GHz, 64-Bit ARMv8 Cortex-A53, quad core Operating system: Android™ 7.0 (Nougat) RAM: 1 GB DDR 3 Storage capacity: 16 GB Graphics processing unit (GPU): Mali-T720 MP2 Display size: 7"...

  • Page 12: Technical Speci Ications Of The Power Adapter

    0,4 A max. Output: DC 5.0 V/2.0 A Manufacturer: Shenzhen Fujia Appliance Co., Ltd. 6. Package contents TREKSTOR SURFTAB BREEZE 7.0 QUAD LTE ■ Micro-USB cable ■ USB host adapter cable ■ USB power adapter (100 V - 240 V) ■...

  • Page 13: Controls & Ports

    Controls & Ports Touch screen Front camera Earpiece Volume + Volume - On/off switch Reset Slit for opening the cover Audio port Rear camera Video light Micro-USB socket/Charging socket...

  • Page 14: Starting Up The Surftab For The Irst Time

    Dual-SIM card slot Memory card slot Speaker Microphone 8. Starting up the Surftab for the first time Charging the Surtab Please fully charge your Surftab before you use it for the irst time. To charge the Surftab, connect the Micro-USB plug on the power adapter supplied to the micro-USB socket on the Surftab.
  • Page 15 Your Surftab will be con igured once you complete the setup process. This may take a few minutes. Do not switch off the Surftab during this period! Each time you turn on the Surftab after setting it up, the lock screen will appear during start up.

  • Page 16: Elements On The Start Screen

    Elements on the start screen Google™ search Google™ voice search View all open elements: Tap this button to view all open elements. To close a recently used element (app, widget, menu), place the tip of your inger on the element you want to close and drag the element to the left or right. Home icon: Tap this button to go back to the start screen.

  • Page 17: Using The Touch Screen

    10. Using the touch screen Selecting an element To open an element or select an option, brie ly touch the icon you require with the tip of your inger.

  • Page 18: Enlarging And Reducing The View

    Enlarging and reducing the view You can change the size of some displays (images, Web pages and so on). Move two ingers apart on the screen to enlarge the display. In reverse, move two ingers towards each other on the screen to reduce the display again. Scrolling To scroll on your Surftab screen or in an app, place your ingertip on the screen and drag the screen in the opposite direction:...

  • Page 19: Personalising The Home Screen

    11. Personalising the home screen You can set up the home screen as you wish by adding or removing app shortcuts and widgets in the form of icons and altering the background. NOTICE You can move an icon located on your home screen at any time. Hold your finger on the icon you want to move until you can move it.

  • Page 20: Removing App Shortcuts And Widgets From The Start Screen

    NOTICE To access an icon that is on a page other than the first page of the start screen, simply scroll to the relevant page (see Section 10, "S "). Removing app shortcuts and widgets from the start screen To remove an app shortcut or widget from the start screen, hold down the respective icon until the following symbol appears in the top in the left of the screen: "X".

  • Page 21: Changing The Screen Background

    Changing the screen background Touch an empty area of the screen background until the word "W " appears at the bottom of the screen. Tap the word. A view of all the background images saved on the Surftab will be displayed. NOTICE If you tap "M "in the row of available background images, this will take...

  • Page 22: Changing The Display Language

    14. Changing the display language Call up Settings (see Section 12). Scroll down in Settings and tap "L & " (globe symbol). Tap "L " in the following view. Tap the required language. The Surftab will now use the selected language as the display language.
  • Page 23 Insert SIM card Switch off your device completely before inserting the SIM card. The card will not be recognised if the device is in standby mode. NOTICE To prevent malfunctions and mechanical defects, never use a SIM card adapter. The SIM card slot is located under the device's cover, in the upper edge on the back of the tablet (see chapter 7, point M).

  • Page 24: Sending And Receiving E-Mails With The Surftab

    Specify settings for LTE mode Different options are available to you in order to adjust LTE mode to suit your requirements. Call up the settings (see chapter 12) and tap “S ”. A menu will appear displaying, among others, the setting option “S 1".

  • Page 25: Setting Up The App

    Setting up the app Connect your Surftab to the Internet (see Section 15). Open the e-mail app ("G "). A con iguration assistant appears. Follow the con iguration assistant’s instructions to set up the app. NOTICE During the setup process, the configuration assistant will prompt you to enter an e-mail address and the associated password.

  • Page 26: Downloading And Installing Apps From The Play Store

    Once you have inished entering all the details, you can send the e-mail. To do this, tap the arrow symbol top right (right next to the paperclip symbol). NOTICE If you want to make further changes to e-mail settings before sending an e-mail, tap the three bullet points on the far right of the screen at the top.

  • Page 27: Uninstalling Apps

    19. Uninstalling apps Proceed as follows to uninstall apps that you have downloaded: Call up Settings (see Section 12). In Settings, tap "A ". A list of all installed apps appears. Scroll to the app you want to uninstall and tap the app. Tap "U "...

  • Page 28: Using The Camera

    20. Using the camera Your Surftab has two cameras: a webcam on the front and a rear camera. To use the cameras, you must irst open the camera app provided. The camera app is located in the Applications menu. The app is recognisable from its icon, a camera lens with the title "C ".

  • Page 29: Transferring Iles Between The Surftab And Other Devices

    Camera symbol: Tap to start recording and tap a second time to stop recording Additional settings for photos and videos Options for: exposure, colour effect, white balance, scene mode NOTICE You can zoom in on or away from your subject in both photo and video mode. Move two fingers apart simultaneously on the screen to zoom in and together again to zoom out.
  • Page 30 The Surftab searches for all available Bluetooth devices nearby and then displays them as a list. Tap the device that you wish to connect to. The Surftab establishes a connection with the selected device and sends what is known as a "B "...

  • Page 31: Transferring Iles Between The Surftab And A Pc

    Transferring files between the Surftab and a PC Connect the Micro-USB plug of the USB 2.0 cable supplied to the Micro- USB socket of the Surftab and the USB plug of the cable with a USB socket on your PC. NOTICE Make sure when connecting the Surftab that it is not in stand-by mode and the screen is unlocked.

  • Page 32: Resetting The Surftab (Reset Hole)

    Also press the On/off switch and hold both buttons down. As soon as the TREKSTOR logo appears, release both buttons. A few moments later the recovery mode menu appears. Use both volume control buttons to navigate in recovery mode. Brie ly press the On/off switch on the device to select an option.

  • Page 33: Switching Off The Surftab

    Navigate to "W ". Con irm your selection by brie ly pressing the On/off switch. Tap: "Y " Navigate to "Y " and con irm your selection by brie ly pressing the On/off switch. Navigate to "R " in the following window and con irm your selection by brie ly pressing the On/off switch.

  • Page 34: Troubleshooting/Faq

    25. Troubleshooting/FAQ In the following, you will ind a list of frequently asked questions along with the appropriate answers and proposed solutions. Why does my Surftab show less storage space than indicated on the packaging? The storage capacity indicated on the packaging and in the technical speci ications refers to the total storage capacity of your Surftab.

  • Page 35: Glossary

    My Surftab won’t switch on. What can I do? The battery may not be suf iciently charged to allow the Surftab to switch on. Connect the Surftab to the charger (see Section 8) to recharge the battery. What can I do if the internal storage of my Surftab is full or almost full? To relieve the pressure on the internal storage of your Surftab and free up storage space, you can transfer media iles stored on the Surftab (for example, images, videos or text iles) to an external storage device (for example, a USB...
  • Page 36 Multi-touch display A touch display is a screen that responds to command inputs via pressure points (for example, from a inger or a stylus pen). The multi-touch display is an extension of the "simple" touch display: It can simultaneously recognise the input of multiple pressure points. The multi- touch display is the most important element for operating your Surftab.

  • Page 37: Notes On Copyright And Trademarks

    Google Permissions. The Bluetooth word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by TREKSTOR GmbH is under license. Other trademarks and trade names are those of their respective owners.

  • Page 38: Notes On Disposal And Recycling

    28. Notes on disposal and recycling Notes on disposal This symbol on the device and in the accompanying documentation indicates that the device must be disposed of separately from normal household waste. This device (and the battery it uses) contain valuable raw materials such as rare earths and precious metals as well as components that are harmful to the environment and/or human health if not disposed of properly.

  • Page 39: Notes On The Warranty

    Directly contacting us, the manufacturer, via our service hotline or by illing out our service form allows us to address your concern more quickly and allows you to bene it from high-quality consulting and support. You can find out how to reach our service team here: www.trekstor.de/support-en.html...
  • Page 40 License (LGPL). For further information visit http://www.gnu.org/licenses/gpl For additional informations concerning Source Code please consult http://www.trekstor.de/opensource/ Disclaimer of liability Since this is concerning free software Contributor does not give any guarantee about free software as far as permitted by law.
  • Page 41 EU DECLARATION OF CONFORMITY As manufacturer and importer respectively: TREKSTOR GmbH | Berliner Ring 7 | D-64625 Bensheim, Germany herewith declares that the products Product: SURFTAB BREEZE 7.0 QUAD LTE ST70416 7 Type: Mobile Internet Device comply with the following directive(s):...
  • Page 42 Der Hersteller erklärt hiermit, dass das Surftab breeze7.0 quad LTE den wesentlichen Anforderungen und anderen relevanten Bestimmungen der Richtlinie 2014/53/EU entspricht. Frequenzbereich BT/BT LE: 2402 - 2480 MHz WiFi: 2412 - 2472 MHz GPS: 1575.42 MHz GSM 900: TX 880 - 915 MHz / RX 925 - 960 MHz DCS 1800: TX 1710 - 175 MHz / RX 1805 - 1880 MHz WCDMA 2100: TX 1922 - 1978 MHz / RX 2112 - 2168 MHz WCDMA 900: TX 882 - 913 MHz / RX 927 - 958 MHz...
  • Page 43 TREKSTOR GmbH Berliner Ring 7 64625 Bensheim, Germany www.trekstor.de BA-STB70QLTE-V1-10-EN-170816...
