- Page 1 INSTRUCTION MANUAL Elliptical Bike SKY1675 Ver. 2...
-
Page 2: Tools Required
TOOLS REQUIRED AA - MULTIFUNCTION TOOL DOUBLE OPEN-END ALLEN (WRENCH/ 1 PERSON APPROXIMATELY WRENCH BATTERY WRENCH SCREWDRIVER ASSEMBLY 45 MIN (PROVIDED) (PROVIDED) (3, PROVIDED) PROVIDED) ASSEMBLY HARDWARE φ15.6X88.8X1/2 φ15.6X88.8X1/2 M10X45 M10X57 4 PCS 1 PC 1 PC 1 PC 4 PCS 1 PC 2 PCS 4 PCS... -
Page 3: Product Assembly
PRODUCT ASSEMBLY Please retain these instructions for future reference. Loosen the tension with the knob on the main frame. Install the part B front bottom tube and part C rear bottom tube with two part 2 nut, bolt, and washer sets on each side. Note: The front bottom tube has wheels to easily maneuver your elliptical. - Page 4 Remove hardware from part 4 pedal hinge bolt (right) and insert it through part D right frame, replacing the hardware in the appropriate places as shown. Repeat this process on the left side with part 3 and part E. NOTE: The left pedal hinge bolt must be screwed counter-clockwise, and the right must be screwed Install part F and G pedals with four part 1 nut and clockwise.
- Page 5 Remove hardware from the part K seat and use the same hardware to attach the seat to the part L seat tube. Then, slide the part A bellow onto the seat tube and slide the assembled seat onto the main frame. Use a part 6 tri-knob to secure it in place.
-
Page 6: Caution During Use
FRONT VIEW Insert a AA battery into the part J monitor. Slide the monitor onto the bracket between the handle bars. Join the wire from the monitor to the wire on the elliptical. CAUTION DURING USE • Please read the manual carefully before beginning to exercise. •... -
Page 7: Display Monitor
DISPLAY MONITOR SPEED TIME DISTANCE CALORIE SCAN MODE Functional Buttons • Mode: Press this button to select a function to display. Press and hold to reset all functions. Function and Operations • Scan: Press the “MODE” button until “SCAN” is selected. The monitor will then rotate through all 3 functions - Time, Distance, Calories - and display each for 4 seconds. -
Page 8: Tension Adjustment
NOTICE • Please read these assembly instructions carefully before installing. • Firmly secure all screws before use. • Product is intended for indoor use only. • If any parts are missing, broken, damaged, or worn, stop using this item until repairs are made and/or factory replacement parts are installed.
