- Page 1 RCK-202B Rackmount Chassis User Manual...
- Page 2 Copyright Notice This document and product is copyrighted, January 2014, by AICSYS, Inc. All rights are reserved. No part of this manual may be reproduced, copied, or translated without prior notice to AICSYS, Inc. RCK-202B is trademark of AICSYS, Inc.
-
Page 3: Table Of Contents
Table of Contents Chapter 1 Getting Started ..............4 General Information ........................4 Product Specification......................... 4 Packing Checklist ........................4 Recommended Tools ......................... 5 Recommended Working Environment .................. 5 Chassis Mechanical Drawing ....................5 Chapter 2 Installation Guide ..............6 Unpacking the Chassis ...................... -
Page 4: Chapter 1 Getting Started
Chapter 1 Getting Started General Information The RCK-202B Rackmount chassis supports full-size SBC through 2U PICMG1.0/ 1.3 butterfly backplanes, and (2) 5.25" external drives bays, or (3) 3.5” internal drive bays. The chassis has (2) 80mm replaceable high-speed ball-bearing fans, and supports PS2 or Mini-redundant power supply. -
Page 5: Recommended Tools
Recommended Tools - Philips Head Screwdriver - Flat Head Screwdriver - Forceps (for pulling out jumpers and screws) Recommended Working Environment A flat anti-static work surface is required when assembling a complete system Chassis Mechanical Drawing Drawing with dimension in millimeter: - 5 -... -
Page 6: Chapter 2 Installation Guide
Chapter 2 Installation Guide Unpacking the Chassis The RCK-202B is shipped in a plastic bag that is placed inside a cardboard box. The accessories are also shipped with the chassis. When you unpack the chassis you must: - Make sure all the accessories and components listed above are present. -
Page 7: Installing The Power Supply Unit
Compatible Power Supply Unit models are available in Appendix A. Installing the Hard Disk Drive The RCK-202B chassis supports two 5.25" external drives bays, or three 3.5” internal drive bays. To install the drives, please follow the steps outlined in the sections below. -
Page 8: Installing The Backplane
Installing the Backplane To install the backplane please follow the instructions below: 1. Remove the fours crews securing the 2. Place the backplane to the bracket, and backplane bracket and pull upside to remove insert the screw to secure the backplane to from the chassis the bracket ... -
Page 9: Appendix A Power Supply Unit
SS-400R8P 400W Mini-redundant 150 x 200 x 86mm R4B-500G1V2 500W Mini-redundant Appendix B Backplane Compatible AICSYS Backplane are listed in the table below: Model number Type PCIe BP-0602P-2U Full-size PICMG 1.0 Backplanes 2 BP-0604P-2U Full-size PICMG 1.0 Backplanes 4 BPE-0502P-2U Full-size PICMG 1.3 Backplanes 2... - Page 10 The Global Choice for Premium Industrial Computer Products www.aicsys.com - 10 -...
