5-3. Measurement of Line Current
1) Set the power switch to "ON" position.
2) Set the range selector switch to a range appropriate to the current to be measured.
3) Clamp the conductor of the circuit under test.
4) If you make measurements in a dark place or in a place where it is difficult to see
the readings, use the data hold switch.
Note: Clamp around only one conductor of the circuit to be measured.
CAUTION:
This tester is designed for low voltage applications.
To avoid electrical shock or damage, the measurement is
limited to the circuit under 600V AC.

6. REPLACEMENT OF BATTERIES

When the battery becomes exhausted or drops below the operating voltage, the "B"
mark is displayed. Turn the power switch to "OFF", prior to installing batteries.
To install the batteries, remove the battery cover located on the unit back.(See Fig.2)
Insert the two LR-44 or SR-44 into the battery case making sure that proper polarity is
observed. (See Fig.3).
Always replace both batteries at the same time. If the difference between the voltages
of the batteries is big, the measurement error may be caused.
