Specification - MULTI MEASURING INSTRUMENTS 102 Instruction Manual

Ac current mini digital clamp-on tester
Table of Contents

Advertisement

2. CAUTION
● Before operating this instrument, familiarize yourself with all instructions outlined
in this manual.
● Always check to make sure that the function switch is set to the proper position.
● When making measurements, use CAUTION as dangerous voltages may be
present in normally safe areas.
● To avoid electrical shock, use CAUTION when working above 60V DC or 25V AC
rms.
Such voltages pose a shock hazard.
● Never make measurements with the battery cover OFF.
● Never fail to keep the maximum tolerable input.
● Never operate this instrument if it becomes wet, damp or has any liquid
condensation build-up on any part of the instrument.
Never make measurements for uninsulated conductors or bus bars.

3. SPECIFICATION

Measuring Method:
Display:
Range:
Accuracy:
Range
200mA
100A
Jaw opening capability:
Over range indication:
Maximum indication:
Low battery indication:
Data hold indication:
Sampling time:
Limitation of circuit voltage:
Withstanding Voltage:
Operating Temperature:
Storage temperature:
Power supply:
Power consumption:
Battery life:
Size:
Weight:
Accessories:
Dual integration mode
3.5 digit LCD max. reading of 1999
0~200mA/100A
23℃±5℃, 80%RH or less
Resolution
0.01mA
100mA
23mmφ
Blanking of all digits except MSD1
1999
"B" mark on LCD
"DH" mark on LCD
Approx. 2 times/s.
Less than AC 600V
AC 2000V (between the core of CT and rear
case)
0℃ to +40℃, <80%RH
-10℃ to +60℃, <70% RH
SR-44 (1.55V)x2 or LR-44x2
Approx. 3mW
Approx. 100 hours (LR-44)
Approx. 200 hours (SR-44)
48.0(W)x146(H)x20(D)mm
Approx. 80 gs.
Batteries, LR-44 (1.55V).............2
Instruction manual....................1
Soft case...................................1
Accuracy
±2.0%rdg ±5dgt(50/60Hz)
