MULTI MEASURING INSTRUMENTS 102 Instruction Manual

Ac current mini digital clamp-on tester

AC CURRENT

MINI DIGITAL CLAMP-ON TESTER

Thank you very much for selecting our digital AC clamp-on tester.

This model is complex instrument and employ a very reliable

mechanical/electronic design.

Before you use your new instrument, read this Instruction Manual

completely and familiarize yourself thoroughly with all functions.

With proper use and care, your tester will give you years of

satisfactory service.

1. FEATURES

● This tester is a clamp-on type leakage ammeter which represents the latest in current

transducer and digital technology and is the world's smallest and most accurate

clamp-on type instrument of its type.

● Compact and lightweight.

● This tester is least affected by the external magnetic field.

MODEL 102

INSTRUCTION MANUAL

Table of Contents

Do you have a question about the 102 and is the answer not in the manual?

Page 1 AC CURRENT MINI DIGITAL CLAMP-ON TESTER MODEL 102 INSTRUCTION MANUAL Thank you very much for selecting our digital AC clamp-on tester. This model is complex instrument and employ a very reliable mechanical/electronic design. Before you use your new instrument, read this Instruction Manual completely and familiarize yourself thoroughly with all functions.
Page 2 2. CAUTION ● Before operating this instrument, familiarize yourself with all instructions outlined in this manual. ● Always check to make sure that the function switch is set to the proper position. ● When making measurements, use CAUTION as dangerous voltages may be present in normally safe areas.
Page 3 4. DIMENSIONS AND PANEL FUNCTION ①Current transducer(Jaw) ⑥Range selector switch ②Jaw opening lever ⑦Power switch ③Data hold switch ⑧Battery cover ④LCD display ⑤Wrist strap 5. METHOD OF MEASUREMENT 5-1. Preparation and Caution before Measurement ● Before making measurements, install the batteries. Two LR-44 batteries can be used.
Page 4 Always replace both batteries at the same time. If the difference between the voltages of the batteries is big, the measurement error may be caused. MULTI MEASURING INSTRUMENTS CO.,LTD. Akihabara Murai Bldg. 7F, 1-26 Kanda Sakuma-cho, Chiyoda-ku, Tokyo 101-0025 JAPAN TEL: +81-3-3251-7016 FAX: +81-3-3253-4278 Home Page: http://www.multimic.com/...
