SAFETY INSTRUCTIONS CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVIC- ING TO QUALIFIED SERVICE PERSONNEL. DANGEROUS VOLTAGE: The lightning flash with arrowhead symbol, within an equilateral trian- gle is intended to alert the user to the presence of uninsulated dan-...
Page 3
SAFETY INSTRUCTIONS Before using the unit, be sure to read all operat- ing instructions carefully . Please note that these are general precautions and may not pertain to your unit. For example, this unit may not have the capability to be connected to an outdoor antenna.
Page 4
SAFETY INSTRUCTIONS voltage points or short out parts that could result in fire or electric shock. Never spill or spray any type of liquid on the product. 17. OUTDOOR ANTENNA GROUNDING If an outside antenna is connected to the prod- uct, be sure the antenna system is grounded so as to provide some protection against voltage surges and built-up static charges.
Page 5
PREPARATION FOR USE Power Sources This portable audio system is designed to operate on DC 12V (use 120V AC/DC 12V adaptor) AC Outlet AC Plug AC Operation Unwind the AC cord of the power adaptor and extend it to its full length. Insert the small end of the DC socket into the DC jack on the rear of the unit.
LOCATION OF CONTROLS MAIN UNIT (FRONT VIEW): IPOD BUTTON FUNCTION BUTTON MEM/CLK SET BUTTON PRESET EQ BUTTON POWER BUTTON IR SENSOR PLAY/PAUSE M+ BUTTON STOP/BAND BUTTON SKIP/TUNE UP BUTTON SKIP/TUNE DOWN BUTTON VOLUME UP BUTTON VOLUME DOWN BUTTON LCD DISPLAY...
Page 7
LOCATION OF CONTROLS MAIN UNIT (REAR VIEW): AUX2 IN RIGHT CHANNEL AUX2 IN LEFT CHANNEL AUX1 IN LEFT CHANNEL AUX1 IN RIGHT CHANNEL AUX OUT LEFT CHANNEL AUX OUT RIGHT CHANNEL AM ANTENNA JACK DC INPUT JACK IPOD VIDEO OUT DBBS SWITCH SPEAKER STAND RELEASE BUTTON (Press to release) AM ANTENNA...
LOCATION OF REMOTE CONTROLS REMOTE: S T AND FUNCTION BAND i P od MENU MEM/CLK SET MENU SELECT SHUFFLE MENU SLEEP MUTE ALBUM PLAYLIST V OL POWER BUTTON IPOD BUTTON STOP/BAND BUTTON MENU/MEMORY/CLOCK SET BUTTON SKIP BACKWARD BUTTON SHUFFLE BUTTON REPEAT/MEMORY DOWN BUTTON ALBUM UP BUTTON PLAYLIST UP BUTTON...
BATTERIES NOTE: The button cell battery contains mercury, don't put in the trash. Recycle or dispose as hazardous waste. NOTE: You may need to remove a protective covering from the remote's battery compartment before using the remote control. iPod Inserts Model iPod mini iPod (fourth generation)
Page 10
OPERATING INSTRUCTIONS Setting up your micro system Checking FM/AM Radio reception Your micro system has an external loop antenna for AM radio. To improve reception, you need to rotate your AM antenna. Unwind the external FM wire antenna and extend it to its full length to improve FM reception.
Page 11
OPERATING INSTRUCTIONS Using your radio Plug the AC Power cord into a power outlet and insert DC socket to DC jack of the unit. Press the POWER button on the main unit or remote control to turn the system "On". If necessary, press the FUNCTION button to select the Radio mode and the frequency will be shown in display.
Page 12
OPERATING INSTRUCTIONS Programming radio station presets: You can program as many as 10 FM and 10 AM radio station presets. To program a radio station: Press the FUNCTION Button one or more times until on the display Press the BAND Button to select AM or FM. Press and hold one of the SKIP/TUNE UP or DN Buttons to select a radio Press one of the SKIP/TUNE UP or DN Buttons to select the preset number Press the MEM/CLK Button to store the station with the preset number you...
Page 13
OPERATING INSTRUCTIONS To start Sleep function : Press the SLEEP button and "90" will appear and set the unit to turn off after 90 minutes. Each time you press the SLEEP button, the length of time decreases by 10 minutes. After five seconds, the Sleep function will activate and the SLEEP indicator will light solid.
Page 14
OPERATING INSTRUCTIONS Video Out You will need a television or other video device that has a composite video input. Securely dock the iPod. Connect the yellow RCA cable (Not Included) into the rear video out jack on the unit. Connect the other end of the yellow RCA cable to the video device. For Movie Output Press the IPOD Button on the unit.
TROUBLESHOOTING GUIDE PROBLEM No sound is heard. No sound is heard. iPod does not Using no or wrong iPod insert. dock properly iPod didn’t install properly . iPod does not iPod is not installed properly. respond to the unit iPod is locked up. iPod didn’...
