  • Page 1 OWNER’S MANUAL YZF-R6W 2C0-28199-21...
  • Page 3 Welcome to the Yamaha world of motorcycling! As the owner of the YZF-R6W, you are benefiting from Yamaha’s vast experience and newest technology regarding the de- sign and manufacture of high-quality products, which have earned Yamaha a reputation for dependability.
  • Page 4 This manual should be considered a permanent part of this motorcycle and should remain with it even if the motorcycle is subsequently sold. Yamaha continually seeks advancements in product design and quality. Therefore, while this manual contains the most current product information available at the time of printing, there may be minor discrepancies between your motorcycle and this manual.
  • Page 5 IMPORTANT MANUAL INFORMATION EAU10200 YZF-R6W OWNER’S MANUAL ©2006 by Yamaha Motor Co., Ltd. 1st edition, July 2006 All rights reserved. Any reprinting or unauthorized use without the written permission of Yamaha Motor Co., Ltd. is expressly prohibited. Printed in Japan.

  • Page 6: Table Of Contents

    TABLE OF CONTENTS SAFETY INFORMATION ....1-1 PRE-OPERATION CHECKS ..... 4-1 Adjusting the rear brake light Location of important labels ....1-5 Pre-operation check list ....4-2 switch ........6-22 Checking the front and rear brake DESCRIPTION ........2-1 OPERATION AND IMPORTANT pads .......... 6-22 Left view ..........2-1 RIDING POINTS.........
  • Page 7 TABLE OF CONTENTS Replacing the license plate light bulb ...........6-35 Auxiliary light bulb ......6-36 Supporting the motorcycle ....6-36 Front wheel ........6-37 Rear wheel ........6-39 Troubleshooting ......6-40 Troubleshooting charts ....6-41 MOTORCYCLE CARE AND STORAGE ..........7-1 Matte color caution ......7-1 Care ..........7-1 Storage ...........7-4 SPECIFICATIONS ......8-1 CONSUMER INFORMATION.....9-1...

  • Page 8: Safety Information

    SAFETY INFORMATION EAU10281 AND/OR WHEN MADE NECES- • Ride where other motorists can SARY BY MECHANICAL CONDI- see you. Avoid riding in another MOTORCYCLES SINGLE TIONS. motorist’s blind spot. TRACK VEHICLES. THEIR SAFE USE Many accidents involve inexperi- AND OPERATION ARE DEPENDENT Safe riding enced operators.
  • Page 9 Modifications made to this motorcycle other motorists can see you. the single most critical factor in the pre- not approved by Yamaha, or the re- The posture of the operator and vention or reduction of head injuries. moval of original equipment, may ren- passenger is important for proper Always wear an approved helmet.
  • Page 10 Maximum load: been specifically designed for use on create instability due to improper 193 kg (425 lb) this motorcycle. Since Yamaha cannot weight distribution or aerody- test all other accessories that may be namic changes. If accessories When loading within this weight limit,...
  • Page 11 SAFETY INFORMATION tor and may limit control ability, Always turn the engine off before or clothing, immediately wash the therefore, such accessories are leaving the motorcycle unattended affected area with soap and water not recommended. and remove the key from the main and change your clothes.

  • Page 12: Location Of Important Labels

    SAFETY INFORMATION EAU10381 Location of important labels Please read the following important labels carefully before operating this vehicle.
  • Page 13 SAFETY INFORMATION Before you operate this vehicle, read the owner’s manual. Prima di usare il veicolo, leggete il manuale di istruzioni. Lire le manuel du propriétaire avant d’utiliser ce véhicule. Lesen Sie die Bedienungsanleitung bevor Sie dieses Fahrzeug fahren. Antes de conducir este vehículo, lea el Manual del Propietario. 5PA-21568-00 Cold tire normal pressure should be set as follows.

  • Page 14: Description

    DESCRIPTION EAU10410 Left view 1. Fuse box 2 (page 6-32) 8. Shock absorber assembly rebound damping force adjusting screw (page 3-22) 2. Front fork spring preload adjusting bolt (page 3-20) 9. Shift pedal (page 3-15) 3. Front fork rebound damping force adjusting screw (page 3-20) 10.Engine oil drain bolt (page 6-11) 4.

  • Page 15: Right View

    DESCRIPTION EAU10420 Right view 1. Luggage strap holder (page 3-25) 9. Radiator cap (page 6-14) 2. Helmet holder (page 3-19) 10.Coolant reservoir (page 6-14) 3. Fuse box 1 (page 6-32) 11.Engine oil filler cap (page 6-11) 4. Main fuse (page 6-32) 12.Coolant drain bolt (page 6-15) 5.

  • Page 16: Controls And Instruments

    DESCRIPTION EAU10430 Controls and instruments 1. Clutch lever (page 3-14) 2. Left handlebar switches (page 3-13) 3. Main switch/steering lock (page 3-2) 4. Multi-function meter unit (page 3-7) 5. Right handlebar switches (page 3-13) 6. Brake lever (page 3-15) 7. Throttle grip (page 6-18)

  • Page 17: Instrument And Control Functions

    Do not expose any key to exces- a Yamaha dealer to have them re-reg- sively high temperatures. istered. Do not use the key with the red Do not place any key close to bow for driving.

  • Page 18: Main Switch/Steering Lock

    INSTRUMENT AND CONTROL FUNCTIONS EAU10471 EAU38530 To lock the steering Main switch/steering lock All electrical circuits are supplied with power; the meter lighting, taillight, li- cense plate light and auxiliary light come on, and the engine can be start- ed. The key cannot be removed. NOTE: The headlight comes on automatically when the engine is started and stays on...

  • Page 19: Indicator And Warning Lights

    INSTRUMENT AND CONTROL FUNCTIONS To unlock the steering EAU34341 EAU11003 (Parking) Indicator and warning lights The steering is locked, and the taillight, license plate light and auxiliary light are on. The hazard lights and turn signal lights can be turned on, but all other electrical systems are off.
  • Page 20 Yamaha dealer check the elec- Yamaha dealer check the electrical cir- riding on a slope or during sudden trical circuit.
  • Page 21 INSTRUMENT AND CONTROL FUNCTIONS ECA10020 CAUTION: Do not operate the engine if it is overheated.
  • Page 22 INSTRUMENT AND CONTROL FUNCTIONS Coolant Display Conditions What to do temperature Under 39 °C Message “Lo” is displayed. OK. Go ahead with riding. (Under 103 °F) 40–116 °C Temperature is displayed. OK. Go ahead with riding. (104–242 °F) Stop the vehicle and allow it to idle until 117–134 °C Temperature display flashes.

  • Page 23: Multi-Function Meter Unit

    When this occurs, EAU38620 have a Yamaha dealer check the self- Immobilizer system indicator light diagnosis system. (See page 3-7 for an The electrical circuit of the indicator...
  • Page 24 INSTRUMENT AND CONTROL FUNCTIONS a speedometer (which shows the Tachometer Clock mode riding speed) a tachometer (which shows engine speed) an odometer (which shows the to- tal distance traveled) two tripmeters (which show the distance traveled since they were last set to zero) a fuel reserve tripmeter (which shows the distance traveled since 1.
  • Page 25 INSTRUMENT AND CONTROL FUNCTIONS Odometer, tripmeter, and stopwatch between the various tripmeter, odome- 3. Push the “SELECT” button again modes ter, and stopwatch modes in the follow- to reset the stopwatch. ing order: F-TRIP → Stopwatch → TRIP A → Split-time measurement TRIP B →...
  • Page 26 INSTRUMENT AND CONTROL FUNCTIONS Coolant temperature display Air intake temperature display When the air intake temperature display is selected, “A” is displayed before the temperature. Self-diagnosis devices This model is equipped with a self-diag- nosis device for various electrical cir- cuits.
  • Page 27 Shift timing indicator light bright- codes, note the code number, and then 3. Shift timing indicator light ness: have a Yamaha dealer check the vehi- This mode cycles through five control This function allows you to adjust cle. functions, allowing you to make the fol-...
  • Page 28 INSTRUMENT AND CONTROL FUNCTIONS The indicator light will stay on can be set in increments of 500 r/min. NOTE: when activated. (This setting From 13000 r/min to 18000 r/min, the In this mode, the right display shows is selected when the indicator indicator light can be set in increments the current setting for each function light stays on.)

  • Page 29: Handlebar Switches

    INSTRUMENT AND CONTROL FUNCTIONS Be sure to set the deactivation EAU12347 Right Handlebar switches function to a higher engine speed than for the activation function, Left otherwise the shift timing indicator light will remain deactivated. 1. Push the “RESET” button to select the desired engine speed for deac- tivating the indicator light.

  • Page 30: Clutch Lever

    INSTRUMENT AND CONTROL FUNCTIONS position. To cancel the turn signal EAU12733 EAU12820 Hazard switch “ ” Clutch lever lights, push the switch in after it has re- With the key in the “ON” or “ ” posi- turned to the center position. tion, use this switch to turn on the haz- ard lights (simultaneous flashing of all EAU12500...

  • Page 31: Shift Pedal

    INSTRUMENT AND CONTROL FUNCTIONS EAU12870 EAU33850 it by aligning a groove on the adjusting Shift pedal Brake lever knob with the “ ” mark on the brake lever. 1. Shift pedal 1. Brake lever 2. “ ” mark The shift pedal is located on the left 3.

  • Page 32: Brake Pedal

    INSTRUMENT AND CONTROL FUNCTIONS EAU12941 EAU13070 Brake pedal Fuel tank cap NOTE: The fuel tank cap cannot be closed un- less the key is in the lock. In addition, the key cannot be removed if the cap is not properly closed and locked. EWA11090 WARNING Make sure that the fuel tank cap is...

  • Page 33: Fuel

    Avoid spilling fuel on the hot en- as well as to the exhaust system. gine. Your Yamaha engine has been de- signed to use premium unleaded gaso- line with a research octane number of 95 or higher. If knocking (or pinging) oc-...

  • Page 34: Catalytic Converter

    INSTRUMENT AND CONTROL FUNCTIONS EAU13441 EAU39030 Catalytic converter Seats This vehicle is equipped with catalytic converters in the exhaust system. Rider seat EWA10860 WARNING To remove the rider seat Pull back the rear of the rider seat as The exhaust system is hot after op- eration.

  • Page 35: Helmet Holding Cable

    INSTRUMENT AND CONTROL FUNCTIONS 2. While holding the key in that posi- EAU39072 3. Pass one of the other snap hooks Helmet holding cable tion, lift the front of the passenger of the cable through the helmet seat and pull it forward. strap buckle, and then clip the snap hook onto the cable holder as To install the passenger seat...

  • Page 36: Adjusting The Front Fork

    INSTRUMENT AND CONTROL FUNCTIONS EWA14330 EAU38941 load thereby soften Adjusting the front fork WARNING suspension, turn the adjusting bolt on This front fork is equipped with spring Never ride with a helmet attached to each fork leg in direction (b). preload adjusting bolts, rebound damp- a helmet holding cable, since the NOTE:...
  • Page 37 INSTRUMENT AND CONTROL FUNCTIONS Rebound damping force Compression damping force NOTE: The compression damping force set- ting is determined by measuring dis- tance A, shown in the illustration. The longer distance A is, the higher the compression damping force; the short- er distance A is, the lower the compres- sion damping force.

  • Page 38: Adjusting The Shock Absorber

    INSTRUMENT AND CONTROL FUNCTIONS To adjust the compression damping EAU38951 NOTE: Adjusting the shock absorber force (for slow compression damping) Although the total number of clicks of a assembly To increase the compression damping damping force adjusting mechanism This shock absorber assembly is force and thereby harden the compres- may not exactly match the above spec- equipped with a spring preload adjust-...
  • Page 39 INSTRUMENT AND CONTROL FUNCTIONS To increase the spring preload and Rebound damping force Compression damping force thereby harden the suspension, turn the adjusting ring in direction (a). To de- crease the spring preload and thereby soften the suspension, turn the adjust- ing ring in direction (b).
  • Page 40 To obtain a precise adjustment, in direction (a) formance. it would be advisable to check the num- Always have a Yamaha dealer ber of clicks of each damping force ad- service the shock absorber. Compression damping force (for slow...

  • Page 41: Luggage Strap Holders

    EAU41940 Luggage strap holders EXUP system passenger seat, unhook the straps This model is equipped with Yamaha’s from the hooks, and then install the EXUP (EXhaust Ultimate Power valve) seat with the straps hanging out from system. This system boosts engine under the passenger seat.

  • Page 42: Sidestand

    INSTRUMENT AND CONTROL FUNCTIONS EAU15301 below and have a Yamaha dealer re- EAU15311 Sidestand Ignition circuit cut-off system pair it if it does not function proper- The sidestand is located on the left side The ignition circuit cut-off system (com- of the frame.
  • Page 43 5. Push the start switch. Does the engine start? The neutral switch may be defective. The motorcycle should not be ridden until checked by a Yamaha dealer. With the engine still running: 6. Move the sidestand up. 7. Keep the clutch lever pulled.

  • Page 44: Pre-Operation Checks

    PRE-OPERATION CHECKS EAU15591 The condition of a vehicle is the owner’s responsibility. Vital components can start to deteriorate quickly and unexpectedly, even if the vehicle remains unused (for example, as a result of exposure to the elements). Any damage, fluid leakage or loss of tire air pressure could have serious consequences.

  • Page 45: Pre-Operation Check List

    • If necessary, add recommended coolant to specified level. 6-14 • Check cooling system for leakage. • Check operation. • If soft or spongy, have Yamaha dealer bleed hydraulic system. • Check brake pads for wear. Front brake • Replace if necessary.
  • Page 46 • Make sure that operation is smooth. • Check cable free play. Throttle grip 6-18, 6-26 • If necessary, have Yamaha dealer adjust cable free play and lubricate cable and grip housing. • Make sure that operation is smooth. Control cables 6-26 •...

  • Page 47: Operation And Important Riding Points

    3-26. should be on, otherwise have a short time. Always make sure Never ride with the sidestand Yamaha dealer check the electrical cir- that there is adequate ventila- down. cuit. tion. 1. Turn the key to “ON” and make 3.

  • Page 48: Shifting

    OPERATION AND IMPORTANT RIDING POINTS serve the battery. Do not crank the en- EAU16671 ECA10260 Shifting CAUTION: gine more than 10 seconds on any one attempt. Even with the transmission in the neutral position, do not ECA11130 coast for long periods of time CAUTION: with the engine off, and do not For maximum engine life, always...

  • Page 49: Tips For Reducing Fuel Consumption

    If any engine trouble should oc- result in engine overheating must be lights or at railroad crossings). cur during the engine break-in avoided. period, immediately have a Yamaha dealer check the vehi- EAU17091 cle. 0–1000 km (0–600 mi) Avoid prolonged operation above 8300 r/min.

  • Page 50: Parking

    OPERATION AND IMPORTANT RIDING POINTS EAU17212 Parking When parking, stop the engine, and then remove the key from the main switch. EWA10310 WARNING Since the engine and exhaust system can become very hot, park in a place where pedestri- ans or children are not likely to touch them.

  • Page 51: Owner's Tool Kit

    If you are not familiar with mainte- certain maintenance work correctly. nance work, have a Yamaha dealer do it for you. NOTE: If you do not have the tools or experi- ence required for a particular job, have a Yamaha dealer perform it for you.

  • Page 52: Periodic Maintenance And Lubrication Chart

    The annual checks must be performed every year, except if a kilometer-based maintenance is performed in- stead. From 50000 km, repeat the maintenance intervals starting from 10000 km. Items marked with an asterisk should be performed by a Yamaha dealer as they require special tools, data and technical skills. ODOMETER READING (× 1000 km)
  • Page 53 PERIODIC MAINTENANCE AND MINOR REPAIR ODOMETER READING (× 1000 km) ANNUAL ITEM CHECK OR MAINTENANCE JOB CHECK • Check tread depth and for damage. • Replace if necessary. √ √ √ √ √ 10 * Tires • Check air pressure. •...
  • Page 54 PERIODIC MAINTENANCE AND MINOR REPAIR ODOMETER READING (× 1000 km) ANNUAL ITEM CHECK OR MAINTENANCE JOB CHECK Engine oil filter car- √ √ √ • Replace. tridge √ √ √ √ √ • Check coolant level and vehicle for coolant leakage. 24 * Cooling system •...
  • Page 55 PERIODIC MAINTENANCE AND MINOR REPAIR Hydraulic brake service • Regularly check and, if necessary, correct the brake fluid level. • Every two years replace the internal components of the brake master cylinders and calipers, and change the brake fluid. • Replace the brake hoses every four years and if cracked or damaged.

  • Page 56: Removing And Installing Cowlings And Panels

    PERIODIC MAINTENANCE AND MINOR REPAIR EAU18712 EAU38970 Removing and installing cowl- Cowlings A and B ings and panels To remove one of the cowlings The cowlings and panels shown need Remove the bolts and the quick fasten- to be removed to perform some of the er, and then pull the cowling off as maintenance jobs described in this shown.
  • Page 57 PERIODIC MAINTENANCE AND MINOR REPAIR EAU38980 Cowlings C and D To remove one of the cowlings 1. Remove cowling A (if removing cowling C) or cowling B (if remov- ing cowling D). (See page 6-6.) 2. Disconnect the turn signal light lead coupler.
  • Page 58 PERIODIC MAINTENANCE AND MINOR REPAIR 2. Unfasten the wire harness by pressing on the tab to open the plastic fastener. 1. Cowling D 1. Quick fastener screw 2. Bolt 3. Turn signal light lead coupler To install the cowling 4. Quick fastener 1.
  • Page 59 PERIODIC MAINTENANCE AND MINOR REPAIR 1. Cowling E 1. Cowling E 1. Panel B 2. Bolt 2. Slot 2. Bolt 3. Quick fastener 3. Front cowling 4. Tab To install the panel To install the cowling Place the panel in the original position, 2.

  • Page 60: Checking The Spark Plugs

    Do not attempt to diagnose wipe off any grime from the spark plug such problems yourself. Instead, have threads. a Yamaha dealer check the vehicle. If a spark plug shows signs of electrode Tightening torque: Spark plug: erosion and excessive carbon or other 12.5 Nm (1.25 m·kgf, 9.0 ft·lbf)

  • Page 61: Engine Oil And Oil Filter Cartridge

    PERIODIC MAINTENANCE AND MINOR REPAIR EAU38992 4. Remove the engine oil dipstick and Engine oil and oil filter car- wipe it clean, insert it back into the tridge hole (without screwing it in), and The engine oil level should be checked then remove it again to check the before each ride.
  • Page 62 PERIODIC MAINTENANCE AND MINOR REPAIR NOTE: An oil filter wrench is available at a Yamaha dealer. 8. Apply a thin coat of engine oil to the O-ring of the new oil filter car- tridge. 1. Engine oil drain bolt 1. Bolt 2.
  • Page 63 PERIODIC MAINTENANCE AND MINOR REPAIR If the match marks are not aligned, Tightening torque: the shift arm will not move correctly Engine oil drain bolt: and you may not be able to shift up 43 Nm (4.3 m·kgf, 31 ft·lbf) or down the gears.

  • Page 64: Coolant

    B. (See page 6-6.) or remains on, immediately turn the varies with engine temperature. 4. Remove the reservoir cap, add engine off and have a Yamaha dealer coolant to the maximum level Make sure that the vehicle is posi- check the vehicle.
  • Page 65 PERIODIC MAINTENANCE AND MINOR REPAIR If water has been added to the 3. Place a container under the engine coolant, have a Yamaha dealer to collect the used coolant. check the antifreeze content of 4. Remove the radiator cap. the coolant as soon as possible,...
  • Page 66 PERIODIC MAINTENANCE AND MINOR REPAIR Tightening torque: Coolant drain bolt: 10 Nm (1.0 m·kgf, 7.2 ft·lbf) 13. Pour the recommended coolant into the reservoir to the maximum level mark, and then install the coolant reservoir cap. 14. Pour the recommended coolant into the radiator until it is full.

  • Page 67: Air Filter Element

    18. Install the cowlings. instead. Do not use hard water Have a Yamaha dealer replace the air or salt water since it is harmful filter element. to the engine. If water has been used instead...

  • Page 68: Checking The Throttle Cable Free Play

    Yamaha dealer at the intervals specified in the periodic Tire air pressure maintenance and lubrication chart. The tire air pressure should be checked and, if necessary, adjusted before each ride.
  • Page 69 LOAD YOUR VEHICLE. Make sure in it, or if the sidewall is cracked, con- Rear: that the total weight of the cargo, rid- tact a Yamaha dealer immediately and 250 kPa (36 psi) (2.50 kgf/cm²) er, passenger, and accessories have the tire replaced.
  • Page 70 This motorcycle is fitted with super- from country to country. Always comply Yamaha Motor Co., Ltd. high-speed tires. Note the following with the local regulations. Always make sure that the valve points in order to make the most ef- caps are securely installed to ficient use of these tires.

  • Page 71: Cast Wheels

    If any damage is 2. Loosen the locknut at the crank- found, have a Yamaha dealer re- case. place the wheel. Do not attempt 3. To increase the clutch lever free...

  • Page 72: Adjusting The Rear Brake Light Switch

    EAU22390 the point that a wear indicator almost Adjusting the rear brake light Checking the front and rear touches the brake disc, have a Yamaha switch brake pads dealer replace the brake pads as a set. The front and rear brake pads must be...

  • Page 73: Checking The Brake Fluid Level

    However, if the Use only the recommended quality brake fluid level goes down sud- 1. Minimum level mark brake fluid, otherwise the rubber denly, have a Yamaha dealer Rear brake seals may deteriorate, causing check the cause. leakage and poor braking perfor- mance.

  • Page 74: Changing The Brake Fluid

    EAU22730 EAU22760 Changing the brake fluid Drive chain slack Have a Yamaha dealer change the The drive chain slack should be brake fluid at the intervals specified in checked before each ride and adjusted the NOTE after the periodic mainte- if necessary.

  • Page 75: Cleaning And Lubricating The Drive Chain

    PERIODIC MAINTENANCE AND MINOR REPAIR ECA10570 EAU23022 Cleaning and lubricating the CAUTION: drive chain Improper drive chain slack will over- The drive chain must be cleaned and load the engine as well as other vital lubricated at the intervals specified in parts of the motorcycle and can lead the periodic maintenance and lubrica- to chain slippage or breakage.

  • Page 76: Checking And Lubricating The Cables

    If a cable is damaged maintenance chart. or does not move smoothly, have a Yamaha dealer check or replace it. Recommended lubricant: Engine oil EWA10720 WARNING...

  • Page 77: Checking And Lubricating The Brake And Shift Pedals

    PERIODIC MAINTENANCE AND MINOR REPAIR EAU23131 EAU23140 Recommended lubricant: Checking and lubricating the Checking and lubricating the Lithium-soap-based grease (all-pur- brake and shift pedals brake and clutch levers pose grease) Brake lever Clutch lever The operation of the brake and shift pedals should be checked before each The operation of the brake and clutch ride, and the pedal pivots should be lu-...

  • Page 78: Checking And Lubricating The Sidestand

    EWA10730 WARNING If the sidestand does not move up and down smoothly, have a Yamaha dealer check or repair it. Recommended lubricant: Lithium-soap-based grease (all-pur- pose grease) 6-28...

  • Page 79: Checking The Front Fork

    Securely support the vehicle so that fork does not operate smoothly, damage and excessive oil leakage. there is no danger of it falling over. have a Yamaha dealer check or re- pair it. To check the operation 2. Hold the lower ends of the front 1.

  • Page 80: Checking The Wheel Bearings

    Yamaha dealer check the wheel bearings. To charge the battery Have a Yamaha dealer charge the bat- tery as soon as possible if it seems to have discharged. Keep in mind that the battery tends to discharge more quickly if the vehicle is equipped with optional electrical accessories.
  • Page 81 4. After installation, make sure that sealed-type (MF) battery charg- tities of water or milk and im- the battery leads are properly con- have a Yamaha dealer mediately call a physician. nected to the battery terminals. charge your battery. • EYES: Flush with water for 15 minutes and seek prompt medical attention.

  • Page 82: Replacing The Fuses

    PERIODIC MAINTENANCE AND MINOR REPAIR EAU23703 Specified fuses: Replacing the fuses Main fuse: The main fuse and fuse box 1 are locat- 50.0 A ed under the rider seat. (See page Fuel injection system fuse: 3-18.) 15.0 A Electric throttle valve fuse: 7.5 A Backup fuse: 7.5 A...

  • Page 83: Replacing A Headlight Bulb

    PERIODIC MAINTENANCE AND MINOR REPAIR 4. If the fuse immediately blows EAU39010 3. Unhook the headlight bulb holder, Replacing a headlight bulb again, have a Yamaha dealer and then remove the defective This model is equipped with quartz bulb check the electrical system. bulb.

  • Page 84: Tail/Brake Light

    7. Have a Yamaha dealer adjust the If the tail/brake light does not come on, ency of the glass, the luminosity headlight beam if necessary.

  • Page 85: Replacing A Turn Signal Light Bulb

    PERIODIC MAINTENANCE AND MINOR REPAIR EAU24202 EAU24310 3. Remove the defective bulb by pull- Replacing a turn signal light Replacing the license plate ing it out. bulb light bulb 4. Insert a new bulb into the socket. 1. Remove the turn signal light lens 1.

  • Page 86: Auxiliary Light Bulb

    1. Auxiliary light bulb If the auxiliary light does not come on, To service the front wheel have a Yamaha dealer check the elec- 1. Stabilize the rear of the motorcycle trical circuit or replace the bulb. by using a motorcycle stand or, if...

  • Page 87: Front Wheel

    4. Remove the brake caliper on each To remove the front wheel side by removing the bolts. EWA10820 WARNING It is advisable to have a Yamaha dealer service the wheel. Securely support the motor- cycle so that there is no danger 1. Wheel axle of it falling over.
  • Page 88 PERIODIC MAINTENANCE AND MINOR REPAIR Tightening torque: NOTE: Wheel axle pinch bolt: Make sure that there is enough space 21 Nm (2.1 m·kgf, 15 ft·lbf) between the brake pads before install- ing the brake calipers onto the brake 12. While applying the front brake, discs.

  • Page 89: Rear Wheel

    WARNING the swingarm. 5. Turn the drive chain slack adjust- It is advisable to have a Yamaha ing bolts fully in direction (a) and dealer service the wheel. push the wheel forward. Securely support the motor- 6.

  • Page 90: Troubleshooting

    7. Tighten the locknuts to their speci- for checking these vital systems your- fied torque. self. However, should your motorcycle require any repair, take it to a Yamaha Tightening torque: dealer, whose skilled technicians have Locknut: the necessary tools, experience, and 16 Nm (1.6 m·kgf, 11 ft·lbf)

  • Page 91: Troubleshooting Charts

    Remove the spark plugs and check the electrodes. The engine does not start. Have a Yamaha dealer check the vehicle. Check the battery. 4. Battery The engine turns over The battery is good.
  • Page 92 Start the engine. If the engine overheats again, have a The coolant level Yamaha dealer check and repair the cooling system. is OK. NOTE: If coolant is not available, tap water can be temporarily used instead, provided that it is changed to the recommended coolant as soon as possible.

  • Page 93: Motorcycle Care And Storage

    Rust and corrosion can develop matte colored finished parts. Be Cleaning even if high-quality components are sure to consult a Yamaha dealer for ECA11140 advice on what products to use be- used. A rusty exhaust pipe may go un- CAUTION: fore cleaning the vehicle.
  • Page 94 MOTORCYCLE CARE AND STORAGE Do not use any harsh chemical den part of the windshield to NOTE: products on plastic parts or the make sure that it does not leave Salt sprayed on roads in the winter may muffler. Be sure to avoid using any marks.
  • Page 95 Note that the thermally induced discoloring of the portion of the ex- Make sure that there is no oil or Consult a Yamaha dealer for advice on haust pipe leading into the titanium what products to use. wax on the brakes or tires.

  • Page 96: Storage

    MOTORCYCLE CARE AND STORAGE EAU26180 3. Perform the following steps to pro- 4. Lubricate all control cables and the Storage tect the cylinders, piston rings, etc. pivoting points of all levers and from corrosion. pedals as well as of the side- Short-term a.

  • Page 97: Specifications

    SPECIFICATIONS Dimensions: Engine oil: Fuel: Overall length: Type: Recommended fuel: 2040 mm (80.3 in) SAE10W30, SAE10W40, SAE15W40, Premium unleaded gasoline only Overall width: SAE20W40 or SAE20W50 Fuel tank capacity: 700 mm (27.6 in) 17.5 L (4.62 US gal) (3.85 Imp.gal) Overall height: Fuel reserve amount: -20 -10...
  • Page 98 SPECIFICATIONS Gear ratio: Loading: Front brake: 1st: Maximum load: Type: 31/12 (2.583) 193 kg (425 lb) Dual disc brake 2nd: (Total weight of rider, passenger, cargo and Operation: 32/16 (2.000) accessories) Right hand operation 3rd: Tire air pressure (measured on cold Recommended fluid: 30/18 (1.667) DOT 4...
  • Page 99 SPECIFICATIONS Battery: Coolant temperature warning light: Model: Engine trouble warning light: YTZ10S Voltage, capacity: Immobilizer system indicator light: 12 V, 8.6 Ah Headlight: Shift timing indicator light: Bulb type: Halogen bulb Bulb voltage, wattage × quantity: Fuses: Main fuse: Headlight: 12 V, 55.0 W ×...

  • Page 100: Consumer Information

    Record the key identification number, vehicle identification number and mod- el label information in the spaces pro- vided below for assistance when ordering spare parts from a Yamaha dealer or for reference in case the vehi- cle is stolen. KEY IDENTIFICATION NUMBER: 1.

  • Page 101: For Solo Riding

    Be sure to have a a. The removal or rendering inopera- Yamaha dealer install or remove these tive by any person other than for covers, and make any changes in the purposes of maintenance, repair...
  • Page 102 INDEX Air filter element ........6-17 For solo riding......... 9-2 Neutral indicator light ......3-4 Auxiliary light bulb ......... 6-36 Front and rear brake pads, checking..6-22 Noise regulation (for Australia)....9-2 Front fork, adjusting......3-20 Front fork, checking ......6-29 Battery...........
  • Page 103 INDEX Throttle grip and cable, checking and lubricating ........... 6-26 Tires............6-18 Tool kit ............ 6-1 Troubleshooting........6-40 Troubleshooting charts ......6-41 Turn signal indicator lights ...... 3-3 Turn signal light bulb, replacing.... 6-35 Turn signal switch......... 3-13 Valve clearance ........6-18 Vehicle identification number....
  • Page 106 YAMAHA MOTOR CO., LTD. PRINTED ON RECYCLED PAPER PRINTED IN JAPAN 2006.07-0.4×1 CR...
