- Page 1 LED Television USER'S MANUAL LED televizor NÁVOD K OBSLUZE LED televízor NÁVOD NA OBSLUHU LED televízió HASZNÁLATI ÚTMUTATÓ Telewizor LED INSTRUKCJA OBSŁUGI SLE 2057M4...
-
Page 3: Table Of Contents
Contents Warnings…………………………………………………………….………..…..……..1 Assembling the stand…………………………………………..……………..…6 Main Unit Control…………………………….…………………..……..……………..8 Front Panel…..……………….…………………………………………….………..8 Side&Rear Panel..……………………….……………………………..…………...9 Getting Started…………………………...………………………..……..………..10 Using the remote control……………………………………………………..10 Installing Batteries in the Remote Control………………………………..…..1 0 Battery replacement……………………………..………........10 Connection and setup…………………...……………........1 1 Cable Installation…………................11 Remote Control…………………………..……………………………………..…12 Basic Operation…………………………………………………………....14 QUICK START GUIDE……………….………………………………………..14 Turning on and off the TV…................14 Programme Selection…………….…………………………………………..…15 Volume adjustment…………………………………………………………….. -
Page 4: Warnings
Warnings REGULATORY INFORMATION This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference with radio and television reception. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference with radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:... - Page 5 Warnings Mains Supply This television is designed to operate from a 100-240 Volts 50/60Hz AC mains supply. Other power sources may damage it. Check that the rating plate (on the back cover of the television) states 100-240V~ before you plug it in for the first time.
- Page 6 Warnings Avoid harsh conditions such as wet or damp places, high humidity, strong vibration, extremely high or low temperatures, strong sunlight and places that are very dusty. Never fit makeshift stands or legs to the television. Never push objects into holes and ventilation slots. To prevent electric shock do not remove any cover.
- Page 7 Warnings Battery handling and usage Only adults should handle batteries. Do not allow a child to use this remote control unless the battery cover is securely attached to the remote control. The battery type used in the remote control is 2 x 1.5V AAA size batteries (not included) which are accessible and can be replaced.
- Page 8 Warnings GENERAL SAFETY INSTRUCTIONS • Do not install the appliance near any heat source such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. • To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture.
-
Page 9: Assembling The Stand
Assembling the stand... - Page 10 Assembling the stand Wall Mounting the TV The TV can be mounted on a wall using a 75mm x 75mm VESA kit sold separately. Mount the TV according to the instructions supplied with the kit. Beware of electrical cables, gas and water pipes in the wall. In case of any doubt, please contact a qualified installer.
-
Page 11: Main Unit Control
Main Unit Control Front Panel 1. CH+/CH-: Change channel 2. VOL+/VOL-: Change the volume 3. MENU:Access the menu : Select the input source : Power button Infrared sensor 7. Power Indicator... -
Page 12: Side&Rear Panel
Main Unit Control Side&Rear Panel: PC/DVI AUDIO Earphones / headphones j ack SCART connector / PC ports DVI AUDI O COAXIAL jack Antenna input HDMI1/2/3 port port AV/COMPONENT AUDIO IN input COMPONENT(YPbPr) input COMMON INTERFACE slot... -
Page 13: Getting Started
Getting Started Using the remote control When using the remote control, aim it at the remote sensor on the television. If there is an object between the remote control and the remote sensor on the unit, the unit may no operate. Point the remote control at the REMOTE SENSOR located on the television. -
Page 14: Connection And Setup
Connection and setup Cable Installation Please read this section carefully before installation and use. 1. Take out the TV from the package and put it on a stable surface. Allow the TV set to reach the ambient room temperature before you connect it to the mains. NOTE: When you plug or unplug the TV, computer or other equipments, you must make sure that the AC power has been already shut down;... -
Page 15: Remote Control
Remote Control The buttons of the original remote control are follows: : Power, switch on or off TV set. INFO: Press to display the current programme information on the screen (in DTV mode), or press to display information on a picture you are viewing (in media mode). - Page 16 Remote Control 17. EPG: Electronic Programme Guide (in DTV mode). Press again to exit. : Return to last viewed programme. 19. COLOURED BUTTONS: Red/ green/ yellow/ blue buttons (See footnote). : Fast reverse (in media mode). : Fast forward (in media mode). : Previous (in media mode).
-
Page 17: Basic Operation
Basic Operation QUICK START GUIDE • Connection 1. Connect the TV set to the mains. 2. Connect the “aerial” or “cable TV” plug to the AERIAL INPUT (ANT) socket located on the back of the TV. • First Time Setup When the TV is initially powered on, a sequence of on-screen prompts will assist you in configuring the basic settings. -
Page 18: Programme Selection
Basic Operation Programme Selection • Using the CH+/CH- on the panel of TV or on the remote control. Press CH+ to go to the following channel. Press CH- to go to the preceding channel. • Using 0- 9 numeric buttons. You can select the channel number by pressing 0 to 9. -
Page 19: Menu Operation
Menu Operation Configuring the Picture Menu • Picture Mode You can select the type of picture which best corresponds to your viewing requirements. You can choose from Standard, Mild, Personal, and Dynamic. • Brightness You can adjust the brightness value of the picture. -
Page 20: Configuring The Sound Menu
Menu Operation Configuring the Sound Menu • Sound Mode You can select a sound mode to suit your personal preferences. You can choose from Standard, Music, Personal and Movie. • Treble You can adjust the treble effect by increasing or decreasing high-pitched sounds. -
Page 21: Configuring The Channel Menu
Menu Operation Configuring the Channel Menu • Tuner Type Before your TV can begin memorising the available channels, you must specify the type of signal Channel source that is connected to the TV Channel Tuner Type Antenna (antenna or cable). If the set signal Tuner Type Antenna Auto Scan... - Page 22 Menu Operation Symbol Rate: Press the ◄/► button to select Symbol Rate: Auto or enter digital numbers. Modulation: Press the ◄/► button to select Modulation: Auto, 16QAM, 32QAM, 64QAM, 128QAM, 256QAM. Start: Press the ENTER button to start the channel search. Strength: Display the quality of current TV signal.
-
Page 23: Configuring The Lock System Menu
Menu Operation Configuring the Lock System Menu • Enter Password Press ENTER to enter the Lock System menu and input a password. The default password is 0000. If you forgot your password, please call the service centre. Lock System Enter Password Note that the items described below are Enable only available if the password you input is... -
Page 24: Configuring The Setup Menu
Menu Operation - Default Source Set the default input source when turning on your TV. - Default Dtv Program Only available when the Default Source is set to DTV. - Default Atv Program Only available when the Default Source is set to ATV. - Backup to USB Backup data to USB. - Page 25 Menu Operation • Blue Screen Press the◄/►button to select blue screen On or Off. • Mode Setting Press ◄/► button to select Store mode or Home Mode. It is recommended to set the TV to Home Mode. • Time Settings Press the ▲/▼...
-
Page 26: Using Media Mode
Menu Operation NOTE: You should use a USB disk with at least 4GB capacity. If the recording on the inserted USB disk failed, please format the disk. Warning: do not disconnect the device while formatting is in progress. If you format the device, all files will be deleted. - Page 27 Menu Operation • Supported file formats Multimedia Decoder File Extension Notes Categories Video Decode Audio Decode MPEG-1 MPEG-2 MP MPEG-4 SP MPEG-4 ASP MPGE1/MPEG2/M MPEG-4 XVID *.avi PEG4: H.264(AVC) Up to 1080p @ 30F MP@Level 4 MPEG-1 Layer 2 H.264: Up to 1080p H.264(AVC) MPEG-1 Layer 3 @ 25F...
- Page 28 Menu Operation 72x72 < Baseline resolution < Baseline Mode 7680x4320 *.jpg Photo *.jpeg Progressive Mode Progressive Size <=1280x1024 Mode File Size <=10MB UTF-8 Text *.txt UNICODE File Size <=1MB ASCII Note: Max 500 files are supported in each folder. NOTE: Special algorithm documents may be not or not well supported with USB.
- Page 29 Menu Operation Music Press the ◄/► button to select Music in the main menu, then press ENTER button to enter. Press the ▲/▼ button to select disk you want to watch, then press ENTER button to enter. Press the ◄/► button to change page. Press the INDEX button to access the quick menu.
-
Page 30: Important Unique Buttons
Important Unique Buttons PROGRAM GUIDE (In DTV mode) Press the EPG button to enter PROGRAM GUIDE menu. Press ▲/▼ to highlight the programme you would like to record and press button to set the parameters for recording. You then have to select the frequency (Rec:Record) of the recording and check that the other settings (start time, end time and channel) correct. -
Page 31: Teletext
Teletext Using the teletext feature • Display teletext 1. Select a TV station with a teletext signal. 2. Press the button to enter teletext mode. 3. Press the button again to enter Mix mode. This function enables you to display the teletext page over the TV programme. -
Page 32: Troubleshooting Guide
Troubleshooting Guide Troubleshooting Before contacting the service technician, please check the following points. If a problem still persists, unplug the TV and call for assistance. Analogue TV Sound Symptoms Possible causes What to do Interference from cars, Turn off one piece of fluorescent lights, video equipment at a time to see Crackling noises or... - Page 33 Troubleshooting Guide Picture interference like Some other equipment is Put other equipment on wavy lines or patterns. using the same frequency. stand-by to see if the interference stops: change Sound interference may Poor quality cable in the the output frequency of the also be present.
- Page 34 Troubleshooting Guide Multiplex DVB-T (Digital Video Broadcasting - Terrestrial) is broadcast in groups of channels on one common frequency. This arrangement is known as a Multiplex. There are several multiplexes in the DVB-T system, each carrying a group of channels. If the signal level on a particular multiplex frequency is poor you may lose the whole group of channels on that multiplex.
- Page 35 Troubleshooting Guide Power Symptoms Possible causes What to do Check the power switches on the television and at the power outlet. Check power is present at the outlet. Mains supply missing. Television seems 'dead' - Main power switch is off. no lights come on and Blown fuse or circuit Check the fuse or circuit...
-
Page 36: Maintenance
Troubleshooting Guide Maintenance Early malfunctions can be prevented. Use your product with care and clean it regularly to help extending its lifetime. Be sure to turn the power off and unplug the power cord before you begin any cleaning. Cleaning the screen 1. -
Page 37: Product Fiche
Product fiche SPECIFICATIONS MODEL SLE 2057M4 Panel Panel Size 19.5” Brightness Contrast Ratio 3000:1 Max.Resolution 1366x768 I/O Connector CI Slot HDMI YPbPr VIDEO AUDIO IN VGA/PC AUDIO IN COAXIAL OUT EARPHONE ANTENNA IN SCART AC 100-240V~ Power Source 50/60Hz Max.30W, Power Consumption Standby<0.5W... - Page 38 Information sheet Importer: FAST ČR, a.s., Černokostelecká 1621, 251 01 Říčany Brand Sencor Model SLE 2057M4 Energy efficiency class Screen diagonal in centimetres / inches [cm/in] 49.5/19.5 Power consumption in turned on state Annual power consumption* [kWh] Power consumption in stand-by mode ≤0.5W...
