CADDX Ranger 8000 Installation Manual

Downloadable control communicator
Hide thumbs Also See for Ranger 8000:

Advertisement

Quick Links

RANGER 8000
DOWNLOADABLE CONTROL COMMUNICATOR
INSTALLATION MANUAL

TABLE OF CONTENTS

GENERAL DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
STANDARD AND OPTIONAL PARTS LIST . . . . . . . . . . . . . . . . . . . . . . . . . . 2
PARTS DIAGRAM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
TERMINAL DRAWING AND SPECIAL NOTES . . . . . . . . . . . . . . . . . . . . . . . . 4
TERMINAL & FUSE DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
HOW TO PROGRAM THE RANGER 8000 . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
KEYPAD PROGRAMMING EXAMPLES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
PROGRAMMING PHONE NUMBERS & FORMATS . . . . . . . . . . . . . . . . . . . 8-9
COMMUNICATOR FORMAT SELECTION GUIDE . . . . . . . . . . . . . . . . . . . . . 9
OPTIONAL PROGRAMMING INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . 10-22
AVAILABLE ZONE TYPES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
PROGRAMMING THE AUXILIARY OUTPUTS . . . . . . . . . . . . . . . . . . . . . . . 17
DOWNLOAD PROGRAMMING INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . 23
PROGRAMMING WORKSHEETS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24-26
LOCAL TELEPHONE COMPANY INTERFACE INFO . . . . . . . . . . . . . . . . . . 28
SPECIFICATIONS & WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
CADDX CONTROLS, INC.
GLADEWATER, TEXAS
800-727-2339

Advertisement

loading
Need help?

Need help?

Do you have a question about the Ranger 8000 and is the answer not in the manual?

Questions and answers

Related Manuals for CADDX Ranger 8000

Summary of Contents for CADDX Ranger 8000

  • Page 1: Table Of Contents

    TERMINAL & FUSE DESCRIPTION ....... 4 HOW TO PROGRAM THE RANGER 8000 ......6 KEYPAD PROGRAMMING EXAMPLES .

  • Page 2: General Description

    11 for a description of all zone types. Read the User’s Manual before you begin the installation for the best overall description of how the Ranger 8000 functions. After installation of the security system, complete the information on page 1 of the User’s Manual and explain the system operation to all security system users.

  • Page 3: Parts Diagram

    PARTS DIAGRAM...

  • Page 5: Terminal & Fuse Description

    TERMINAL DESCRIPTION TERMINAL DESCRIPTION Connect one side of zone 1 loop. The other side of loop to common terminal 2. Open or short causes alarm. Common (-) Terminal. Connect one side of zone 2 loop. The other side of loop to common terminal 2. Open or short causes alarm.

  • Page 6: How To Program The Ranger 8000

    When the system keypad is utilized for programming (as described by method 1 above), the Ranger 8000 will be in the "Program" mode, and the yellow LED's will display the data in location 000. The data is displayed using a Binary system. With this system the yellow zone 1 LED equals "1"...
  • Page 8 13 and program the data in location 052. If this location contains a "0", the built-in communicator will be disabled, and the Ranger 8000 will function as a local only control.
  • Page 9 LOCATION 074: PROGRAMMING COMMUNICATOR FORMAT FOR THE SECONDARY TELEPHONE NUMBER Location 074 contains the communicator format for the secondary phone number. Consult the instructions for your central station receiver to determine which format is compatible. To select Ademco/Silent Knight Fast, program a "2" in this location.
  • Page 10 LOCATIONS 000-003: PROGRAMMING THE MASTER ARM/DISARM CODE Locations 000-003 contain master arm/disarm code (user number 1). Location 000 contains the first digit of the code; location 003 contains the fourth digit of the code. THE CODE MUST CONTAIN FOUR (4) DIGITS. The master code can then be used in the run mode to enter arm/disarm codes 1-7.

  • Page 11: Available Zone Types

    LOCATION 088-089: PROGRAMMING FOR AUXILIARY 1, [1] & [3] DOUBLE KEYPRESS The Ranger 8000 has the ability to report an Auxiliary 1 code and activate the Priority siren each time the [1] and [3] keys are pressed simultaneously on the keypad. The desired reporting code is programmed in locations 088-089. If both locations are "0", the Auxiliary 1 double keypress is disabled.
  • Page 12 LOCATION 092-093: PROGRAMMING FOR KEYPAD PANIC, [ r r ] & [#] DOUBLE KEYPRESS The Ranger 8000 has the ability to report a Keypad panic code and activate the burglary siren each time the [ r ] and [#] keys are pressed simultaneously on the keypad. The desired Keypad panic code is programmed in locations 092-093.
  • Page 13 LOCATION 120-121: PROGRAMMING TO REPORT AC POWER LOSS The Ranger 8000 has the ability to report an AC power failure code when AC power is lost. This report can be immediate, or delayed depending on the information programmed in location 150 (AC Power Loss Delay). The desired AC failure mode should be programmed in locations 120-121.
  • Page 14 LOCATION 122-123: PROGRAMMING TO REPORT LOW BATTERY The Ranger 8000 has the ability to report a low battery code when AC power has been lost and the battery has discharged down to 10.3 volts. The desired low battery code is programmed in locations 122-123. If both locations are "0", low battery will not be reported.
  • Page 15 If a "2" is programmed in this location, it will power up armed. If this location contains a "0", the Ranger 8000 will power up in the condition it was in at power down. A watchdog circuit reset will cause the Ranger 8000 to reset to the selected condition.
  • Page 16 If a "1" is programmed in location 138, the Ranger 8000 will not arm with any zone bypassed. If programmed with a "0", up to 5 of the 6 burglary zones can be bypassed, and the Ranger 8000 can still be armed. If an A 8" is programmed, it will prevent beeping if A.C.

  • Page 17: Programming The Auxiliary Outputs

    ION 145-148: PROGRAMMING THE AUXILIARY OUTPUTS Four of the functions in the following table are available on the 4-pin connector on the PC board. These outputs are often used to switch small relays, LED's, trip long range radio, or to add a remote sensor. For example, to create an LED that lights for alarm memory, program a "7"...
  • Page 18 LOCATION 151: PROGRAMMING THE NUMBER OF RINGS TO ANSWER DOWNLOAD CALL Location 151 contains the number of rings the 8000 must detect before answering the telephone when initiating a download. If a number from "1" to "15" is programmed in this location, the control will answer after THIS number of rings has been detected.
  • Page 19 LOCATION 167: PROGRAMMING FOR ROTATING MAINTENANCE CODES The Ranger 8000 has the ability to automatically generate a different MAINTENANCE arm/disarm code daily. This code is produced using the current date programmed in locations 153-157, and the 4 digit complex or "seed code", programmed in locations 168-171.
  • Page 20 LOCATION 172: PROGRAMMING USER 7 OR MAINTENANCE CODE OPENING COMMUNICATOR CODE The Ranger 8000 has the ability to give an opening report each time user number 7 disarms the control. The desired opening code should be programmed in this location. This feature can be used in conjunction with the rotating maintenance code to give an opening report each time the maintenance code is used to disarm.
  • Page 21 LOCATION 175: PROGRAMMING ZONES 1, AND/OR 2 FOR NORMALLY CLOSED OPERATION ONLY Location 175 is used to program zones 1 and/or 2 for normally closed operation only, eliminating the need for the end of line resistors on these zones. When a zone is programmed for normally closed operation, a short on that zone will not change the loop condition, and an open on that zone will produce a faulted condition.
  • Page 22 LOCATION 177: SPLIT REPORTING - PROGRAMMING AC POWER FAIL, LOW BATTERY, OPEN/CLOSE, AND MAINTENANCE OPEN/CLOSE TO REPORT TO THE SECONDARY PHONE NUMBER The 8000 is capable sending certain reports to the secondary telephone number. This feature known as split reporting can be used to send alarm reports to one number, and supervisory reports to another number.
  • Page 23 Locations 186-193 contain the eight digit access code the 8000 must receive from the downloading software before the panel will permit downloading to occur. The factory default code is listed in the instructions provided with the CADDX download software package. LOCATIONS 194-209: CALL BACK TELEPHONE NUMBER The presence of a phone number in locations 194-209 will cause the control panel to dial back this number after a successful panel access code has been entered.
  • Page 24 ARM/DISARM CODES 1-7 LOCATION PAGE DESCRIPTION DATA 1 DATA 2 DATA 3 DATA 4 DEFAULT 000-003 USER #1 ARM / DISARM CODE "1-2-3-4" 004-007 USER #2 ARM / DISARM CODE "15" DISABLED 008-011 USER #3 ARM / DISARM CODE "15" DISABLED 012-015 USER #4 ARM / DISARM CODE "15"...
  • Page 25 LOCATION PAGE DESCRIPTION ZONE ID EVENT/EXT CODE DEFAULT OPENING COMMUNICATOR CODE MAN NUMBER "0" DISABLED 104-105 ZONE 1 COMMUNICATOR CODE "1 - 0" 106-107 ZONE 2 COMMUNICATOR CODE "2 - 0" 108-109 ZONE 3 COMMUNICATOR CODE "3 - 0" 110-111 ZONE 4 COMMUNICATOR CODE "4 - 0"...
  • Page 26 LOCATION PAGE DESCRIPTION DATA DEFAULT PROGRAM CLOCK, CURRENT DAY OF MONTH - TENS DIGIT UNDEFINED PROGRAM CLOCK, CURRENT DAY OF MONTH - ONES DIGIT UNDEFINED PROGRAM CLOCK, CURRENT HOUR - TENS DIGIT UNDEFINED PROGRAM CLOCK, CURRENT HOUR - ONES DIGIT UNDEFINED PROGRAM CLOCK, CURRENT MINUTE - TENS DIGIT UNDEFINED...

  • Page 27: Local Telephone Company Interface Info

    If the problem is with the device the customer shall discontinue use until it is repaired. EQUIPMENT INFORMATION MANUFACTURER OF CONNECTING EQUIPMENT: CADDX CONTROLS INC. FCC REGISTRATION NUMBER: GCQ4DC-17266-AL-E RINGER EQUIVALENCE: 0.2 B...
  • Page 28 RESPONSIBILITY FOR REPAIRING DAMAGE TO THE PRODUCT CAUSED BY MISUSE, CARELESS HANDLING, OR WHERE REPAIRS HAVE BEEN MADE BY OTHERS. NO OTHER GUARANTEE, WRITTEN OR VERBAL, IS AUTHORIZED BY OR ON BEHALF OF CADDX CONTROLS, INC., GLADEWATER, TEXAS. CADDX CONTROLS, INC.
