WARRANTY
Do not re t ur n t h is p ro d u ct to t h e store.
IF YOU NEED HELP OR PARTS, CALL THE COLEMAN® HOTLINE
HOURS: 10AM-7PM EST Mon-Fri, CLOSED Saturday and Sunday
M ISS IN G / DA M AG E D PARTS • ASSEM B LY • T R O U B L E SH O OT I N G
T IP: ASS EM B LE YO U R B A RB E CU E I M M ED I AT ELY. M I SSI N G O R DA M AGED PA RTS
BARBECUE SAFETY CHECK-LIST
For your family's safety, please check the following:
READ and UNDERSTAND the owner's manual and safety instructions.
DO NOT position or operate barbecue under overhang or unprotected construction, against
a wall, near aluminum siding, windows, or fencing.
CHECK that the regulator nipple is centered into the LP tank valve. Do NOT cross thread this
connection. Cross threading may result in a fire, or explosion at the tank connection.
PERFORM LEAK TEST on all connections as specified in this user manual. Leak Checks should
be performed on all new barbecue's even if assembled by an assembler or gas technician.
Leak checks should be performed frequently thereafter.
BEFORE OPENING THE GAS SUPPLY, ensure the lid is open, control knobs are in "OFF"
position, gas is turned off, and the regulator is attached to tank correctly. Then follow the
PROPER LIGHTING PROCEDURE as shown in the manual. If above steps are not followed, you
may experience low flames, or other performance issues.
Beware HOT SURFACES including lid, lid handle, side tables, and control panel.
protective gloves while barbecuing.
Remove and clean the grease channel, front grease cup, side grease cup, and the heat
distribution plates, to avoid grease fires and flare ups.
Remove and clean the burners to avoid flash fires caused by spider webs and blockages.
Ensure that the barbecue is level.
1 -8 0 0 -275 -4 617
GE T H E L P F O R:
• WA RR A N TY ASSI STAN C E • P R O D UC T I N FO R M AT I O N
M U ST B E CL A IME D W I T H I N 3 0 DAYS O F P UR C H ASE.
REVOLUTION
STO P
1
TM
Wear

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Revolution and is the answer not in the manual?

Questions and answers

Summary of Contents for Coleman Revolution

  • Page 1 STO P Do not re t ur n t h is p ro d u ct to t h e store. IF YOU NEED HELP OR PARTS, CALL THE COLEMAN® HOTLINE 1 -8 0 0 -275 -4 617 HOURS: 10AM-7PM EST Mon-Fri, CLOSED Saturday and Sunday GE T H E L P F O R: M ISS IN G / DA M AG E D PARTS •...
  • Page 2 SAFE U S E & CARE MAN UAL THIS MANUAL MUST REMAIN WITH THE PRODUCT AT ALL TIMES To ORDER non-warranty replacement parts or accessories, or to register your warranty, please visit us on the web at www.colemanbbqs.com CAUTION DANGER Read and follow all safety statements, 1.
  • Page 3: Table Of Contents

    CAUTION Some parts may contain sharp edges, especially as noted in the manual. Wear protective gloves during assembly and usage of this appliance. For residential use ONLY. Do not use for commercial cooking. WARNING Do not attempt to repair or alter the hose and regulator or valve assembly for any assumed defect or for any type of retro fit or conversion.
  • Page 4: Installation / Additional Warnings

    INSTALLATION Installation must conform with local codes or, in the absence of local codes, with either the National Fuel Gas Code, ANSI Z223.1/NFPA 54, Natural Gas and Propane Installation Code, CSA B149.1, or Propane Storage and Handling for Recreational Vehicles, ANSI A 119.2/NFPA 1192, and CSA Z240 RV Series, Recreational Vehicle Code, as applicable.
  • Page 5: Gas Hook-Ups And Warnings

    GAS HOOK-UP’S AND WARNINGS (LP) LIQUID PETROLEUM GAS • LP gas is nontoxic, odourless and colourless when produced. For Your Safety, LP gas has been given an odour (similar to rotten cabbage) so that it can be smelled. • LP gas is highly flammable and may ignite unexpectedly when mixed with air. LP cylinder requirements: •...
  • Page 6: Lp Cylinder Removal, Transport And Storage

    LP GAS WARNINGS: • Always turn cylinder valve off when the barbecue is not in use. • Always handle the tank valve with the utmost care. • Never connect an unregulated LP gas cylinder to the barbecue. • Always keep the cylinder, in use, securely fastened in an upright position. •...
  • Page 7: Safety Hose And Regulator

    SAFETY HOSE AND REGULATOR PROPANE MODELS: Regulator Your barbecue is designed to operate on LP gas at a pressure of Heat sensitive hand wheel 2.74Kpa (11” water column). A regulator preset to this pressure is supplied with your barbecue. QCC-1 QUICK CLOSING COUPLING Nipple has to be centered into the LP cylinder valve.
  • Page 8: Leak Testing

    Call for replacement parts. Order new parts by providing the serial number, model number, name and part number of items required (see parts list) to a Coleman® Customer Care Agent 1-800-275-4617. 6. Always close LP cylinder valve after performing leak test by turning hand wheel clockwise.
  • Page 9: Resetting Flow Limiting Device (Natural Gas)

    NATURAL GAS HOOK-UPS AND WARNINGS FOR NATURAL GAS MODELS ONLY All Coleman® Natural Gas Barbecues come equipped with a 10’ Natural Gas hose with a quick connect socket connection. This will allow you to attach your barbecue to your residential gas line.
  • Page 10: Operation - Lighting Instructions

    7. After the burner is lit you can turn on the other burner control knobs. If the Revolution™ burner fails to light properly within 3-5 seconds, turn the burner control knob “OFF”. Also turn off the LP cylinder valve. Wait five minutes before attempting to light the burner again. This will allow time for released gas to disperse.
  • Page 11: Operation - To Extinguish

    CAUTION Side burner flame may be difficult to see on a bright sunny day. CAUTION If side burner fails to light immediately, turn burner control knobs “OFF” and wait 5 minutes before re-lighting with a match. Match lighting the Side Stove / Sear Stove (if applicable) 1.
  • Page 12: Prevention

    PREVENTION ATTENTION Once lit, confirm that the burner is properly lit and that the flame pattern is as desired. If the flame pattern is other than normal, consult the troubleshooting guide for corrective action. Burner Flame Check Always do a visual check of all burners prior to lighting. Burners have been factory set for the correct air and gas mixture.
  • Page 13: Flash-Back Fires

    Flash-Back Fires Spiders and insects are attracted to the smell of gas, and often build nests inside your barbecue’s burners, causing the potential risk of a Flash-Back fire. Lighting your burners without first cleaning the venturi tubes, port holes, and interior of your burners, can lead to a serious Flash-Back fire resulting in property damage and/ or personal injury.
  • Page 14: Troubleshooting

    Press Ignition button and listen for rapid clicks. and index finger and push-in firmly, until you feel a ‘Click’. 4. Check that the main electrode and side burner electrode spark when the InstaStart™ Button is pressed. COLEMAN® REVOLUTION™ 3-BURNER / 4-BURNER InstaStart™ Side Stove /...
  • Page 15 PROBLEM IDENTIFYING THE CAUSE: Flame blows out on LOW PROPANE MODELS: • Flow limiting device in regulator has been activated either due to a leak or improper lighting. See page 4. • Low or out of propane. • High Wind condition – Adjust barbecue o shield from wind •...
  • Page 16: Care And Maintenace

    , prevent damage and deterioration due to moisture and humidity, and extend the life of your cooking grates. How to season your Coleman® Flare Free, Porcelain Cast Iron Top Grate: Wash cooking grates with soap and water. Do not submerge grates in water.
  • Page 17 Cleaning Flare-Free, Double-Stacked Cooking Grates During Preheat: Locate the grate cleaning tool that came with your barbecue. Use the tool to push debris to the back of the burner box (figure A-1). Use a barbecue brush to remove any remaining debris. Note: Using the cleaning tool to pull grease to the front of the cooking grates may clog the front grease channel and require more thorough cleaning of this Figure A-1...
  • Page 18: Regular Maintenance Regime

    CARE AND CLEANING ATTENTION: If you are experiencing any of the following performance or safety issues: 1) barbecue not reaching temperature potential, 2) yellow burner flames, 3) the smell gas, 4) popping noises, 5) delayed burner ignition, 6) uneven heat, 7) flash fires, or 8) grease fires, TURN “OFF” YOUR barbecue immediately and perform the following maintenance regime.
  • Page 19: Storing Your Barbecue

    Caring for your Barbecues EXTERIOR SURFACES ALL MATERIALS including stainless steel, porcelain, and painted steel parts can become stained, soiled and corroded by dirt, pollution, deposits from inappropriate cleaners and grease. Routine cleaning of exterior surfaces is necessary to remove contaminants and avoid permanent damage.
  • Page 20: Start Grilling

    • Always preheat the appliance on “MAX” ( ) to the desired temperature before adding food. Coleman® Revolution™ Barbecues have been designed to offer a range of temperatures and unlike most barbecues , can quickly reach searing temperatures: • To Preheat: depending on the foods you are preparing, always preheat your barbecue to the temperature required.
  • Page 21 BARBECUE COOKING METHODS Direct Cooking — This is the most popular cooking method and involves cooking food directly over the flame, such as searing a steak. Indirect Cooking — Food is placed on the cooking grates, offset from the heat source. With the barbecue lid closed reflected heat surrounds the food cooking it more evenly and gently.
  • Page 22: General Side Burner / Sear Stove Tips

    GENERAL SIDE STOVE TIPS (if applicable) Your side stove will boil, sauté, stir fry and warm with ease. • For best results preheat your side burner for 10-15 minutes on “MAX” ( • When boiling water or warming foods always ensure that you are using a covered pot or wok. •...
  • Page 23 WARNING: HOT SURFACES WARNING EXTERIOR SURFACES WILL BECOME VERY HOT. TO PREVENT BURNS, ALWAYS WEAR INSULATED PROTECTIVE BARBECUE MITTS WHEN WORKING AT THE BARBECUE. • KEEP AWAY FROM COMBUSTIBLE MATERIALS • KEEP CHILDREN AND PETS AWAY FROM THIS GAS FIRED APPLIANCE •...
  • Page 24: Warranty And Service

    1. Call the Coleman® Customer Care Hotline 1-800-275-4617. 2. Do not return to the store for replacement of damaged or defective parts. Coleman® Customer Care will ensure that all in-stock replacement parts arrive at your home within 3-10 business days.
  • Page 25 To ensure your satisfaction And for follow-up service, register your barbecue online at: www.colemanbbqs.com Join the conversation facebook.com/colemangrills twitter.com/colemangrills ©2021 The Coleman Company, Inc. Coleman®, , and are registered trademarks of The Coleman Company, Inc. used under license.
