N
L E I S U R E
CAUTION – ALL OUTER SURFACES WILL GET HOT WHEN IN USE
MODEL:
USER AND INSTALLATION INSTRUCTIONS
FOR USE IN: -
GB, IE, FR, NL, BE, LU, ES, IT, NO, DE, DK, SE
WARNING
Only use this appliance in a well-ventilated area.
•
Read the instructions before use.
•
This appliance must be installed in accordance with
•
the regulations in force.
SPINFLO LIMITED, 4-10 Welland Close, Parkwood Industrial Estate
Rutland Road, Sheffield S3 9QY, ENGLAND.
TEL: + 44 (0) 114 273 8157
BUILD IN APPLIANCES
FOR USE WITH NATURAL GAS
PRIMA 600NG OP96000NG
FAX: + 44 (0) 114 275 3094
GAS APPLIANCES
Advertisement
Related Manuals for spinflo Country Leisure PRIMA 600NG
Summary of Contents for spinflo Country Leisure PRIMA 600NG
- Page 1 This appliance must be installed in accordance with • the regulations in force. SPINFLO LIMITED, 4-10 Welland Close, Parkwood Industrial Estate Rutland Road, Sheffield S3 9QY, ENGLAND. TEL: + 44 (0) 114 273 8157 FAX: + 44 (0) 114 275 3094...
- Page 3 CONTENTS User’s Section Specification ………………………………………………… Introduction ………………………………………………… Using the Grill ………………………………………………… Using the Oven ………………………………………………… Installation and Servicing Installation Dimensions ………………………………………………… Specification ………………………………………………… Installation Instructions ………………………………………………… Maintenance & Servicing ………………………………………………… SPECIFICATION Model Mk3 PRIMA 600NG External Dimensions, mm 761 x 600 x 450mm (HxWxD) Oven Capacity, litres (HxWxD) 53 (308x475x358)
- Page 4 INTRODUCTION This appliance must be installed in accordance with the local, national and European regulations in force. Particular attention shall be given to the requirements regarding ventilation. Read the instructions before installing or using the appliance The appliance is designed for either high or low level installations. Failure to install the appliance correctly could invalidate any warranty or liability claims and lead to prosecution.
- Page 5 OPERATION Using the Grill WARNING Accessible parts may be hot when the grill is used, young children should be kept away. IMPORTANT • The pan supplied with the appliance is multi functional, for use in grill or oven. • The handle design allows removal or insertion whilst the pan is in use. •...
- Page 6 OPERATION Using the Oven WARNING When cooking always ensure young children are kept away. 1. Ensure gas cylinder/supply is connected and turned on. In the event of a gas smell turn off at gas cylinder/mains and contact supplier. 2. To light: Open door, push in the control knob and turn to gas mark 9. Hold a lighted match or taper to the burner and push the control knob in and hold.
- Page 7 OPERATION Cooking Guidelines Best results will be obtained by the shelf positions in this guide. It is not necessary to preheat the oven but advisable for a range of dishes. The oven is capable of full temperature in 15-20 minutes. Most cookery books give details of the shelf positions and gas mark settings for each recipe.
- Page 8 INSTALLATION Regulations and Standards In your own interest of safety, it is law that all gas appliances are installed and serviced by competent persons. CORGI (Confederation for the Registration of Gas Installers) registered installers undertake to work to safe and satisfactory standards. Failure to install the appliance correctly could invalidate any warranty or liability claims and lead to prosecution.
- Page 9 INSTALLATION Fixing There are 8 fixing screw positions, located as follows. (A) – 2 in each side trim of the Grill opening (B) – 2 in each side trim of the Oven opening Make sure the appliance is fully home in the cabinet/aperture. Open the Oven door and fix the screws in position.
- Page 10 MAINTENANCE & SERVICING 3. Control replacement Disconnect from gas supply (1). Remove appliance from housing (2). Grill controls – Remove the locknut from the front of the control panel. Disengage the control from the gas rail and remove. Oven thermostat - Open the oven door and unscrew the 2 screws holding the thermostat probe in position and push the probe back out through the hole in the rear of oven.
