Summary of Contents for Heartway Medical Products HP7K

  • Page 1 USERS MANUAL HP7K HP7KX HEARTWAY MEDICAL PRODUCTS CO., LTD. 70030165 Part no:...
  • Page 2 COMPONENTS Your power wheelchair is shipped partially dissembled to protect it during shipping. After unpacking, please check whether you have received the following main components as our standard specification (See Fig.1). 1. Main frame with motor 5.Armrest (left) 2. Captain Seat 6.Armrest (Right) 3.
  • Page 3: Safety Instruction

    1-1/2” height. Transfers, Reaching and Bending 10. Transferring on and off the HP7K requires a good sense of balance. To eliminate the possibility of injury, we recommends performing the following tasks before attempting a transfer: → Position chair so that the distance between your power chair and the object to which you are transferring is close enough for a safe transfer.
  • Page 4: Electromagnetic Interference (Emi) From Radio Wave Sources

    General 12. Always use a seat belt, and keep feet on the footplate at all the time. 13. For safety reasons, make sure that your weight does not exceed the recommended weight limit of the wheelchair. Consult your dealer for the specified weight limits for your particular model. 14.
  • Page 5 is. At this time, current technology is capable of providing at least 20 V/m of immunity level, which would provide useful protection against common sources of radiated EMI. Following the warnings listed below should reduce the chance of unintended brake release or powered wheelchair movement that could result in serious injury: 1.
  • Page 6: Environmental Conditions

    ENVIRONMENTAL CONDITIONS Environmental conditions may affect the safety and performance of your power wheelchair. Water and extreme temperatures are the main elements that can cause damage and affect performance. A) Rain, Sleet and Snow If exposed to water, your power wheelchair is susceptible to damage to electronic or mechanical components.
  • Page 7: Assembly Instruction

    ASSEMBLY INSTRUCTION 1.Installing the Front Light on the Seat Turn the seat (#2) over. Insert the Front left light w/bracket (#8) on the seat frame. (See Fig 2) Insert the bolts and washer with the nuts into the holes of the seat frame. , then use the wrench and Allen Key to tighten the light frame (See Fig 3).
  • Page 8 Connection point Front connection (Fig 6) (Fig 7) 3. Installing the footrest Put the footrest set (# connected tube (3 places) into the frame.(See Fig 8) (Fig 8) 4.Installing the Footrest Insert the footrest ( with left-#7 and Right-#6 each) into footrest frame with side direction (See Fig 9) then turn around 90 degree to correct direction (See Fig 9) Footrest angle adjustment tube...
  • Page 9 Insert the 4pcs M6 bolts (With 2 washers each) into the hole and tighten the bolts and nuts. (See Fig 10) Use the E-clip to fix the footrest angle adjustment tube.(See Fig 11) E Clip Bolt and Nut (Fig 10) (Fig 11) Footrest angle adjustment tube 6.Installing controller and connect cables Assemble the controller (#4) on right armrest (#6) bracket with 2 screws.(See Fig 12)
  • Page 10 Plug-In Anode by Anode (Fig 14)
  • Page 11: Armrest Width Adjustment

    ADJUSTMENTS FOR SEATING CONFORT To maximize seating comfort, your power wheelchair lets you adjust: →Armrest width →Footrest angle →Controller position →Backrest angle →Headrest height A. Armrest Width Adjustment → Loosen the tension knob → slide the armrest frame to your desired width →...
  • Page 12: Operation

    OPERATION The power wheelchair is simple to operate. However , we recommend that you read carefully the following instructions to become familiarized with your new vehicle. A Word of Caution: Before you turn the power on, always be aware of the environment that surrounds you to select your desired speed.
  • Page 13: Controller Display

    ally and automatically for your safety. 3.Joystick The joystick controls the direction and speed of your vehicle, pointing the joystick away from the neutral position,(center), will move the vehicle in the direction where the joystick is pointing. The farther away(forward/backward) the joystick is from the neutral position, the faster the vehicle will go.
  • Page 14: Thermal Protection

    Free-wheeling is accomplished by turning the free-wheeling levers to the free-wheeling position.(See Fig 17) (Fig 17) Warning ! →Never free-wheel your power wheelchair on a slope. →Never free-wheel the motors while operating your vehicle. →Always remember to engage the motors before turning the power back ON. D.
  • Page 15 Breaker (Fig 18) The main circuit breaker monitors the electric current drawn from the battery. It is a safety feature built in your power wheelchair for your extra safety. When the batteries and motors are heavily strained (e.g., from excessive loads),the main circuit breaker will trip to prevent damage to the motor and the electronics.
  • Page 16: Batteries And Charger

    BATTERIES & CHARGER BATTERY We recommend that you use deep-cycle batteries that are sealed and maintenance free for your power wheelchair. Both sealed lead-acid (SLA) and gel cell are deep-cycle batteries and are similar in performance. Deep-cycle batteries are specifically designed to provide power, drain down, and then accept a relatively quick recharge.
  • Page 17 →Disconnect the charger power cord from the wall outlet when the batteries are fully charged. (See Fig 19) Important! Do not use for voltage input except the specified. Make sure your present voltage input (110V or 220V) and adjust manually. (See Fig 20) plug-in controller plug-in wall outlet (Fig 20) (Fig 19)
  • Page 18: Maintenance And Repair

    MAINTENANCE & REPAIR Your power wheelchair is designed for minimal maintenance. However, like any motorized vehicle it requires routine maintenance. To keep your HP7C for years of trouble-free operation, we recommend you follow the following maintenance checks as scheduled. DAILY CHECKS 1.
  • Page 19 o inspect or replace the motor brushes: 1.Unscrew the motor brush caps. (See Fig 21) 2.Remove the brushes. 3.Inspect the brushes for wear. (See Fig 22) 4.Replace the brushes if necessary. Motor Brush caps New Motor Brush Worn Motor Brush (Fig 21) (Fig 22) 2.
  • Page 20 FLASHING LIGHTS DIAGNOSIS AND SOLUTION Note: The battery needs charging or there is a bad connection to the following battery. Check the connections to the battery. If the connect- symptoms ions are good, try charging the battery. could The left motor has a bad connection. Check the left motor indicate a connection.
