PD602 User Guide
Quick Reference
Radio Guide for
Left View
Push to Talk Button
Short Press
Long Press
Radio Operation
Charging the Radio
• Please ensure the radio is off when charging
• Charging while the radio is on shortens the lifespan of your battery
• Full charge may take up to 3 hours
• The radio should be placed in the charger with the speaker (front of
radio) facing the front of the charger.
Transmitting Voice Calls
• To initiate a transmission hold the Push to Talk (PTT) Button
• Once you press the PTT Button, the radio will emit a talk permit chirp
• This talk permit chirp signals that you can begin to speak
• When done speaking release the PTT Button
• For a set period of time the system resources are held to allow
immediate responses
• If there is no response within this period the system will be released
signaled by a call ended chirp
Quick Reference User Guide
LED Indicator
Microphone
Speaker
Turning the Radio On
•
•
•
Receiving Voice Calls
•
Channel Controls
•
•
•
•
Front View
Channel Knob
Rotate the on / off volume knob to power on & set the volume
If the radio is tuned to a non‐programmed channel it will emit a continuous
error tone
Please reference the zone / channel list to select the appropriate channel
Portables automatically receive transmissions on the Talkgroup
There are zones
Each zone has channels programmed
To switch zones
To switch channels Turn the Channel Knob
Power / Volume Knob
Accessory / Programming Port
