CONFIGURATION GUIDE
Rear View
A
J
Legend
A.
USB Connectors
B.
Management LAN Connector
C.
Module ID LED
D.
Data LAN Connectors (10GBase-T)
E.
Data LAN Connectors (1000Base-T)
1
For service personnel only.
NEC Corporation
–
NEC EXPRESS5800/R320c-M4 for Linux
B
I
Revision 3.1, April 2016
C
D
D
H
F.
AC Inlet
G.
PCI Slots (Low-Profile)
H.
PCI Slots (Full-Height)
I.
Serial Port Connector
J.
VGA Connector
E
E
G
1
F
6
