Summary of Contents for Crown CMA-1
- Page 1 CMA-1 Installation Instructions...
- Page 2 PLEASE NOTE: Read the enclosed warranty statement before installation. Installation of the CMA-l is complex and should not be attempted by anyone without the proper tools or knowledge. This amplifier is intended for state-of-the-art mobile fidelity and requires state- of-the-art installation methods for full benefits. **CAUTION** Because this amplifier can draw extremely large current from the battery, the standard automobile charging system may not be...
- Page 3 Fig. 1 Fuse-Size Nomograph 14 1/2" 13 5/8" .275 DIA. TYP. 1/2" 8" 15 1/2" 16" Fig 2 CMA-1 Mounting-Hole Locations...
-
Page 4: Accessories Supplied
(at least 1”) and sufficient airflow around the heat fins for cooling. The CMA-1 may be mounted horizontally or vertically in the trunk or behind rear car seats. DO NOT place the CMA-1 in the engine compartment or in an area exposed to a harsh environment. Do not mount near the vehicle heater. - Page 5 CAUTION: THE USE OF WIRE SMALLER THAN #8 GUAGE COULD DEGRADE AMPLIFIER PERFORMANCE AND CREATE A FIRE HAZARD Fig. 3 Power-Wiring Connections CMA-1 CONNECT GREEN REMOTE WIRE TO: Ignition Fuse Box Terminal Controlled By Key Fig. 4 Remote On/Off Wire Connection...
- Page 6 1. Turn down your sound system volume to minimum. 2. The green “remote” wire on the CMA-1 is, in effect, the on/off switch of the amplifier. Connect the green remote wire to the switched +12 VDC supply, either through the ignition key, the tape deck/tuner, or a switched terminal at the fuse box.
- Page 7 This unusual flexibility allows for 2-channel plus sub woofer, as well as other variations for custom installations. NOTE: The CMA-1 inputs are high-impedance line-level inputs. Speaker outputs from the car radio should NOT be wired into this amplifier. When connecting tuner/tape deck outputs to the CMA-1 inputs, use an appropriate connector, or solder the connections and insulate them with electrical tape.
- Page 8 (Right Rear) To CH3 Source (Left Rear) CAUTION: Read instruction manual before operating this switch. Improper installation Fig. 6 Switch Position for 5 CH Operation SPEAKER REMOTE OUTPUTS CMA-1 BLK/WHT CH1+ CH1- WHT/RED CH2+ CH2- RED/WHT CH3+ Fig. 5 5-Channel Connections CMA-1 could damage vehicle and amplifier.
- Page 9 CH5: 100 W at 8 ohms (These are minimum recommend loads.) 3. Refer to Figure 5 . Connect the speakers as follows. Route the CMA-1 colored output cables separate from its white input cables to prevent oscillations. Using crimp terminals, connect the...
- Page 10 To CH3 Source (Left Rear) CAUTION: Read instruction manual before operating this switch. Improper installation Fig. 8 Switch Position for 4 CH Operation SPEAKER REMOTE OUTPUTS CMA-1 BLK/WHT CH1+ CH1- WHT/RED CH2+ CH2- RED/WHT CH3+ Fig. 7 4-Channel Connections CMA-1 could damage vehicle and amplifier.
- Page 11 CH4: 100 W at 8 ohms (These are minimum recommend loads.) 3. Refer to Figure 7 . Connect the speakers as follows. Route the CMA-1 colored output cables separate from its white input cables to prevent oscillations. Using crimp terminals, connect the...
- Page 12 (Left ) Connected use wire Connected use wire To CH2 Source (Right) Fig. 10 Switch Position for 3 CH Operation SPEAKER REMOTE OUTPUTS CMA-1 BLK/WHT CH1+ Cut and Tape WHT/RED CH1-+ Cut and RED/WHT Tape Fig. 9 3-Channel Connections CMA-1 CAUTION: Read instruction manual before operating this switch.
- Page 13 CH3: 100 W at 8 ohms (These are minimum recommend loads.) 3. Refer to Figure 9 . Connect the speakers as follows. Route the CMA-1 colored output cables separate from its white input cables to prevent oscillations. Using crimp terminals, connect the...
-
Page 14: Operation
5. The CMA-2 has no level controls to preset. All level adjustment is done at the front end of the sound system. 6. With your sound system volume turned all the way DOWN, apply power to the CMA-1 by turning on your ignition key or tape deck/tuner. - Page 15 10. Make sure all power-cable connections are tight and secure. 11. Re-route the power cables. Service Policies: Due to the sophisticated circuitry of the CMA-1, only qualified, fully trained technicians should be allowed to service it. Specifications: Output Power: (20Hz-20kHz):...
