- Page 1 Crestron TPS-VIDL-1/TPS-VIDL-2 Video Card for TPS/Lectern Panel Operations & Installation Guide...
- Page 2 This document was prepared and written by the Technical Documentation department at: Crestron Electronics, Inc. 15 Volvo Drive Rockleigh, NJ 07647 1-888-CRESTRON All brand names, product names and trademarks are the property of their respective owners. ©2002 Crestron Electronics, Inc.
-
Page 3: Table Of Contents
Crestron TPS-VIDL-1/TPS-VIDL-2 Contents Video Card for TPS/Lectern Panel: TPS-VIDL-1/TPS-VIDL-2 Introduction...1 Features and Functions ...1 Specifications...2 Physical Description ...4 Industry Compliance...5 Installation and Hookup...6 Setup...12 Configuring the Touchpanel...12 VT Pro-e Setup ...14 SIMPL Windows Setup ...15 Problem Solving...16 Troubleshooting...16 Further Inquiries ...17 Future Updates...17... -
Page 5: Video Card For Tps/Lectern Panel: Tps-Vidl-1/Tps-Vidl-2
TPS-TPI Touchpanel Interface. Each card contains a video digitizer that allows video signals to be displayed on a touchpanel. The TPS-VIDL-1 can display one S-video or composite video source while the TPS-VIDL-2 can display one S-Video source or two composite video sources. -
Page 6: Specifications
Video Card for TPS/Lectern Panel The TPS-VIDL-1 can automatically detect composite or S-video. The TPS-VIDL-2 adds input for a second composite video source (on the TPS-VIDL-2, Composite/S-Video can be auto-detected only when input signal 2 is not used). When using the TPS-VIDL-2 for receiving two video sources, the “Comp/Y”... - Page 7 1. The latest versions can be obtained from the Downloads | Software Updates section of the Crestron website (www.crestron.com). Refer to NOTE after last footnote. 2. Crestron 2-Series control systems include the AV2, CP2, CP2E, MP2, MP2E, PAC2, PRO2, and RACK2.
-
Page 8: Physical Description
PORT COMP / Y Physical Description The TPS-VIDL-1 and TPS-VIDL-2 card, shown in the following diagrams, is a printed circuit board (PCB) that is designed for installation into a dedicated expansion slot on the touchpanel motherboard. The card contains a 60-pin connector that attaches directly to the motherboard and is secured with four mounting screws (supplied with each model of the video card). -
Page 9: Industry Compliance
(2.95 cm) TPS-VIDL-1/VIDL-2 Top View 2.63 in (6.67 cm) NOTE: The TPS-VIDL-1 circuit board is slightly less populated than the TPS-VIDL-2. Industry Compliance As of the date of manufacture, the card has been tested and found to comply with specifications for CE marking and standards per EMC and Radiocommunications Compliance Labelling (N11785). -
Page 10: Installation And Hookup
Video Card for TPS/Lectern Panel Installation and Hookup The TPS-VIDL-1 and TPS-VIDL-2 video cards are designed for installation into a dedicated expansion slot on the TPS touchpanel. The only tools required for installation are a #1 Phillips screwdriver and a grounding strap (or grounded workstation). - Page 11 4. Remove the touchpanel rear cover by sliding it towards the bottom of the touchpanel as shown in the following diagram. Operations & Installation Guide - DOC. 6070 Video Card for TPS/Lectern Panel Video Card for TPS/Lectern Panel: TPS-VIDL-1/TPS-VIDL-2 • 7...
- Page 12 6. As shown in the diagram after this step, align the pins on the touchpanel interface connector of the TPS-VIDL-1/VIDL-2 with the touchpanel motherboard connector. 8 • Video Card for TPS/Lectern Panel: TPS-VIDL-1/TPS-VIDL-2 Crestron TPS-VIDL-1/TPS-VIDL-2 Operations & Installation Guide - DOC. 6070...
- Page 13 Crestron TPS-VIDL-1/TPS-VIDL-2 Install TPS-VIDL-1/VIDL-2 7. Press the TPS-VIDL-1/VIDL-2 until the connector pins are fully seated. DO NOT force pins into connector. Make sure that the mounted screws align with the mounting posts of the motherboard. 8. Tighten the card mounting screws to finger-tight.
- Page 14 (0.45 Newton-meters) to secure the cover. Install Touchpanel Rear Cover Screws 11. Refer to the following diagram and make the appropriate S-video or composite video connection(s) as shown. 10 • Video Card for TPS/Lectern Panel: TPS-VIDL-1/TPS-VIDL-2 Crestron TPS-VIDL-1/TPS-VIDL-2 Operations & Installation Guide - DOC. 6070...
- Page 15 Refer to “Configuring the Touchpanel” on page 12 for more information. NOTE: For additional information on video connections over CAT5, refer to the latest version of the Crestron CAT5 Wiring Reference Guide (Doc. 6137) which is available from the Downloads | Product Manuals section of the Crestron website (www.crestron.com).
-
Page 16: Setup
SETUP MENU. SETUP MENU (TPS-VIDL-1 shown) NOTE: If the TPS-VIDL-1 is installed, a single “Video” button will be displayed. If the TPS-VIDL-2 is installed, buttons labeled “Video 1” and “Video 2” will be displayed instead of the single “Video” button. - Page 17 If the source is properly connected and functioning, a distribution amplifier may need to be used. Operations & Installation Guide - DOC. 6070 Video Card for TPS/Lectern Panel Video Card for TPS/Lectern Panel: TPS-VIDL-1/TPS-VIDL-2 • 13...
-
Page 18: Vt Pro-E Setup
SETUP MENU. VT Pro-e Setup A video window object must reside on a page within the uploaded VT Pro-e touchpanel project and the TPS-VIDL-1 or TPS-VIDL-2 must be properly installed into the touchpanel in order for video signals to be displayed. -
Page 19: Simpl Windows Setup
Selecting the Video Source NOTE: If the card is not present, the Crestron Viewport displays a warning message during the upload and the video window remains blank. For further information regarding video window objects, refer to the VT Pro-e help file. -
Page 20: Problem Solving
Video Card for TPS/Lectern Panel Problem Solving Troubleshooting The table below provides corrective action for possible trouble situations. If further assistance is required, please contact a Crestron customer service representative. TPS-VIDL-1/VIDL-2 Troubleshooting TROUBLE Video window touchpanel has no display. Video colors... -
Page 21: Further Inquiries
If after reviewing this Operations & Installations Guide, you cannot locate specific information or have questions, please take advantage of Crestron's award winning customer service team by calling: • In the US and Canada, call Crestron’s corporate headquarters at 1-888-CRESTRON [1-888-273-7876]. • In Europe, call Crestron International at +32-15-50-99-50. -
Page 22: Operations & Installation Guide - Doc
CRESTRON shall not be liable to honor the terms of this warranty if the product has been used in any application other than that for which it was intended, or if it has been subjected to misuse, accidental damage, modification, or improper installation procedures. - Page 23 Crestron TPS-VIDL-1/TPS-VIDL-2 Video Card for TPS/Lectern Panel This page intentionally left blank Video Card for TPS/Lectern Panel: TPS-VIDL-1/TPS-VIDL-2 • 19 Operations & Installation Guide - DOC. 6070...
- Page 24 Crestron Electronics, Inc. Operations & Installation Guide - DOC. 6070 15 Volvo Drive Rockleigh, NJ 07647 12.02 Tel: 888.CRESTRON Fax: 201.767.7576 Specifications subject to www.crestron.com change without notice.
