Summary of Contents for Crestron TPS-VIDL
-
Page 3: Table Of Contents
Crestron TPS-VIDL Contents Video Card for TPS/Lectern Panel: TPS-VIDL Description Functional Description Physical Description Leading Specifications Connector Specifications Installation and Hookup Problem Solving Troubleshooting Further Inquiries Return and Warranty Policies Merchandise Returns / Repair Service CRESTRON Limited Warranty Operations & Installation Guide - DOC. 5830 Video Card for TPS/Lectern Panel Contents •... -
Page 5: Video Card For Tps/Lectern Panel: Tps-Vidl
VT Pro-e help file. Physical Description The TPS-VIDL card, shown below and on the next page, is a printed circuit board (PCB) designed to be installed into a specific expansion slot in the touchpanel (or interface). The card contains a 60-pin connector that attaches directly to the motherboard. -
Page 6: Leading Specifications
Video Card for TPS/Lectern Panel TPS-VIDL Top View 2.63 in (6.67 cm) Leading Specifications The table below provides a summary of leading specifications for the TPS-VIDL. Dimensions and weight are rounded to the nearest hundredth unit. Leading Specifications of the TPS-VIDL SPECIFICATION Power Requirements... -
Page 7: Connector Specifications
COMP / Y Installation and Hookup The TPS-VIDL is designed to be installed into a specific expansion slot in the TPS-5000L and TPS-6000L touchpanel and the TPS-TPI touchpanel interface. The tools required for installation are a grounding strap (or grounded workstation), #1 Phillips screwdriver, #1 Phillips 1/4-inch hex bit and an inch-pound torque driver. - Page 8 3. Remove the touchpanel rear cover by sliding it towards the bottom of the touchpanel as shown below. Remove Touchpanel Rear Cover 4 • Video Card for TPS/Lectern Panel: TPS-VIDL Crestron TPS-VIDL Operations & Installation Guide - DOC. 5830...
- Page 9 5. As shown below, align the pins on the touchpanel interface connector of the TPS-VIDL with the touchpanel motherboard connector. Install TPS-VIDL 6. DO NOT force pins into connector. Press TPS-VIDL until pins are fully seated. Make sure that the mounted screws align with mounting posts of the motherboard.
- Page 10 Video Card for TPS/Lectern Panel CAUTION: The TPS-VIDL connectors may have to be aligned slightly to fit through the openings in the rear cover. Align the connectors of this card (or any other optional card that is installed) carefully to prevent damage to the card, cover, or touchpanel.
- Page 11 BB-6000 Installation Guide (Doc. 5826 or 5827, respectively) for the proper installation procedure of the touchpanel. The latest software version of the Operations & Installation Guides can be obtained from the Downloads page (MANUAL Library) of Crestron’s website (www.crestron.com). NOTE: Refer to the latest revision of the TPS-5000L, TPS-6000L, or TPS-TPI Operations &...
-
Page 12: Problem Solving
Video window of touchpanel has no display. Further Inquiries If after reviewing this Operations & Installations Guide, you cannot locate specific information or have questions, please take advantage of Crestron's award winning technical support team by calling: • • •... -
Page 13: Return And Warranty Policies
CRESTRON shall not be liable to honor the terms of this warranty if the product has been used in any application other than that for which it was intended, or if it has been subjected to misuse, accidental damage, modification, or improper installation procedures. - Page 14 Video Card for TPS/Lectern Panel Crestron TPS-VIDL This page intentionally left blank. 10 • Video Card for TPS/Lectern Panel: TPS-VIDL Operations & Installation Guide - DOC. 5830...
- Page 15 Crestron TPS-VIDL Video Card for TPS/Lectern Panel This page intentionally left blank. Video Card for TPS/Lectern Panel: TPS-VIDL • 11 Operations & Installation Guide - DOC. 5830...
