Summary of Contents for Crestron TPS-VID
- Page 2 This document was prepared and written by the Technical Documentation department at: Crestron Electronics, Inc. 15 Volvo Drive Rockleigh, NJ 07647 1-888-CRESTRON...
-
Page 3: Table Of Contents
Crestron TPS-VID Contents Video Card for TPS/Tilt Panel: TPS-VID Description Functional Description Physical Description Leading Specifications Installation and Hookup Setup VT Pro-e Setup Programming and Configuration of Touchpanel Problem Solving Troubleshooting Further Inquiries Return and Warranty Policies Merchandise Returns / Repair Service CRESTRON Limited Warranty Operations &... -
Page 5: Video Card For Tps/Tilt Panel: Tps-Vid
TPS-VID Description Functional Description The TPS-VID video card is an optional feature designed for Crestron’s Isys™ tilt touchpanels. The card is a video digitizer that allows television (TV) National Television System Committee (NTSC) or Phase Alternating Line (PAL) video to be displayed on the touchpanel. The TV video is displayed through a video window on a page within the uploaded ™... -
Page 6: Physical Description
FTP site. Physical Description The TPS-VID card, shown in the two diagrams below, is a printed circuit board (PCB) designed to be installed into a specific expansion slot on the touchpanel motherboard. The card contains a 60-pin connector that attaches directly to the motherboard and the card is secured with four mounting screws (supplied with TPS-VID). -
Page 7: Leading Specifications
New page (Touchpanels section) or Downloads page (TOUCHPNL Library) of Crestron’s website. Crestron 2-Series control systems consist of the AV2, AV2 with Card Cage, CP2, CP2E, PAC2, PAC2M, PRO2, and RACK2. Filenames for 2-Series control system update files have a CUZ extension and can be obtained from the What’s New page (Control Systems Update Files section) or Downloads page... -
Page 8: Installation And Hookup
Crestron. Update files with an “S” designator are for the ST-CP, “V” designator for CEN/CN-TVAV, “W” for CNRACKX/-DP, and “X” for CNMSX-AV/Pro control systems. - Page 9 TPS-VID Installation (1 of 6) - Remove Touchpanel Base Cover Screws 6. Place the touchpanel upright on the work surface. 7. As shown on the next page, remove the touchpanel base cover by raising it upwards and rearward.
- Page 10 Video Card for TPS/Tilt Panel TPS-VID Installation (2 of 6) - Remove Touchpanel Base Cover 8. As shown below, align the pins on the touchpanel interface connector of the TPS-VID with the touchpanel motherboard connector. DO NOT force pins into connector. Press TPS-VID until pins are fully seated.
- Page 11 (supplied), tighten to finger-tight then, using a Philips screwdriver, tighten an additional 1/8-turn. TPS-VID Installation (4 of 6) - Install TPS-VID Mounting Screws 10. Position the touchpanel base cover onto the base by tilting the front of the cover downward under the touchpanel pivot and lowering.
-
Page 12: Pin Designation
Video Card for TPS/Tilt Panel TPS-VID Installation (5 of 6) - Re-install Touchpanel Base Cover Screws NOTE: The table below is provided as reference information about the pinouts of the NET/VIDEO connector. TYPE 10-position RJ45 While facing the NET/VIDEO port of the touchpanel, pin 1 is located at the upper- left of the port. -
Page 13: Setup
Pro-e touchpanel project and the TPS-VID must be installed into the proper expansion slot of the Isys™ tilt touchpanel in order for the TV video to be displayed. If the card is not present, the Crestron Viewport displays a warning message during the upload and the video window remains blank. -
Page 14: Programming And Configuration Of Touchpanel
FTP site. Problem Solving Troubleshooting The table below provides corrective action for possible trouble situations. If further assistance is required, please contact a Crestron customer service representative. TPS-VID Troubleshooting TROUBLE... -
Page 15: Further Inquiries
If after reviewing this Operations & Installations Guide, you cannot locate specific information or have questions, please take advantage of Crestron's award winning customer service team by calling: In the US and Canada, call Crestron’s corporate headquarters at 1-888-CRESTRON [1-888-273-7876] or 1-201-767-3400. In Europe, call Crestron International at +32-15-50-99-50. -
Page 16: Return And Warranty Policies
CRESTRON shall not be liable to honor the terms of this warranty if the product has been used in any application other than that for which it was intended, or if it has been subjected to misuse, accidental damage, modification, or improper installation procedures. - Page 17 Crestron TPS-VID Video Card for TPS/Tilt Panel This page intentionally left blank. Operations & Installation Guide - DOC. 5869A Video Card for TPS/Tilt Panel: TPS-VID...
- Page 18 Video Card for TPS/Tilt Panel Crestron TPS-VID This page intentionally left blank. Video Card for TPS/Tilt Panel: TPS-VID Operations & Installation Guide - DOC. 5869A...
- Page 19 Crestron TPS-VID Video Card for TPS/Tilt Panel This page intentionally left blank. Operations & Installation Guide - DOC. 5869A Video Card for TPS/Tilt Panel: TPS-VID...
- Page 20 Crestron Electronics, Inc. Installation Guide - DOC. 5869A 15 Volvo Drive Rockleigh, NJ 07647 11.01 Tel: 888.CRESTRON Fax: 201.767.7576 Specifications subject to www.crestron.com change without notice.
