- Page 1 Crestron TPS-ENETL Ethernet Card for TPS/Lectern Panel Operations & Installation Guide...
- Page 2 This document was prepared and written by the Technical Documentation department at: Crestron Electronics, Inc. 15 Volvo Drive Rockleigh, NJ 07647 1-888-CRESTRON All brand names, product names and trademarks are the property of their respective owners. ©2002 Crestron Electronics, Inc.
-
Page 3: Table Of Contents
Crestron TPS-ENETL Contents Ethernet Card for TPS/Lectern Panel: TPS-ENETL Introduction...1 Features and Functions ...1 Specifications...2 Connector Specifications...3 Physical Description ...3 Industry Compliance...5 Setup...5 Installation and Hookup...5 Obtaining Communications...11 Ethernet Setup...16 Communicating with the Touchpanel via Ethernet...17 Programming...19 Programming with the Crestron AppBuilder ...19 Programming with SIMPL Windows...20... -
Page 5: Ethernet Card For Tps/Lectern Panel: Tps-Enetl
Panel: TPS-ENETL Introduction Features and Functions The TPS-ENETL Ethernet card is an optional feature designed for Crestron’s Isys™ wall/lectern mounted TPS-5000L and TPS-6000L touchpanels and the TPS-TPI touchpanel interface. The card provides communication via Ethernet/local area network (LAN) and wide area network (WAN) to any Crestron Internet protocol (IP) control device. -
Page 6: Specifications
LED Indicators Dimensions & Weight The latest versions can be obtained from the Downloads | Software Updates section of the Crestron website (www.crestron.com). Refer to NOTE after last footnote. Crestron 2-Series control systems include the AV2, PAC2, PRO2, and RACK2. -
Page 7: Connector Specifications
Pin 1 is on the far left. Physical Description The TPS-ENETL card, shown on the next page, is a printed circuit board (PCB) that is designed to be installed in a specific expansion slot in the touchpanel (or interface). - Page 8 .587 in 1.491 cm 1.022 in 2.596 cm TPS-ENETL Top View 1.425 in 3.620 cm 4 • Ethernet Card for TPS/Lectern Panel: TPS-ENETL RJ 45 port 5.850 in 14.859 cm Crestron TPS-ENETL Touchpanel interface connector Operations & Installation Guide - DOC. 6013...
-
Page 9: Industry Compliance
LINK STATUS LED (GREEN) Industry Compliance As of the date of manufacture, the TPS-ENETL has been tested and found to comply with specifications for CE marking and standards per EMC and Radiocommunications Compliance Labelling (N14176). NOTE: This device complies with part 15 of the FCC rules. Operation is... - Page 10 2. Refer to the diagram below. Using a #1 Phillips screwdriver, loosen and remove the 10 screws that secure the touchpanel rear cover. Remove Touchpanel Rear Cover Screws 6 • Ethernet Card for TPS/Lectern Panel: TPS-ENETL Crestron TPS-ENETL Operations & Installation Guide - DOC. 6013...
- Page 11 4. Refer to the diagram on next page. Using a #1 Phillips screwdriver, loosen and remove the two screws that secure the PCB blank plate and remove the plate. Operations & Installation Guide - DOC. 6013 Ethernet Card for TPS/Lectern Panel Ethernet Card for TPS/Lectern Panel: TPS-ENETL • 7...
- Page 12 TPS-ENETL with the touchpanel motherboard connector. Install TPS-ENETL 6. DO NOT force pins into connector. Press TPS-ENETL until pins are fully seated. Make sure that the mounted screws align with mounting posts of the motherboard. 8 • Ethernet Card for TPS/Lectern Panel: TPS-ENETL Crestron TPS-ENETL Operations &...
- Page 13 Crestron TPS-ENETL 7. Tighten the card mounting screws to finger-tight. CAUTION: The TPS-ENETL connector may have to be aligned slightly to fit through the opening in the rear cover. Align the connector of this card (or any other optional card that is installed) carefully to prevent damage to the card, cover, or touchpanel.
- Page 14 10. Refer to the diagram on next page and make the appropriate connection as shown. NOTE: For Ethernet connections, refer to table on page 3. 10 • Ethernet Card for TPS/Lectern Panel: TPS-ENETL Crestron TPS-ENETL Operations & Installation Guide - DOC. 6013...
-
Page 15: Obtaining Communications
BB-5000 or BB-6000 Installation Guide (Doc. 5826 or 5827, respectively) for the proper installation procedure of the touchpanel. The latest version of the appropriate guide can be obtained from the Downloads | Product Manuals section of Crestron’s website (www.crestron.com). Obtaining Communications To setup the touchpanel for Ethernet communication, it is necessary to first obtain communication with the device. - Page 16 RS-232 port of the touchpanel and the PC COM port. 1. Make sure that no programs accessing the COM port of the PC are running. 2. Select Start | Programs | Crestron | SIMPL Windows to start SIMPL Windows. 3. SIMPL Windows responds with an opening splash screen and may display the “What do you want to do?”...
- Page 17 RS-232 settings (Baud Rate: 115200, Parity: None, Data Bits: Eight, and Stop Bits: One) for TPS panels when shipped from the factory. Operations & Installation Guide - DOC. 6013 Ethernet Card for TPS/Lectern Panel Ethernet Card for TPS/Lectern Panel: TPS-ENETL • 13...
- Page 18 1. If using the Stand-alone Viewport, open the Viewport and proceed to step 5. To access the Viewport via SIMPL Windows, select Start | Programs | Crestron | SIMPL Windows to start SIMPL Windows. 2. SIMPL Windows responds with an opening splash screen and may display the “What do you want to do?”...
- Page 19 6. From the window, select the appropriate NET ID of the touchpanel. 7. Observe the Viewport connect to the touchpanel. Operations & Installation Guide - DOC. 6013 Ethernet Card for TPS/Lectern Panel Ethernet Card for TPS/Lectern Panel: TPS-ENETL • 15...
-
Page 20: Ethernet Setup
For a complete listing and description of each, refer to the latest version of the 2-Series Console Commands Reference Guide (Doc. 6002) available from the Downloads | Product Manuals section of the Crestron website (www.crestron.com). 16 • Ethernet Card for TPS/Lectern Panel: TPS-ENETL Crestron TPS-ENETL Operations &... -
Page 21: Communicating With The Touchpanel Via Ethernet
Communicating with the Touchpanel via Ethernet After Ethernet parameters have been configured on the touchpanel, the Crestron Viewport may be used to communicate with the touchpanel. To connect the Viewport to the touchpanel, perform the following procedure. NOTE: Make sure the remote console is disconnected. - Page 22 4. As shown on next page (left), enter the required password. (The correct password must be entered within three attempts or the password window shown on next page (right) displays a password invalid message.) 18 • Ethernet Card for TPS/Lectern Panel: TPS-ENETL Crestron TPS-ENETL Operations & Installation Guide - DOC. 6013...
-
Page 23: Programming
Password Windows 5. Observe the Viewport connect to the touchpanel. Programming You can create a program that allows you to control the TPS-ENETL equipped TPS touchpanel via Ethernet through a Crestron control system using the Crestron programming tools Crestron Application Builder™... -
Page 24: Programming With Simpl Windows
Ethernet Card for TPS/Lectern Panel The Crestron AppBuilder is fully integrated with Crestron's suite of software development tools, including SIMPL Windows, VisionTools Pro-e (VT Pro-e), Crestron Database, User IR Database, and User Modules Directory. The Crestron AppBuilder accesses these tools behind the scenes, enabling you to easily create robust systems. - Page 25 System Views. The System Views upper pane displays the Ethernet Units icon below the PRO2 graphic. The PRO2 system tree displays the C2ENET-2 in Slot 8. Operations & Installation Guide - DOC. 6013 Ethernet Card for TPS/Lectern Panel Ethernet Card for TPS/Lectern Panel: TPS-ENETL • 21...
- Page 26 Windows program. NOTE: For operation of a touchpanel that contains the TPS-ENETL, refer to the “IP Table Setup” section of the latest revision of the Crestron e-Control Reference Guide (Doc. 6052). The latest version can be obtained from the Downloads | Product Manuals section of Crestron’s website (www.crestron.com).
-
Page 27: Example Program
Crestron TPS-ENETL Example Program An example program for the TPS touchpanel with TPS-ENET is available from the Crestron FTP site (ftp://ftp.crestron.com). Select the Examples folder and search for: TPS-ENET_SIMPL_Windows_files_VTPro-e_touchpanel_files_supporting_files.zip Operations & Installation Guide - DOC. 6013 Ethernet Card for TPS/Lectern Panel... -
Page 28: Problem Solving
Ethernet Card for TPS/Lectern Panel Problem Solving Troubleshooting The table below provides corrective action for possible trouble situations. If further assistance is required, please contact a Crestron customer service representative. TPS-ENETL Troubleshooting TROUBLE Communications via the LAN port is not functioning. -
Page 29: Further Inquiries
• In Australia and New Zealand, call Creston Control Solutions at +61-2-9737-8203. Firmware Upgrades To take advantage of all the TPS-ENETL’s features, the unit should contain the latest firmware available. Therefore, please check Crestron’s website (http://www.crestron.com/downloads/software_updates.asp) for the latest version of firmware. Not every product has a firmware upgrade, but as Crestron improves functions, adds new features, and extends the capabilities of its products, firmware upgrades are posted. -
Page 30: Return And Warranty Policies
CRESTRON shall not be liable to honor the terms of this warranty if the product has been used in any application other than that for which it was intended, or if it has been subjected to misuse, accidental damage, modification, or improper installation procedures. - Page 31 Crestron TPS-ENETL Ethernet Card for TPS/Lectern Panel This page intentionally left blank. Ethernet Card for TPS/Lectern Panel: TPS-ENETL • 27 Operations & Installation Guide - DOC. 6013...
- Page 32 Crestron Electronics, Inc. Operations & Installation Guide - DOC. 6013 15 Volvo Drive Rockleigh, NJ 07647 08.02 Tel: 888.CRESTRON Fax: 201.767.7576 Specifications subject to www.crestron.com change without notice.
