Summary of Contents for Crestron TPS-ENET
- Page 1 Crestron TPS-ENET Ethernet Card for TPS/Tilt Panel Operations & Installation Guide...
- Page 2 This document was prepared and written by the Technical Documentation department at: Crestron Electronics, Inc. 15 Volvo Drive Rockleigh, NJ 07647 1-888-CRESTRON All brand names, product names and trademarks are the property of their respective owners. ©2002 Crestron Electronics, Inc.
-
Page 3: Table Of Contents
Crestron TPS-ENET Contents Ethernet Card for TPS/Tilt Panel: TPS-ENET Introduction...1 Features and Functions ...1 Specifications...2 Connector Specifications...3 Physical Description ...3 Industry Compliance...5 Setup...5 Installation and Hookup...5 Obtaining Communications...9 Ethernet Setup...13 Communicating with the Touchpanel via Ethernet...15 Programming...16 Programming with the Crestron AppBuilder ...17 Programming with SIMPL Windows...18... -
Page 5: Ethernet Card For Tps/Tilt Panel: Tps-Enet
Ethernet Card for TPS/Tilt Panel: TPS-ENET Introduction Features and Functions The TPS-ENET Ethernet card is an optional feature designed for Crestron’s Isys provides communication via Ethernet/local area network (LAN) and wide area network (WAN) to any Crestron device. Adding Ethernet capabilities into the touchpanel via SIMPL Windows allows remote diagnostics and upgrades, access to Crestron’s... -
Page 6: Specifications
LED Indicators Dimensions & Weight The latest versions can be obtained from the Downloads | Software Updates section of the Crestron website (www.crestron.com). Refer to NOTE after last footnote. Crestron 2-Series control systems include the AV2, PAC2, PRO2, and RACK2. -
Page 7: Connector Specifications
Pin 1 is on the far left. Physical Description The TPS-ENET card, as shown on the next page, is a printed circuit board (PCB) that is designed to be installed in a specific expansion slot on the touchpanel motherboard. - Page 8 TPS-ENET Physical Views TPS-ENET Side View 0.631 in 1.603 cm TPS-ENET Top View 1.125 in 2.858 cm 4 • Ethernet Card for TPS/Tilt Panel: TPS-ENET Crestron TPS-ENET Touchpanel connector 5.750 in 14.605 cm Operations & Installation Guide - DOC. 6016...
-
Page 9: Industry Compliance
LINK STATUS LED (GREEN) Industry Compliance As of the date of manufacture, the TPS-ENET has been tested and found to comply with specifications for CE marking and standards per EMC and Radiocommunications Compliance Labelling. NOTE: This device complies with part 15 of the FCC rules. Operation is... - Page 10 Refer to the diagram below. Using a #1 Phillips screwdriver, loosen and remove the eight screws that secure the touchpanel base cover. Remove Touchpanel Base Cover Screws 6 • Ethernet Card for TPS/Tilt Panel: TPS-ENET Crestron TPS-ENET Operations & Installation Guide - DOC. 6016...
- Page 11 TPS-ENET with the touchpanel motherboard connector. DO NOT force pins into connector. Press TPS-ENET until pins are fully seated. Make sure that the screw holes of the card align with the mounting posts on the motherboard.
- Page 12 (supplied), tighten to finger-tight then, using a #1 Philips screwdriver, tighten an additional 1/8-turn. Install TPS-ENET Mounting Screws 11. Position the touchpanel base cover on the base. 8 • Ethernet Card for TPS/Tilt Panel: TPS-ENET Crestron TPS-ENET Operations & Installation Guide - DOC. 6016...
-
Page 13: Obtaining Communications
12. Operations & Installation Guide - DOC. 6016 Ethernet Card for TPS/Tilt Panel HEADPHONES AUDIO RS-232 Ethernet Card for TPS/Tilt Panel: TPS-ENET • 9 CABLE FROM ETHERNET NET/VIDEO 24VDC 2.0A... - Page 14 RS-232 port of the touchpanel and the PC COM port. Make sure that no programs accessing the COM port of the PC are running. Select Start | Programs | Crestron | SIMPL Windows to start SIMPL Windows. SIMPL Windows responds with an opening splash screen and may display the “What do you want to do?”...
- Page 15 RS-232 settings (Baud Rate: 115200, Parity: None, Data Bits: Eight, and Stop Bits: One) for TPS panels when shipped from the factory. Operations & Installation Guide - DOC. 6016 Ethernet Card for TPS/Tilt Panel Ethernet Card for TPS/Tilt Panel: TPS-ENET • 11...
- Page 16 If using the Stand-alone Viewport, open the Viewport and proceed to step 5. To access the Viewport via SIMPL Windows, select Start | Programs | Crestron | SIMPL Windows to start SIMPL Windows. SIMPL Windows responds with an opening splash screen and may display the “What do you want to do?”...
-
Page 17: Ethernet Setup
An example Ethernet setup is described on page 14. When in remote console mode, Viewport will display <TPS at the command prompt. Operations & Installation Guide - DOC. 6016 Ethernet Card for TPS/Tilt Panel Ethernet Card for TPS/Tilt Panel: TPS-ENET • 13... - Page 18 NOTE: Some of the specific console commands are listed below. For a complete listing and description of each, refer to the latest version of the 2-Series Console Commands Reference Guide (Doc. 6002) available from the Downloads | Product Manuals section of the Crestron website (www.crestron.com). Console Commands for Ethernet Setup...
-
Page 19: Communicating With The Touchpanel Via Ethernet
Communicating with the Touchpanel via Ethernet After Ethernet parameters have been configured on the touchpanel, the Crestron Viewport may be used to communicate with the touchpanel. To connect the Viewport to the touchpanel, perform the following procedure. NOTE: Make sure the remote console is disconnected. -
Page 20: Programming
Password Windows Observe the Viewport connect to the touchpanel. Programming You can create a program that allows you to control the TPS-ENET equipped TPS touchpanel via Ethernet through a Crestron control system using the Crestron programming tools Crestron Application Builder™... -
Page 21: Programming With The Crestron Appbuilder
(i.e., the more flexible, the more a programmer needs to know and account for). Of course, one can initiate programming using the easiest method (Crestron AppBuilder) and use advanced techniques that are available from SIMPL Windows to customize the job. -
Page 22: Programming With Simpl Windows
It provides a well-designed graphical environment with a number of workspaces (i.e., windows) in which a programmer can select, configure, program, test, and monitor a Crestron control system. SIMPL Windows offers drag and drop functionality in a familiar ... - Page 23 C2ENET-2 Device, Slot 8 Drag the appropriate Ethernet TPS touchpanel (for example, the TPS-6000 w/TPS-ENET) from the Touchpanels folder and drop it on Slot 8 in System Views. The lower pane shows the touchpanel in IP-ID as shown on next page.
-
Page 24: Example Program
Windows program. NOTE: For operation of a touchpanel that contains the TPS-ENETL, refer to the “IP Table Setup” section of the latest revision of the Crestron e-Control Reference Guide (Doc. 6052). The latest version can be obtained from the Downloads | Product Manuals section of Crestron’s website (www.crestron.com). -
Page 25: Problem Solving
Crestron TPS-ENET Problem Solving Troubleshooting The table below provides corrective action for possible trouble situations. If further assistance is required, please contact a Crestron customer service representative. TPS-ENET Troubleshooting TROUBLE Communications via the LAN port is not functioning. Operations & Installation Guide - DOC. 6016... -
Page 26: Further Inquiries
Crestron website (www.crestron.com) for a listing of Crestron worldwide offices. Firmware Upgrades To take advantage of all the TPS-ENET’s features, the unit should contain the latest firmware available. Therefore, please check Crestron’s website (http://www.crestron.com/downloads/software_updates.asp) for the latest version of firmware. Not every product has a firmware upgrade, but as Crestron improves functions, adds new features, and extends the capabilities of its products, firmware upgrades are posted. -
Page 27: Return And Warranty Policies
CRESTRON shall not be liable to honor the terms of this warranty if the product has been used in any application other than that for which it was intended, or if it has been subjected to misuse, accidental damage, modification, or improper installation procedures. - Page 28 Crestron Electronics, Inc. Operations & Installation Guide - DOC. 6016 15 Volvo Drive Rockleigh, NJ 07647 08.02 Tel: 888.CRESTRON Fax: 201.767.7576 Specifications subject to www.crestron.com change without notice.
