Operating Instructions
GB
English,1
GE640X
GE640TX
GE641TX
GE640KX
GE641TKX
Contents
Installation, 2-5
Troubleshooting, 11
Guarantee, 13
HOB
GB
Advertisement
Table of Contents
Related Manuals for Hotpoint GE640X
Summary of Contents for Hotpoint GE640X
-
Page 1: Table Of Contents
Description of the appliance, 7 Overall view Start-up and use, 8 Practical advice on using the burners Precautions and tips, 9 General safety Disposal GE640X Recycling & Disposal Information GE640TX GE641TX Maintenance and care, 10 GE640KX Switching the appliance off... -
Page 2: Installation
Installation ! The installation instructions for cooking ranges shall fitted with air circulation tubes as described above. include a recommendation that such appliances However, these rooms must not be communal rooms, should not be placed adjacent to a door access to bedrooms or rooms that may present a fire hazard. -
Page 3: Gas Connection
Hook fastening diagram ! Check that the pressure of the gas supply is consistent with the values indicated in Table 1 (“Burner and nozzle specifications”). This will ensure the safe operation and longevity of your appliance while maintaining efficient energy consumption. Connection with a rigid pipe (copper or steel) ! Connection to the gas system must be carried out in such Hooking position... - Page 4 • Setting the burners to minimum: 5. Once the adjustment has been made, replace the seals on the by-passes using sealing wax or a similar 1. Turn the tap to the low flame position. substance. 2. Remove the knob and adjust ! If the appliance is connected to liquid gas, the regulation the adjustment screw, which is screw must be fastened as tightly as possible.
-
Page 5: Burner And Nozzle Specifications
Burner and nozzle specifications Table 1 Liquid Gas Natural Gas Burner Diameter Thermal Thermal By-pass Nozzle Flow* Thermal Nozzle Flow* power power 1/100 1/100 (g/h) power 1/100 (g/h) (p.c.s.*) (p.c.s.*) (p.c.s.*) (mm) (Reduced) (Nominal) (mm) (mm) (Nominal) (mm) Fast (Large) (R) 0.70 3.00 3.00... -
Page 6: Electrical Connection
Electrical Connection Power supply voltage and frequency: 220-240V a.c. Disposing of the plug 50/60Hz. Ensure that before disposing of the plug itself, you make the pins unusable so that it cannot be ! The supply cable must be positioned so that it never accidentally inserted into a socket. -
Page 7: Description Of The Appliance
Description of the appliance Overall view GAS BURNERS Support Grid for COOKWARE Control Knobs for GAS BURNERS SAFETY DEVICES* Ignition for GAS BURNERS* • GAS BURNER ignition* enables a specific burner • GAS BURNERS differ in size and power. Use the to be lit automatically. -
Page 8: Start-Up And Use
Start-up and use Practical advice on using the burners ! The position of the corresponding gas burner is shown on every knob. To ensure the burners operate efficiently: Gas burners Each burner can be adjusted to one of the following •... -
Page 9: Precautions And Tips
Recycling & Disposal Information with the hot parts of the oven. • The openings used for ventilation and dispersion As part of Hotpoint's continued commitment to helping of heat must never be covered. the environment, Hotpoint reserves the right to use •... -
Page 10: Maintenance And Care
Maintenance and care Gas tap maintenance Switching the appliance off Over time, the taps may become jammed or difficult to Disconnect your appliance from the electricity supply turn. If this happens, the tap must be replaced. before carrying out any work on it. ! This procedure must be performed by a qualified Cleaning the appliance technician authorised by the manufacturer. -
Page 11: Troubleshooting
Troubleshooting It may happen that the appliance does not function properly or at all. Before calling the service centre for assistance, check if anything can be done. First, check to see that there are no interruptions in the gas and electrical supplies, and, in particular, that the gas valves for the mains are open. - Page 12 5 Year Parts Guarantee Hotpoint also offers you a free 5 year parts guarantee. This additional guarantee is conditional on you registering your appliance with us and the parts being fitted by one of our authorised engineers. There will be a charge for our engineer’s time.
-
Page 13: After Sales Service
After Sales Service No one is better placed to care for your Hotpoint appliance during the course of its working life than us – the manufacturer. Essential Contact Information Hotpoint Service We are the largest service team in the country offering you access to 400 skilled telephone advisors and 1000 fully qualified engineers on call to ensure you receive fast, reliable, local service. - Page 14 Notes PLEASE PHONE US TO REGISTER YOUR APPLIANCE AND ACTIVATE YOUR PARTS GUARANTEE ON 08448 24 24 24...
