Installation and User Manual
REU-VR2632WDHD-E - HD50e
REU-VRM3237WHD-E - HD70e
Read these instructions carefully before attempting installation or use of this
All work must be carried out by competent persons.
REU-VR2632FFUD - 26i
Continuous Flow Water Heater
REU-VR2632FFUDHD-E - HD50i
REU-VRM3237FFUHD-E - HD70i
Important.
appliance.
Advertisement
Table of Contents
Related Manuals for Rinnai REU-VR2632FFUD - 26i
Summary of Contents for Rinnai REU-VR2632FFUD - 26i
- Page 1 Installation and User Manual REU-VR2632FFUD - 26i REU-VR2632WDHD-E - HD50e REU-VR2632FFUDHD-E - HD50i REU-VRM3237WHD-E - HD70e REU-VRM3237FFUHD-E - HD70i Continuous Flow Water Heater Important. Read these instructions carefully before attempting installation or use of this appliance. All work must be carried out by competent persons.
- Page 2 Date of Issue: 23/12/2004 - 28/07/2003 - 26/10/2007 - 26/10/2007 Quality System Standard ISO 9001 - 2008 The Design, Development, and Manufacture of Gas Water Heating Appliances done under Rinnai’s Quality Management System is certified under the Quality Management System Standard ISO 9001. Registration Number JQ0003D Registered since: February 1994 Certified by JIA—QA Centre.
-
Page 3: Table Of Contents
CONTENTS USERS INSTRUCTIONS FEATURES AND BENEFITS IMPORTANT INFORMATION OPERATION WITHOUT REMOTES STATUS MONITOR TEMPERATURE CONTROLS ERROR MESSAGES RESTARTING THE RINNAI WATER HEATER UK CARING AND MAINTENANCE INSTALLATION INSTRUCTIONS UK INSTALLATION INSTRUCTIONS UNPACKING RINNAI WATER HEATER OPERATION MAIN COMPONENTS INSTALLATION INSTRUCTIONS... -
Page 4: Users Instructions
The user must not use the appliance in any way that it was not meant to be used. The user may only use the heater as detailed in the User portion of this manual. Interference with a sealed component is not permitted. In case of defect parts only use genuine Rinnai components for replacement. -
Page 5: Features And Benefits
IGNITION IS ELECTRONIC, so there is no pilot light. When the hot water tap is off, no gas is used. The Rinnai 32 litres models water heaters have a built in Status Monitor on the front of the unit to display error codes and run condition. -
Page 6: Important Information
Do make sure that the tap is turned off tightly. Consider reducing the tempera- • ture of the water supplied to the Do consider setting your Rinnai Water hot tap to 50°C. Heater at a maximum temperature of 50°C. This approach can be extremely •... - Page 7 IMPORTANT INFORMATION Always check water temperature before use. Hot water may go cold without warning at very low water flows (less than 3 l/min). OFF! Refer to warning about hot water on page 6 for important safety information. If freezing temperatures are expected, turn off The delivered water temperature is controlled automatically.
-
Page 8: Operation Without Remotes
OPERATION WITHOUT REMOTES Rinnai products have no pilot light and operate automatically as soon as water flow is sensed. The burner ignites with electronic ignition and the flame extinguishes as soon as water flowing through the appliance stops. Turn On by opening the hot water tap... -
Page 9: Temperature Controls
Controllers. Each Temperature Controller can be individually programmed. Up to four universal can be fitted with Rinnai water heaters. Universal Controllers allow temperature selection only and one comes as standard with the water heater. Deluxe Temperature Controllers are available as an optional extra. - Page 10 TEMPERATURE CONTROLS Remote temperature controllers provide control over the water temperature. Rinnai water heaters can be operated with 1, 2, 3, 4 or no temperature controllers. Each time a button is pressed, a BEEP will sound. The BEEP sound can be muted by depressing the Temperature Controller Up and Down buttons simultaneously for more than 3 seconds.
- Page 11 The Digital Monitor will go out. If hot water taps are opened when the Rinnai is off, cold water will flow from the taps. If the system is to be left off over the winter be sure to drain it down if there is a possibility of freezing temperatures.
- Page 12 TEMPERATURE CONTROLS Using 2 or more universal Temperature Controllers. Switching the system ON. The hot water system and all controllers can be switched ON and OFF from any controller by pressing the ON/OFF button as shown. When the system is turned ON the water temperature display will be lit. During normal operation the system is left ON.
- Page 13 TEMPERATURE CONTROLS Do not push the ON/OFF button on the Master Temperature priority cannot be switched to controller after transferring priority another controller when the water is flowing temperature selection to a Secondary controller through the water heater. as the system will shut down. Controller 1 Controller 2 in use...
-
Page 14: Error Messages
ERROR MESSAGES Rinnai water heaters have the ability to check their own operation continuously. If a fault occurs, an error code will flash on the digital display (and on the Status Monitor) if you have temperature controllers installed. This assists with diagnosing the fault, and may enable you to overcome a problem without a service call. -
Page 15: Restarting The Rinnai Water Heater
If following the above procedure does not reset the heater switch it on and off at its main supply, and then go through these steps again. If heater is still not working call your local service agent or Rinnai for... -
Page 16: Caring And Maintenance
This is to ensure continued safety of the gas appliance. If you need a recommended service engineer contact Rinnai or your supplier. For more detailed instructions on maintenance contact Rinnai or your supplier. -
Page 17: Installation Instructions
If the information in this manual is not followed exactly a fire or explosion could result. This manual must be read in its entirety before installing the ap- pliance. If you are unsure of any point contact Rinnai or your supplier. -
Page 18: Installation Instructions
Building Regulations G3 require installers of unvented systems to be competent to do so. Competence can be shown by holding a current certificate in Unvented Domestic Hot Water Systems. If the Rinnai is installed in a flow and return, or tank system, or any other closed system then the system is unvented. -
Page 19: Unpacking Rinnai Water Heater
HD range of heaters because they are commercial units. If you require controllers in commercial situations they are compatible with the HD range and available from Rinnai or your supplier. Check that the appliance supplied is the correct gas type and pressure for the installation. - Page 20 OPERATION HD50e 26i - HD50i...
- Page 21 OPERATION HD70e AC 230V HD70i AC 230V...
-
Page 22: Main Components
MAIN COMPONENTS 1. Gas Control Unit 1.1 Modulating Valve This device is used by the PCB to adjust the volume of gas to the burner in proportion to the volumetric flow rate of water in order to maintain a supply of constant temperature hot water amid changes in water flow rates and incoming temperatures. -
Page 23: Installation Instructions
Rinnai can not be held responsible for any consequential water damage so it may be necessary to fit a drain pan under the unit. - Page 24 See the pressure chart on page 48. Contact Rinnai or your supplier for 'gravity fed' or 'low pressure' hot water installations. Water pipe sizing and layout should be designed correctly to ensure the given water flows from the appliance are available.
-
Page 25: Installation Instructions
UK INSTALLATION INSTRUCTIONS Water Connection For all closed systems (with flow and return or tank) the system must incorporate an unvented kit with the components shown below. The safety relieve valve must discharge safely into a suitable drain via a tundish. -
Page 26: Flue Requirements
Windows and doors can not be considered ventilation unless they are permanently fixed in the open position. Please refer to IGE/UP/10 Part 1. Edition 2 page 17; for further information or contact Rinnai UK. FLUE REQUIREMENTS The flue must be installed by a competent, authorised person. It is the installer’s responsibility to ensure that the unit has been installed to all current local requirements. - Page 27 Installations with total equivalent length of flue >7m must alter the flue length Dip Switch (see page 36). Common Header (Cascade) Flues: do not connect this appliance into any common header flue, cas- cade system, or natural draught chimney. For information on these installations contact Rinnai. Condensate disposal internal models It is important that any condensate is kept away from the heat exchanger.
- Page 28 FLUE REQUIREMENTS For the Internal range the flue system is considered part of the continuous flow water heater. The follow- ing flue type and make is approved in combination with above mentioned water heaters. Separate in- structions are provided with the flue detailing the installation of the flue parts. Ubbink flue system for HD70i: 952-032-001 HD70i standard horizontal kit...
-
Page 29: Flue Requirements
UK FLUE REQUIREMENTS The Rinnai internal range are for internal installation in conjunction with the Rinnai flue system. The flue must be installed in accordance with: -Manufacturers Installation Instructions; -British Standards including BS5440; -Gas Safety (Installation and Use) Regulations; -IGE/UP/10 Part1 Edition 2;... -
Page 30: Temperature Controls
TEMPERATURE CONTROLS General Information Commercial installations do not generally have controllers installed. These installations usually have one permanent set temperature that is constant at all times. The public should not have access to alter the temperature in these situations. These installations do not require controllers as the temperature can be set by a series of dip switches on the PCB. - Page 31 TEMPERATURE CONTROLS Universal temperature controller - MC-91 1. Determine the most suitable position for the temperature controller. 2. Drill 3 holes in the wall (Fig.1), one for the cable and two for the securing screws. Fit wall plugs if needed and ensure controller is level. 3.
-
Page 32: Ez Connect
EZ CONNECT EZ Connect Installation The EZ Connect allows the installation of two water heaters to be controlled by one remote controller without PAM valves or a MECS. The EZ Connect will sequence the heaters for low flows and rotate the lead heater for even use. -
Page 33: Testing
TESTING 1.Purge gas, hot water and cold water supply lines before making the final connection of the water heater. Swarf in either the gas or water supplies may cause damage. 2.Turn on gas and cold water supplies. 3.Test for water leaks and gas escapes near the unit. 4.Isolate gas and electric supply. -
Page 34: Gas Pressure Setting
Contact Rinnai before attempting to alter the gas pressure if you are unsure of what to do. Incorrect adjustment can void the warranty. - Page 35 GAS PRESSURE SETTING 10. Set the Rinnai to 'Forced Low' combustion by setting No.7 switch of Dip SW1 to 'ON'. (Fig. 3) 11. Check the burner test point operating pressure. Dip SW1 HD50e HD70e HD70i HD50i Fig. 3 1.29 1.83 1.75...
-
Page 36: Dip Switch Setting
Warm Water Switch WARM WATER SWITCH Forced Combustion If activated reduces the min flowrate to light Forced Combustion OFF ON Dip SW1 Rinnai when inlet water temperature is close to OFF ON Dip SW2 setpoint temperature Gas Type OFF = +3°C (default setting) Gas Type ON = off when outgoing temp +6°C... - Page 37 DIP SWITCH SETTING 26i - HD50e - HD50i - HD70e - HD70i Temperatures - with or without remotes connected OFF ON Dip SW1 OFF ON Dip SW1 OFF ON Dip SW1 40°C 42°C 50°C OFF ON Dip SW1 OFF ON Dip SW1 OFF ON Dip SW1 55°C 60°C...
-
Page 38: Dimensions
DIMENSIONS HD70e... - Page 39 DIMENSIONS HD70i...
- Page 40 DIMENSIONS HD50e...
- Page 41 DIMENSIONS 26i - HD50i...
-
Page 42: Technical Details
TECHNICAL DETAILS Model HD50e 26i - HD50i Unit Installation External Internal G20 Nat Gas Press Low / High 1.29 / 6.81 1.75 / 9.35 mbar G31 Propane Press Low / High 2.21 / 11.2 2.36 / 11.1 mbar Flue System Direct Forced Exhaust Forced Room Sealed 37-46,48,50,55,... - Page 43 TECHNICAL DETAILS Model HD70e HD70i Unit Installation External Internal G20 Nat Gas Press Low / High 1.83 / 7.95 1.86 / 7.95 mbar G31 Propane Press Low / High 2.34/ 9.25 2.22 / 9.25 mbar Flue System Direct Forced Exhaust Forced Room Sealed 37-46,48,50,55, 37-46,48,50,55,...
-
Page 44: Flow Chart
FLOW CHART 26i - HD50e - HD50i - HD70e - HD70i... -
Page 45: Wiring Diagram
WIRING DIAGRAM HD70e - HD70i... - Page 46 WIRING DIAGRAM 26i - HD50e - HD50i...
-
Page 47: Diagnostic Points
DIAGNOSTIC POINTS... -
Page 48: Water Flow Characteristics
WATER FLOW CHARACTERISTICS 26i - HD50e - HD50i - HD70e - HD70i... -
Page 49: Letter Of Compliance
LETTER OF COMPLIANCE... -
Page 50: Ce Certificate
CE CERTIFICATE... - Page 51 CE CERTIFICATE...
- Page 52 CE CERTIFICATE...
- Page 53 CE CERTIFICATE...
-
Page 54: Commissioning Check List
COMMISSIONING CHECK LIST The water heater is not subject to corrosive compounds in the air. □ □ The water supply does not contain chemicals or exceeds total hardness that will damage the heat exchanger. □ Clearances from the water heater unit are met. □... -
Page 55: Commissioning Sheet
COMMISSIONING SHEET... -
Page 56: Service Record
SERVICE RECORD... -
Page 57: Warranty
UK WARRANTY As the purchaser of this high quality Rinnai Water Heater you are provided with the following conditional warranty. Heat Exchanger All Other Parts Parts Labour Parts Labour 3 Years 1 Year 3 Years 1 Year Standard Use Rinnai 26i... - Page 58 WHAT WILL RINNAI DO? Rinnai will repair or replace the product or any part or component that is defective in materials or workmanship, except as set forth below: All repairs must be performed using genuine Rinnai parts. All repairs or replacements must be performed by a registered gas engineer.
-
Page 59: Product Fiche
TECHNICAL DETAILS PRODUCT FICHE Supplier’s Name Rinnai UK Ltd REU-VR2632FFUD-E Model Name REU-VR2632FFUDHD-E Declared Load Profile on Energy Label Energy Efficiency Class Water Heating Efficiency η 82.3 Annual Electricity Consumption AEC (kWh/annum) Annual Fuel Consumption AFC (GJ/annum) Second Load Profile Energy Efficiency Class Water Heating Efficiency η... - Page 60 TECHNICAL DETAILS PRODUCT FICHE Supplier’s Name Rinnai UK Ltd REU-VRM3237W-E Model Name REU-VRM3237WHD-E Declared Load Profile on Energy Label Energy Efficiency Class Water Heating Efficiency η 83.2 Annual Electricity Consumption AEC (kWh/annum) Annual Fuel Consumption AFC (GJ/annum) Second Load Profile Energy Efficiency Class Water Heating Efficiency η...
-
Page 61: Contact
CONTACT UK LTD. 9 Christleton Court Manor Park Runcorn Cheshire WA7 1ST Tel. 01928 531870 Fax. 01928 531880 E-mail. info@rinnaiuk.com Web. www.rinnaiuk.com HEATER DETAILS Model Number _____________________________________________ Serial Number _____________________________________________ Date of Purchase _____________________________________________... - Page 64 (VR2632, VRM3237, UK) U287-3089X02(00) 15/10/05(RJ) 060 00012 31437 3...
