Parts checklist
a
2
b
c
d
e
a
Handle
b
Canister release latch
c
See through dust canister
d
Lower hose
e
Clear window
f
Bumper bar
g
Hepa filter
h
Canister lid
i
Main hose
j
Cord clip
Putting your cleaner together
1
3
Place the base of the cleaner so it
is facing away from you.
Position the body so that the lower
hose is on your right hand side.
Push the body down into place.
i
h
g
f
Phillips screwdriver required
2
To secure the body in place insert
one of the screws supplied into the
back of the cleaner, through the
hole located above the on/off pedal.
s
j
r
k
q
l
p
m
o
n
k
Extension wand
l
Carrying handle/ Cord wrap
m
On/Off pedal
n
Handle release pedal
o
Cord wrap with quick release
p
Power cord
q
Crevice tool
r
2-in-1 Tool - Dust brush/ Upholstery tool
s
Hose bracket
t
Turbotool
Pull back the flap on the clear
window. Match the slots on the
hose to the tabs on the hose inlet.
Push down firmly on the cuff and
turn anti-clockwise to lock in place.
t
3
Advertisement
Related Manuals for Vax VS 183
Summary of Contents for Vax VS 183
- Page 1 Parts checklist Extension wand Handle Carrying handle/ Cord wrap Canister release latch On/Off pedal See through dust canister Handle release pedal Lower hose Cord wrap with quick release Clear window Power cord Bumper bar Crevice tool Hepa filter 2-in-1 Tool - Dust brush/ Upholstery tool Canister lid Hose bracket Main hose...
- Page 2 Putting your vacuum cleaner together Align the holes in the tool holder, Use two of the screws supplied to With the hose clip on the handle with the holes on top of the body. secure the tool holder in place. facing you place it onto the top of Do not over tighten.
- Page 3 Putting your vacuum cleaner together Using the handle attach the main Push the canister lid firmly on top of Attach the tools to the tool holder. hose into the left hand side of the the dust canister and place it onto The 2 in 1 tool fits over a post at cleaner.
- Page 4 Cleaning upholstery Operating the vacuum cleaner Make sure the vacuum cleaner has Remove the hose from the tool Slide the hose into the lower hose been switched off and is in an Holder. with the tab facing upwards twist upright position. Remove the lower together to secure.
- Page 5 Emptying the dust canister Empty the all the dust and dirt from Make sure the vacuum To remove the lid of the dust the dust canister. cleaner has been switched off and canister hold the top and the side unplugged from the mains supply. handles firmly and turn the lid To remove the dust canister from anti-clockwise.
- Page 6 Belt or Brush removal and replacement Phillips screwdriver required nozzle guard tabs Unplug the vacuum cleaner from Lift and remove the brush bar, then The belt should sit on the end of the the mains supply. Press the handle slide the belt off the motor shaft brush bar with no bristles against release button and turn the vacuum and dispose of it.
-
