Summary of Contents for Powerbuilt AC4025
-
Page 2: Table Of Contents
TABLE OF CONTENTS Thank You For your Purchase ............................3 Unpacking Your New Compressor ..........................3 Hazards and Safety ................................. 4 Work Area Safety ................................4 Personal Safety ................................4 Electrical Safety ................................5 Air compressor Safety ..............................5 Technical Description..............................6 Compliance Plate ................................ -
Page 4: Hazards And Safety
Read all safety warning and all instructions. This Operating Manual has been designed to instruct you on the correct operation of your Powerbuilt product. Your satisfaction with this product and its safe operation is our ultimate concern. Therefore, please take the time to read the entire manual, especially the safety symbols and instructions They will help you to avoid potential hazards that may exist when working with this product. -
Page 5: Electrical Safety
ELECTRICAL SAFETY ELECTRICITY CAN KILL • Guard against electrical shock by preventing body contact with grounded surfaces, e.g., pipes, radiators, ovens, refrigerator enclosures. • Do not abuse cord. Never carry or drag the compressor by the cord or yank it to disconnect from wall socket. Keep cord away from heat, oil, and sharp edges. -
Page 6: Technical Description
TECHNICAL DESCRIPTION SPECIFICATION UNITS AC4025 Drive Direct Drive Motor Winding Copper Tank Size Horsepower Motor RPM 2850 Pump RPM 2850 Air Pressure 0-120 Displacement 230 L/min @ 90 PSI Free Air Delivery @ 90 PSI 138 L/min @ 90 PSI... -
Page 7: Input Plug
Whilst running a vehicle in the red zone all the time is great to get you where you need fast!! It dramatically shortens the life of the vehicle’s engine. The same is said with duty cycles – to obtain the best life and performance out of your tool or compressor purchase a compressor that suits your application. -
Page 15: Troubleshooting
TROUBLESHOOTING PROBLEM POSSIBLE CAUSE SOLUTION Compressor does not run No Electrical power Check unit is plug in and power point turned on Check fuse/circuit breaker Motor overload protection has tripped Let motor cool and overload protection switch will reset Faulty pressure switch Replace pressure switch Tank is full of air Compressor will only turn on when tank... -
Page 16: Warranty Statement
Powerbuilt Tools and assist you through the warranty process. WARNING Repairs to this compressor must be made by a qualify Powerbuilt service agent. Powerbuilt will not be responsible for any damage or injuries caused by the repair or attempted repair by an unauthorized... -
Page 19: Notes
NOTES... - Page 20 Powerbuilt is a registered trademark of Alltrade Tools, LLC. New Zealand Customer enquiries should be directed to: Alltrade Tools NZ (2016) Ltd support@powerbuilttools.co.nz www.powerbuilttools.co.nz Made in China 2021, Alltrade Tools, LLC...
