Summary of Contents for Crestron CNXRMIRD
- Page 1 Crestron CNXRMIRD Infrared Detector Operations Guide...
- Page 2 This document was prepared and written by the Technical Documentation department at: Crestron Electronics, Inc. 15 Volvo Drive Rockleigh, NJ 07647 1-888-CRESTRON...
-
Page 3: Table Of Contents
Crestron CNXRMIRD Contents Infrared Detector: CNXRMIRD ... 1 Description ... 1 Functional Description ... 1 Physical Description... 1 Setup... 2 Leading Specifications ... 4 Problem Solving... 5 Troubleshooting ... 5 Further Inquiries ... 6 Future Updates ... 6 Return and Warranty Policies... 7 Merchandise Returns / Repair Service ... -
Page 5: Infrared Detector: Cnxrmird
Infrared Detector: CNXRMIRD Description Functional Description The Crestron Infrared (IR) Detector (CNXRMIRD) is used by Crestron's CNXRMC (Room Solution Box) and CNXRMCLV (Room Solution Box with Local Video) to detect fixed low frequency (38KHz) type IR formats generated by typical hand-held remote devices. Commands received by the detector can either be processed locally to control video or audio, or sent to a host control system. -
Page 6: Setup
Setup Plug the mini phone jack into the IR IN port on the CNXRMC or CNXRMCLV, and place the IR receiver in a convenient location free of obstructions to receive IR signals. Secure it with the supplied dual lock fasteners. - Page 7 Crestron CNXRMIRD Example The following is an example of a typical CNXRMIRD connection as part of a Crestron control system. CNXRMIRD Connection Example CRESTRON CONTROL SYSTEM (INCLUDING WIRED AND WIRELESS TOUCHPANELS AS USER INTERFACES) CNX-PVID VIDEO CRESNET (CAT 5) AUDIO...
-
Page 8: Leading Specifications
Detection Range * Can be extended up to 500 ft. As of the date of manufacture, the CNXRMIRD has been tested and found to comply with specifications for CE marking. NOTE: This device complies with part 15 of the FCC rules. Operation is... -
Page 9: Problem Solving
Crestron CNXRMIRD Problem Solving Troubleshooting The following table provides corrective action for possible trouble situations. If further assistance is required, please contact a Crestron customer service representative. CNXRMIRD Troubleshooting TROUBLE No response from commands sent to CNXRMC or CNXRMCLV. Operations Guide - DOC. 8165... -
Page 10: Further Inquiries
If after reviewing this Operations Guide, you cannot locate specific information or have questions, please take advantage of Crestron's award winning customer service team by calling: • In the US and Canada, call Crestron’s corporate headquarters at 1-888-CRESTRON [1-888-273-7876]. • In Europe, call Crestron International at +32-15-50-99-50. -
Page 11: Operations Guide - Doc
CRESTRON shall not be liable to honor the terms of this warranty if the product has been used in any application other than that for which it was intended, or if it has been subjected to misuse, accidental damage, modification, or improper installation procedures. - Page 12 Crestron Electronics, Inc. Operations Guide – DOC. 8165 15 Volvo Drive Rockleigh, NJ 07647 03.02 Tel: 888.CRESTRON Fax: 201.767.7576 Specifications subject to www.crestron.com change without notice.
