Crestron PinPoint PP-100 Installation Manual

PP-100
Proximity Detection Beacon
Installation Guide
Description
The Crestron PP-100 PinPoint™ Proximity Detection
®
Beacon is a low-pro le hardware device that plugs into
a USB wall charger (or any USB host port).
The PP-100 uses Bluetooth
the location of a mobile smart device by measuring its
signal strength relative to each of the beacons in the
system.
Additional Resources
Visit the product page on the
Crestron website (www.crestron.com)
for additional information and the
latest rmware updates. Use a QR
reader application on your mobile
device to scan the QR code.
Placement Tips
For optimal performance of the PinPoint system
throughout a residence or facility, utilize the following
placement tips:
• The PinPoint pattern of detection is roughly
hemispherical from the front face of the PP-100
enclosure. Ensure the Crestron swirl logo is facing
the general direction of desired detection.
• Minimize physical obstructions (e.g., furniture,
walls, etc.) between the PP-100 and its area of
desired detection. PP-100 is closer to the device.
• If PP-100s are used in adjacent rooms, avoid
placing them along a common wall in close
proximity to each other. Since PinPoint detection
works through walls and other obstructions,
avoiding such placement will make it easier to
determine which PP-100 is closer to the device.
• If PP-100s are used in two rooms that are directly
above and below each other, avoid placing
PP-100s close to the ceiling in the lower room.
• For very large rooms or areas, using multiple
PP-100s can achieve more tightly controlled
PinPoint coverage.
technology to determine
®
Factory Restore
If a PP-100 cannot be detected via the Crestron Home
Beacon Setup App or if default factory values need to
be restored, use the following procedure:
1. Start by unplugging the PP-100.
2. Plug the PP-100 in for 6 seconds.
3. Unplug the PP-100.
4. Repeat steps 2 and 3 two more times.
5. Plug in the PP-100. The factory defaults should
now be restored.
