Basic Operation

Select Desired Temperature

In any mode, adjust the
desired Set Point Temperature
with
buttons.
Pressing the up/down buttons in Auto mode will adjust both the heat
and cool set point temperatures simultaneously.
Pressing the up/down buttons in Heat or Cool modes will adjust only
the heat or cool set point temperature.
Override
:
ProgramOn
Stop
Pm
unoccupied
Su
COOL
HEAT
:
Pm
:
ProgramOn
occupied 1
Su
COOL
Override
HEAT
Programming
Occupied and Unoccupied Periods
Select the maximum number
of occupied periods to be
used on any one day.
Typically 1.
(1,2 or 3)
Adjust the cooling
set point for occupied 1.
(35 to 99 F)
Adjust the heating
set point for occupied 1.
(35 to 99 F)
Adjust the cooling
set point for unoccupied
periods.
(35 to 99 F)
:
Pm
M
COOL
AUTO
HEAT
During programmed, unoccupied
periods a press of the Override
button will force the thermostat into
Occupied 1 comfort settings,
temporarily.
With each successive push of the
Override button, the override timer
will add 30 minutes, until the maxi-
mum of 4 hours is reached. Then
the next press will zero out the over-
ride timer, returning to unoccupied if
there are no further button presses.
When in Override, the Override icon
and the Occupied 1 icon appear on
the display.
The time of day clock alternates with
the time remaining in override.
During Override, the set point tem-
peratures are adjustable, provided
the keypad is not locked.
occupied 1
occupied 1
COOL
occupied 1
COOL
HEAT
unoccupied
COOL
Adjust the heating
set point for unoccupied
periods.
(35 to 99 F)
Select the day for
Occupied 1.
Adjust the start time
for occupied 1.
Adjust the stop time
for occupied 1.
Select Occupied 1 to run
on this day (On), or not to
run this day (Off).
Selecting Yes, then pressing mode will copy the previous day's program and
then will ask the same copy question again. If yes is selected each time, this
routine will repeat until Saturday is copied to Sunday. After Saturday is
copied to Sunday, the copy command is unavailable.
Page 3
unoccupied
occupied 1
M
:
Am
Start
occupied 1
M
:
Stop
Pm
occupied 1
M
occupied 1
M
ON
The copy command becomes available after the maxi-
mum number of occupied periods are programmed in a
day. This example uses 1 as the maximum occupied
periods ever programmed in one day.
Tu
occupied 1
Tu
:
Am
Start
occupied 1
Tu
:
Stop
Pm
occupied 1
Tu
COOL
HEAT
