Single Gang Temperature Sensor
Specifications
The following table provides specifications for the sensors.
Specifications for the Sensors
Power Requirements
Default Network ID
Temperature Range
Control System Update Files
2-Series Control System Update Version C2-1001.CUZ or later
CEN/CN-TVAV Update File
CNMSX-AV/Pro Update File
CNRACKX/-DP Update File
ST-CP Update File
Dimensions and Weight
1
2. Crestron 2-Series control systems include the AV2, PAC2, PRO2, RACK2, CP2, and MP2.
3. CNX update files are required for either CNMSX-AV/Pro or CNRACKX/-DP. Filenames for
4. The depth of the Sensor is listed without the Cresnet connector (approximately 0.45 in) plus
NOTE: Crestron software and any files on the website are for
Authorized Crestron dealers only. New users may be required to register
to obtain access to certain areas of the site (including the FTP site).
Physical Description
Refer to the illustrations on the next page. The sensor unit consists of a
Cresnet circuit board, a rear speaker, and a male port (standard Cresnet
network port labeled 24 Y Z G). The port provides operating power and
communications to/from the sensor.
2 • Single Gang Temperature Sensor: CNX-TS
SPECIFICATION
The latest software versions can be obtained from the Downloads | Software Updates section
of the Crestron website (www.crestron.com). Refer to the NOTE after footnote 4.
CNX update files have a UPZ extension, and ST-CP files are in one EXE or zipped UPZ file.
To avoid program problems, make sure you are using the update file with the correct suffix
letter (e.g., S, V, W, X).
clearance for the wiring.
DETAILS
24 VDC, 0.010A, .25 Watts
53
o
o
32
F - 113
F (0
1, 2, 3
Version 5.10.13V.UPZ or later
Version 5.12.63X.UPZ or later
Version 5.10.11W.UPZ or later
Version 4.02.04S.UPZ or later
Height: 4.76 in (12.1 cm)
Width: 2.91 in (5.57 cm)
Depth: 1.40 in (3.56 cm)
Weight: 2.60 oz (75 g)
Operations & Installation Guide - DOC. 8191
Crestron CNX-TS
o
o
C - 45
C)
4
