Laird Pinnacle 100 Quick Start Manual

Features at
a Glance
W I D E R A N G E O F
I N T E R F A C E S
Integrated Cortex M4F
Microcontroller exposes SPI,
QSPI, USART, ADC, I2C,
GPIO, and JTAG.
L T E - M / B L U E T O O T H 5 -
A L L W I T H C O - L O C A T E D
R A D I O C E R T I F I C A T I O N
Simplified certification process with
reduced costs - multi-wireless
integration at its very best for your
risk reduction
D E P L O Y W I T H C O N F I D E N C E
Wireless security, smart power
management, and popular cloud
service integration helps your
device continue gathering data
autonomously.
Z E P H Y R R T O S
The Zephyr tools suite simplifies
complicated configurations, and
our DVK environmental sensor and
sample test apps get you up and
running quickly.
C E R T I F I E D F O R
D E P L O Y M E N T A R O U N D
T H E W O R L D
Regulatory approvals for FCC
(USA), IC (Canada), ETSI (Europe).
Carrier certified for Vodafone,
T-Mobile US, AT&T, and Verizon.
[all pending].
P E R S O N A L S U P P O R T F O R
Y O U R I M P L E M E N T A T I O N
Free antenna scans, design
reviews, on-site EMC support and
a global team of FAEs and Tier 2
support help accelerate your
product to market.
Interested in Laird's Pinnacle 100? Visit us at lairdconnect.com/pinnacle-100-modem
The Pinnacle™ modem seamlessly
incorporates a powerful Cortex M4F
controller, full Bluetooth v5 and LTE-M
capabilities – all with full regulatory
certifications and LTE carrier approvals.
Develop your application directly on the M4F
controller using Zephyr RTOS to cut BOM costs
and power consumption. Take advantage of the
Zephyr community, Laird Connectivity's sample
code (cellular, Bluetooth) and hardware
interfaces, OR use our hosted mode AT
commands set.
This innovative modem family also offers
complete antenna flexibility – on-device, off-
board, as well as external antennas – to give you
design flexibility, reduce complexity, and simplify
your overall product solution.
Extremely power conscious, the Pinnacle 100 is
ideal for battery-powered devices operating at the
edge of your IoT networks, seamlessly bridging
the cellular WAN to the Bluetooth PAN. It's never
been easier to bridge wireless Bluetooth 5 sensor
data to cloud services like AWS IoT over a low-
power LTE connection.
Security and Building
Automation
Pinnacle™ 100 Modem
•
•
Integrated or external antennas
Integrated or external antennas
•
• Hostless operation – Full flexibility of Zephyr RTOS
Hostless operation – Full flexibility of Zephyr RTOS
•
• Low power operation – eDRX and PSM
Low power operation – eDRX and PSM
•
•
Powerful MCU on board with integrated Bluetooth v5
Powerful MCU on board with integrated Bluetooth v5
including LE long range and Mesh
including LE long range and Mesh
•
•
Complete radio and cellular certifications
Complete radio and cellular certifications
•
•
Wide input voltage range
Wide input voltage range
•
LTE-M radio via Sierra HL7800
(Altair ALT1250) – LTE bands 1, 2, 3, 4, 5, 8, 12, 13, 20, 28
o
Nordic nRF52840 – BT v5, Coded PHY (Long range),
o
2MPHY
•
Onboard Cortex-M4F Microcontroller – 32-bit @64 MHz,
256 KB of RAM, 1 MB internal flash, 8MB QSPI
•
Industrial Temp Range – Operating range -40° to +85° C
•
Globally & Carrier Certified – FCC, IC CE, BT SIG plus
PTCRB, GCF and End Device certified – AT&T, Verizon,
Vodafone (all pending)
•
Flexible Programming – Design your way: Hostless mode
via Zephyr RTOS or Hosted mode AT Command Set
•
Secure Firmware Upgrade – Comes pre-programmed
with Laird Connectivity's secure bootloader
•
Antenna Options – Unique integrated antenna variant
plus external variant with U.FL connectors
