Kofferträger / Side carrier,
festverschraubt / firmly bolted
BMW S 1000 XR
(2020-)
Artikel Nr.: / Item-no.:
6526
650
00 01
schwarz/black
Baubreite des Kofferträgers 44 cm
Width of the side carrier 44 cm
Kombinierbar mit Easy-/Alurack
Carrier can be combined with Easy-/Alurack
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 6506526 00 01 and is the answer not in the manual?

Questions and answers

Summary of Contents for hepco & becker 6506526 00 01

  • Page 1 Kofferträger / Side carrier, festverschraubt / firmly bolted BMW S 1000 XR (2020-) Artikel Nr.: / Item-no.: 6526 00 01 schwarz/black Baubreite des Kofferträgers 44 cm Kombinierbar mit Easy-/Alurack Width of the side carrier 44 cm Carrier can be combined with Easy-/Alurack...
  • Page 2 First, tighten all screws only loosely. After mounting all parts, the screws should be tightened to the torque specified. This guarantees, that the product is mounted without tension. Observe the tightening torques of the manufacturer! Control all screw connections after the assembling for tightness! 6506526 00 01...
  • Page 3 Den Träger jeweils in die seitlichen Aus- sparungen einhängen. Fastening of the carrier rear right/left: Middle: Hang the carrier in each of the lateral recesses. Rear: Fahrtrichtung/driving direction Hang the carrier in each of the lateral recesses. Fahrtrichtung/driving direction 6506526 00 01...
  • Page 4 Ø8,4 in the threads of the alrea- dy mounted adapters. Montage Verbindungsbügel rechts/links: Die Montage erfolgt zwischen den Trägern mit den Sechskantschrauben M6x16 sowie U-Scheiben Ø6,4. Fastening of the bracing bow right/left: Between the carriers with hexagon screws M6x16 and washers Ø6,4. 6506526 00 01...
  • Page 5 Weiteres Zubehör auf unsere Homepage. More accessories: see our homepage. Hepco & Becker GmbH Tel.: +49 (0)6331 - 1453 - 100 An der Steinmauer 6 Fax: +49 (0)6331 - 1453 - 120 D-66955 Pirmasens eMail: vertrieb@hepco-becker.de Germany www.hepco-becker.de 6506526 00 01...
