- Page 1 ASSEMBLY INSTRUCTIONS COASTER FINE FURNITURE Fine Furniture for every stage of life 122101 BAR STOOL PAGE 1 OF 6 COASTERFURNITURE.COM...
-
Page 2: Assembly Tips
122101 ITEM: ASSEMBLY INSTRUCTIONS ASSEMBLY TIPS: 1. Remove hardware from box and sort by size. 2. Please check to see that all hardware and parts are present prior to start of assembly. 3. Please follow attached instructions in the same sequence as numbered to assure fast & easy assembly. WARNING! 1. -
Page 3: Hardware Identification
122101 ITEM: HARDWARE IDENTIFICATION BOLT LOCK WASHER 8PCS 16PCS (Φ1/4"x1/2") (Φ10.5xΦ7.0x1.5) FLAT WASHER BOLT 4PCS 16PCS (Φ16.0xΦ7.0x1.5) (Φ1/4"x1") BOLT ALLEN KEY 4PCS (Φ1/4"x3/4") (4.0mm) NOTE: Phillips head screw driver is required in the assembly process; however, manufacturer does not provide this item. PAGE 3 OF 6 COASTERFURNITURE.COM... - Page 4 122101 ITEM: ASSEMBLY INSTRUCTIONS STEP 1 STEP 2 PAGE 4 OF 6 COASTERFURNITURE.COM...
- Page 5 122101 ITEM: ASSEMBLY INSTRUCTIONS STEP 3 STEP 4 PAGE 5 OF 6 COASTERFURNITURE.COM...
- Page 6 122101 ITEM: Product size:402Wx402Dx745H(mm) Product size:15-7/8"Wx15-7/8"Dx29-3/8"H Ø381x18mm Ø15"x3/4" 18x18x1178mm Solid 3/4"x3/4"x46-3/8" 20x40x153mm Solid 3/4"x1-5/8"x6" 20x40x540mm Solid 3/4"x1-5/8"x21-1/4" 15x30x1005mm Solid 5/8"x1-1/8"x39-5/8" PAGE 6 OF 6 COASTERFURNITURE.COM...
