- Page 1 300053(B1-B3) FINE FURNITURE DAYBED ASSEMBLY INSTRUCTIONS COASTER FINE FURNITURE www.coastercompany.com REVISION 0 : 05 / 05 / 2014 PAGE 1 OF 5...
-
Page 2: Parts Identification
ASSEMBLY INSTRUCTIONS ITEM : 300053(B1-B3) PARTS IDENTIFICATION HARDWARE IDENTIFICATION B1(BOX1) Z-B2(BOX2)-HARDWARE PACK IS LOCATED IN 300053(B2) RIGHT SIDE BOLT 12PCS FRAME LEFT SIDE NYLON 12PCS FRAME WASHER 4PCS WOOD SCREW 26PCS FINIAL 4PCS BUN FOOT WOOD DOWEL 8PCS 1 SET ALLEN ROLL SLAT WRENCH... - Page 3 ASSEMBLY INSTRUCTIONS ITEM : 300053(B1-B3) STEP 1 Insert wood dowel(4) to both ends of back rest frame(F), front(G) & back(H) bed rail. STEP 2 2.1 Align & fasten back rest frame(F) & back bed rail(H) to right(A)& left(B) side frame using bolt(1)&nylon washer(2). DO NOT FULLY TIGHTEN AT THIS STEP. 2.2 Align &...
- Page 4 ASSEMBLY INSTRUCTIONS ITEM : 300053(B1-B3) STEP 3 Align and fasten roll slat(E) to bed rails using wood screw(3). Tighten with screw driver(NOT INCLUDED) STEP 4 4.1 Insert wood dowel(10) to both ends of back panel(K) & front frame(J). 4.2 Align and fasten front frame(J) & back panel(K) to left(M) and right(L) end panel using Medium bolt(8).
- Page 5 ASSEMBLY INSTRUCTIONS ITEM : 300053(B1-B3) Align & fasten roll slat(I) to front frame(J)& back panel(K) STEP 5 using wood screw(9). Tighten with screw driver(NOT INCLUDED) STEP 6 Complete www.coastercompany.com PAGE 5 OF 5 FINE FURNITURE...
