CONCORD PZ2180 AF User Manual

Concord camera pz2180 af: user guide
Hide thumbs
Table of Contents

Advertisement

Quick Links

Using the Camera

1. Press the Power button to turn on the power.
The lens cover will open, and the LCD panel
will appear (Figure 5).
2. The lens cover will close and the power will
switch off automatically after 3 minutes if the
camera is not in use.
3. Press the zoom button to the
the lens will zoom out. Press the zoom button
to
, and the lens will zoom in (Figure 6).

Holding Your Camera

1. Hold the camera steadily with both hands.
Support the camera with your left hand with
elbows close to your body in order to prevent
the camera from shaking.
2. Take pictures with sunlight behind you.
3. When holding the camera vertically, always
position your camera with the flash at the top.
4. Be careful not to place your fingers over the
lens, flash, or viewfinder.
position, and
English
9

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PZ2180 AF and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for CONCORD PZ2180 AF

Summary of Contents for CONCORD PZ2180 AF

  • Page 1: Using The Camera

    Using the Camera 1. Press the Power button to turn on the power. The lens cover will open, and the LCD panel will appear (Figure 5). 2. The lens cover will close and the power will switch off automatically after 3 minutes if the camera is not in use.

  • Page 2: Taking Pictures

    Taking Pictures Close-up Correction Mark Auto focus Mark 1. Turn on the power and aim the auto focus frame of the viewfinder at the subject. Press the shutter halfway down. The auto focus green lamp lights up when the subject is in focus (Figure 7).

  • Page 3: Flash Mode

    Flash Mode 1. Auto Flash : Flash turns on and off automatically as needed. 2. Fill-in Flash : If the subject is in the same direction of light source or under the shade or in a bright background, the background will be too bright, and the subject too dark.

  • Page 4: Rewinding The Film

    5. Self-timer/Remote Control self-timer to take a picture of yourself. Please select the self-timer/remote control mode. The self-timer lamp will be lit for about 7 seconds when the shutter is pressed, and the self-timer will blink for 3 seconds before the shutter is released.
  • Page 5 If the entire roll of film has been rewound into the film cartridge, but is still kept in the film chamber, the camera cannot take pictures until the film is unloaded. English...
  • Page 6 Proper Care of Your Camera The camera can only function properly between -10˚C and 40˚C (104˚F and 14˚F). Be careful of sudden changes of temperature and humidity, since moisture may condense on the inside of the camera. Do not place your camera close to objects with strong magnetic fields such as televisions or radios.

  • Page 7: Safety Guide

    Safety Guide This camera is intended for photography. Please do not use it for any other purpose other than photography. Please follow the basic safety precautions as follows: Never disassemble this camera on your own. There are high voltage wires in the camera, and thus carries the risk of electric shock.

  • Page 8: Specifications

    Specifications Type 35mm full automatic lens shutter camera with power zoom lens. Film Format 35mm DX-code film; 24 x 36mm Lens 38 ~ 80 mm Japan Lens: F5.2 ~ 10.2 (4 elements in 4 groups) Shutter Programmed electronic shutter; shutter speed 1/6 ~ 1/125 second Focusing Auto focusing system with focus lock Exposure...
  • Page 9 Loading Film Automatically loading film: After closing the back cover, the film will automati- cally advance. Advancing Automatically advancing film Rewinding Automatically rewinding film: The film will automatically rewind when it reaches its end. As soon as rewinding is completed, it will stop automatically. The mid- roll rewinding button can be used to rewind the film anytime.
  • Page 10 Date Back (Optional) Operating the Date Back Before imprinting data, set the date and time using the buttons mentioned below. Display Panel MODE Switch Button SELECT Button To select the desired mode, press the MODE button. The sequence of mode change is shown below: 5) Day-month-year 4) Month-day-year...
