  • Page 2 TABLE OF CONTENTS Information on the hybrid system and adjusting and op- Before driving erating features such as door locks, mirrors, and steer- ing column When driving Driving, stopping and safe-driving information Interior Air conditioning and audio systems, as well as other in- features terior features for a comfortable driving experience Maintenance...
  • Page 3: Table Of Contents

    TABLE OF CONTENTS Index 1-5. Opening and closing the Before driving windows Power windows ....101 1-1. Hybrid system 1-6. Refueling Hybrid system features ..26 Opening the fuel Hybrid system precautions ... 31 tank cap ......104 Energy monitor/consumption screen.........
  • Page 4 2-3. Operating the lights and 3-2. Using the “Display Audio” windshield wipers Touch screen ..... 263 Headlight switch....213 Setup menu......265 Fog light switch ....217 Audio system...... 274 Windshield wipers and Using the radio ....278 washer ......218 Using the CD player ...
  • Page 5 TABLE OF CONTENTS Index 3-3. Using the interior lights Maintenance and care Interior lights list....377 • Interior lights ..... 378 • Personal lights ....379 4-1. Maintenance and care Cleaning and protecting 3-4. Using the storage features the vehicle exterior... 410 List of storage features ..
  • Page 6 When trouble arises Vehicle specifications 5-1. Essential information 6-1. Specifications Emergency flashers .... 482 Maintenance data (fuel, oil level, etc.) ... 552 If your vehicle needs to Fuel information ....563 be towed ......483 If you think something is wrong ......489 6-2.
  • Page 7 Pictorial index Exterior Outside rear view mirrors Windshield wipers P. 218 P. 99 Hood P. 424 Side turn signal lights P. 190 Front fog lights Headlights P. 217 P. 213 Front position lights P. 213 Front turn signal lights P. 190...
  • Page 8 Rear window defogger P. 262 Tail lights P. 213 Rear window wiper P. 221 Fuel filler door P. 104 Back door P. 68 Side doors P. 65 Rear fog light P. 217 Tires License plate lights ●Rotation P. 445 P. 213 ●Replacement P.
  • Page 9 Pictorial index Interior SRS front passenger airbag P. 111 Glove boxes P. 383 Head restraints P. 87 Seat belts P. 90 Bottle holder P. 387 Third seats P. 83 Second seats P. 77 SRS side airbags P. 111 Front seats P.
  • Page 10 Sun visors P. 392 Interior light P. 378 Personal light P. 379 ∗ Microphone P. 331 Assist grips P. 402 Interior light P. 378 SRS curtain shield airbags P. 111 Vanity mirrors P. 393 ∗ Auxiliary box P. 389 ∗ Panoramic roof shades switch P.
  • Page 11 Pictorial index Interior Outside rear view mirror switches P. 99 Window lock switch P. 101 Door lock switch P. 65 Inside lock button P. 65 Power window switches P. 101...
  • Page 12 EV drive mode switch P. 178 Eco drive mode switch P. 183 Power mode switch P. 183 Console box P. 384 Cup holders P. 385 Auxiliary box P. 389...
  • Page 13 Pictorial index Instrument panel SRS driver airbag P. 111 Horn P. 192 Windshield wipers and washer switch P. 218 Headlight switch P. 213 Rear window wiper and washer Turn signal lever P. 190 switch P. 221 Fog light switch P. 217 Head-up display Gauges and meters P.
  • Page 14 Air conditioning system P. 248 Rear window and outside rear view mirror defoggers P. 262 Power outlet P. 395 ∗ AUX port/USB port P. 311 ∗ : If equipped : For vehicles with a navigation system, refer to “Navigation System Owner’s Manual”.
  • Page 15 Pictorial index Instrument panel Emergency flasher switch P. 482 Instrument cluster light control button P. 194 Clock adjustment buttons P. 394 Power (ignition) switch P. 171 P position switch P. 184 Shift lever P. 181...
  • Page 16 “TRIP” button P. 195 Climate remote control switches P. 260 Audio remote “DISP” button P. 195 ∗ control switches P. 326 ∗ Talk switch Cruise control switch P. 224 ∗ Telephone switches P. 330 ∗ : If equipped : Refer to “Navigation System Owner’s Manual”. : For vehicles with a navigation system, refer to “Navigation System Owner’s Manual”.
  • Page 17 Pictorial index Instrument panel ∗ IPA pre-support switch ∗ Headlight cleaner switch P. 223 ∗ Headlight leveling dial P. 214 Hood lock release lever P. 424 Card holder P. 391...
  • Page 18 ∗ : If equipped : Refer to “Navigation System Owner’s Manual”.
  • Page 19 Accessories, spare parts and modification of your Toyota A wide variety of non-genuine spare parts and accessories for Toyota vehi- cles are currently available in the market. Using these spare parts and...
  • Page 20 ● Anti-lock brake system ● SRS airbag system ● Seat belt pretensioner system Be sure to check with your Toyota dealer for precautionary measures or spe- cial instructions regarding installation. High voltage parts and cables on the hybrid vehicles emit approximately the...
  • Page 21 Furthermore, these computers do not record con- versations, sounds or pictures. ● Data usage Toyota may use the data recorded in these computers to diagnose malfunc- tions, conduct research and development, and improve quality. Toyota will not disclose the recorded data to a third party except: •...
  • Page 22 ● Disclosure of the EDR data Toyota will not disclose the data recorded in an EDR to a third party except when: • An agreement from the vehicle’s owner (or the leasing company for a leased vehicle) is obtained •...
  • Page 23 Be sure to have the systems of the SRS airbag and seat belt pretensioner removed and disposed of by a qualified service shop or by your Toyota dealer before you scrap your vehicle.
  • Page 24 In the event that your vehicle must be disposed of, the hybrid battery (traction battery) must be disposed of by your Toyota dealer or a qualified service shop. If the hybrid battery (traction battery) is not disposed of properly, it may cause electric shock that...
  • Page 25 This is a warning against something which, if ignored, may cause damage to the vehicle or its equipment. You are informed about what you must or must not do in order to avoid or reduce the risk of damage to your Toyota and its equipment.
  • Page 26: Before Driving

    Before driving 1-1. Hybrid system 1-4. Adjustable components (seats, mirrors, steering Hybrid system features..26 wheel) Hybrid system precautions ....... 31 Front seats......73 Energy monitor/consumption Second seats ...... 77 screen....... 37 Third seats ......83 Hybrid vehicle driving Head restraints ....87 tips ........
  • Page 27: Hybrid System Hybrid System Features

    1-1. Hybrid system Hybrid system features Your vehicle is a hybrid vehicle. It has characteristics different from conventional vehicles. Be sure you are closely familiar with the char- acteristics of your vehicle, and operate with care. The hybrid system combines the use of a gasoline engine and an electric motor (traction motor) according to driving conditions, improving fuel efficiency and reducing exhaust emissions.
  • Page 28 1-1. Hybrid system ■ When stopped/during start off The gasoline engine stops when the vehicle is stopped. During start off, the electric motor (traction motor) drives the vehicle. At slow speeds or when traveling down a gentle slope, the engine is stopped and the electric motor (traction motor) is used.
  • Page 29 1-1. Hybrid system ■ Regenerative braking In the following situations, kinetic energy is converted to electric energy and deceleration force can be obtained in conjunction with the recharging of the hybrid battery (traction battery). ● The accelerator pedal is released while driving with the shift position in D or B.
  • Page 30 After the 12-volt battery has discharged or has been changed or removed The gasoline engine may not stop even if the vehicle is running on the hybrid battery (traction battery). If this continues for a few days, contact your Toyota dealer.
  • Page 31 P. 32) ● The operation sound of the air conditioning system (air conditioning com- pressor, blower motor). ■ Maintenance, repair, recycling, and disposal Contact your Toyota dealer regarding maintenance, repair, recycling and dis- posal. Do not dispose of the vehicle yourself.
  • Page 32: Hybrid System Precautions

    1-1. Hybrid system Hybrid system precautions Take care when handling the hybrid system, as it contains a high voltage system (about 650V at maximum) as well as parts that become extremely hot when the hybrid system is operating. Obey the caution labels attached to the vehicle. Air conditioning compressor Hybrid battery (traction bat- tery)
  • Page 33 If the emergency shut off system activates, your vehicle will not restart. To restart the hybrid system, contact your Toyota dealer.
  • Page 34 If a warning light comes on, a warning message is displayed or the 12- volt battery is disconnected The hybrid system may not start. In that case, try to start the system again. If the “READY” indicator does not come on, contact your Toyota dealer. ■ Running out of fuel...
  • Page 35 1-1. Hybrid system CAUTION ■ High voltage precautions The vehicle has high voltage DC and AC systems as well as a 12-volt sys- tem. DC and AC high voltage is very dangerous and can cause severe burns and electric shock that may result in death or serious injury. ●...
  • Page 36 1-1. Hybrid system CAUTION ■ Road accident cautions If your vehicle is involved in an accident, observe the following precautions to reduce the risk of death or serious injury: ● Stop the vehicle in a safe place to prevent subsequent accidents. While depressing the brake pedal, apply the parking brake, shift the shift position to P and turn the hybrid system off.
  • Page 37 (traction battery). ● Do not carry large amounts of water such as water cooler bottles in the vehicle. If water spills onto the hybrid battery (traction battery), the battery may be damaged. Have the vehicle inspected by your Toyota dealer.
  • Page 38: Energy Monitor/Consumption Screen

    1-1. Hybrid system Energy monitor/consumption screen You can view the status of your hybrid system on the “Display Audio” screen or the navigation system screen. “Display Audio” screen or nav- igation system screen Energy monitor Displays the flow of energy as it changes in accordance with driving conditions.
  • Page 39 1-1. Hybrid system Condition Display When the vehicle is powered by the electric motor (traction motor) When the vehicle is powered by both the gasoline engine and the electric motor (traction motor) When the vehicle is powered by the gasoline engine...
  • Page 40 1-1. Hybrid system Condition Display When the vehicle is charging the hybrid battery (traction battery) When there is no energy flow Full Hybrid battery (traction battery) status These images are examples only, and may vary slightly from actual conditions.
  • Page 41 1-1. Hybrid system Navigation system Press “INFO”. If the “Trip information” screen is displayed, touch “Energy”. Condition Display When the vehicle is powered by the electric motor (traction motor) When the vehicle is powered by both the gasoline engine and the electric motor (traction motor) When the vehicle is powered by the gasoline engine...
  • Page 42 1-1. Hybrid system Condition Display When the vehicle is charging the hybrid battery (traction battery) When there is no energy flow Full Hybrid battery (traction battery) status These images are examples only, and may vary slightly from actual conditions.
  • Page 43 1-1. Hybrid system Trip information screen “Display Audio” Press “CAR”. If the “Energy monitor” screen is displayed, touch “Trip information”. Fuel consumption in the past 15 minutes Displays the average vehicle speed since the hybrid system was started Displays the elapsed time since the hybrid system was started Cruising range (→P.
  • Page 44 1-1. Hybrid system Navigation system Press “INFO”. If the “Energy monitor” screen is displayed, touch “Fuel consumption”. Fuel consumption in the past 15 minutes Regenerated energy in the past 15 minutes One symbol indicates 30 Wh. Up to 4 symbols are shown. Displays the average vehicle speed since the hybrid system was started...
  • Page 45 1-1. Hybrid system ■ Resetting the consumption data “Display Audio” Selecting “Clear” on the “Trip information” screen will reset the fuel con- sumption and the regenerated energy for the past 15 minutes. Selecting “Yes” on the following screen will confirm resetting of all the data. Navigation system Selecting “Clear”...
  • Page 46: Hybrid Vehicle Driving Tips

    1-1. Hybrid system Hybrid vehicle driving tips For economical and ecological driving, pay attention to the following points: ■ Using Eco drive mode When using Eco drive mode, the torque corresponding to the accelerator pedal depression amount can be generated more smoothly than it is in normal conditions.
  • Page 47 1-1. Hybrid system ■ Air conditioning on/off Switch the air conditioning ( ) to off when it is not needed. Doing so can help control excessive gasoline consumption. In summer: In high temperatures, use the recirculated air mode. Doing so will help to reduce the burden on the air conditioner and reduce fuel consumption as well.
  • Page 48: 1-2. Key Information

    1-2. Key information Keys The following keys are provided with the vehicle. Electronic keys • Operating the smart entry & start system (→P. 50) • Operating wireless remote control function (→P. 63) Mechanical keys Key number plate Using the mechanical key To take out the mechanical key, push the release button and take the key out.
  • Page 49 Keep the plate in a safe place such as your wallet, not in the vehicle. In the event that a mechanical key is lost, a new key can be made at your Toyota dealer using the key number plate. (→P. 534) ■...
  • Page 50 Take your vehicle with all the electronic keys provided with your vehicle to your Toyota dealer. ■ When a vehicle key is lost If the key remains lost, the risk of vehicle theft increases significantly. Visit your Toyota dealer immediately with all remaining electronic keys that was provided with your vehicle.
  • Page 51: 1-3. Opening, Closing And Locking The Doors

    1-3. Opening, closing and locking the doors Smart entry & start system The following operations can be performed simply by carrying the electronic key on your person, for example in your pocket. (The driver should always carry the electronic key.) Unlocks and locks the side doors (→P.
  • Page 52 1-3. Opening, closing and locking the doors Unlocking and locking the doors Front door handles Grip the handle to unlock the doors. Make sure to touch the sensor on the back of the handle. The doors cannot be unlocked for 3 seconds after the doors are locked.
  • Page 53 1-3. Opening, closing and locking the doors Back door Press the unlock button to unlock all the doors. The doors cannot be unlocked for 3 seconds after the doors are locked. Press the lock button to lock all the doors.
  • Page 54 1-3. Opening, closing and locking the doors Antenna location and effective range ■ Antenna location Antennas outside the cabin Antennas inside the cabin Antenna outside the luggage compartment...
  • Page 55 1-3. Opening, closing and locking the doors ■ Effective range (areas within which the electronic key is detected) When locking or unlocking the doors The system can be operated when the electronic key is within about 0.7 m (2.3 ft.) of either of the outside front door handle and back door opener switch.
  • Page 56 1-3. Opening, closing and locking the doors ■ Alarms and warning lights A combination of exterior and interior alarms as well as warning lights are used to prevent theft of the vehicle and accidents resulting from erroneous operation. Take appropriate measures depending on which warning light comes on.
  • Page 57 1-3. Opening, closing and locking the doors Alarm Situation Correction procedure The “POWER” switch was turned to ACCESSORY mode while the driver’s Close the driver’s door was open (or the door, or turn the driver’s door was opened “POWER” switch off while the “POWER”...
  • Page 58 1-3. Opening, closing and locking the doors ■ Conditions affecting operation The smart entry & start system, wireless remote control and immobilizer sys- tem use weak radio waves. In the following situations, the communication between the electronic key and the vehicle may be affected, preventing the smart entry &...
  • Page 59 1-3. Opening, closing and locking the doors ■ Note for the entry function ● Even when the electronic key is within the effective range (detection areas), the system may not operate properly in the following cases: • The electronic key is too close to the window or outside door handle, near the ground, or in a high place when the doors are locked or unlocked.
  • Page 60 1-3. Opening, closing and locking the doors ■ Note for locking the doors ● Touching the door lock sensor while wearing gloves may delay or prevent lock operation. Remove the gloves and touch the lock sensor again. ● When the lock operation is performed using the lock sensor, recognition signals will be shown up to two consecutive times.
  • Page 61 1-3. Opening, closing and locking the doors ■ Note for the unlocking function ● A sudden approach to the effective range or door handle may prevent the doors from being unlocked. In this case, return the door handle to the original position and check that the doors unlock before pulling the door handle again.
  • Page 62 1-3. Opening, closing and locking the doors ■ If the smart entry & start system does not operate properly ● Locking and unlocking the doors: Use the mechanical key. (→P. 535) Starting the hybrid system: →P. 536 ● ■ Electronic key battery depletion ●...
  • Page 63 (→P. 53) The radio waves may affect the operation of such devices. If necessary, the entry function can be disabled. Ask your Toyota dealer for details, such as the frequency of radio waves and timing of emitting the radio waves.
  • Page 64: Wireless Remote Control

    1-3. Opening, closing and locking the doors Wireless remote control The wireless remote control can be used to lock and unlock the vehi- cle. Locks all the doors Unlocks all the doors Sounds the alarm (press and hold) (→P. 64) ■...
  • Page 65 1-3. Opening, closing and locking the doors ■ Panic mode When is pressed for longer than about one second, an alarm will sound intermittently and the vehicle lights will flash to deter any person from trying to break into or damage your vehicle. To stop the alarm, press any button on the electronic key.
  • Page 66: Side Doors

    1-3. Opening, closing and locking the doors Side doors The vehicle can be locked and unlocked using the entry function, wireless remote control or door lock switch. ■ Entry function →P. 50 ■ Wireless remote control →P. 63 ■ Door lock switch Locks all the doors Unlocks all the doors ■...
  • Page 67 1-3. Opening, closing and locking the doors Locking the front doors from the outside without a key Move the inside lock button to the lock position. STEP Close the door while pulling the door handle. STEP The door cannot be locked if the “POWER” switch is in ACCESSORY or ON mode, or the electronic key is left inside the vehicle.
  • Page 68 1-3. Opening, closing and locking the doors ■ Using the mechanical key The doors can also be locked and unlocked with the mechanical key. (→P. 535) ■ If a wrong key is used The key cylinder rotates freely to isolate inside mechanism. ■...
  • Page 69: Back Door

    1-3. Opening, closing and locking the doors Back door The back door can be locked/unlocked and opened by the following procedures. ■ Locking and unlocking the back door Entry function →P. 50 Wireless remote control →P. 63 Door lock switch →P.
  • Page 70 1-3. Opening, closing and locking the doors ■ Luggage compartment light The luggage compartment light turns on when the back door is opened with the luggage compartment light switch on. ■ If the back door opener is inoperative The back door can be unlocked from the inside. Remove the cover.
  • Page 71 1-3. Opening, closing and locking the doors CAUTION ■ Caution while driving ● Keep the back door closed while driving. If the back door is left open, it may hit near-by objects while driving or lug- gage may be unexpectedly thrown out, causing an accident. In addition, exhaust gases may enter the vehicle, causing death or a seri- ous health hazard.
  • Page 72 1-3. Opening, closing and locking the doors CAUTION ■ Operating the back door Observe the following precautions. Failure to do so may cause parts of the body to be caught, resulting in death or serious injury. ● Remove any heavy loads, such as snow and ice, from the back door before opening it.
  • Page 73 If a bicycle carrier or similar heavy object is attached to the back door, it may fall closed again after being opened, causing someone’s hands, head or neck to be caught and injured. When installing an accessory part to the back door, using a genuine Toyota part is recommended. NOTICE ■...
  • Page 74: Adjustable Components (Seats, Mirrors, Steering Wheel) Front Seats

    1-4. Adjustable components (seats, mirrors, steering wheel) Front seats Seat position adjustment lever Seatback angle adjustment lever Vertical height adjustment lever (for driver’s side) Lumbar support adjustment switch (for driver’s side)
  • Page 75 1-4. Adjustable components (seats, mirrors, steering wheel) Flattening the seatbacks ■ Before flattening the seatbacks Stop the vehicle in a safe place. STEP Apply the parking brake firmly and shift the shift position to P. (→P. 184) → Slide the second seats as far back as possible. ( P.
  • Page 76 1-4. Adjustable components (seats, mirrors, steering wheel) CAUTION ■ Seat adjustment ● To reduce the risk of sliding under the lap belt during a collision, do not recline the seat more than necessary. If the seat is too reclined, the lap belt may slide past the hips and apply restraint forces directly to the abdomen, or your neck may contact the shoulder belt, increasing the risk of death or serious injury in the event of an accident.
  • Page 77 1-4. Adjustable components (seats, mirrors, steering wheel) CAUTION ■ After returning the seats to their upright positions Observe the following precautions. Failure to do so may result in death or serious injury. ● Gently rock the seats back and forth to ensure they are firmly in place. ●...
  • Page 78: Second Seats

    1-4. Adjustable components (seats, mirrors, steering wheel) Second seats Seatback angle adjustment lever Seat position adjustment lever Moving a second seat for third seat access Pull up the lever (either ), tilt the seatback forward, and slide the seat forward. After getting in or out of the vehi- cle, slide the seat backward and raise the seatback.
  • Page 79 1-4. Adjustable components (seats, mirrors, steering wheel) Before folding down the seatbacks Park the vehicle in a safe place. STEP Apply the parking brake firmly and shift the shift position to P. (→P. 184) Adjust the position of the front seat and the angle of the seat- STEP →...
  • Page 80 1-4. Adjustable components (seats, mirrors, steering wheel) Press the seat-folding button. STEP The seats will be folded forward. Gently rock the seats back and forth to ensure that they are securely locked. Pull the lever. STEP To return the rear seatbacks to their original positions, lift them up until they lock.
  • Page 81 1-4. Adjustable components (seats, mirrors, steering wheel) ■ Seat belt hangers Stow the seat belts of the outside seats in their seat belt hangers when not in use. CAUTION ■ When folding the seatbacks down Observe the following precautions. Failure to do so may result in death or serious injury.
  • Page 82 1-4. Adjustable components (seats, mirrors, steering wheel) CAUTION ■ Reclining adjustment ● To reduce the risk of sliding under the lap belt during a collision, do not recline the seat more than necessary. If the seat is too reclined, the lap belt may slide past the hips and apply restraint forces directly to the abdomen, or your neck may contact the shoulder belt, increasing the risk of death or serious injury in the event of an accident.
  • Page 83 1-4. Adjustable components (seats, mirrors, steering wheel) NOTICE ■ When the third seat is folded forward To prevent damage to the seats, avoid making contact with the second seat when adjusting the third seat.
  • Page 84: Third Seats

    1-4. Adjustable components (seats, mirrors, steering wheel) Third seats Seatback angle adjustment lever Before folding down the seatbacks Park the vehicle in a safe place. STEP (→P. 184) Apply the parking brake firmly and shift the shift position to P. Adjust the position of the second seats and the angle of the STEP seatback.
  • Page 85 1-4. Adjustable components (seats, mirrors, steering wheel) Folding down the seatbacks Pull the seatback angle adjust- ment lever. To return the rear seatbacks to their original positions, lift them up until they lock. ■ Seat belt hangers Stow the seat belts in their seat belt hang- ers when not in use.
  • Page 86 1-4. Adjustable components (seats, mirrors, steering wheel) ■ Seatback strap The folded third seat can be raised from the luggage compartment. CAUTION ■ When folding the seatbacks down Observe the following precautions. Failure to do so may result in death or serious injury.
  • Page 87 1-4. Adjustable components (seats, mirrors, steering wheel) CAUTION ■ Reclining adjustment ● To reduce the risk of sliding under the lap belt during a collision, do not recline the seat more than necessary. If the seat is too reclined, the lap belt may slide past the hips and apply restraint forces directly to the abdomen, or your neck may contact the shoulder belt, increasing the risk of death or serious injury in the event of an accident.
  • Page 88: Head Restraints

    1-4. Adjustable components (seats, mirrors, steering wheel) Head restraints Head restraints are provided for all seats. Front and second seats Pull the head restraints up. Down Press hold lock release button when lowering the head restraint. Lock release button Third seats Pull the head restraints up.
  • Page 89 1-4. Adjustable components (seats, mirrors, steering wheel) ■ Removing the head restraints Front and seconds seats Pull the head restraint up while pressing the lock release button. Lock release button Third seats Pull the head restraint up while pressing the lock release button. Lock release button ■...
  • Page 90 1-4. Adjustable components (seats, mirrors, steering wheel) ■ Adjusting the height of the head restraints (front seats) Make sure that the head restraints are adjusted so that the center of the head restraint is closest to the top of your ears. ■...
  • Page 91: Seat Belts

    1-4. Adjustable components (seats, mirrors, steering wheel) Seat belts Make sure that all occupants are wearing their seat belts before driv- ing the vehicle. ■ Correct use of the seat belts ● Extend the shoulder belt so that it comes fully over the shoulder, does come into contact with the...
  • Page 92 1-4. Adjustable components (seats, mirrors, steering wheel) ■ Fastening the seat belt (second center seat) Press the plate to release, and STEP pull out the seat belt. Connect by inserting plate B STEP Plate B into buckle B until a click sound is heard.
  • Page 93 1-4. Adjustable components (seats, mirrors, steering wheel) ■ Releasing the seat belt (second center seat) Press the release button on STEP buckle A and release the belt. Release button Buckle A Use plate A etc. to push the STEP button on buckle B, and Plate B uncouple plate B.
  • Page 94 1-4. Adjustable components (seats, mirrors, steering wheel) ■ Adjusting the seat belt shoulder anchor height (front seats) Push the seat belt shoulder anchor down while pressing the release button. Push the seat belt shoulder anchor up. Move the height adjuster up and down as needed until you hear a click.
  • Page 95 1-4. Adjustable components (seats, mirrors, steering wheel) ■ Emergency locking retractor (ELR) The retractor will lock the belt during a sudden stop or on impact. It may also lock if you lean forward too quickly. A slow, easy motion will allow the belt to extend so that you can move around fully.
  • Page 96 Each seat belt should be used by one person only. Do not use a seat belt for more than one person at once, including children. ● Toyota recommends that children be seated in the rear seat and always use a seat belt and/or an appropriate child restraint system. ●...
  • Page 97 ● Ensure that the belt and plate are locked and the belt is not twisted. If the seat belt does not function correctly, immediately contact your Toyota dealer. ● Replace the seat assembly, including the belts, if your vehicle has been involved in a serious accident, even if there’s no obvious damage.
  • Page 98: Steering Wheel

    1-4. Adjustable components (seats, mirrors, steering wheel) Steering wheel The steering wheel can be adjusted to a comfortable position. Hold the steering wheel and STEP push the lever down. Adjust to the ideal position by STEP moving the steering wheel horizontally and vertically.
  • Page 99: Inside Rear View Mirror

    1-4. Adjustable components (seats, mirrors, steering wheel) Inside rear view mirror Glare from the headlights of vehicles behind can be reduced by using the following functions: Normal position Anti-glare position Adjusting the height of rear view mirror Adjust the height of the rear view mirror by moving it up and down.
  • Page 100: Outside Rear View Mirrors

    1-4. Adjustable components (seats, mirrors, steering wheel) Outside rear view mirrors Mirror angle can be adjusted using the switch. To select a mirror to adjust, STEP press the switch. Left Right To adjust the mirror, press the STEP switch. Right Down Left Folding the mirrors...
  • Page 101 1-4. Adjustable components (seats, mirrors, steering wheel) ■ Mirror angle can be adjusted when The “POWER” switch is in ACCESSORY or ON mode. ■ When the mirrors are fogged up Turn on the mirror defoggers to defog the mirrors. (→P. 262) CAUTION ■...
  • Page 102: 1-5. Opening And Closing The Windows

    1-5. Opening and closing the windows Power windows The power windows can be opened and closed using the switches. Operating the switch moves the windows as follows: Closing One-touch closing Opening One-touch opening : Pushing the switch in the opposite direction will stop win- dow travel partway.
  • Page 103 If you release the switch while the window is moving, start again from the beginning. If the window continues to close but then re-open slightly even after perform- ing the above procedure correctly, have the vehicle inspected by your Toyota dealer.
  • Page 104 1-5. Opening and closing the windows CAUTION ■ Closing the windows Observe the following precautions. Failing to do so may result in death or serious injury. ● Check to make sure that all passengers do not have any part of their body in a position where it could be caught when a window is being operated.
  • Page 105: Refueling Opening The Fuel Tank Cap

    1-6. Refueling Opening the fuel tank cap Perform the following steps to open the fuel tank cap: ■ Before refueling the vehicle Turn the “POWER” switch off and close all the doors and win- dows. ■ Opening the fuel tank cap Pull up the opener to open the STEP fuel filler door.
  • Page 106 1-6. Refueling Closing the fuel tank cap After refueling, turn the fuel tank cap until you hear a click. Once the cap is released, it will turn slightly in the opposite direction. ■ Fuel types Premium unleaded gasoline, Research Octane Number of 95 or higher ■...
  • Page 107 ■ When replacing the fuel tank cap Do not use anything but a genuine Toyota fuel tank cap designed for your vehicle. Doing so may cause a fire or other incident which may result in death or serious injury.
  • Page 108 1-6. Refueling NOTICE ■ Refueling Do not spill fuel during refueling. Doing so may damage the vehicle, such as causing the emission control system to operate abnormally or damaging fuel system components or the vehicle’s painted surface.
  • Page 109: 1-7. Theft Deterrent System

    1-7. Theft deterrent system Immobilizer system The vehicle’s keys have built-in transponder chips that prevent the hybrid system from starting if a key has not been previously regis- tered in the vehicle’s on-board computer. Never leave the keys inside the vehicle when you leave the vehicle. The indicator light flashes after the “POWER”...
  • Page 110: 1-8. Safety Information

    1-8. Safety information Correct driving posture Drive with a good posture as follows: Sit upright and well back in the seat. (→P. 73) Adjust the position of the seat forward or backward to ensure the pedals can be reached easily depressed to the extent required.
  • Page 111 1-8. Safety information CAUTION ■ While driving ● Do not adjust the position of the driver’s seat. Doing so could cause the driver to lose control of the vehicle. ● Do not place a cushion between the driver or passenger and the seatback. A cushion may prevent correct posture from being achieved, and reduce the effectiveness of the seat belt and head restraint, increasing the risk of death or serious injury to the driver or passenger.
  • Page 112: Srs Airbags

    1-8. Safety information SRS airbags The SRS airbags inflate when the vehicle is subjected to certain types of severe impacts that may cause significant injury to the occupants. They work together with the seat belts to help reduce the risk of death or serious injury. SRS front airbags SRS driver airbag/front passenger airbag Can help protect the head and chest of the driver and front pas-...
  • Page 113 1-8. Safety information SRS side and curtain shield airbags SRS side airbags Can help protect the torso of the front seat occupants SRS curtain shield airbags Can help protect primarily the head of occupants in the outer seats...
  • Page 114 1-8. Safety information SRS airbag system components Front impact sensors Side airbags Front passenger airbag Curtain shield airbags SRS warning light Side impact sensors (rear) Side impact sensors (front) Driver airbag Seat belt pretensioners and Driver’s knee airbag force limiters Airbag sensor assembly The main SRS airbag system components are shown above.
  • Page 115 1-8. Safety information ■ If the SRS airbags deploy (inflate) ● Bruising and slight abrasions may result from contact with a deploying (inflating) SRS airbag. ● A loud noise and white powder will be emitted. ● Parts of the airbag module (steering wheel hub, airbag cover and inflator) as well as the front seats, parts of the front and rear pillars, and roof side rails, may be hot for several minutes.
  • Page 116 1-8. Safety information ■ SRS airbag deployment conditions (SRS side and curtain shield air- bags) The SRS side and curtain shield airbags will deploy in the event of an impact that exceeds the set threshold level (the level of force corresponding to the impact force produced by an approximately 1500 kg [3300 lb.] vehicle collid- ing with the vehicle cabin from a direction perpendicular to the vehicle orien- tation at an approximate speed of 20 - 30 km/h [12 - 18 mph]).
  • Page 117 1-8. Safety information ■ Types of collisions that may not deploy the SRS airbags (SRS side and curtain shield airbags) The SRS side and curtain shield airbags may not activate if the vehicle is subjected to a collision from the side at certain angles, or a collision to the side of the vehicle body other than the passenger compartment.
  • Page 118 1-8. Safety information ■ When to contact your Toyota dealer In the following cases, contact your Toyota dealer as soon as possible. ● Any of the SRS airbags has been inflated. ● The front of the vehicle is damaged or...
  • Page 119 1-8. Safety information CAUTION ■ SRS airbag precautions Observe the following precautions regarding the SRS airbags. Failure to do so may cause death or serious injury. ● The driver and all passengers in the vehicle must wear their seat belts properly.
  • Page 120 An infant or child who is too small to use a seat belt should be properly secured using a child restraint sys- tem. Toyota strongly recommends that all infants and children be placed in the rear seats of the vehicle and properly restrained. The rear seats are...
  • Page 121 1-8. Safety information CAUTION ■ SRS airbag precautions ● Do not sit on the edge of the seat or lean against the dashboard. ● Do not allow a child to stand in front of the SRS front passenger airbag unit or sit on the knees of a front passenger.
  • Page 122 1-8. Safety information CAUTION ■ SRS airbag precautions ● Do not attach anything to or lean any- thing against areas such as the dash- board, steering wheel pad and lower portion of the instrument panel. These items can become projectiles when the SRS driver, front passenger and knee airbags deploy.
  • Page 123 Wash off any residue as soon as possible to prevent skin irritation. ● If the areas where the SRS airbags are stored, such as the steering wheel pad and front and rear pillar garnishes, are damaged or cracked, have them replaced by your Toyota dealer.
  • Page 124 Modification and disposal of SRS airbag system components Do not dispose of your vehicle or perform any of the following modifications without consulting your Toyota dealer. The SRS airbags may malfunction or deploy (inflate) accidentally, causing death or serious injury.
  • Page 125: Child Restraint Systems

    (→P. 133) ● If child restraint system regulations exist in the country where you reside, please contact your Toyota dealer. ● Toyota recommends that you use a child restraint system which conforms to the regulation ECE No.44. Types of child restraints Child restraint systems are classified into the following 5 groups according to the regulation “ECE No.44”.
  • Page 126 1-8. Safety information Baby seat (infant seat) Equal to Group 0 and 0 of “ECE No.44” Child seat (convertible seat) Equal to Group 0 and I of “ECE No.44” Junior seat (booster seat) Equal to Group II and III of “ECE No.44”...
  • Page 127 1-8. Safety information Child restraint system suitability for various seating positions Information provided in the table shows your child restraint system suitability for various seating positions. Seating Second seat Front Third position Mass passenger seat seat Outside Center groups Up to 10 kg (22 lb.) Never put (0 - 9 months)
  • Page 128 FIXATION, BASE PLATFORM” (0 to 13 kg [0 to 28 lb.]) approved for the use in this mass group. L2: Suitable for “TOYOTA KID FIX” (15 to 36 kg [34 to 79 lb.]) approved for the use in this mass group.
  • Page 129 1-8. Safety information Child restraint system suitability for various seating positions (with ISOFIX rigid anchor) Information provided in the table shows your child restraint system suitability for various seating positions. Vehicle ISOFIX positions Mass groups Size class Fixture Second outside seat ISO/L1 Carrycot ISO/L2...
  • Page 130 IUF: Suitable for ISOFIX forward-facing child restraints systems of universal category approved for the use in this mass group. Toyota recommend to use “TOYOTA MIDI” approved for the use in this mass group. When using this child restraint system, adjust the support leg to 6th lock position from 1st lock position where the support leg is shortest position.
  • Page 131 ● Toyota strongly urges the use of a proper child restraint system that con- forms to the size of the child, installed on the rear seat. According to acci- dent statistics, the child is safer when properly restrained in the rear seat than in the front seat.
  • Page 132 1-8. Safety information CAUTION ■ Child restraint precautions ● Never install a rear-facing child restraint system on the front passenger seat. In the event of an accident, the force of the rapid inflation of the front passenger airbag can cause death or serious injury to the child if the rear- facing child restraint system is installed on the front passenger seat.
  • Page 133 1-8. Safety information CAUTION ■ When children are in the vehicle Do not allow children to play with the seat belt. If the seat belt becomes twisted around a child’s neck, it may lead to choking or other serious injuries that could result in death.
  • Page 134: Installing Child Restraints

    1-8. Safety information Installing child restraints Follow the child restraint system manufacturer’s instructions. Firmly secure the child restraints using a seat belt or an ISOFIX rigid anchor. Attach the top strap when installing a child restraint system. Seat belts equipped with a child restraint locking mecha- nism (ALR/ELR belts on sec- ond outside seats)
  • Page 135 1-8. Safety information ISOFIX rigid anchors (ISOFIX child restraint system) Lower anchors are provided for second outside seats. (Tags displaying the location of the anchors are attached to the seats.) Child restraint anchor fitting Anchor fittings are provided for each second seats.
  • Page 136 1-8. Safety information Installing child restraints using a seat belt (second outside seats) Rear-facing  Baby seat (infant seat)/child seat (convertible ■ seat) Adjusting the angle of the seat- STEP back. While pulling the lever (either ), fold the seatback forward and then back to the 1st lock position (most upright position) until it locks into place.
  • Page 137 1-8. Safety information Run the seat belt through the STEP child restraint system and insert the plate into the buckle. Make sure that the belt is not twisted. Fully extend the shoulder belt STEP and then allow it to retract slightly in order to activate the ALR lock mode.
  • Page 138 1-8. Safety information Latch the hook of the top strap STEP onto the anchor brackets. (→P. 154) Make sure the seat belt is tightly secured, and that there is not slack in the belt. Forward-facing  Child seat (convertible seat) ■...
  • Page 139 1-8. Safety information Remove the head restraint. (→P. 87) STEP Place the child restraint system STEP on the seat facing the front of the vehicle. Run the seat belt through the STEP child restraint system and insert the plate into the buckle. Make sure that the belt is not twisted.
  • Page 140 1-8. Safety information Fully extend the shoulder belt STEP and then allow it to retract slightly into the ALR lock mode. Lock mode allows the seat belt to retract only. While pushing the child restraint STEP system into the seat, allow the shoulder belt to retract until the child restraint system is securely in place.
  • Page 141 1-8. Safety information ■ Junior seat (booster seat) Adjusting the angle of the seat- STEP back. While pulling the lever (either ), fold the seatback forward and then back to the 1st lock position (most upright position) until it locks into place. Adjust the seatback to the 5th lock position.
  • Page 142 1-8. Safety information Sit the child in the child restraint STEP system. Fit the seat belt to the child restraint system according to the manufacturer’s instruc- tions and insert the plate into the buckle. Make sure that the belt is not twisted.
  • Page 143 1-8. Safety information Installing child restraints using a seat belt (second center seat) Rear-facing  Baby seat (infant seat)/child seat (convertible ■ seat) Adjusting the angle of the seat- STEP back. While pulling the lever, fold the seatback forward and then back to the 1st lock position (most upright position) until it locks into place.
  • Page 144 1-8. Safety information Run the seat belt through the STEP child restraint system and insert the plate into the buckle. Make sure that the belt is not twisted. Keep the lap portion of the belt tight. Follow the directions given in the child restraint system installation manual and fix the child restraint system securely in place.
  • Page 145 1-8. Safety information Forward-facing  Child seat (convertible seat) ■ Adjusting the angle of the seat- STEP back. While pulling the lever, fold the seatback forward and then back to the 1st lock position (most upright position) until it locks into place.
  • Page 146 1-8. Safety information Run the seat belt through the STEP child restraint system and insert the plate into the buckle. Make sure that the belt is not twisted. Keep the lap portion of the belt tight. Follow the directions given in the child restraint system installation manual and fix the child restraint system securely in place.
  • Page 147 1-8. Safety information ■ Junior seat (booster seat) Adjusting the angle of the seat- STEP back. While pulling the lever, fold the seatback forward and then back to the 1st lock position (most upright position) until it locks into place. Adjust the seatback to the 5th lock position.
  • Page 148 1-8. Safety information Sit the child in the child restraint STEP system. Fit the seat belt to the child restraint system according to the manufacturer’s instruc- tions and insert the plate into the buckle. Make sure that the belt is not twisted.
  • Page 149 1-8. Safety information Installing child restraints using a seat belt (except for second seats) Rear-facing  Baby seat/child seat ■ Third seat only: Adjusting the STEP angle of the seatback. Adjust the second seat forward so that it does not interfere with the child restraint system.
  • Page 150 1-8. Safety information If your child restraint system is not equipped with a lock-off (a seat belt locking feature), secure the child restraint system using a locking clip. (→P. 154) After installing the child restraint system, rock it back and forth to ensure that it is installed securely.
  • Page 151 1-8. Safety information Run the seat belt through the STEP child restraint system and insert the plate into the buckle. Make sure that the belt is not twisted. Keep the lap portion of the belt tight. Follow the directions given in the child restraint system installation manual and fix the child restraint system securely in place.
  • Page 152 1-8. Safety information ■ Junior seat Third seat only: Adjusting the STEP angle of the seatback. Adjust the second seat forward so that it does not interfere with the child restraint system. While pull- ing the lever, fold the seatback forward and then back to the 1st lock position (most upright posi- tion) until it locks into place.
  • Page 153 1-8. Safety information Removing a child restraint system installed with a seat belt Press the buckle release button and fully retract the seat belt. Installation with ISOFIX rigid anchor (ISOFIX child restraint sys- tem) (second outside seats only) Adjusting the angle of the seat- STEP back.
  • Page 154 1-8. Safety information Open the fasteners on the lower STEP part of the seatback. Check the positions of the exclu- STEP sive fixing bars, and install the child restraint system to the seat. The bars are installed in the clearance between the seat cush- ion and seatback.
  • Page 155 You need a locking clip to install the child restraint system. Follow the instructions provided by the manufacturer of the system. If your child restraint system does not provide a locking clip, you can purchase the fol- lowing item from your Toyota dealer. Locking clip for child restraint system (Part No. 73119-22010)
  • Page 156 1-8. Safety information CAUTION ■ When installing a junior (booster) seat Do not fully extend the shoulder belt to prevent the belt from going to ALR lock mode: (→P. 94) ALR mode causes the belt to tighten only which could cause injury or dis- comfort to the child.
  • Page 157 1-8. Safety information CAUTION ■ When installing a child restraint system ● Extreme Hazard! Do not use a rear- ward facing child restraint on a seat protected by an airbag in front of it! This is because the force of the rapid infla- tion of the front passenger airbag can cause death or serious injury to the child.
  • Page 158 When installing a child restraint system ● If child restraint system regulations exist in the country where you reside, please contact your Toyota dealer for the child restraint system informa- tion. ● If other second seats interfere with the child restraint system when install- ing a child restraint system in the second seat, adjust the seat cushions to the same position and align the seatbacks at the same angle.
  • Page 159 1-8. Safety information...
  • Page 160: When Driving

    When driving 2-1. Driving procedures 2-2. Instrument cluster Driving the vehicle .... 160 Gauges and meters ..193 Power (ignition) switch..171 Indicators and warning lights ....... 203 EV drive mode ....178 Head-up display....206 Hybrid transmission ..181 Turn signal lever ....
  • Page 161: Driving Procedures Driving The Vehicle

    2-1. Driving procedures Driving the vehicle The following procedures should be observed to ensure safe driv- ing: ■ Starting the hybrid system →P. 171 ■ Driving With the brake pedal depressed, shift the shift position to D. STEP (→P. 181) Check that the shift position indicator shows D.
  • Page 162 ■ Breaking in your new Toyota To extend the life of the vehicle, observing the following precautions is rec- ommended: ●...
  • Page 163 2-1. Driving procedures ■ Operating your vehicle in a foreign country Comply with the relevant vehicle registration laws and confirm the availability of the correct fuel. (→P. 554) ■ For efficient use ● Shift the shift position to D when driving. In the N position, the gasoline engine operates but electricity cannot be generated.
  • Page 164 If the smell of exhaust is noticed inside the vehicle, open the windows and check that the back door is closed. Large amounts of exhaust in the vehi- cle can cause driver drowsiness and an accident, resulting in death or a serious health hazard. Have the vehicle inspected by your Toyota dealer immediately.
  • Page 165 2-1. Driving procedures CAUTION ● Do not shift the shift position to P while the vehicle is moving. Doing so can damage the transmission and may result in a loss of vehicle control. ● Do not shift the shift position to R while the vehicle is moving forward. Doing so can damage the transmission and may result in a loss of vehicle control.
  • Page 166 ■ If you hear a squealing or scraping noise (brake pad wear indicators) Have your Toyota dealer check and replace the brake pads as soon as pos- sible. Rotor damage may result if the pads are not replaced when needed.
  • Page 167 2-1. Driving procedures CAUTION ■ When the vehicle is stopped ● Do not depress the accelerator pedal unnecessarily. If the vehicle is in any shift position other than P or N, the vehicle may accelerate suddenly and unexpectedly, causing an accident. ●...
  • Page 168 2-1. Driving procedures CAUTION ● Do not leave glasses, cigarette lighters, spray cans, or soft drink cans in the vehicle when it is in the sun. Doing so may result in the following: • Gas may leak from a cigarette lighter or spray can, and may lead to a fire.
  • Page 169 The exhaust system should be checked occasionally. If there is a hole or crack caused by corrosion, damage to a joint or abnormal exhaust noise, be sure to have the vehicle inspected and repaired by your Toyota dealer. Failure to do so may allow exhaust gases to enter the vehicle, resulting in death or a serious health hazard.
  • Page 170 2-1. Driving procedures NOTICE ■ When driving the vehicle ● Do not depress the accelerator and brake pedals at the same time during driving, as this may restrain driving torque. ● Do not use the accelerator pedal or depress the accelerator and brake pedals at the same time to hold the vehicle on a hill.
  • Page 171 Short in electrical components ● Engine damage caused by water immersion In the event that you drive on a flooded road and the vehicle is flooded, be sure to have your Toyota dealer check the following: ● Brake function ●...
  • Page 172: Power (Ignition) Switch

    2-1. Driving procedures Power (ignition) switch Performing the following operations when carrying the electronic key on your person starts the hybrid system or changes “POWER” switch modes. ■ Starting the hybrid system Check that the parking brake is set. STEP Firmly depress the brake pedal.
  • Page 173 2-1. Driving procedures Check that the “READY” indicator is on. STEP If the “READY” indicator changes from a flashing light to a solid light and the buzzer sounds, the hybrid system is starting nor- mally. The vehicle will not move when the “READY” indicator is off. The vehicle can move when the “READY”...
  • Page 174 2-1. Driving procedures ■ Changing “POWER” switch modes Modes can be changed by pressing the “POWER” switch with the brake pedal released. (The mode changes each time the switch is pressed.) The emergency flashers can be used. ACCESSORY mode Some electrical components such as the audio system can be used.
  • Page 175 2-1. Driving procedures ■ Auto power off function If the vehicle is left in ACCESSORY mode for more than 20 minutes or ON mode (the hybrid system is not operating) for more than an hour with the shift position in P, the “POWER” switch will automatically turn off. However, this function cannot entirely prevent the 12-volt battery from discharging.
  • Page 176 If the “READY” indicator does not come on If the “READY” indicator does not come on when you press the “POWER” switch with the shift position in P and the brake pedal depressed, contact your Toyota dealer immediately. ■ If the hybrid system is malfunctioning →P.
  • Page 177 When the P position control system malfunctions The “POWER” switch will not be able to be turned off. In such a case, the switch can be turned off after applying the parking brake. Have the vehicle inspected by your Toyota dealer immediately. ■ Meter display When the “POWER”...
  • Page 178 “POWER” switch is off. ■ Symptoms indicating a malfunction with the “POWER” switch If the “POWER” switch seems to be operating somewhat differently than usual, such as the switch sticking slightly, there may be a malfunction. Con- tact your Toyota dealer immediately.
  • Page 179: Ev Drive Mode

    2-1. Driving procedures EV drive mode In EV drive mode, the electric motor (traction motor), powered by the hybrid battery (traction battery), is used to drive the vehicle. This mode allows you to drive in residential areas late at night, or in indoor parking lots etc.
  • Page 180 2-1. Driving procedures ■ Situations in which EV drive mode cannot be turned on It may not be possible to turn EV drive mode on in the following situations. If it cannot be turned on, a buzzer will sound to inform the driver. ●...
  • Page 181 ■ Fuel economy PRIUS v is designed to achieve the best possible fuel economy during nor- mal driving (using the gasoline engine and electric motor [traction motor]). Driving in EV drive mode more than necessary may lower fuel economy.
  • Page 182: Hybrid Transmission

    2-1. Driving procedures Hybrid transmission Select a shift position appropriate for the driving conditions. ■ Shifting the shift lever Shift lever Operate the shift lever gently and ensure correct shifting operation. When shifting to the D or R positions, move the shift lever along the shift gate.
  • Page 183 2-1. Driving procedures Shift position indicator The position of the frame on the shift position indicator changes in accordance with the current shift position. When any shift position other than D or B is selected, the arrow toward B and B position indicator disappear from the shift position indicator. When selecting the shift position, make sure that the shift position has been changed to the desired position by checking the shift position indica- tor provided on the instrument cluster.
  • Page 184 2-1. Driving procedures ■ Selecting a driving mode The following modes can be selected to suit driving conditions: Eco drive mode Suitable for improving the fuel economy, because the torque cor- responding to the accelerator pedal depression amount can be generated more smoothly than it is in normal conditions and the operation of the air conditioning system (heating/cooling) will be minimized.
  • Page 185 2-1. Driving procedures P position switch ■ When shifting the shift position to P Fully stop the vehicle and set the parking brake, and then press the P position switch. When shift position changed to P, the indicator comes Check that the P position is illumi- nated on the shift position indica- tor.
  • Page 186 2-1. Driving procedures ■ Operation of the air conditioning system in Eco drive mode Eco drive mode controls the heating/cooling operations and fan speed of the air conditioning system to enhance fuel efficiency. (→P. 183) To improve air conditioning performance, adjust the fan speed or turn off Eco drive mode. ■...
  • Page 187 2-1. Driving procedures ● Situations where the shift position will automatically change to N: • When the P position switch is pressed while the vehicle is running. • When an attempt is made to select the R position by moving the shift lever when the vehicle is moving forward.
  • Page 188 2-1. Driving procedures ■ About engine braking When shift position B is selected, releasing the accelerator pedal will apply engine braking. ● When the vehicle is driven at high speeds, compared to ordinary gaso- line-fueled vehicles, the engine braking deceleration is felt less than that of other vehicles.
  • Page 189 ■ For the shift lever Do not remove the shift lever knob or use anything but a genuine Toyota shift lever knob. Also, do not hang anything on the shift lever. Doing so could prevent the shift lever from returning to position, causing unexpected accidents to occur when the vehicle is in motion.
  • Page 190 If any of the following situations occurs, P position control system malfunc- tions are possible. Immediately stop the vehicle in a safe place on level ground, apply the park- ing brake, and then contact your Toyota dealer. ● When the “WHEN PARKING, APPLY PARKING BRAKE SECURELY”...
  • Page 191: Turn Signal Lever

    2-1. Driving procedures Turn signal lever The turn signal lever can be used to show the following intention of the driver: Left turn Right turn Lane change to the left (push and hold the lever partway) The left hand signals will flash until you release the lever.
  • Page 192: Parking Brake

    2-1. Driving procedures Parking brake To set the parking brake, fully depress the parking brake pedal with your left foot while depressing the brake pedal with your right foot. (Depressing the pedal again releases the parking brake.) ■ Parking brake engaged warning buzzer →P.
  • Page 193: Horn

    2-1. Driving procedures Horn To sound the horn, press on or close to the mark. ■ After adjusting the steering wheel Make sure that the steering wheel is securely locked. The horn may not sound if the steering wheel is not securely locked. (→P.
  • Page 194: Instrument Cluster Gauges And Meters

    2-2. Instrument cluster Gauges and meters The following gauges and meters and display illuminate when the “POWER” switch is in ON mode: Clock →P. 394 Odometer and trip meter display Odometer: Displays the total distance that the vehicle has been driven.
  • Page 195 2-2. Instrument cluster Hybrid battery (traction battery) status The amount of charge remaining in the hybrid battery (traction battery) is shown by 8 bars. Hybrid System Indicator Hybrid System Indicator represents the hybrid system power output and regenerative charging. Speedometer Displays the vehicle speed.
  • Page 196 2-2. Instrument cluster Changing the display Switches between odometer and trip meter displays. When the trip meter is displayed, pressing and holding the “TRIP” button will reset the trip meter. Switching the trip information display Items displayed can be switched by pressing the “DISP”...
  • Page 197 2-2. Instrument cluster Trip information display ■ Current fuel consumption Displays the instant fuel consumption. ■ Average fuel consumption The average fuel consumption is displayed on both the odometer and the trip meter. • While the odometer is being displayed, or when the odometer/trip meter are not being displayed, the average fuel consumption since the hybrid system was started will be...
  • Page 198 2-2. Instrument cluster ■ Cruising range Displays the estimated maximum distance that can be driven with the quantity of fuel remain- ing. • This distance is computed based on your average fuel consumption. As a result, the actual distance that can be driven may differ from that displayed.
  • Page 199 2-2. Instrument cluster Hybrid System Indicator Hybrid System Indicator displays the hybrid system operating condi- tion and provides Eco-friendly driving assistance in accordance with the driving conditions and the acceleration. ■ Names and meaning of each icons Eco Driving Indicator Light Turns on when the vehicle is driven in Eco-friendly.
  • Page 200 2-2. Instrument cluster As shown below, the driving conditions of the vehicle can be con- firmed by checking the status of the indicator. Hybrid System Indicator status Display Charge area: Shows regenerative charging. (→P. 27) Eco area: Shows that the vehicle is driven in Eco-friendly. Hybrid Eco area: Shows that gasoline engine power is not being used very often.
  • Page 201 2-2. Instrument cluster Changing Hybrid System Indicator settings The items displayed on Hybrid System Indicator can be changed by operating the “DISP” button. Stop the vehicle in a place in which the operation can be safely carried out, apply the parking brake, and shift the shift position to P.
  • Page 202 2-2. Instrument cluster Press and hold the “DISP” button for 1 second or more to STEP complete the setup. If setup is not completed by pressing and holding the “DISP” button for 1 second or more, or if nothing is operated within approximately 10 seconds, the screen will return and the settings will be lost.
  • Page 203 2-2. Instrument cluster ■ Engine speed On hybrid vehicles, engine speed is precisely controlled in order to help improve fuel efficiency and reduce exhaust emissions etc. There are times when the engine speed that is displayed may differ even when vehicle operation and driving conditions are the same. ■...
  • Page 204: Indicators And Warning Lights

    2-2. Instrument cluster Indicators and warning lights The indicator and warning lights on the instrument cluster inform the driver of the status of the vehicle’s various systems. Instrument cluster ■ Indicators The indicators inform the driver of the operating state of the vehicle’s various systems.
  • Page 205 Have the vehicle inspected by your Toyota dealer. : The light flashes to indicate that the system is operating.
  • Page 206 Have the vehicle inspected by your Toyota dealer immediately if this occurs.
  • Page 207: Head-Up Display

    2-2. Instrument cluster Head-up display The head-up display can be used to project vehicle speed and other information onto the windshield. Head-up display Display brightness will change automatically according to the brightness of the surrounding area. “HUD” (Head-up display) switch “SET”...
  • Page 208 2-2. Instrument cluster Switching the head-up display On/off When on, the indicator light on the “HUD” switch comes on. Touch tracer display When the audio control switches, climate control switches, “DISP” button or “TRIP” button of the steering wheel are touched, the touch tracer display will appear in front of the display, with the touched button highlighted to...
  • Page 209 2-2. Instrument cluster Turn-by-turn navigation display (if equipped) When approaching an intersec- tion while the navigation system is giving route guidance, an arrow will automatically be dis- played on the head-up display to indicate the direction of travel. At one of the following distances from the intersection, the guid- ance display will be shown and the distance to the intersection...
  • Page 210 2-2. Instrument cluster Setting up the display ■ Setting the brightness The brightness of the display is automatically adjusted in accor- dance with the brightness of the surrounding environment. How- ever, the brightness can also be manually adjusted in 5 stages. Brighter Darker The brightness can be manually...
  • Page 211 2-2. Instrument cluster Customizing the display The following display can be shown or hidden. ● Turn-by-turn navigation display (if equipped) ● Touch tracer display ● Temperature display which is set by the steering switches. Press and hold the “SET” switch. STEP Customization can be performed when the head-up display is on...
  • Page 212 Press and hold the “SET” switch. STEP ■ System check display After switching the “POWER” switch to ON mode, “welcome to PRIUS v” is displayed while system operation is checked. When the system check is complete, the normal screen will return. ■...
  • Page 213 2-2. Instrument cluster CAUTION ■ Before using the head-up display Check that the position and brightness of the head-up display image does not interfere with safe driving. Incorrect adjustment of the image’s position or brightness may obstruct the driver’s view and lead to an accident, resulting in death or serious injury.
  • Page 214: 2-3. Operating The Lights And Windshield Wipers

    2-3. Operating the lights and windshield wipers Headlight switch The headlights can be operated manually or automatically. Turning the end of the lever turns on the lights as follows: The daytime running lights turn on. front position lights, tail, license plate and instrument panel lights turn on.
  • Page 215 2-3. Operating the lights and windshield wipers Turning on the high beam headlights With the headlights on, push the lever away from you to turn on the high beams. Pull the lever toward you to the center position to turn the high beams off.
  • Page 216 2-3. Operating the lights and windshield wipers ■ Guide to dial settings Occupancy and luggage load conditions Dial position Occupants Luggage load Driver None Driver and front None passenger All seats occupied None All seats occupied Full luggage loading Driver Full luggage loading Driver and front passenger.
  • Page 217 2-3. Operating the lights and windshield wipers ■ Automatic light off system ● When the light switch is in the position: The headlights turn off automatically if the “POWER” switch is turned to ACCESSORY mode or OFF. ● When the light switch is in the AUTO position: The headlights and all lights turn off automatically if the “POWER”...
  • Page 218: Fog Light Switch

    2-3. Operating the lights and windshield wipers Fog light switch The fog lights secure excellent visibility in difficult driving condi- tions, such as in rain and fog. Turns the front and rear fog lights off Turns the front fog lights on Turns both front and rear fog lights on Releasing the switch returns...
  • Page 219: Windshield Wipers And Washer

    2-3. Operating the lights and windshield wipers Windshield wipers and washer The wiper operation is selected by moving the lever as follows. When intermittent windshield wiper operation is selected, wiper intervals can be also adjusted. Intermittent wiper operation Low speed wiper operation High speed wiper operation Temporary operation...
  • Page 220 2-3. Operating the lights and windshield wipers Decreases the intermittent windshield wiper frequency Increases the intermittent windshield wiper frequency Washer/wiper dual opera- tion Wipers operate automatically. ■ The windshield wipers and washer can be operated when The “POWER” switch is in ON mode. ■...
  • Page 221 Do not operate the switch continually as the washer fluid pump may over- heat. ■ When a nozzle becomes blocked In this case, contact your Toyota dealer. Do not try to clear it with a pin or other object. The nozzle will be damaged. ■ To prevent 12-volt battery discharge Do not leave the wipers on longer than necessary when the hybrid system is off.
  • Page 222: Rear Window Wiper And Washer

    2-3. Operating the lights and windshield wipers Rear window wiper and washer Turning the end of the lever turns on the rear window wiper and washer as follows: Intermittent window wiper operation Normal window wiper oper- ation Washer/wiper dual opera- tion Washer/wiper dual opera- tion...
  • Page 223 2-3. Operating the lights and windshield wipers ■ The rear window wiper and washer can be operated when The “POWER” switch is in ON mode. ■ If no washer fluid sprays Check that the washer nozzles are not blocked if there is washer fluid in the washer fluid reservoir.
  • Page 224: Headlight Cleaner Switch

    2-3. Operating the lights and windshield wipers ∗ Headlight cleaner switch Washer fluid can be sprayed on the headlights. Press the switch to clean the headlights. ■ The headlight cleaners can be operated when The “POWER” switch is in ON mode and the headlight switch is turned on. ■...
  • Page 225: 2-4. Using Other Driving Systems

    2-4. Using other driving systems Cruise control Use the cruise control to maintain a set speed without depressing the accelerator pedal. Indicators Cruise control switch ■ Setting the vehicle speed Press the “ON-OFF” button to STEP activate the cruise control. Cruise control indicator will come on.
  • Page 226 2-4. Using other driving systems ■ Adjusting the set speed To change the set speed, operate the lever until the desired set speed is obtained. Increases the speed Decreases the speed Fine adjustment: Momentarily move the lever in the desired direction.
  • Page 227 If the cruise control speed cannot be set or if the cruise control cancels immediately after being activated, there may be a malfunction in the cruise control system. Have the vehicle inspected by your Toyota dealer.
  • Page 228 2-4. Using other driving systems CAUTION ■ To avoid operating the cruise control by mistake Switch the cruise control off using the “ON-OFF” button when not in use. ■ Situations unsuitable for cruise control Do not use cruise control in any of the following situations. Doing so may result in loss of control and could cause an accident resulting in death or serious injury.
  • Page 229: Rear View Monitor System

    2-4. Using other driving systems ∗ Rear view monitor system The rear view monitor system assists the driver by displaying an image of the area behind the vehicle while reversing. The image is displayed in reverse on the screen. This reversed image is a similar image to the one on the inside rear view mirror.
  • Page 230 2-4. Using other driving systems ■ The rear view monitor system can be operated when The “POWER” switch is in ON mode and the shift position is in “R”. ■ Displayed area The area covered by the camera is lim- ited.
  • Page 231 2-4. Using other driving systems ■ Rear view monitor system camera In the following cases, it may be difficult to see the images on the screen, even when the system is functioning correctly. ● The vehicle is in a dark area, such as at night.
  • Page 232 Conditions which may affect the rear view monitor system ● If the back of the vehicle is hit, the camera’s position and mounting angle may change. Contact your Toyota dealer. ● Rapid temperature changes, such as when hot water is poured on the vehicle in cold weather, may cause the system to function abnormally.
  • Page 233 2-4. Using other driving systems CAUTION ■ Caution while driving in reverse Do not change modes while the vehicle is moving. Doing so may cause an accident. NOTICE ■ Camera precautions ● As the camera has a water proof construction, do not detach, disassemble or modify it.
  • Page 234: Driving Assist Systems

    2-4. Using other driving systems Driving assist systems To help enhance driving safety and performance, the following sys- tems operate automatically in response to various driving situations. Be aware, however, that these systems are supplementary and should not be relied upon too heavily when operating the vehicle. ■...
  • Page 235 2-4. Using other driving systems When the TRC/VSC/ABS systems are operating The slip indicator light will flash while the TRC/VSC/ABS sys- tems are operating. ■ Sounds and vibrations caused by the ABS, brake assist, VSC and TRC ● A sound may be heard from the engine compartment when the hybrid system is started, just after the vehicle begins to move, if the brake pedal is depressed forcefully or repeatedly, or 1-2 minutes after the hybrid sys- tem is stopped.
  • Page 236 2-4. Using other driving systems ■ Reduced effectiveness of the EPS system The effectiveness of the EPS system is reduced to prevent the system from overheating when there is frequent steering input over an extended period of time. The steering wheel may feel heavy as a result. Should this occur, refrain from excessive steering input or stop the vehicle and turn the hybrid system off.
  • Page 237 2-4. Using other driving systems CAUTION ■ The ABS does not operate effectively when ● Tires with inadequate gripping ability are used (such as excessively worn tires on a snow covered road). ● The vehicle hydroplanes while driving at high speed on wet or slick road. ■...
  • Page 238 The ABS and VSC systems will not function correctly if different tires are installed on the vehicle. Contact your Toyota dealer for further information when replacing tires or wheels. ■ Handling of tires and the suspension Using tires with any kind of problem or modifying the suspension will affect the driving assist systems, and may cause a system to malfunction.
  • Page 239: Hill-Start Assist Control

    2-4. Using other driving systems Hill-start assist control Hill-start assist control helps to prevent the vehicle from rolling backwards when starting on an incline or slippery slope. To engage hill-start assist con- trol, further depress the brake pedal when the vehicle is stopped completely.
  • Page 240 • The brake pedal is depressed again. • The brake pedal has been depressed for more than approximately 3 minutes. ■ If the slip indicator light comes on It may indicate a malfunction in the system. Contact your Toyota dealer. CAUTION ■ Hill-start assist control ●...
  • Page 241: Driving Information Cargo And Luggage

    2-5. Driving information Cargo and luggage Take notice of the following information about storage precautions, cargo capacity and load: ● Stow cargo and luggage in the luggage compartment whenever possible. ● Be sure all items are secured in place. ● To maintain vehicle balance while driving, position luggage evenly within the luggage compartment.
  • Page 242 2-5. Driving information CAUTION ■ Things that must not be carried in the luggage compartment The following things may cause a fire if loaded in the luggage compartment: ● Receptacles containing gasoline ● Aerosol cans ■ Storage precautions Observe the following precautions. Failure to do so may result in death or serious injury.
  • Page 243 2-5. Driving information NOTICE ■ If luggage is loaded on the roof (vehicles with a panoramic roof) Observe the following precautions. Failure to observe them could lead to the roof rack being damaged or deformed, or the roof rack falling off. ●...
  • Page 244: Winter Driving Tips

    2-5. Driving information Winter driving tips Carry out the necessary preparations and inspections before driving the vehicle in winter. Always drive the vehicle in a manner appropri- ate to the prevailing weather conditions. ■ Pre-winter preparations ● Use fluids that are appropriate to the prevailing outside tem- peratures.
  • Page 245 2-5. Driving information ■ When driving the vehicle Accelerate the vehicle slowly and drive at a reduced speed suit- able to the road conditions. ■ When parking the vehicle Park the vehicle and shift the shift position to P and block the wheel under the vehicle without setting the parking brake.
  • Page 246 2-5. Driving information ■ Tire chain installation Observe the following precautions when installing and removing chains: ● Install and remove tire chains in a safe location. ● Install tire chains on the front tires only. Do not install tire chains on the rear tires.
  • Page 247: Trailer Towing

    Trailer towing Toyota does not recommend towing a trailer with your vehicle. Toyota also does not recommend the installation of a tow hitch or the use of a tow hitch carrier for a wheelchair, scooter, bicycle, etc. Your vehicle is not designed for trailer towing or for the use of tow...
  • Page 248: Interior Features

    Interior features 3-1. Using the air conditioning 3-3. Using the interior lights system and defogger Interior lights list....377 • Interior lights ....378 Automatic air conditioning • Personal lights ....379 system ......248 Using the steering wheel 3-4. Using the storage features climate remote control switches......
  • Page 249: 3-1. Using The Air Conditioning System And Defogger

    3-1. Using the air conditioning system and defogger Automatic air conditioning system Air outlets and fan speed are automatically adjusted according to the temperature setting. Fan speed display Temperature setting display Pollen removal mode Air outlet display Outside temperature display Windshield defogger button...
  • Page 250 3-1. Using the air conditioning system and defogger Switching functions and changing settings STEP Slide left and right to select the function. The function currently being set up will be surrounded by a frame. The arrows displayed at the sides of the frame indicate the direc- tions in which the frame can be moved.
  • Page 251 3-1. Using the air conditioning system and defogger Using automatic air conditioning system Press STEP The air conditioning system begins to operate. Air outlets and fan speed are automatically adjusted according to the temper- ature setting. To switch the air conditioning (cooler/dehumidifier functions) ON or OFF, press .
  • Page 252 3-1. Using the air conditioning system and defogger Adjusting the settings manually ■ Basic setting Adjusting the fan speed Slide to the left to select the fan speed display STEP Turn to the clockwise to increase the fan speed, or STEP counterclockwise to decrease.
  • Page 253 3-1. Using the air conditioning system and defogger Changing the air outlets Slide to the right to select the air outlet display STEP Turn clockwise or counterclockwise. STEP The air flow shown on the display indicates the following: Air flows to the upper body. Air flows to the upper body and feet.
  • Page 254 3-1. Using the air conditioning system and defogger Air flows to the feet. Air flows to the feet and the windshield defogger operates. ■ Switching between outside air and recirculated air modes Press The mode switches between recirculated air mode and outside air mode each time the button is pressed.
  • Page 255 3-1. Using the air conditioning system and defogger Defogging the windshield Press The air conditioning system oper- ates automatically. Recirculated air mode will auto- matically switch to outside air mode. It is not possible to return to recirculated air mode when the switch is on.
  • Page 256 3-1. Using the air conditioning system and defogger Adjusting the position of and opening and closing the air outlets ■ Adjusting the position of the air outlets Center outlets Direct air flow to the left or right, up or down. Front side outlets Direct air flow to the left or right, up or down.
  • Page 257 3-1. Using the air conditioning system and defogger ■ Opening and closing the air outlets Center outlets Open the vent. Close the vent. Move the knob in the direction of the printed arrow until a click is heard. Front side outlets Open the vent.
  • Page 258 3-1. Using the air conditioning system and defogger ■ Using automatic mode Fan speed is adjusted automatically according to the temperature setting and ambient conditions. As a result, the following may occur: ● Immediately after is pressed, the fan may stop for a while until warm or cool air is ready to flow.
  • Page 259 3-1. Using the air conditioning system and defogger ■ Outside temperature display In the following situations, the correct outside temperature may not be dis- played, or the display may take longer than normal to change. ● When stopped, or driving at low speeds (less than 25 km/h [16 mph]) ●...
  • Page 260 3-1. Using the air conditioning system and defogger ■ Customization Settings (e.g. enable/disable automatic operation of the air conditioning compressor when the “AUTO” switch ON) can be changed. (Customizable features →P. 564) CAUTION ■ To prevent the windshield from fogging up Do not use during cool air operation in extremely humid weather.
  • Page 261: Using The Steering Wheel Climate Remote Control Switches

    3-1. Using the air conditioning system and defogger Using the steering wheel climate remote control switches Some air conditioning features can be controlled using the switches on the steering wheel. Temperature control Outside air or recirculated air mode Adjusting the temperature setting Press “∧”...
  • Page 262 3-1. Using the air conditioning system and defogger ■ When changing the temperature setting using the steering switches The temperature will change, however the position of the selection frame on the air conditioning display will remain the same. ■ When operating the steering switches ●...
  • Page 263: Rear Window And Outside Rear View Mirror Defogger Switch

    3-1. Using the air conditioning system and defogger Rear window and outside rear view mirror defogger switch Defoggers are used to defog the rear window, and to remove rain- drops, dew and frost from the outside rear view mirrors. Turns the rear window and outside rear view mirror defog- gers on/off The defoggers will automati-...
  • Page 264: 3-2. Using The "Display Audio

    3-2. Using the “Display Audio” ∗ Touch screen By touching the screen with your finger, you can control the audio system and hands-free system, etc. Button Function “MEDIA” Audio system (→P. 274) “ ” Hands-free system (→P. 330) “SETUP” Setup menu (→P. 265) “CAR”...
  • Page 265 3-2. Using the “Display Audio” ■ To avoid damaging the touch screen ● Touch the screen lightly with your finger. If there is no response, remove your finger from the screen and try again. ● Remove any dirt on the screen by wiping with a soft cloth. Do not use detergent.
  • Page 266: Setup Menu

    3-2. Using the “Display Audio” ∗ Setup menu You can change the “Display Audio” to your desired setting. Press “SETUP” to display the “Setup” screen. Switch Page “General” P. 266 “Display” P. 268 “Bluetooth ” P. 367 “Telephone” P. 352 “Audio”...
  • Page 267 3-2. Using the “Display Audio” General settings This screen is used for various settings such as language selection and setting operation sounds. Press “SETUP”. STEP Touch “General” on the “Setup” screen. STEP Select language (→P. 267) Beep on/off Display captured image on/off “On”...
  • Page 268 3-2. Using the “Display Audio” ■ Selecting a language Touch “Language” on the “General settings” screen. STEP Select the desired language. STEP The desired one of the 7 lan- guages can be selected. Touch “OK”. STEP ■ Delete personal data Touch “Delete personal data”...
  • Page 269 3-2. Using the “Display Audio” Display settings Press “SETUP”. STEP Touch “Display” on the “Setup” screen. STEP Turn off screen The screen is turned off. To turn it on, press any button such as “MEDIA” or “SETUP”. Changes to day mode. Adjust screen contrast/bright- ness (→P.
  • Page 270 3-2. Using the “Display Audio” ■ Adjusting the screen contrast/brightness Touch “General” or “Camera” on the “Display settings” screen. STEP Adjust the display as desired STEP using “+” or “-”. Select “Contrast” or “Brightness” using the “<<” or “>>”. “-” “+”...
  • Page 271 3-2. Using the “Display Audio” Audio settings Press “SETUP”. STEP Touch “Audio” on the “Setup” screen. STEP Adjust sound settings (→P. 270) Radio settings (→P. 272) ■ Adjust sound settings Touch “Sound settings” on the “Audio settings” screen. STEP “Sound” tab Touch “-”...
  • Page 272 3-2. Using the “Display Audio” “DSP” tab Automatic sound levelizer (ASL) Adjust the ASL level in the order of “High”, “Mid”, “Low” or “Off”. When you complete settings, touch “OK”. STEP ■ The sound quality level is adjusted individually The treble, mid and bass levels can be adjusted for the each audio mode separately.
  • Page 273 3-2. Using the “Display Audio” ■ Radio settings Touch “Radio settings” on the “Audio settings” screen. STEP FM Traffic announcement on/ system automatically switches to traffic information when a broadcast with a traffic information signal is received. FM Alternative frequency on/ The station among those of the same network with strong recep- tion is selected.
  • Page 274 3-2. Using the “Display Audio” Vehicle settings Press “SETUP”. STEP Touch “Vehicle” on the “Setup” screen. STEP Various setting can be changed. Refer to the list of settings that can be changed for details. (→P. 564) When you complete settings, touch “OK”. STEP...
  • Page 275: Audio System

    3-2. Using the “Display Audio” ∗ Audio system Press “MEDIA” to display the audio control screen. Title Page Using the radio P. 278 Using the CD player P. 281 Playing an audio CD and MP3/WMA discs P. 282 Listening to an iPod P.
  • Page 276 3-2. Using the “Display Audio” Switching the audio source Press “MEDIA” to display the audio control screen. STEP Touch “Source” press STEP “MEDIA” to display the audio source selection screen. Touch the desired audio source. STEP : To scroll the screen. :Change to the list style screen as follows.
  • Page 277 3-2. Using the “Display Audio” List screen operation When a list is displayed, use the appropriate button to scroll through the list. : To scroll to the next or previous page. : If appears to the right of titles, the complete titles are too long for the display.
  • Page 278 3-2. Using the “Display Audio” CAUTION ■ Laser product This product is a class 1 laser product. ● A laser beam leak may result in hazardous radiation exposure. ● Do not open the cover of the player or attempt to repair the unit yourself. Refer servicing to qualified personnel.
  • Page 279: Using The Radio

    3-2. Using the “Display Audio” ∗ Using the radio Touch “AM” or “FM” on the audio source selection screen. Power Volume Adjusting the frequency Displaying the source selection or audio control screen Selecting a frequency ■ Audio control screen Pressing “MEDIA” displays the audio control screen from any screens of the selected source.
  • Page 280 3-2. Using the “Display Audio” Selecting a station ■ Seek tuning Press “∧” or “∨”. ■ Manual tuning Turn ■ Preset stations Touch desired preset stations (1 to 6). Using the FM station list ■ Selecting a station from the FM station list Touch “Station list”.
  • Page 281 3-2. Using the “Display Audio” ■ FM Traffic announcement system automatically switches to traffic information when a broadcast with a traffic information signal is received. “TP” (Traffic program) will appear on the screen. The station returns to the previous one when the traf- fic information ends.
  • Page 282: Using The Cd Player

    3-2. Using the “Display Audio” ∗ Using the CD player Power Volume Ejecting a disc Selecting a track and file Displaying the source selection or audio control screen Selecting a track and file/fast-forwarding and reversing Loading a disc Insert a disc into the disc slot. Ejecting a disc Press and remove the disc.
  • Page 283: Playing An Audio Cd And Mp3/Wma Discs

    3-2. Using the “Display Audio” ∗ Playing an audio CD and MP3/WMA discs Insert disc or touch “CD” on the audio source selection screen with a disc inserted. ■ Audio control screen Pressing “MEDIA” displays the audio control screen from any screens of the selected source.
  • Page 284 3-2. Using the “Display Audio” Selecting, fast-forwarding and reversing tracks (Audio CD) ■ Selecting a track Press “∧” or “∨” or turn to select the desired track num- ber. To fast-forward or reverse, press and hold “∧” or “∨”. ■ Selecting a track from the track list Touch “Tracks”...
  • Page 285 3-2. Using the “Display Audio” ■ Selecting a file from the file list Touch “Files” on the screen. STEP Touch the desired file number. STEP Selecting a folder (MP3/WMA disc) Touch “Folders” on the screen. STEP Touch the desired folder number. STEP Touch the desired file number.
  • Page 286 3-2. Using the “Display Audio” Random playback Each time is touched, the mode changes in the following order: Audio CD : Random play on the disc : Off MP3/WMA disc : Random play on the folder : Random play in all the folders : Off Repeat play Each time...
  • Page 287 If a CD-TEXT disc is inserted, the title of the disc and track will be displayed. ■ Error messages Refer to the following table and take the appropriate measures. If the prob- lem is not rectified, take the vehicle to your Toyota dealer. Message Cause Correction procedures •...
  • Page 288 3-2. Using the “Display Audio” ■ Discs that can be used Discs with the marks shown below can be used. Playback may not be possible depending on recording format or disc fea- tures, or due to scratches, dirt or deterioration. CDs with copy-protection features may not play correctly.
  • Page 289 3-2. Using the “Display Audio” ● MP3 file compatibility • Compatible standards MP3 (MPEG1 LAYER3, MPEG2 LSF LAYER3) • Compatible sampling frequencies MPEG1 LAYER3: 32, 44.1, 48 (kHz) MPEG2 LSF LAYER3: 16, 22.05, 24 (kHz) • Compatible bit rates (compatible with VBR) MPEG1 LAYER3: 32—320 (kbps) MPEG2 LSF LAYER3: 8—160 (kbps) •...
  • Page 290 3-2. Using the “Display Audio” ● Compatible disc formats The following disc formats can be used. • Disc formats: CD-ROM Mode 1 and Mode 2 CD-ROM XA Mode 2, Form 1 and Form 2 • File formats: ISO9660 Level 1, Level 2, (Romeo, Joliet) UDF (2.01 or lower) MP3 and WMA files written in any format other than those listed above may not play correctly, and their file names and folder names may not be...
  • Page 291 3-2. Using the “Display Audio” ● MP3 and WMA playback When a disc containing MP3 or WMA files is inserted, all files on the disc are first checked. Once the file check is finished, the first MP3 or WMA file is played.
  • Page 292 3-2. Using the “Display Audio” NOTICE ■ Discs and adapters that cannot be used Do not use the following types of discs, 8 cm (3 in.) disc adapters or Dual Discs. Doing so may damage the player and/or disc insert/eject function. ●...
  • Page 293 3-2. Using the “Display Audio” NOTICE ■ Player precautions Failure to follow the precautions below may result in damage to the discs or the player itself. ● Do not insert anything other than discs into the disc slot. ● Do not apply oil to the player. ●...
  • Page 294: Listening To An Ipod

    3-2. Using the “Display Audio” ∗ Listening to an iPod Connecting an iPod enables you to enjoy music from the vehicle speakers. Touch “iPod” on the audio source selection screen. Power Volume Selecting a song Displaying the source selection or audio control screen Selecting a song/fast-forwarding and reversing ∗...
  • Page 295 3-2. Using the “Display Audio” ■ Audio control screen Pressing “MEDIA” displays the audio control screen from any screens of the selected source. Audio source selection screen appears Selecting the play mode Displaying the song list Pause Touch to playback Repeat play Shuffle play...
  • Page 296 3-2. Using the “Display Audio” Connecting an iPod Open the cover and connect the iPod. Turn on the power of the iPod if it is not turned on. Playing an iPod ■ Play/Pause Touch to Play/Pause. ■ Selecting a play mode Touch “Browse”...
  • Page 297 3-2. Using the “Display Audio” Selecting, fast-forwarding and reversing songs ■ Selecting one song at a time Press “∧” or “∨” or turn to select the desired song. To fast-forward or reverse, press and hold “∧” or “∨” until you hear a beep.
  • Page 298 3-2. Using the “Display Audio” Shuffle play Each time is touched, the mode changes in the following order: : Playing the songs in shuffle : Playing the albums in the iPod in shuffle : Off When a large number of songs is stored in an iPod, shuffle selection may take time.
  • Page 299 3-2. Using the “Display Audio” ■ About iPod ● “Made for iPod” and “Made for iPhone” means that an electronic acces- sory has been designed to connect specifically to iPod, or iPhone, respectively, and has been certified by the developer to meet Apple per- formance standards.
  • Page 300 3-2. Using the “Display Audio” ■ iPod problems To resolve most problems encountered when using your iPod, disconnect your iPod from the vehicle iPod connection and reset it. For instructions on how to reset your iPod, refer to your iPod Owner’s Manual. ■...
  • Page 301 3-2. Using the “Display Audio” ■ Compatible models ® ® ® ® ® The following iPod , iPod nano , iPod classic , iPod touch , and iPhone devices can be used with this system. ● Made for • iPod touch (4th generation) •...
  • Page 302 3-2. Using the “Display Audio” NOTICE ■ To prevent damage to the iPod or its terminal ● Do not leave the iPod in the vehicle. The temperature inside the vehicle may become high, resulting in damage to the iPod. ● Do not push down on or apply unnecessary pressure to the iPod while it is connected.
  • Page 303: Listening To A Usb Memory

    3-2. Using the “Display Audio” ∗ Listening to a USB memory Connecting a USB memory enables you to enjoy music from the vehicle speakers. Touch “USB” on the audio source selection screen. Power Volume Selecting a song Displaying the source selection or audio control screen Selecting a song/fast-forwarding and reversing ∗...
  • Page 304 3-2. Using the “Display Audio” ■ Audio control screen Pressing “MEDIA” displays the audio control screen from any screens of the selected source. Audio source selection screen appears Displaying the folder list Displaying the file list Pause Touch to playback Repeat play Random playback Connecting a USB memory...
  • Page 305 3-2. Using the “Display Audio” Selecting, fast-forwarding and reversing files ■ Selecting one file at time Press “∧” or “∨” or turn to select the desired file. To fast-forward or reverse, press and hold “∧” or “∨” until you hear a beep.
  • Page 306 3-2. Using the “Display Audio” Selecting a folder Touch “Folders” on the screen. STEP Touch the desired folder number. STEP Touch the desired file number. STEP...
  • Page 307 3-2. Using the “Display Audio” Random playback Each time is touched, the mode changes in the following order: : Random play on the folder : Random play in all the folders : Off Repeat play Each time is touched, the mode changes in the following order: : File repeat : Folder repeat...
  • Page 308 3-2. Using the “Display Audio” ■ USB memory functions ● Depending on the USB memory that is connected to the system, the device itself may not be operable and certain functions may not be avail- able. If the device is inoperable or a function is unavailable due to a mal- function (as opposed to a system specification), disconnecting the device and reconnecting it once again may resolve the problem.
  • Page 309 3-2. Using the “Display Audio” ● MP3 and WMA files MP3 (MPEG Audio LAYER 3) is a standard audio compression format. Files can be compressed to approximately 1/10 of their original size using MP3 compression. WMA (Windows Media Audio) is a Microsoft audio compression format. This format compresses audio data to a size smaller than that of the MP3 format.
  • Page 310 3-2. Using the “Display Audio” ● File names The only files that can be recognized as MP3/WMA and played are those with the extension .mp3 or .wma. ● ID3 and WMA tags ID3 tags can be added to MP3 files, making it possible to record the track title, artist name, etc.
  • Page 311 3-2. Using the “Display Audio” ● Playback • To play MP3 files with steady sound quality, we recommend a fixed bit rate of at least 128 kbps and a sampling frequency of 44.1 kHz. • There is a wide variety of freeware and other encoding software for MP3 and WMA files on the market, and depending on the status of the encod- ing and the file format, poor sound quality or noise at the start of play- back may result.
  • Page 312: Using The Aux Port/Usb Port

    3-2. Using the “Display Audio” ∗ Using the AUX port/USB port This port can be used to connect a portable audio device and listen to it through the vehicle’s speakers. Open the cover and connect STEP the portable audio device. Touch “AUX”...
  • Page 313: Listening To Bluetooth ® Audio

    3-2. Using the “Display Audio” ® ∗ Listening to Bluetooth audio ® The Bluetooth audio system enables users to enjoy music played on a portable player from the vehicle speaker via wireless communi- ® cation. This audio system supports Bluetooth , a wireless data sys- tem capable of playing portable audio music without cables.
  • Page 314 3-2. Using the “Display Audio” ■ Audio control screen Pressing “MEDIA” displays the audio control screen from any screens of the selected source. Audio source selection screen appears Displaying the album list Displaying the track list ® Connecting a Bluetooth audio player Playback Pause...
  • Page 315 3-2. Using the “Display Audio” Status display You can check such indicators as signal strength and battery charge on the screen. Connection status Battery charge Indicators Conditions Good Not connected Connection status Full Empty Battery charge...
  • Page 316 3-2. Using the “Display Audio” ® Registering a Bluetooth audio player ® To use the Bluetooth audio system, you need to register your porta- ble audio player into the system. Once registered, you can enjoy your music on the vehicle’s audio system. You can register up to 5 devices in the system.
  • Page 317 3-2. Using the “Display Audio” Input the passcode displayed on STEP the screen into your portable audio player. For the operation of the portable audio player, see the manual that comes with your portable audio player. Passcodes are not required for SSP (Secure Simple Pairing) ®...
  • Page 318 3-2. Using the “Display Audio” ® Selecting the Bluetooth audio player ® If multiple Bluetooth devices are registered, follow the procedure ® below to select the Bluetooth device to be used. You may only use one device at a time. Display the “Bluetooth Audio”...
  • Page 319 3-2. Using the “Display Audio” ® Connecting the Bluetooth audio player There are two connection methods available. ■ When the connection method is set to “From vehicle” When the portable audio player is on standby for the connection, it will be automatically connected whenever the “POWER” switch is in either the ACCESSORY or ON mode.
  • Page 320 3-2. Using the “Display Audio” ® Playing Bluetooth audio Touch to play/pause. Some titles and controls may not be displayed depending on the type of portable audio player.
  • Page 321 3-2. Using the “Display Audio” Selecting a track ■ Selecting a track Press “∧” or “∨” or turn to select the desired track num- ber. To fast-forward or rewind, press and hold “∧” or “∨” until you hear a beep. ■...
  • Page 322 3-2. Using the “Display Audio” Selecting an album Touch “Browse” on the screen. STEP Touch the desired album. STEP Touch the desired track. STEP...
  • Page 323 3-2. Using the “Display Audio” Random playback Each time is touched, the mode changes in the following order: : Random play on the album : Random play in all the album : Off Repeat play Each time is touched, the mode changes in the following order: : Track repeat : Album repeat...
  • Page 324 3-2. Using the “Display Audio” ■ ® When using the Bluetooth audio system ● In the following conditions, the system may not function. • If the portable audio player is turned off • If the portable audio player is not connected •...
  • Page 325 3-2. Using the “Display Audio” ■ Compatible models Portable audio players must correspond to the specifications. ● ® Bluetooth specifications: Ver. 1.1, or higher (Recommended: Ver. 2.1 + EDR or higher) ● Profiles: • A2DP (Advanced Audio Distribution Profile) Ver. 1.0, or higher (Recommended: Ver.
  • Page 326 3-2. Using the “Display Audio” CAUTION ■ While driving ® Do not use the portable audio player or connect the Bluetooth system. NOTICE ■ When leaving the vehicle Do not leave your portable audio player in the vehicle. The inside of the vehi- cle may become hot, causing damage to the portable audio player.
  • Page 327: Using The Steering Wheel Audio Switches

    3-2. Using the “Display Audio” Using the steering wheel audio switches Some audio features can be controlled using the switches on the steering wheel. Operation may differ and usage may not be possible with audio/ navigation systems that are not compatible with the steering switches in this vehicle.
  • Page 328 3-2. Using the “Display Audio” Turning on the power Press “MODE” when the audio system is turned off. Changing the audio source Press “MODE” when the audio system is turned on. The audio source changes as follows each time “MODE” is pressed. If no discs are inserted in the player, or if the external device is not connected, that mode will be skipped.
  • Page 329 3-2. Using the “Display Audio” Selecting a radio station Press “MODE” to select the radio mode. STEP Press “∧” or “∨” on to select a radio station. STEP To seek stations, press and hold the switch until you hear a beep. Selecting a track/file or song ®...
  • Page 330 3-2. Using the “Display Audio” Selecting an album ® Press “MODE” to select the Bluetooth audio mode. STEP Press and hold “∧” or “∨” on until you hear a beep. STEP ■ Canceling automatic selection of a radio station Push the same switch. ■...
  • Page 331: Hands-Free System (For Cellular Phone)

    3-2. Using the “Display Audio” ∗ Hands-free system (for cellular phone) Then hands-free system is a function that allows you to use your cel- lular phone without touching it. ® ® This system supports Bluetooth . Bluetooth is a wireless data sys- tem that allows the cellular phone to wirelessly connect to the hands-free system and make/receive calls.
  • Page 332 3-2. Using the “Display Audio” ■ Microphone Type A You can use the microphone when talking on the phone. The person you are speaking to can be heard from the front speakers. Type B ® To use the hands-free system, you must register your Bluetooth phone in the system.
  • Page 333 3-2. Using the “Display Audio” Status display You can check indicators such as signal strength and battery charge on the “Telephone” screen. Connection status Battery charge Call area Signal strength Indicators Conditions Good Not connected Connection status Full Empty Battery charge Call area “Rm”: Roaming area Excellent...
  • Page 334 3-2. Using the “Display Audio” ■ When using the hands-free system ● The audio system is muted when making a call. ● If both parties speak at the same time, it may be difficult to hear. ● If the received call volume is overly loud, an echo may be heard. ®...
  • Page 335 3-2. Using the “Display Audio” ■ Battery charge/Signal status ● This display may not correspond exactly with the cellular phone itself. ● This system does not have a charging function. ● ® The Bluetooth phone battery will burn quickly when it is connected to ®...
  • Page 336 3-2. Using the “Display Audio” ■ Compatible models This system supports the following service. ● ® Bluetooth Specification: Ver. 1.1 or higher (Recommended: Ver. 2.1+EDR or higher) ● Profiles: • HFP (Hands Free Profile) Ver. 1.0 or higher (Recommended: Ver. 1.5 or higher) This is a profile to allow hands-free phone calls using the cellular phone or head sets.
  • Page 337: Using The Bluetooth ® Phone

    3-2. Using the “Display Audio” ® ∗ Using the Bluetooth phone Device name ® Bluetooth connection status Make a call To display the screen shown above, press on the steering wheel or ∗ : If equipped...
  • Page 338 3-2. Using the “Display Audio” ® Registering a Bluetooth phone ® To use the hands-free system, you must register a Bluetooth phone in the system. You can register up to 5 phones in the system. Display the “Telephone” screen. (→P. 336) STEP Touch “Yes”.
  • Page 339 3-2. Using the “Display Audio” ® Selecting the Bluetooth phone ® If multiple Bluetooth devices are registered, follow the procedure ® below to select the Bluetooth device to be used. You may only use one device at a time. Display the “Telephone” screen. (→P. 336) STEP Touch “Connect telephone”.
  • Page 340 3-2. Using the “Display Audio” ® Connecting a Bluetooth phone There are two connecting methods available-automatic and manual. Automatic When you register your phone, auto connection will be activated. ® Always set it to this mode and leave the Bluetooth phone in a place where connection can be established.
  • Page 341 3-2. Using the “Display Audio” Touch the device to connect. STEP A message is shown if connection has been successful. If connection fails, a message will be displayed and connection will be re-attempted. ■ ® Reconnecting to the Bluetooth phone If the system cannot connect due to poor signal strength with the “POWER”...
  • Page 342 3-2. Using the “Display Audio” Making a call ® Once the Bluetooth phone is registered, you can make a call using the following procedure: ■ Dialing Display the “Telephone” screen. (→P. 336) STEP Input the phone number. STEP To delete the inputted phone number, touch For the first digit, you can enter “+”...
  • Page 343 3-2. Using the “Display Audio” ■ Dialing from the phonebook You can dial a number from the phonebook data imported from your cellular phone. The system has one phonebook for each tele- phone. Up to 1000 entries may be stored in each phonebook. (→P.
  • Page 344 3-2. Using the “Display Audio” ● When the phonebook is empty ® You can transfer the phone numbers in your Bluetooth phone to the system. Operation methods differ between PBAP compatible and PBAP ® incompatible Bluetooth phones. If your cellular phone does not support either PBAP or OPP service, you cannot transfer contacts.
  • Page 345 3-2. Using the “Display Audio” ■ Calling using speed dial You can make a call using numbers registered from the phone- book. Display the “Telephone” screen. (→P. 336) STEP Touch “Speed dials” on the “Telephone” screen. STEP Select the desired tab and STEP choose the desired number to make a call.
  • Page 346 3-2. Using the “Display Audio” ■ Dialing from history You can call using the call history which has the 4 functions below. “All”: all the calls below which were memorized “Missed”: calls which you missed “Incoming”: calls which you received “Outgoing”: calls which you called Display the “Telephone”...
  • Page 347 3-2. Using the “Display Audio” ■ Call history list ● If you make a call to or receive a call from a number registered in the phonebook, the name is displayed in the call history. ● If you make multiple calls to the same number, only the last call made is displayed in the call history.
  • Page 348 3-2. Using the “Display Audio” Receiving a call When a call is received, the following screen is displayed together with a sound. To answer the phone: • Press on the steering wheel. • Touch ■ To refuse a call Press on the steering wheel or touch ■...
  • Page 349 3-2. Using the “Display Audio” Speaking on the phone The following screen is displayed when speaking on the phone. ■ To adjust the incoming call volume Touch “-” or “+”. You can also adjust the volume using the steering switches or the volume knob. ■...
  • Page 350 3-2. Using the “Display Audio” ■ Inputting tones When using phone services such as an answering service or a bank, you can store phone numbers and code numbers in the phonebook. Touch “0-9”. STEP Input the number. STEP If repeated tone symbols STEP stored in the phone book, “Send”...
  • Page 351 3-2. Using the “Display Audio” ■ To transfer a call Touch “Handset Mode” to change from Hands-free call to cellular phone call. Touch “Handsfree Mode” to change from cellular phone call to Hands-free call. ■ To hang up Press on the steering wheel or touch ■...
  • Page 352 3-2. Using the “Display Audio” ■ Transferring calls ● It is not possible to transfer from hands-free to the cellular phone while driving. ● If you transfer from the cellular phone to hands-free, the hands-free screen will be displayed, and you can operate the system using the screen.
  • Page 353: Setting The Hands-Free System

    3-2. Using the “Display Audio” ∗ Setting the hands-free system You can set the hands-free system to your desired settings. Setting the sound Phonebook settings To display the screen shown above, press “SETUP”, and touch “Telephone” on the “Setup” screen. ∗...
  • Page 354 3-2. Using the “Display Audio” Setting the sound Display the “Telephone settings” screen. (→P. 352) STEP Touch “Sound settings” on the “Telephone settings” screen. STEP Changes the speaker volume STEP Changes the ring tone volume Changes the ring tone (→P. 354) Restore default settings ■...
  • Page 355 3-2. Using the “Display Audio” ■ Setting the ring tone Touch “Ring tone” on the “Sound settings” screen. STEP Touch “Tone 1”, “Tone 2” STEP “Tone 3” to change the ring tone, and then “OK”. When you complete all settings, touch “OK”. STEP ■...
  • Page 356 3-2. Using the “Display Audio” Phonebook settings The phonebook manages a maximum of 5 phones in total. The data for 1000 contacts (up to 3 numbers per contact) can be registered in each phonebook. Managing the contacts Managing the speed dials Deleting the call history To display the screen above, follow the steps below.
  • Page 357 3-2. Using the “Display Audio” ■ Managing the contacts ● Transferring a phone number  You can transfer the phone numbers in your Bluetooth phone to the system. Operation methods differ between PBAP compatible and  PBAP incompatible Bluetooth phones. If your cellular phone does not support either PBAP or OPP services, you cannot transfer con- tacts.
  • Page 358 3-2. Using the “Display Audio”  For PBAP compatible Bluetooth phones Automatic phonebook down- STEP load on/off The phonebook data can be auto- matically transferred. Depending on the cellular phone, call history will be also trans- ferred. Update phonebook The phonebook data can be updated.
  • Page 359 3-2. Using the “Display Audio” ● Deleting the phonebook data Display the “Phonebook settings” screen. (→P. 355) STEP Touch “Manage contacts” on the “Phonebook settings” STEP screen. Touch “Delete contacts”. STEP If your phone supports PBAP ser- vice, “Automatic phonebook download”...
  • Page 360 3-2. Using the “Display Audio” ■ Phonebook data Phonebook data is managed for every registered phone. When another phone is connecting, you cannot read the registered data. ■ Setting the phonebook in a different way (To display the “Contacts” screen) Display the “Telephone”...
  • Page 361: Bluetooth

    3-2. Using the “Display Audio” ■ Transferring the phone number in a different way (To display the “Contact transfer method” screen) Display the “Telephone” screen. (→P. 336) STEP Touch “Contacts” on the “Telephone” screen. STEP Touch “Transfer” on the “Contacts” screen. STEP ...
  • Page 362 3-2. Using the “Display Audio” ■ Managing the speed dials ● Registering the speed dial from contacts You can register the desired phone number from phonebook. Up to 18 numbers per phone can be registered. Display the “Phonebook settings” screen. (→P. 355) STEP Touch “Manage speed dials”...
  • Page 363 3-2. Using the “Display Audio” Touch the switch you want to STEP register the number in. If you select a switch you registered before, a confirmation STEP message will be displayed. If you want to replace it, touch “Yes”. ● Registering the speed dial from call history Display the “Phonebook settings”...
  • Page 364 3-2. Using the “Display Audio” Touch the switch you want to STEP register the number in. If you select a switch you registered before, a confirmation STEP message will be displayed. If you want to replace it, touch “Yes”. ● Deleting the speed dial Display the “Phonebook settings”...
  • Page 365 3-2. Using the “Display Audio” ■ Setting the speed dials in a different way (From “Speed dial” screen) Display the “Telephone” screen. (→P. 336) STEP Touch “Speed dials” on the “Telephone” screen. STEP Touch “Options” on the “Speed dial” screen. STEP ■...
  • Page 366 3-2. Using the “Display Audio” ■ Registering the speed dial in a different way (From “Contact” screen) Display the “Telephone” screen. (→P. 336) STEP Touch “Contacts” on the “Telephone” screen. STEP Choose the desired data from the list. STEP Touch “Options” on the “Contact” screen. STEP Touch “Set speed dial”...
  • Page 367 3-2. Using the “Display Audio” ■ Deleting the call history Display the “Phonebook settings” screen. (→P. 355) STEP Touch “Delete call history” on the “Phonebook settings” STEP screen. If your phone supports PBAP service, the “Automatic phonebook download” setting needs to be set to “Off”. (→P. 357) Choose the desired history to STEP delete.
  • Page 368: Settings

    3-2. Using the “Display Audio” ® ∗ Bluetooth settings  You can set the Bluetooth system to your desired settings. Registered devices settings Connecting telephone Connecting audio player  Detailed Bluetooth settings To display the screen shown above, press “SETUP”, and touch “Bluetooth ”...
  • Page 369 3-2. Using the “Display Audio” Registered devices settings  ■ Registering a Bluetooth device  Bluetooth devices compatible with phones (HFP) and portable audio players (AVP) can be registered simultaneously. You can register up  to 5 Bluetooth devices. Display the “Bluetooth Settings”...
  • Page 370 3-2. Using the “Display Audio” When this screen is displayed, STEP input the passcode displayed on  the screen into your Bluetooth device. operation ® Bluetooth device, manual that comes with your ® Bluetooth device. Passcodes are not required for SSP (Secure Simple Pairing) ®...
  • Page 371 3-2. Using the “Display Audio”  ■ Removing a Bluetooth device Display the “Bluetooth Settings” screen. (→P. 367) STEP Touch “Registered devices” on the “Bluetooth Settings” STEP screen. Touch “Remove”. STEP Touch the device to remove. STEP A confirmation message will be displayed, touch “Yes” to STEP remove the device.
  • Page 372 3-2. Using the “Display Audio”  ■ Displaying a Bluetooth device details You can confirm and change the device details. Display the “Bluetooth Settings” screen. (→P. 367) STEP Touch “Registered devices” on the “Bluetooth Settings” STEP screen. Touch “Details”. STEP Touch the device.
  • Page 373 3-2. Using the “Display Audio” Following screen is displayed: STEP Display device name Display device address Display your telephone num- The number may not be dis- played depending on the phones. Display compatibility profile of the device Change connection method Restore default settings When you complete settings, touch “OK”.
  • Page 374 3-2. Using the “Display Audio”  Selecting the Bluetooth phone  If multiple Bluetooth devices are registered, follow the procedure  below to select the Bluetooth device to be used. You may only use one device at a time. Display the “Bluetooth Settings”...
  • Page 375 3-2. Using the “Display Audio” Selecting the audio player  If multiple Bluetooth devices are registered, follow the procedure  below to select the Bluetooth device to be used. You may only use one device at a time. Display the “Bluetooth Settings”...
  • Page 376 3-2. Using the “Display Audio” Following screen is displayed: STEP  Change Bluetooth power on/  You can change Bluetooth func- tion to “On” or “Off” Display device name Change passcode (→P. 376) Display device address Display compatibility profile of the system Change displaying telephone status on/off...
  • Page 377 3-2. Using the “Display Audio” ■ Editing the passcode You can change the passcode that you use to register your  Bluetooth device in the system. Touch “Passcode” on the “Detailed Bluetooth settings” STEP screen. Input a passcode, and touch STEP “OK”.
  • Page 378: 3-3. Using The Interior Lights

    3-3. Using the interior lights Interior lights list Front interior/personal lights (→P. 378, 379) Rear interior light (→P. 378) “POWER” switch lighting Shift lever lighting Front door courtesy lights Foot lights...
  • Page 379: Interior Lights

    3-3. Using the interior lights Interior lights Interior lights Front (vehicles without panoramic roof) Turns the lights off Turns the door position on Turns the lights on Front (vehicles with panoramic roof) Turns the lights off Turns the door position on Turns the lights on Rear The light will turn on/off in con-...
  • Page 380: Personal Lights

    3-3. Using the interior lights Personal lights Personal lights Vehicles without panoramic roof Turns the light on/off Vehicles with panoramic roof Turns the light on/off...
  • Page 381 3-3. Using the interior lights Personal lights ■ Illuminated entry system The lights automatically turn on/off according to “POWER” switch mode, the presence of the electronic key, whether the doors are locked/unlocked, and whether the doors are opened/closed. ■ To prevent 12-volt battery discharge If the interior lights remain on when the door is not fully closed and the inte- rior light switch (door position on/off) is on, the lights will go off automatically after 20 minutes.
  • Page 382: 3-4. Using The Storage Features

    3-4. Using the storage features List of storage features Bottle holders Door pockets Glove boxes Cup holders Auxiliary boxes Card holder Console box...
  • Page 383 3-4. Using the storage features CAUTION ■ Items that should not be left in the storage spaces Do not leave glasses, lighters or spray cans in the storage spaces, as this may cause the following when cabin temperature becomes high: ●...
  • Page 384: Glove Boxes

    3-4. Using the storage features Glove boxes Glove boxes Upper glove box Pull up the lever. Lower glove box Pull up the lever. ■ Glove box light (lower glove box only) The glove box light turns on when the tail lights are on. CAUTION ■...
  • Page 385: Console Box

    3-4. Using the storage features Console box Console box Push the button to open the lid. The lid can be opened by pushing either the front or rear button. CAUTION ■ Caution while driving Keep the console box closed when not is use. In the event of sudden brak- ing or sudden swerving, an accident may occur due to an occupant being struck by the open console box or the items stored inside.
  • Page 386: Cup Holders

    3-4. Using the storage features Cup holders Cup holders Front passenger’s side Push the lid. Center console Rear Front...
  • Page 387 3-4. Using the storage features Cup holders CAUTION ■ Items unsuitable for the cup holder Do not place anything other than cups or aluminum cans in the cup holders. Other items may be thrown out of the holders in the event of sudden braking, sudden swerving or an accident, cause injury.
  • Page 388: Bottle Holders

    3-4. Using the storage features Bottle holders Bottle holders Front seats Second seats...
  • Page 389 3-4. Using the storage features Bottle holders Third seats ■ When using the bottle holder ● When storing a bottle, close the cap. ● The bottle may not be stored depending on its size or shape. NOTICE ■ Items that should not be stowed in the bottle holders Put the cap on before stowing a bottle.
  • Page 390: Auxiliary Boxes

    3-4. Using the storage features Auxiliary boxes Auxiliary boxes Type A (if equipped) Press in the lid. This box is useful for temporarily storing sunglasses and similar small items. Type B CAUTION ■ Caution while driving (type A) Keep the auxiliary box closed when not in use. In the event of sudden brak- ing or sudden swerving, an accident may occur due to an occupant being struck by an open auxiliary box or the items stored inside.
  • Page 391: Door Pockets

    3-4. Using the storage features Door pockets Door pockets Front Rear...
  • Page 392: Card Holder

    3-4. Using the storage features Card holder Card holder...
  • Page 393: Other Interior Features Sun Visors

    3-5. Other interior features Sun visors To set the visor in the for- ward position, flip it down. To set the visor in the side position, flip down, unhook, and swing it to the side.
  • Page 394: Vanity Mirrors

    3-5. Other interior features Vanity mirrors Slide the cover to open. The light turns on when the cover is opened. NOTICE ■ To prevent 12-volt battery discharge Do not leave the vanity lights on for extended periods while the hybrid sys- tem is off.
  • Page 395: Clock

    3-5. Other interior features Clock Adjusts the hours Adjusts the minutes Rounds nearest hour : e.g. 1:00 to 1:29 → 1:00 1:30 to 1:59 → 2:00 ■ The clock is displayed when The “POWER” switch is in ON mode. ■ After turning the “POWER”...
  • Page 396: Power Outlets

    3-5. Other interior features Power outlets The power outlets can be used for 12 V accessories that run on less than 10 A. Front Open the cover. Rear Open the cover. ■ The power outlets can be used when The “POWER” switch is in ACCESSORY or ON mode.
  • Page 397 3-5. Other interior features NOTICE ■ To avoid damaging the power outlets Close the power outlet lid when the power outlet is not in use. Foreign objects or liquids that enter the power outlet may cause a short cir- cuit. ■...
  • Page 398: Panoramic Roof Shades

    3-5. Other interior features ∗ Panoramic roof shades Use the overhead switches to open or close the panoramic roof shades. Open Close : To stop partway, press the switch lightly. ■ The panoramic roof shades can be operated when The “POWER” switch is in ON mode. ∗...
  • Page 399 If the panoramic roof shades continue to close but then re-open slightly even after performing the above procedure correctly, have the vehicle inspected by your Toyota dealer. ■ Customization The door lock linked automatic close function can be disabled.
  • Page 400 3-5. Other interior features CAUTION ■ When closing the panoramic roof shades Observe the following precautions. Failing to do so may result in death or serious injury. ● Check to make sure that all passengers do not have any part of their bodies in a position where they could be caught when the panoramic roof shades are being operated.
  • Page 401 3-5. Other interior features NOTICE ■ Panoramic roof The panoramic roof is made of resin. Follow these precautions to prevent damage to the roof. ● When cleaning the roof, use a mild soap and a soft cloth or sponge to remove dirt, then wash clean with plenty of water.
  • Page 402: Rear Sunshades

    3-5. Other interior features Rear sunshades Pull the tab up. Hook the sunshade on to the anchors. To lower the sunshade, pull the tab slightly to unhook the shade from the anchors, and lower it slowly. NOTICE ■ To ensure normal operation of the sunshade Observe the following precautions.
  • Page 403: Assist Grips

    3-5. Other interior features Assist grips An assist grip installed on the ceiling can be used to support your body while sitting on the seat. CAUTION ■ Assist grip Do not use the assist grip when getting in or out of the vehicle or rising from your seat.
  • Page 404: Floor Mats

    3-5. Other interior features Floor mats Use only floor mats designed specifically for vehicles of the same model and model year as your vehicle. Fix them securely in place onto the carpet. Insert the retaining hooks STEP (clips) into the floor mat eye- lets.
  • Page 405 When installing the driver’s floor mat ● Do not use floor mats designed for other models or different model year vehicles, even if they are Toyota Genuine floor mats. ● Only use floor mats designed for the driver’s seat. ●...
  • Page 406: Luggage Compartment Features

    3-5. Other interior features Luggage compartment features ■ Cargo hooks Raise the hook to use. The cargo hooks are provided for securing loose items. ■ Deck board Lift the deck board. Fold out the deck board under trays to keep the deck board open.
  • Page 407 3-5. Other interior features ■ Auxiliary boxes Center Lift the center deck board. Side Lift the center deck board and then lift the side deck boards. Lift the side deck board from the front side of the vehicle to prevent hitting the cargo hook.
  • Page 408 3-5. Other interior features ■ Luggage cover Pull out the luggage cover and secure it to the hook brackets. Attach the hooks to the head restraints. Installing the luggage cover Set the holder of one side into the installation position, then install both holders from below with the cover in its contracted state.
  • Page 409 3-5. Other interior features Stowing the luggage cover Lift the center deck board and STEP remove the side deck boards. Fold inwards together with the STEP head restraint installation hooks and secure. Then, stow in the auxiliary boxes. CAUTION ■ When the cargo hooks are not in use To avoid injury, always return the cargo hooks to their stowed positions.
  • Page 410: Maintenance And Care

    Maintenance and care 4-1. Maintenance and care Cleaning and protecting the vehicle exterior ..410 Cleaning and protecting the vehicle interior ..414 4-2. Maintenance Maintenance requirements....417 4-3. Do-it-yourself maintenance Do-it-yourself service precautions ..... 420 Hood ......... 424 Positioning a floor jack..427 Engine compartment..
  • Page 411: Cleaning And Protecting The Vehicle Exterior

    4-1. Maintenance and care Cleaning and protecting the vehicle exterior Perform the following to protect the vehicle and maintain it in prime condition: ● Working from top to bottom, liberally apply water to the vehicle body, wheel wells and underside of the vehicle to remove any dirt and dust.
  • Page 412 4-1. Maintenance and care ■ When using a car wash If the door handle becomes wet while the electronic key is within the effec- tive range, the door may lock and unlock repeatedly. Place the key in a posi- tion 2 m (6 ft.) or more separate from the vehicle while the vehicle is being washed.
  • Page 413 4-1. Maintenance and care NOTICE ■ To prevent paint deterioration and corrosion on the body and compo- nents (aluminum wheels etc.) ● Wash the vehicle immediately in the following cases: • After driving near the sea coast • After driving on salted roads •...
  • Page 414 4-1. Maintenance and care NOTICE ■ To prevent damage to the panoramic roof (if equipped) Observe the following precautions. Otherwise, the surface of the panoramic roof may be damaged, or the deterioration of the coating may be acceler- ated. ● Before washing the vehicle, remove any dust, sand or other foreign matter using water.
  • Page 415: Cleaning And Protecting The Vehicle Interior

    4-1. Maintenance and care Cleaning and protecting the vehicle interior The following procedures will help protect your vehicle’s interior and keep it in top condition: ■ Protecting the vehicle interior Remove dirt and dust using a vacuum cleaner. Wipe dirty sur- faces with a cloth dampened with lukewarm water.
  • Page 416 4-1. Maintenance and care ■ Caring for leather areas Toyota recommends cleaning the interior of the vehicle at least twice a year to maintain the quality of the vehicle’s interior. ■ Shampooing the carpets There are several commercial foaming-type cleaners available. Use a sponge or brush to apply the foam.
  • Page 417 4-1. Maintenance and care NOTICE ■ Cleaning detergents ● Do not use the following types of detergent, as they may discolor the vehi- cle interior or cause streaks or damage to painted surfaces: • Non-seat portions: Organic substances such as benzene or gasoline, alkaline or acidic solutions, dye, and bleach •...
  • Page 418: 4-2. Maintenance

    These are best performed by qualified technicians. Even if you’re an experienced do-it-yourself mechanic, we recommend that repairs and maintenance be conducted by your Toyota dealer who will keep a record of maintenance on your vehicle. This record could be...
  • Page 419 4-2. Maintenance ■ Where to go for service? It makes good sense to take your vehicle to your local Toyota dealer for ser- vice. Toyota technicians are well-trained specialists receiving the latest service information through technical bulletins, service tips, and in dealership train- ing programs.
  • Page 420 ● Engine coolant temperature continually higher than normal If you notice any of these clues, take your vehicle to your Toyota dealer as soon as possible. Your vehicle may need adjustment or repair. CAUTION ■...
  • Page 421: 4-3. Do-It-Yourself Maintenance

    • Grease 12-volt battery condition • Conventional wrench (→P. 440) (for terminal clamp bolts) • “Toyota Super Long Life Coolant” or a similar high quality ethylene glycol-based non-silicate, non- amine, non-nitrite and non-borate coolant with long-life hybrid Engine/power control unit coolant organic acid technology.
  • Page 422 4-3. Do-it-yourself maintenance Items Parts and tools • Fuse with same amperage rating Fuses (→P. 457) as original • Bulb with same number and watt- age rating as original Light bulbs (→P. 467) • Phillips-head screwdriver • Flathead screwdriver • Wrench Radiator and condenser ...
  • Page 423 4-3. Do-it-yourself maintenance CAUTION The engine compartment contains many mechanisms and fluids that may move suddenly, become hot, or become electrically energized. To avoid death or serious injury, observe the following precautions. ■ When working on the engine compartment ● Make sure that the indicator on the “POWER”...
  • Page 424 4-3. Do-it-yourself maintenance NOTICE ■ If you remove the air cleaner filter Driving with the air cleaner filter removed may cause excessive engine wear due to dirt in the air. Also, a backfire could cause a fire in the engine com- partment.
  • Page 425: Hood

    4-3. Do-it-yourself maintenance Hood Release the lock from the inside of the vehicle to open the hood. Pull the hood lock release STEP lever. The hood will pop up slightly. Pull up the auxiliary catch STEP lever and lift the hood.
  • Page 426 4-3. Do-it-yourself maintenance Hold the hood open by insert- STEP ing the supporting rod into either of the slots. Use the upper slots to open the hood normally, or use the lower slots when the hood needs to be opened wide. CAUTION ■...
  • Page 427 4-3. Do-it-yourself maintenance NOTICE ■ When closing the hood Be sure to return the support rod to its clip before closing the hood. Closing the hood without returning the support rod properly could cause the hood to bend.
  • Page 428: Positioning A Floor Jack

    4-3. Do-it-yourself maintenance Positioning a floor jack When raising your vehicle with a floor jack, position the jack cor- rectly. Improper placement (such as under rear suspension etc.) may damage your vehicle or cause injury. ■ Front ■ Rear...
  • Page 429 4-3. Do-it-yourself maintenance CAUTION ■ When raising your vehicle Make sure to observe the following precautions to reduce the possibility of death or serious injury: ● Lift up the vehicle using a floor jack such as the one shown in the illustra- tion.
  • Page 430 4-3. Do-it-yourself maintenance CAUTION ● Do not raise the vehicle while someone is in the vehicle. ● When raising the vehicle, do not place any object on top of or underneath the floor jack. ● When raising the vehicle, do not set the Rear suspension floor jack under the rear suspension.
  • Page 431: Engine Compartment

    4-3. Do-it-yourself maintenance Engine compartment Engine coolant reservoir Fuse box (→P. 457) (→P. 435) Radiator (→P. 437) Engine oil level dipstick Condenser (→P. 437) (→P. 431) Electric cooling fans Engine oil filler cap Washer fluid tank (→P. 438) (→P. 431) Power control unit coolant reservoir (→P.
  • Page 432 4-3. Do-it-yourself maintenance Engine oil With the engine at operating temperature and turned off, check the oil level on the dipstick. ■ Checking the engine oil Park the vehicle on level ground. After warming up the engine STEP and turning off the hybrid system, wait more than 5 minutes for the oil to drain back into the bottom of the engine.
  • Page 433 4-3. Do-it-yourself maintenance ■ Adding engine oil If the oil level is below or near the low level mark, add engine oil of the same type as that already in the engine. Make sure to check the oil type and prepare the items needed before adding oil.
  • Page 434 Dispose of used oil and filters only in a safe and acceptable manner. Do not dispose of used oil and filters in household trash, in sewers or onto the ground. Call your Toyota dealer, service station or auto parts store for information concerning recycling or disposal.
  • Page 435 4-3. Do-it-yourself maintenance NOTICE ■ To prevent serious engine damage Check the oil level on a regular basis. ■ When replacing the engine oil ● Be careful not to spill engine oil on the vehicle components. ● Avoid overfilling, or the engine could be damaged. ●...
  • Page 436 4-3. Do-it-yourself maintenance Coolant The coolant level is satisfactory if it is between the full (“FULL” or “F”) and low (“LOW” or “L”) lines on the reservoir when the hybrid system is cold. Engine coolant reservoir Reservoir cap “FULL” line “LOW”...
  • Page 437 If the coolant level drops within a short time of replenishing Visually check the radiator, hoses, engine/power control unit coolant reser- voir caps, drain cock and water pump. If you cannot find a leak, have your Toyota dealer test the cap and check for leaks in the cooling system. CAUTION ■...
  • Page 438 Check the radiator and condenser and clear away any foreign objects. If either of the above parts is extremely dirty or you are not sure of their condition, have your vehicle inspected by your Toyota dealer. CAUTION ■ When the hybrid system is hot Do not touch the radiator or condenser as they may be hot and cause seri- ous injuries, such as burns.
  • Page 439 4-3. Do-it-yourself maintenance Washer fluid Open the lid. STEP Check the washer fluid level on STEP the level gauge. “NORMAL” “LOW” If the washer fluid level is at STEP “LOW”, add washer fluid.
  • Page 440 4-3. Do-it-yourself maintenance CAUTION ■ When adding washer fluid Do not add washer fluid when the hybrid system is hot or operating as washer fluid contains alcohol and may catch fire if spilled on the engine etc. NOTICE ■ Do not use any fluid other than washer fluid Do not use soapy water or engine antifreeze instead of washer fluid.
  • Page 441: 12-Volt Battery

    4-3. Do-it-yourself maintenance 12-volt battery ■ Location The 12-volt battery is located in the right-hand side of lug- gage compartment. ■ Removing the 12-volt battery cover Remove the center and right side deck boards. (→P. 405) STEP Remove the center auxiliary box. (→P. 406) STEP Remove the right side auxil- STEP...
  • Page 442 4-3. Do-it-yourself maintenance ■ Exterior Make sure that the 12-volt battery terminals are not corroded and that there are no loose connections, cracks, or loose clamps. Terminals Hold-down clamp ■ Before recharging When recharging, the 12-volt battery produces hydrogen gas which is flam- mable and explosive.
  • Page 443 Restart the hybrid system, depress the brake pedal, and confirm that it is possible to shift into each shift position. If the system will not start even after multiple attempts at all methods above, contact your Toyota dealer. CAUTION ■...
  • Page 444 When replacing the 12-volt battery Use a 12-volt battery designed for this vehicle. Failure to do so may cause gas (hydrogen) to enter the passenger compartment, causing a fire or explo- sion. For replacement of the 12-volt battery, contact your Toyota dealer.
  • Page 445 4-3. Do-it-yourself maintenance CAUTION ■ When disconnecting the 12-volt battery Do not disconnect the negative (-) termi- nal on the body side as shown. The dis- connected negative (-) terminal may touch the positive (+) terminal, which may cause a short and result in death or seri- ous injury.
  • Page 446: Tires

    Check spare tire condition and pressure if not rotated. ■ Tire rotation Rotate the tires in the order shown. To equalize tire wear and help extend tire life, Toyota recom- mends that you rotate tires Front approximately every 10000 km (6000 miles).
  • Page 447 Do not mix tires of different makes, models or tread patterns. Also, do not mix tires of remarkably different treadwear. ● Do not use tire sizes other than those recommended by Toyota. ● Do not mix differently constructed tires (radial, bias-belted or bias-ply tires).
  • Page 448 4-3. Do-it-yourself maintenance NOTICE ■ Driving on rough roads Take particular care when driving on roads with loose surfaces or potholes. These conditions may cause losses in tire inflation pressure, reducing the cushioning ability of the tires. In addition, driving on rough roads may cause damage to the tires themselves, as well as the vehicle’s wheels and body.
  • Page 449: Tire Inflation Pressure

    Reduced driving comfort and tire life ● Reduced safety ● Damage to the drive train If a tire needs frequent inflating, have it checked by your Toyota dealer. ■ Instructions for checking tire inflation pressure When checking tire inflation pressure, observe the following: ●...
  • Page 450 4-3. Do-it-yourself maintenance CAUTION ■ Proper inflation is critical to save tire performance Keep your tires properly inflated. Otherwise, the following conditions may occur and result in an accident causing death or serious injury: ● Excessive wear ● Uneven wear ●...
  • Page 451: Wheels

    ● Bent wheels that have been straightened ■ Aluminum wheel precautions ● Use only Toyota wheel nuts and wrenches designed for use with your aluminum wheels. ● When rotating, repairing or changing your tires, check that the wheel nuts are still tight after driving 1600 km (1000 miles).
  • Page 452 4-3. Do-it-yourself maintenance CAUTION ■ When replacing wheels ● Do not use wheels that are a different size from those recommended in the Owner’s Manual, as this may result in a loss of handling control. ● Never use an inner tube in a leaking wheel which is designed for a tube- less tire.
  • Page 453: Air Conditioning Filter

    4-3. Do-it-yourself maintenance Air conditioning filter The air conditioning filter must be cleaned or changed regularly to maintain air conditioning efficiency. ■ Removal method Turn the “POWER” switch off. STEP Open the glove box and STEP remove the filter exchange cover.
  • Page 454 500 kPa (5.0 kgf/cm , or bar, 72 psi). If an air gun is not available, have the filter cleaned by your Toyota dealer. ■ Replacement method Replace it with a new one. The “↑UP” marks shown on the filter should be pointing up.
  • Page 455 4-3. Do-it-yourself maintenance ■ Checking interval Inspect, clean and replace the air conditioning filter according to the mainte- nance schedule. In dusty areas or areas with heavy traffic flow, more fre- quent cleaning or early replacement may be required. (For scheduled maintenance information, please refer to the “Warranty and Service Book- let”.) ■...
  • Page 456: Electronic Key Battery

    4-3. Do-it-yourself maintenance Electronic key battery Replace the battery with a new one if it is depleted. ■ You will need the following items: ● Flathead screwdriver ● Lithium battery CR1632 ■ Replacing the battery Take out the mechanical key. STEP Remove the cover.
  • Page 457 4-3. Do-it-yourself maintenance ■ Use a CR1632 lithium battery ● Batteries can be purchased at your Toyota dealer, local electrical appli- ance shops or camera stores. ● Replace only with the same or equivalent type recommended by the manufacturer. ●...
  • Page 458: Checking And Replacing Fuses

    4-3. Do-it-yourself maintenance Checking and replacing fuses If any of the electrical components do not operate, a fuse may have blown. If this happens, check and replace the fuses as necessary. STEP Turn the “POWER” switch off. STEP Open the fuse box cover. Engine compartment Push the tab in and lift the lid off.
  • Page 459 4-3. Do-it-yourself maintenance After a system failure, see “Fuse layout and amperage rat- STEP ings” (→P. 460) for details about which fuse to check. Remove the fuse. STEP Only type A fuse can be removed using the pullout tool. Check if the fuse is blown. STEP Type A Normal fuse...
  • Page 460 4-3. Do-it-yourself maintenance Type B Normal fuse Blown fuse Replace the blown fuse with a new fuse of an appropriate amperage rating. The amper- age rating can be found on the fuse box lid. Type C Normal fuse Blown fuse Replace the blown fuse with a new fuse of an appropriate amperage rating.
  • Page 461 4-3. Do-it-yourself maintenance Fuse layout and amperage ratings ■ Engine compartment FUSE Ampere Circuit Air conditioning system Electric cooling fans Electric cooling fans S-HORN S-HORN ENG W/P Cooling system ABS MAIN 7.5A Anti-lock brake system NO.2 H-LP CLN Headlight cleaner P position control system, trans- P-CON MTR mission...
  • Page 462 4-3. Do-it-yourself maintenance FUSE Ampere Circuit P position control system, trans- P CON MAIN 7.5A mission 7.5A Power management system ECU-B2 7.5A Smart entry & start system MAYDAY No circuit ECU-B3 Air conditioning system TURN & HAZ Turn signal lights Multiport fuel injection system/ ETCS sequential multiport fuel injection...
  • Page 463 4-3. Do-it-yourself maintenance FUSE Ampere Circuit MIR HTR Outside rear view mirror defoggers RAD NO.1 Audio system, navigation system Door courtesy lights, personal lights, interior lights, front foot DOME lights, vanity lights, inside rear view mirror, overhead console Smart entry & start system, multi- ECU-B 7.5A plex communication system, per-...
  • Page 464 4-3. Do-it-yourself maintenance ■ Left side instrument panel 9 10 15 16 17 18 27 28 29 30 20 21 23 24 25 26 ITO43P133 FUSE Ampere Circuit Power outlets Multiplex communication system, outside rear view mirrors, driver ECU-ACC support system, audio system, navigation system PWR OUTLET Power outlets...
  • Page 465 4-3. Do-it-yourself maintenance FUSE Ampere Circuit Stop lights, high mounted stop- STOP light, brake system, driver support system P FR DOOR Power windows D FR DOOR Power windows DOOR RR Power windows DOOR RL Power windows S/ROOF Panoramic roof shades Electric cooling fans, multiplex ECU-IG NO.1 communication system...
  • Page 466 After a fuse is replaced ● If the lights do not turn on even after the fuse has been replaced, a bulb may need replacement. (→P. 467) ● If the replaced fuse blows again, have the vehicle inspected by your Toyota dealer.
  • Page 467 The fuses are designed to blow, protecting the wiring harness from damage. ■ When replacing light bulbs Toyota recommends that you use genuine Toyota products designed for this vehicle. Because certain bulbs are connected to circuits designed to prevent overload, non-genuine parts or parts not designed for this vehicle may be unusable.
  • Page 468: Light Bulbs

    You may replace the following bulbs by yourself. The difficulty level of replacement varies depending on the bulb. As there is a danger that components may be damaged, we recommend that replacement is carried out by your Toyota dealer. ■ Preparing for light bulb replacement Check the wattage of the light bulb to be replaced.
  • Page 469 4-3. Do-it-yourself maintenance ■ Rear bulb locations Rear turn signal light Rear fog light License plate lights Back-up light...
  • Page 470 4-3. Do-it-yourself maintenance Replacing light bulbs ■ Headlight low beams (halogen headlights) STEP For the right side only: Remove the bolt and unclip the engine coolant reservoir hose. Then lift up the air cleaner inlet duct. After replacing, return the air cleaner inlet duct to its original position, and firmly install the stay of the engine coolant reservoir...
  • Page 471 4-3. Do-it-yourself maintenance Unplug connector while STEP pressing the lock release. Replace the light bulb, and install STEP the bulb base. Align the 3 tabs on the light bulb with the mounting, and insert. Turn and secure the bulb base. STEP Shake the bulb base gently to check that it is not loose, turn the...
  • Page 472 4-3. Do-it-yourself maintenance ■ Headlight high beams For the right side only: Remove the bolt and unclip the engine STEP coolant reservoir hose. Then lift up the air cleaner inlet duct. (→P. 469) Turn the bulb base counterclockwise. STEP Vehicles with halogen headlights Vehicles with LED headlights Unplug connector...
  • Page 473 4-3. Do-it-yourself maintenance Replace the light bulb, and install STEP the bulb base. Align the 3 tabs on the light bulb with the mounting, and insert. Turn and secure the bulb base. STEP Shake the bulb base gently to check that it is not loose, turn the headlights on once and visually confirm that no light is leaking through the mounting.
  • Page 474 4-3. Do-it-yourself maintenance ■ Front position lights For the right side only: Remove the bolt and unclip the engine STEP coolant reservoir hose. Then lift up the air cleaner inlet duct. (→P. 469) Turn the bulb base counterclockwise. STEP Vehicles with halogen headlights Vehicles with LED headlights Remove the light bulb.
  • Page 475 4-3. Do-it-yourself maintenance ■ Front fog lights Remove the engine under cover STEP bolts and pull down the engine under cover. Unplug connector while STEP pressing the lock release.
  • Page 476 4-3. Do-it-yourself maintenance Turn the bulb base counterclock- STEP wise. When installing, reverse the steps listed. STEP After installing the bulb base, shake the bulb base gently to check that it is not loose.
  • Page 477 4-3. Do-it-yourself maintenance ■ Front turn signal lights Remove the engine under cover bolt and clip and pull down STEP the engine under cover. (→P. 474) Turn the bulb base counterclock- STEP wise. Remove the light bulb. STEP When installing, reverse the steps listed. STEP...
  • Page 478 4-3. Do-it-yourself maintenance ■ Rear turn signal lights and back-up/rear fog light Open the back door and remove STEP the cover. To prevent damage, cover the tip of the screwdriver with a rag. Turn the bulb base counterclock- STEP wise. Rear turn signal light Back-up/rear fog light Remove the light bulb.
  • Page 479 4-3. Do-it-yourself maintenance ■ License plate lights Open the back door and remove STEP the cover. To prevent damage, cover the tip of the screwdriver with a rag. Turn the bulb base counterclock- STEP wise. Remove the light bulb. STEP ITO43P150 When installing, reverse the steps listed.
  • Page 480 The headlight low beams (LED type), stop lights, tail lights, high mounted stoplight and daytime running lights consist of a number of LEDs. If any of the LEDs burn out, take your vehicle to your Toyota dealer to have the light replaced.
  • Page 481 4-3. Do-it-yourself maintenance CAUTION ■ Replacing light bulbs ● Be sure to stop the hybrid system and turn off the lights. Do not attempt to replace the bulb immediately after turning off the lights. The bulbs become very hot and may cause burns. ●...
  • Page 482 When trouble arises 5-1. Essential information Emergency flashers ..482 If your vehicle needs to be towed ......483 If you think something is wrong ......489 5-2. Steps to take in an emergency If a warning light turns on or a warning buzzer sounds ......
  • Page 483: Essential Information Emergency Flashers

    5-1. Essential information Emergency flashers Use the emergency flashers if the vehicle malfunctions or is involved in an accident. Press the switch to flash all the turn signal lights. To turn them off, press the switch once again. NOTICE ■ To prevent 12-volt battery discharge Do not leave the emergency flashers on longer than necessary when the hybrid system is not operating.
  • Page 484: If Your Vehicle Needs To Be Towed

    If your vehicle needs to be towed If towing is necessary, we recommend having your vehicle towed by your Toyota dealer or a commercial towing service, using a lift-type truck or flat bed truck. Use a safety chain system for all towing, and abide by all state/pro- vincial and local laws.
  • Page 485 5-1. Essential information Emergency towing If a tow truck is not available in an emergency, your vehicle may be temporarily towed using a cable or chain secured to the emergency towing eyelet(s). This should only be attempted on hard surfaced roads for short distances at under 30 km/h (18 mph).
  • Page 486 5-1. Essential information Installing towing eyelets Remove the eyelet cover using a STEP flathead screwdriver. To prevent damage, cover the tip of the screwdriver with a rag. Insert the towing eyelet into the STEP hole and tighten partially by hand. Tighten down the towing eyelet STEP securely using a wheel nut...
  • Page 487 5-1. Essential information Towing with a sling-type truck Do not tow with a sling-type truck to prevent body damage. Towing with a wheel-lift type truck From the front Release the parking brake. From the rear Use a towing dolly under the front wheels.
  • Page 488 5-1. Essential information Using a flat bed truck If you use chains or cables to tie down your vehicle, the angles shaded in black must be 45°. Do not overly tighten the tie downs or the vehicle may be damaged. ■...
  • Page 489 5-1. Essential information CAUTION ■ Caution while towing ● Use extreme caution when towing the vehicle. Avoid sudden starts or erratic driving maneuvers which place excessive stress on the emergency towing eyelets and the cables or chains. Always be cautious of the surroundings and other vehicles while towing. ●...
  • Page 490: If You Think Something Is Wrong

    5-1. Essential information If you think something is wrong If you notice any of the following symptoms, your vehicle probably needs adjustment or repair. Contact your Toyota dealer as soon as possible. ■ Visible symptoms ● Fluid leaks under the vehicle (Water dripping from the air conditioning after use is normal.)
  • Page 491: Steps To Take In An Emergency If A Warning Light Turns On Or A Warning Buzzer Sounds

    If a light comes on or flashes, but then goes off, this does not necessarily indicate a malfunction in the system. However, if this continues to occur, have the vehicle inspected by your Toyota dealer. Stop the vehicle immediately. Continuing to drive the vehicle may be dangerous.
  • Page 492 Stop the vehicle immediately. The following warning indicates the possibility of damage to the vehi- cle that may lead to an accident. Immediately stop the vehicle in a safe place and contact your Toyota dealer. Warning light Warning light/Details Charging system warning light Indicates a malfunction in the vehicle’s charging system...
  • Page 493 5-2. Steps to take in an emergency Have the vehicle inspected by your Toyota dealer immediately. Failure to investigate the cause of the following warnings may lead to the system operating abnormally and possibly cause an accident. Have the vehicle inspected by your Toyota dealer immediately.
  • Page 494 5-2. Steps to take in an emergency Warning light Warning light/Details Slip indicator light Indicates a malfunction in: • VSC; • TRC; or • Hill-start assist control (Turns on) Flashes when the above systems and/or ABS are oper- ating. (→P. 234) Brake system warning light (yellow indicator) Indicates a malfunction in: •...
  • Page 495 The hybrid battery (traction battery) will soon need to be inspected or replaced Have the hybrid battery (traction battery) inspected by your Toyota dealer immediately. LED headlight warning light Indicates a malfunction in the LED headlights The LED headlights will not normally illuminate when...
  • Page 496 5-2. Steps to take in an emergency Follow the correction procedures. After taking the specified steps to correct the suspected problem, check that the warning light goes off. Warning light Warning light/Details Correction procedure P position request indicator light (warning buzzer) Because recharging The amount of charge remain- is not possible when...
  • Page 497 5-2. Steps to take in an emergency Warning light Warning light/Details Correction procedure Open door warning light (warning buzzer) Check that all the Indicates that a door is not fully doors are closed. closed Low fuel level warning light Indicates remaining fuel is Refuel the vehicle.
  • Page 498 Customization The vehicle speed linked seat belt reminder buzzer can be disabled. (Customizable features →P. 564) However, Toyota recommends that the seat belt reminder buzzer be operational to alert the driver and front passen- ger when seat belts are not fastened.
  • Page 499 ■ If both the ABS and the brake system warning lights remain on Stop your vehicle in a safe place immediately and contact your Toyota dealer. The vehicle will become extremely unstable during braking, and the ABS system may fail, which could cause an accident resulting in death or serious injury.
  • Page 500 5-2. Steps to take in an emergency Follow the correction procedures. After taking the specified steps to correct the suspected problem, check that the warning light turn off. Interior Exterior Warning Details Correction procedure buzzer buzzer light The electronic key is not detected Start the hybrid sys- when an attempt...
  • Page 501 5-2. Steps to take in an emergency Interior Exterior Warning Correction Details buzzer buzzer light procedure Driving has been started without the Confirm the location  Once correct electronic of the electronic key. key inside the vehicle. The electronic key was carried out- side the vehicle and a door other...
  • Page 502 5-2. Steps to take in an emergency Interior Exterior Warning Correction Details buzzer buzzer light procedure An attempt was made to exit the vehicle with the Turn the “POWER” Contin- electronic key and  switch off and lock the lock the doors uous doors again.
  • Page 503: If You Have A Flat Tire (Vehicles With Spare Tire)

    5-2. Steps to take in an emergency If you have a flat tire (vehicles with spare tire) Remove the flat tire and replace it with the spare tire provided. ■ Before jacking up the vehicle ● Stop the vehicle on a hard, flat surface. ●...
  • Page 504 5-2. Steps to take in an emergency Taking out the jack Remove the center and left side STEP deck boards and then remove the center auxiliary box. Take out the jack. STEP Taking out the spare tire Unload the tool holder from the vehicle and loosen the center fastener that secures the spare tire.
  • Page 505 5-2. Steps to take in an emergency Replacing a flat tire Chock the tires. STEP Flat tire Wheel chock positions Left-hand side Behind the rear right-hand side tire Front Right-hand side Behind the rear left-hand side tire Left-hand side In front of the front right-hand side tire Rear Right-hand side In front of the front left-hand side tire...
  • Page 506 5-2. Steps to take in an emergency Turn the tire jack portion “A” by STEP hand until the notch of the jack is in contact with the jack point. The jack point guides are located under the rocker panel. They indi- cate the jack point positions.
  • Page 507 5-2. Steps to take in an emergency Installing the spare tire Remove any dirt or foreign mat- STEP ter from the wheel contact sur- face. If foreign matter is on the wheel contact surface, the wheel nuts may loosen while the vehicle is in motion, causing the tire to come off.
  • Page 508 5-2. Steps to take in an emergency Firmly tighten each wheel nut STEP two or three times in the order shown in the illustration. Tightening torque: 103 N•m (10.5 kgf•m, 76 ft•lbf) Stow the flat tire, tire jack and all tools. STEP ■...
  • Page 509 5-2. Steps to take in an emergency CAUTION ■ When using the compact spare tire ● Remember that the spare tire provided is specifically designed for use with your vehicle. Do not use your spare tire on another vehicle. ● Do not use more than one spare tires simultaneously.
  • Page 510 5-2. Steps to take in an emergency CAUTION ■ Speed limit when using the compact spare tire Do not drive at speeds in excess of 80 km/h (50 mph) when a compact spare tire is installed on the vehicle. The compact spare tire is not designed for driving at high speeds. Failure to observe this precaution may lead to an accident causing death or serious injury.
  • Page 511 • If there are any cracks or deformations in the bolt screws, nut threads or bolt holes of the wheel, have the vehicle inspected by your Toyota dealer. • When installing the wheel nuts, be sure to install the wheel nuts with the tapered end facing inward.
  • Page 512 5-2. Steps to take in an emergency NOTICE ■ Do not drive the vehicle with a flat tire Do not continue driving with a flat tire. Driving even a short distance with a flat tire can damage the tire and the wheel beyond repair.
  • Page 513: If You Have A Flat Tire (Vehicles Without A Spare Tire)

    (The kit contains a bottle of sealant. The sealant can be used only once to temporarily repair one tire without removing the nail or screw from the tire.) After temporarily repairing the tire with the kit, have the tire repaired or replaced by your Toyota dealer. ■ Before repairing the tire ●...
  • Page 514 5-2. Steps to take in an emergency ■ Tools and emergency tire puncture repair kit Emergency tire puncture repair kit Wheel nut wrench Towing eyelet Jack handle Jack : Removing and using the jack (→P. 505)
  • Page 515 5-2. Steps to take in an emergency ■ Emergency tire puncture repair kit components Bottle Air release cap Stickers Hose...
  • Page 516 5-2. Steps to take in an emergency Compressor Air pressure gauge Power plug Compressor switch...
  • Page 517 ■ In the following cases, the tire cannot be repaired with the emergency tire puncture repair kit. Contact your Toyota dealer. ● When the tire is damaged due to driving without sufficient air pressure ●...
  • Page 518 5-2. Steps to take in an emergency Taking out the emergency tire puncture repair kit Remove the left-side and center STEP deck boards, and remove the center auxiliary box. Take out the emergency tire STEP puncture repair kit.
  • Page 519 5-2. Steps to take in an emergency Emergency repair method Take out the repair kit from the plastic bag. STEP Remove the valve cap from the STEP valve of the punctured tire. Remove the protective film from STEP the bottle and extend the hose. Remove the air release cap from the hose.
  • Page 520 5-2. Steps to take in an emergency Make sure that the compressor STEP switch is off. Open the cover and remove the STEP power plug from the compressor. Connect the power plug to the STEP power outlet socket. (→P. 395) Remove the sticker.
  • Page 521 Remove any dirt and moisture from the wheel before attaching the sticker. If you are unable to apply the stickers, inform the nearest authorized Toyota dealer, tire dealer or repairer, or another duly qualified and equipped pro- fessional that sealant has been applied to the puncture when hav- ing the tire repaired or replaced.
  • Page 522 5-2. Steps to take in an emergency Check the specified tire inflation STEP pressure. Tire inflation pressure is speci- fied on the label on the driver’s side pillar as shown. (→P. 561) Start the hybrid system. (→P. 171) STEP To inject the sealant and inflate STEP the tire, turn the compressor switch on.
  • Page 523 Turn the compressor switch off contact your Toyota dealer. • If the tire inflation pressure exceeds the specified air pres- sure, let out some air to adjust the tire inflation pressure.
  • Page 524 5-2. Steps to take in an emergency With the compressor switch off, disconnect the hose from the STEP valve on the tire and then pull out the power plug from the power outlet socket. Some sealant may leak when the hose is removed. Install the valve cap onto the valve of the emergency repaired STEP tire.
  • Page 525 If the tire inflation pressure is under 130 kPa (1.3 kgf/cm bar, 19 psi): The puncture can- not be repaired. Contact your Toyota dealer. If the tire inflation pressure is 130 kPa (1.3 kgf/cm or bar, 19 psi) or higher, but less than...
  • Page 526 Taking precautions to avoid sudden braking, sudden accelera- STEP tion and sharp turns, drive carefully at under 80 km/h (50 mph) to the nearest authorized Toyota dealer or repairer, or another duly qualified and equipped professional for tire repair or replacement.
  • Page 527 5-2. Steps to take in an emergency ■ If the tire is inflated to more than the specified air pressure STEP Disconnect the hose from the valve. Install the air release cap to the end of the STEP hose and push the protrusion on the air release cap into the tire valve to let some air out.
  • Page 528 The sealant stored in the emergency tire puncture repair kit can be used only once to temporarily repair a single tire. If the sealant has been used and needs to be purchased, contact your Toyota dealer. ● The sealant can be used when the outside temperature is from -30°C (-22°F) to 60°C (140°F).
  • Page 529 5-2. Steps to take in an emergency CAUTION ■ Do not drive the vehicle with a flat tire Do not continue driving with a flat tire. Driving even a short distance with a flat tire can damage the tire and the wheel beyond repair.
  • Page 530 5-2. Steps to take in an emergency CAUTION ■ When fixing the flat tire ● Stop your vehicle in a safe and flat area. ● Do not touch the wheels or the area around the brakes immediately after the vehicle has been driven. After the vehicle has been driven, the wheels and the area around the brakes may be extremely hot.
  • Page 531 5-2. Steps to take in an emergency CAUTION ● The repair kit may overheat if operated for a long period of time. Do not operate the repair kit continuously for more than 40 minutes. ● Parts of the repair kit become hot during operation. Be careful handling the repair kit during and after operation.
  • Page 532 5-2. Steps to take in an emergency NOTICE ■ When performing an emergency repair ● A tire should only be repaired with the emergency tire puncture repair kit if the damage is caused by a sharp object such as nail or screw passing through the tire tread.
  • Page 533: If The Hybrid System Will Not Start

    5-2. Steps to take in an emergency If the hybrid system will not start Reasons for the hybrid system not starting vary depending on the situation. Check the following and perform the appropriate proce- dure: ■ The hybrid system will not start even though the correct starting procedure is being followed (→P.
  • Page 534 ● One or both of the 12-volt battery terminals may be discon- nected. ● The 12-volt battery may be discharged. (→P. 537) Contact your Toyota dealer if the problem cannot be repaired, or if repair procedures are unknown. Emergency start function...
  • Page 535: If You Lose Your Keys

    5-2. Steps to take in an emergency If you lose your keys New genuine keys can be made by your Toyota dealer using the other key and the key number stamped on your key number plate.
  • Page 536: If The Electronic Key Does Not Operate Properly

    5-2. Steps to take in an emergency If the electronic key does not operate properly If communication between the electronic key and vehicle is inter- rupted (→P. 57) or the electronic key cannot be used because the battery is depleted, the smart entry & start system and wireless remote control cannot be used.
  • Page 537 5-2. Steps to take in an emergency Changing “POWER” switch modes and starting the hybrid system Depress the brake pedal. STEP Touch the Toyota emblem side of STEP electronic “POWER” switch. If any of the doors is opened or closed while the key is being...
  • Page 538: If The 12-Volt Battery Is Discharged

    The following procedures may be used to start the hybrid system if the vehicle’s 12-volt battery is discharged. You can also call your Toyota dealer or a qualified repair shop. If you have a set of jumper (or booster) cables and a second vehi- cle with a 12-volt battery, you can jump start your vehicle by follow- ing the steps below.
  • Page 539 5-2. Steps to take in an emergency STEP Connect the jumper cables according to the following procedure: Connect a positive jumper cable clamp to the exclusive jump starting terminal on your vehicle. Connect the clamp on the other end of the positive cable to the positive (+) battery terminal on the second vehicle.
  • Page 540 ON mode. Make sure the “READY” indicator comes on. If the indicator STEP light does not come on, contact your Toyota dealer. Once the hybrid system has started, remove the jumper STEP cables in the exact reverse order from which they were con- nected.
  • Page 541 5-2. Steps to take in an emergency ■ Starting the hybrid system when the 12-volt battery is discharged The hybrid system cannot be started by push-starting. ■ To prevent 12-volt battery discharge ● Turn off the headlights and the audio system while the hybrid system is off.
  • Page 542 5-2. Steps to take in an emergency CAUTION ■ Avoiding 12-volt battery fires or explosions Observe the following precautions to prevent accidentally igniting the flam- mable gas that may be emitted from the 12-volt battery: ● Make sure each jumper cable is connected to the correct terminal and that it is not unintentionally in contact with any other than the intended terminal.
  • Page 543 CAUTION ■ After recharging the 12-volt battery Have the 12-volt battery inspected at your Toyota dealer as soon as possi- ble. If the 12-volt battery is deteriorating, continued use may cause the 12-volt battery to emit a malodorous gas, which may be detrimental to the health of passengers.
  • Page 544: If Your Vehicle Overheats

    Check to see if the cooling fans are operating. STEP If the fans are operating: Wait until the high coolant temperature warning light goes off and then stop the hybrid system. If the fans are not operating: Stop the hybrid system immediately and call your Toyota dealer.
  • Page 545 “FULL” line. Water can be used in an emer- gency measure if engine coolant is unavailable. (→P. 558) Have the vehicle checked at nearest Toyota dealer as soon as possi- ble. ■ If the hybrid system overheat warning light comes on...
  • Page 546 Water can be used in an emer- gency measure if power control unit coolant is unavailable. (→P. 558) Have the vehicle checked at nearest Toyota dealer as soon as possi- ble. ■ Overheating The following symptoms may occur when your vehicle is overheating: ●...
  • Page 547 5-2. Steps to take in an emergency CAUTION ■ To prevent an accident or injury when inspecting under the hood of your vehicle ● If steam is seen coming from under the hood, do not open the hood until the steam has subsided. The engine compartment may be very hot, caus- ing serious injuries such as burns.
  • Page 548: If The Vehicle Becomes Stuck

    5-2. Steps to take in an emergency If the vehicle becomes stuck Carry out the following procedures if the tires spin or the vehicle becomes stuck in mud, dirt or snow: Set the parking brake and shift the shift position to P. Stop STEP the hybrid system.
  • Page 549 5-2. Steps to take in an emergency NOTICE ■ To avoid damage to the hybrid transmission and other components ● Avoid spinning the wheels and depressing the accelerator pedal more than necessary. ● If the vehicle remains stuck even after these procedures are performed, the vehicle may require towing to be freed.
  • Page 550: If Your Vehicle Has To Be Stopped In An Emergency

    5-2. Steps to take in an emergency If your vehicle has to be stopped in an emergency Only in an emergency, such as if it becomes impossible to stop the vehicle in the normal way, stop the vehicle using the following pro- cedure: Steadily step on the brake pedal with both feet and firmly STEP...
  • Page 551 5-2. Steps to take in an emergency CAUTION ■ If the hybrid system has to be turned off while driving Power assist for the brakes and steering wheel will be lost, making the brake pedal harder to depress and the steering wheel heavier to turn. Decelerate as much as possible before turning off the hybrid system.
  • Page 552: Vehicle Specifications

    Vehicle specifications 6-1. Specifications Maintenance data (fuel, oil level, etc.)..552 Fuel information ....563 6-2. Customization Customizable features ..564...
  • Page 553: Specifications Maintenance Data (Fuel, Oil Level, Etc.)

    6-1. Specifications Maintenance data (fuel, oil level, etc.) Dimensions Overall length 4615 mm (181.7 in.) Overall width 1775 mm (69.9 in.) 1590 mm (62.6 in.) Overall height 1615 mm (63.6 in.) Wheelbase 2780 mm (109.4 in.) Front 1540 mm (60.6 in.) Tread Rear 1545 mm (60.8 in.)
  • Page 554 The vehicle identification number (VIN) is the legal identifier for your vehicle. This is the primary identification number for your Toyota. It is used in registering the ownership of your vehicle. This number is stamped on the top left of the instrument panel.
  • Page 555 6-1. Specifications ■ Engine number The engine number is stamped on the engine block as shown. Engine Model 2ZR-FXE Type 4-cylinder in line, 4-cycle, gasoline 80.5 × 88.3 mm (3.17 × 3.48 in.) Bore and stroke Displacement 1798 cm (109.7 cu.in.) Valve clearance Automatic adjustment (engine cold)
  • Page 556 6-1. Specifications Electric motor (Traction motor) Type Permanent magnet motor Maximum output 60 kW Maximum torque 207 N•m (21.1 kgf•m, 153 ft•lbf) Hybrid battery (traction battery) Type Lithium-ion battery Voltage 3.6 V/cell Capacity 5 Ah Quantity 56 cells Overall voltage 201.6 Lubrication system Oil capacity...
  • Page 557 6-1. Specifications ■ Engine oil selection “Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use Toyota approved “Toyota Genuine Motor Oil” or equivalent to satisfy the following grade and viscosity. Oil grade: 0W-20, 5W-20, 5W-30 and 10W-30: API grade SL “Energy-Conserving”, SM “Energy-Conserving”, SN “Resource-Conserving”...
  • Page 558 6-1. Specifications Oil viscosity (0W-20 is explained here as an example): • The 0W in 0W-20 indicates the characteristic of the oil which allows cold startability. Oils with a lower value before the W allow for easier starting of the engine in cold weather. •...
  • Page 559 Power control 2.7 L (2.9 qt., 2.4 Imp.qt.) unit Use either of the following: • “Toyota Super Long Life Coolant” • Similar high-quality ethylene glycol-based non- Coolant type silicate, non-amine, non-nitrite, and non-borate coolant with long-life hybrid organic acid technol-...
  • Page 560 6-1. Specifications Ignition system Spark plug Make DENSO SC20HR11 1.1 mm (0.043 in.) NOTICE ■ Iridium-tipped spark plugs Use only iridium-tipped spark plugs. Do not adjust the spark plug gap. Electrical system 12-volt battery 12.6  12.8 V Fully charged Open voltage 12.2 ...
  • Page 561 If replacement is necessary, contact your Toyota dealer. NOTICE ■ Transmission fluid type Using transmission fluid other than “Toyota Genuine ATF WS” may cause deterioration in shift quality, locking up of your transmission accompanied by vibration, and ultimately damage the transmission of your vehicle. Brakes Pedal clearance 79 mm (3.11 in.)
  • Page 562 6-1. Specifications Steering Free play Less than 30 mm (1.2 in.) Tires and wheels Standard tire Tire size 205/60R16 92V Front tire Tire inflation pressure 240 kPa (2.4 kgf/cm or bar, 35 psi) (Recommended cold tire infla- Rear tire tion pressure) 230 kPa (2.3 kgf/cm or bar, 33psi) 16 ×...
  • Page 563 6-1. Specifications Light bulbs Light Bulbs Type Halogen headlights Low beam High beam Front fog lights Front turn signal lights Exterior Front position lights Rear turn signal lights Back-up lights Rear fog light License plate lights Personal/interior lights Vehicles without panoramic roof Vehicles with panoramic roof Rear interior light Interior...
  • Page 564: Fuel Information

    Research Octane Number of 95 or higher. ■ Fuel tank opening for unleaded gasoline To help prevent incorrect fueling, your Toyota has a fuel tank opening that only accommodates the special nozzle on unleaded fuel pumps. ■...
  • Page 565: 6-2. Customization

    Toyota dealer. Some function settings are changed simultaneously with other functions being customized. Contact your Toyota dealer for further details. Customizable features Vehicles with a “Display Audio”: Settings that can be changed using the “Display Audio”...
  • Page 566 6-2. Customization Custom- Default Item Function ized setting setting Smart entry & Smart entry start system & start sys- Number of con- As many secutive door 2 times – – (→P. 50) as desired lock operations Wireless remote – – control Wireless Panic function...
  • Page 567 6-2. Customization Custom- Default Item Function ized setting setting Operation signals (Emer- – gency flashers) Operation sig- – – nals (Buzzers) Time elapsed Smart entry before auto- 60 seconds & start sys- matic door lock function is acti- 30 seconds –...
  • Page 568 6-2. Customization Custom- Default set- Item Function ized ting setting Time elapsed before lights turn 15 seconds – seconds 30 seconds Operation when the doors are – unlocked Operation after the “POWER” – switch turned Illumination Operation when (→P. 377) you approach the vehicle with the electric key...
  • Page 569 6-2. Customization Custom- Default set- Item Function ized ting setting Sensor sensitiv- ity for darkening the brightness of the meter, navi- gation system -2 to +2 – – and instrument panel depend- ing on the out- side brightness Meter and instrument Sensor sensitiv- panel...
  • Page 570 6-2. Customization Custom- Default set- Item Function ized ting setting Operates when the “POWER” switch is turned off and the doors Panoramic are locked from roof shades inside or outside door lock- the vehicle using linked auto- the wireless – –...
  • Page 571 6-2. Customization...
  • Page 572: Index

    Index Abbreviation list ...... 572 Alphabetical index....573 What to do if......584 For details of equipment related to the navigation sys- tem, such as the audio system, refer to the “Navigation System Owner’s Manual”.
  • Page 573: Abbreviation List

    Abbreviation list Abbreviation/Acronym list ABBREVIATIONS MEANING Air Conditioning Anti-lock Brake System Automatic Locking Retractor Child Restraint System DISP Display Economy/Ecology Electronic Control Unit Emergency Locking Retractor Electric Power Steering Electric Vehicle Intelligent Parking Assist Light Emitting Diode On Board Diagnostics Power Supplemental Restraint System Traction Control...
  • Page 574: Alphabetical Index

    Alphabetical index Alphabetical index Antenna ........412 Air conditioning filter....452 Anti-lock brake system ... 233 Assist grips ......402 Automatic air conditioning system ........ 248 Audio input ......311 ABS ........... 233 Audio remote control Air conditioning filter ....452 switches .......
  • Page 575 Alphabetical index ® Bluetooth ......330 Child safety Bottle holders......387 Airbag precautions....118 Brake Back door precautions .... 70 Fluid ........560 Child restraint system ... 124 Parking brake......191 Child-protectors ...... 66 Brake assist......233 How your child should wear Break-in tips ......
  • Page 576 Alphabetical index Daytime running light Eco drive mode switch.... 183 system ........215 Electric power steering ... 233 Deck board ....... 405 Electronic key Defogger If the electronic key does not Rear window ......262 operate properly ....535 Side mirrors......262 Replacing battery....
  • Page 577 Alphabetical index Engine Floor mats ........ 403 Accessory mode ....173 Fluid Compartment ......430 Brake ........560 Hood ........424 Washer ......... 438 How to start the hybrid Fog lights system ........ 171 Replacing light bulbs..... 467 Identification number..... 553 Switch ........
  • Page 578 Alphabetical index Gauges........193 Identification Glove boxes ......383 Engine........554 Vehicle ........553 Ignition switch ......171 Hands-free system Illuminated entry system ..377 (for cellular phone) ....330 Immobilizer system ....108 Hazard lights Indicator lights......203 Switch ........482 Inside rear view mirror ....
  • Page 579 Alphabetical index License plate lights Meter Replacing light bulbs..... 467 Instrument cluster light Wattage......... 562 control......... 194 Light bulbs Meters........193 Replacing ......467 Trip information display..196 Wattage......... 562 Microphone ......331 Lights Mirrors Emergency flasher switch ..482 Inside rear view mirror ....
  • Page 580 Alphabetical index Panoramic roof Seat belt reminder light... 496 Sun shade......397 Seat belts Washing precautions .... 413 Adjusting the seat belt .... 93 Parking brake ......191 Automatic Locking Retractor Personal lights (ALR) ........94 Switch ........379 Child restraint system Wattage.........
  • Page 581 Alphabetical index Service reminder Switch indicators ......203 Audio remote control Shift lever switches ......326 Transmission......181 Cruise control switch..... 224 Side airbags ......111 Driving mode select Side mirrors switch ......... 183 Adjusting and folding....99 Eco drive mode switch..183 Smart entry &...
  • Page 582 Alphabetical index Tail lights Tonneau cover ......407 Switch ........213 Touch tracer display ....207 Talk switch Tools ......... 502, 512 Telephone switch ....330 Towing Theft deterrent system Emergency towing ....484 Immobilizer system ....108 Trailer towing ......246 Tire inflation pressure .....
  • Page 583 Alphabetical index Warning buzzers Warning message Brake system ......490 Parking lock system....494 Open door ......496 Washer Seat belt reminder....496 Checking....... 438 Warning lights Preparing and checking Anti-lock brake system before winter....... 243 (ABS) ........492 Switch ......218, 221 Washing and waxing ....
  • Page 584 Alphabetical index : For vehicles with a navigation system, refer to “Navigation System Owner’s Manual”.
  • Page 585: What To Do If

    What to do if... What to do if... P. 502, If you have a flat tire A tire punctures P. 532 If the hybrid system will not start P. 108 Immobilizer system The hybrid system does not start If the 12-volt battery is P.
  • Page 586 What to do if... ■ Warning lights Brake system warning Malfunction indicator light (red indicator) lamp P. 490 P. 492 Charging system SRS warning light warning light P. 491 P. 492 Low engine oil pressure ABS warning light warning light P.
  • Page 587 What to do if... Slip indicator light Hybrid system overheat warning light P. 493 P. 495 Brake system warning Low hybrid battery light (yellow indicator) (traction battery) P. 493 P. 495 warning light Parking lock system Hybrid battery warning light indicator light P.
  • Page 588 What to do if...
  • Page 589 With filter 4.2 (4.4, 3.7) reference) Without filter 3.9 (4.1, 3.4 Toyota Genuine Motor Oil or equivalent Oil grade: 0W-20, 5W-20, 5W-30 and 10W-30: API grade SL “Energy-Conserving”, SM “Energy- Conserving”, SN “Resource-Conserving” or ILSAC Engine oil type multigrade engine oil...

Table of Contents

Save PDF
