JUNO JBKM131D0 User Manual

JUNO JBKM131D0 User Manual

Microwave combi-oven
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
EN
User Manual
Microwave
combi-oven
JBKM131D0
JBKM131D2
JBKM131S2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the JBKM131D0 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for JUNO JBKM131D0

Summary of Contents for JUNO JBKM131D0

  • Page 1 User Manual Microwave combi-oven JBKM131D0 JBKM131D2 JBKM131S2...

  • Page 2: Table Of Contents

    Subject to change without notice. VISIT OUR WEBSITE TO: Get usage advice, brochures, trouble shooter, service and repair information: www.juno.de/support SAFETY INFORMATION Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible for any injuries or damage that are the result of incorrect installation or usage.
  • Page 3 WARNING: Keep children and pets away from the • appliance when it operates or when it cools down. Accessible parts become hot during use. If the appliance has a child safety device, it should be • activated. Children shall not carry out cleaning and user maintenance •...
  • Page 4 WARNING: Only a qualified person can carry out any • service or repair operation that involves the removal of a cover which gives protection against exposure to microwave energy. WARNING: Do not heat liquids and other foods in sealed • containers.

  • Page 5: Safety Instructions

    affect the life of the appliance and possibly result in a hazardous situation. SAFETY INSTRUCTIONS Installation Width of the back of 559 mm WARNING! Only a qualified the appliance person must install this appliance. Depth of the appli‐ 567 mm ance •...
  • Page 6 below the appliance, especially when it • Do not apply pressure on the open operates or the door is hot. door. • The shock protection of live and • Do not use the appliance as a work insulated parts must be fastened in surface or as a storage surface.
  • Page 7 Care and cleaning • Do not drop or hit glassware against a hard object or strike utensils against it. WARNING! Risk of injury, fire, • Do not heat empty or nearly empty or damage to the appliance. glassware in microwave, or overheat oil or butter in microwave (use minimum •...

  • Page 8: Product Description

    • Disconnect the appliance from the • Remove the door catch to prevent mains supply. children or pets from becoming trapped • Cut off the mains electrical cable close in the appliance. to the appliance and dispose of it. PRODUCT DESCRIPTION General overview Control panel Electronic programmer...

  • Page 9: Control Panel

    CONTROL PANEL Electronic programmer Use the sensor fields to operate the appliance. Sensor Function Description Field DISPLAY Shows the current settings of the appliance. ON / OFF To activate and deactivate the appliance. OPTIONS To set an oven function or an automatic pro‐ gramme.
  • Page 10 Sensor Function Description Field MINUTE MINDER To set the Minute Minder. Display A. Oven function symbol B. Temperature / time of day / microwave power display C. Clock / Residual heat display / Minute Minder D. Residual heat indicator E. Indicators for the clock functions F.

  • Page 11: Before First Use

    BEFORE FIRST USE After the software version goes off, the WARNING! Refer to Safety display shows h and 12:00. chapters. 1. Touch to set the hours. Initial Cleaning 2. Touch Remove all accessories and removable 3. Touch to set the minutes. shelf supports from the oven.

  • Page 12: Microwave Mode

    When the oven is at the set temperature a signal sounds and the Heat up indicator Oven func‐ Application disappears. tion How to check: Temperature To make convenience food (e.g., french fries, You can check the current temperature in potato wedges or spring Frozen Foods the oven when the function or programme rolls) crispy.
  • Page 13 Put the accessory on the bottom of the WARNING! The microwave cavity. Put the food on the microwave bottom glass plate can become bottom glass plate. hot when the appliance operates. Use the microwave bottom glass plate whenever the microwave function is on. It is necessary for heating food or liquids.

  • Page 14: Clock Functions

    When you use the Microwave function in Combi mode the Microwave power cannot MICROWAVE MAXIMUM TIME be more than 600 W. POWER Setting the Quick Start function 100 - 600 W More than 600 W 7 minutes 1. Touch to deactivate the appliance. 2.
  • Page 15 Count Up Timer 3. Use to set the END and to confirm. First you set the The Count Up Timer is not minutes and then the hours. activated if Duration and End When the set time ends, an acoustic are set. signal sounds for two minutes.

  • Page 16: Automatic Programmes

    Setting the Time delay function When the Time delay function is activated, the display shows The DURATION and END can be a static symbol of the oven used at the same time, if the appliance is function, with a dot and to be switched on and off automatically The dot shows which clock later.

  • Page 17: Using The Accessories

    6. Touch a sensor field or open the door 4. Touch or the settings save to stop the acoustic signal. automatically after five seconds. The appliance activates. Automatic programmes with 5. You can change the default weight weight input value with .

  • Page 18: Additional Functions

    Wire shelf, Baking tray: Push the tray between the guide bars of the shelf support and the wire shelf on the guide bars above. Microwave bottom glass plate: Use the microwave bottom glass plate only with microwave function. It is not suitable for combined microwave func‐...

  • Page 19: Hints And Tips

    Description Value to set SET+GO ON / OFF RESIDUAL HEAT INDICATOR ON / OFF CLICK / BEEP / OFF KEY TONE FAULTY TONE ON / OFF BRIGHTNESS LOW / MEDIUM / HIGH SERVICE MENU RESTORE SETTINGS YES / NO 1) It is not possible to deactivate the tone of the ON / OFF sensor field. Brightness of the display 1.
  • Page 20 Cooking recommendations The temperature and cooking times in the tables are guidelines only. They depend on the rec‐ ipes and the quality and quantity of the ingredients used. Your oven may bake or roast differently to the oven you had before. The hints below show rec‐ ommended settings for temperature, cooking time and shelf position for specific types of the food.
  • Page 21 Cookware / Material Microwave function Microwave Combi function De‐ Heating, frosting Cooking Ovenproof glass and porcelain with no metal components, e.g. heat-proof glass Non-ovenproof glass and porcelain without any silver, gold, platinum or other metal decorations Glass and glass ceramic made of ovenproof / frost-proof material Ceramic and earthenware without any quartz or metal components and gla‐...
  • Page 22 Trays in the oven can distort during baking. When the trays are cold again, the distortions disappear. Tips on baking Baking results Possible cause Remedy The bottom of the cake The shelf position is incor‐ Put the cake on a lower shelf. is not baked sufficiently.
  • Page 23 BAKING IN TINS (°C) (min) Sponge cake 35 - 50 Cheesecake, use a deep pan 160 - 170 60 - 90 Apple pie, 2 tins Ø20 cm 70 - 90 Use the first shelf position. Use the function: True Fan Cooking. Use the baking tray unless specified otherwise.
  • Page 24 CAKES / PASTRIES / BREADS (°C) (min) Christstollen 160 - 180 50 - 70 Use the function: True Fan Cooking. BISCUITS (°C) (min) Short pastry biscuits 150 - 160 10 - 20 Biscuits made of sponge cake mixture 150 - 160 15 - 20 Puff pastries, preheat the empty oven 170 - 180...
  • Page 25 (°C) (min) Vegetables au gratin, Turbo Grilling 160 - 170 15 - 30 preheat the empty oven Lasagne Conventional Cooking 180 - 200 25 - 40 Fish bakes Conventional Cooking 180 - 200 30 - 60 Stuffed vegetables True Fan Cooking 160 - 170 30 - 60 Sweet bakes...
  • Page 26 PORK (kg) (°C) (min) Pork knuckle, 0.75 - 1 150 - 170 60 - 75 precooked Use the function: Turbo Grilling. VEAL (kg) (°C) (min) Roast veal 160 - 180 50 - 70 Veal knuckle 1.5 - 2 160 - 180 75 - 100 Use the function: Turbo Grilling.
  • Page 27 DISHES (kg) (°C) (min) Sweet dishes 160 - 180 20 - 35 Savoury dishes 400 - 600 160 - 180 20 - 45 with cooked in‐ gredients (noo‐ dles, vegetables) Savoury dishes 400 - 600 160 - 180 30 - 45 with raw ingredi‐...
  • Page 28 GRILL (°C) (min) (min) 1st side 2nd side Roast beef, medium 210 - 230 30 - 40 30 - 40 Beef fillet, medium 20 - 30 20 - 30 Pork loin 210 - 230 30 - 40 30 - 40 Veal loin 210 - 230 30 - 40...
  • Page 29 Use the first shelf position. (kg) (°C) (min) Roast beef 1 - 1.5 120 - 150 Beef fillet 1 - 1.5 90 - 110 Roast veal 1 - 1.5 120 - 150 Steak 0.2 - 0.3 20 - 40 Frozen Foods Remove the food packaging.
  • Page 30 (kg) (min) (min) Defrosting Further de‐ time frosting time Chicken 100 - 140 20 - 30 Turn halfway through. Meat 100 - 140 20 - 30 Turn halfway through. Trout 0.15 25 - 35 10 - 15 Strawberries 30 - 40 10 - 20 Butter 0.25...
  • Page 31 VEGETA‐ (min) (min) (°C) BLES Cooking Continue Peppers 60 - 70 5 - 6 time until to cook at simmer‐ 100 °C Vegetables 60 - 70 5 - 6 for soup Carrots 50 - 60 5 - 10 Mushrooms 50 - 60 6 - 8 Cucumbers 50 - 60...
  • Page 32 MEAT / FISH Set power for 100 W unless specified (kg) (min) Standing otherwise. time (min) Steak 5 - 7 5 - 10 Minced meat, set 200 W 7 - 8 5 - 10 Chicken 30 - 35 10 - 20 Chicken breast 0.15 5 - 9...
  • Page 33 REHEATING (min) Standing time (min) Baby food in jars 0.2 kg 1 - 2 Baby milk, put a spoon into the bottle 180 ml 0:20 - 0:40 Milk 200 ml 1000 1 - 1:30 Water 200 ml 1000 1:30 - 2 Sauce 200 ml 1 - 3...
  • Page 34 COOKING (min) Standing time (min) Rice 0.2 kg + 400 ml 15 - 18 of water Popcorn 1000 1:30 - 3 Microwave Combi function Combine the functions: Turbo Grilling and Microwave. (kg) (°C) (min) Stand‐ ing time (min) Chicken, half, 0.55 Round glass use the second...
  • Page 35 500 - 600 W Heating one-plate Defrosting and heat‐ Cooking egg dishes Simmering stews meals ing frozen meals 300 - 400 W Melting cheese, Simmering Heating baby Cooking / Heat‐ Continuing chocolate, but‐ rice food ing delicate food cooking 100 - 200 W Defrosting fruit and Defrosting cheese, Defrosting meat,...

  • Page 36: Care And Cleaning

    Use the wire shelf. MICRO‐ WAVE COMBI (°C) (min) FUNC‐ TION Cake, True Fan 29 - 31 Turn container 0.7 kg Cooking + around by 1/4, halfway through the cooking time. Potato Turbo Grill‐ 40 - 45 Turn container gratin, ing + MW around by 1/4, 1.1 kg...

  • Page 37: Troubleshooting

    Clean all accessories after each use and let them dry. Use a soft cloth with warm water and a mild detergent. Do not clean the accessories in a dish‐ washer. Do not clean the non-stick accessories using abrasive cleaner or sharp- Accessories edged objects.
  • Page 38 What to do if... Problem Possible cause Remedy You cannot activate or oper‐ The oven is not connected Check if the oven is correct‐ ate the oven. to an electrical supply or it is ly connected to the electrical connected incorrectly. supply (refer to the connec‐...

  • Page 39: Environmental Concerns

    The necessary data for the service centre is on the rating plate. The rating plate is on the front frame of the oven cavity. Do not remove the rating plate from the oven cavity. We recommend that you write the data here: Model (MOD.) .........
  • Page 40 867353440-C-352021...

This manual is also suitable for:

Jbkm131d2Jbkm131s2
