Ingics iBS03 User Manual

INGICS
Guide
Ver.0d
Introduction
The document is a quick guide for iBS03/iBS03T/iBS03G/iBS03TP/iBS03P/iBS03R. To quickly
verify it, please download INGICS iBS01 Tag Utility APP from below link(Android only):
https://play.google.com/store/apps/details?id=com.ingics.tag.igstagconfig
Power on
One CR2450 battery is pre-installed in each iBS03 beacon at shipment. For transportation safety it is powered off by
default. User should open the case to turn the power on.
Open the case from the gap position,
Because it is airtight, please half open
it from this side then fully open it from
the other side.
Close the case. To make it airtight,
hold two sides of the case, then twist
back and forth like in the figure below.
Operation
Basically, iBS03 will always transmit BLE payload in the configured time period(default 5s,
iBS03TP 30s) in background. It can be used to track the position of a target by deployment with
iGS01S or iGS02E beacon gateway. Besides background transmission, button or sensor
activation will also trigger a burst of BLE transmission in 300ms(3-4 transmission). This is to
increase the possibility that backends can receive sensor status change.
INGICS TECHNOLOGY CO., LTD. • SUPPORT@INGICS.COM • WWW.INGICS.COM
TECHNOLOGY
iBS03 User Guide
Check if the O-ring is still settled at the
correct position during opening.
For usage in normal
conditions, the
airtight condition will
make iBS03
waterproof.
Switch the small handle to the "ON"
position.
For harsh environments or tough
conditions, please fix iBS03 by the
attached stainless screws. This will
make iBS03 a more rugged beacon.
