Summary of Contents for Tuv nord 6ft
- Page 1 TRAMPOLINE ENCLOSURE INSTRUCTIONS. FOR OUTDOOR FAMILY DOMESTIC USE ONLY. Enclosure Specifications: 6ft Enclosure 8ft Enclosure 10ft Enclosure 12ft Enclosure 14ft Enclosure 13ft Enclosure 15ft Enclosure 16ft Enclosure Legs:...
- Page 2 ASSEMBLY INSTRUCTIONS FOR TRAMPOLINE ENCLOSURE 1. PACK CONTENTS : TRAMPOLINE DIAMETER 10’ 13’ 13’ 14’ 14’ 14’ 6’ 8’ 10’ 12’ 15’ 15’ 16’ 16’ PARTS NAME FIG. (4Legs) (3Legs) (3Legs) (3Legs) (4Legs) (4Legs) (5Legs) (4Legs) (5Legs) (6Legs) (5Legs) (6Legs) (5Legs) (6Legs) 8PCS...
- Page 3 3. ASSEMBLY: Step 1: 1).Take the Bracket (A) and insert the support poles(B), locate and tighten Square Neck Bolt (D1), Flat Washers (F), Bracket(A),Nylon Lock Nut(G) and Dome Nut (E) together. 2). Using the Spacer (C) take Screw (D), Flat Washer (F),Nylon Lock Nut (G) & Dome Nut and connect to the frame as shown in diagram, repeat this in order...
- Page 4 Step 3: Opening with zipper Working around the trampoline gradually ease the enclosure net(5) to the level of the trampoline pad. Step 4: Lastly, take each elasticated strap (along the bottom edge of the net), pass wrap around the trampoline frame fasten using the hook/ring. Fix the hook into ring in order IMPORTANT WARNING You should go back now and stretch all attachment hooks tight and double check to see whether you have fastened the hook/bolts using screw sets if...
- Page 5 WARNING: 1. Adequate overhead clearance is essential. A minimum of 24 ft and a clearance of 2m around the perimeter of the trampoline from ground level is recommended. Provide clearance for wires, tree limbs and other possible hazards. 2. Lateral clearance is essential. Place the trampoline and trampoline enclosure away from walls, structures, fences and other play areas.
