ChildLife Outback XL Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
O U T B A C K
X L
PG-MA-0029-02
817 Maxwell Avenue • Evansville, IN 47711 • 1-800-GO-SWING • www.escaladesports.com • ©2016 Escalade Sports

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Outback XL and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ChildLife Outback XL

Summary of Contents for ChildLife Outback XL

  • Page 1 O U T B A C K PG-MA-0029-02 817 Maxwell Avenue • Evansville, IN 47711 • 1-800-GO-SWING • www.escaladesports.com • ©2016 Escalade Sports...
  • Page 2 I N T R O D U C T I O N I N T R O D U C T I O N Welcome to our family of ready-to-build backyard play equipment. WOODPLAY playsets are designed with ease of Welcome to our family of ready-to-build backyard play equipment.
  • Page 3 S A F E T Y I N S T R U C T I O N S Teach Children: • Not to walk close to, in front of, behind, or between • Not to stand in the swing seats. moving items.

  • Page 4: Qty

    O U T B A C K P A R T S L I S T NOTE : Woodplay playsets are sold in both Redwood and Chinese Cedar. All the part numbers in this manual with the suffix “PG-“ are made of Chinese Cedar. If you have a Redwood set change the suffix to “PGR-“ to order redwood parts. PART NUMBER DESCRIPTION QTY.
  • Page 5 O U T B A C K H A R D W A R E I D E N T I F I E R 1/2"-13 x 6" HEX BOLT PG-HW-B013 Measurement taken from bottom of bolt head to the bottom of bolt 3/8"...
  • Page 6 O U T B A C K P A R T S I D E N T I F I E R NOTE : Woodplay playsets are sold in both Redwood and Chinese Cedar. All the part numbers in this manual with the suffix “PG-“...
  • Page 7 O U T B A C K P A R T S I D E N T I F I E R 69" Base Support 60 5/8" Horizontal Roof Support 67 3/8" Horizontal Roof Support 40 1/4" - Corner Post PG-4X4-069-BS PG-2X4-068-HRS PG-2X4-061-HRS...

  • Page 8: Table Of Contents

    O U T B A C K P A R T S I D E N T I F I E R PARTS FOR DECK: PARTS FOR SIDE PANEL: PART NUMBER DESCRIPTION QTY. PART NUMBER DESCRIPTION QTY. PG-2X4-025-PBT 25" Panel Top PG-2X6-054-DEK 53 5/8"...
  • Page 9 SPLIT LADDER FOR 5’ DECK: 18 1/4 Ladder Step PART NUMBER DESCRIPTION QTY. PG-2X6-018-STP PG-4X4-069-STP-CHN-R 69" Step Chain Ladder Rail Right PG-4X4-069-STP-CHN-L 69" Step Chain Ladder Rail Left PG-4X4-069-CL 69" Chain Ladder Rail ST-CHLAD76-SP 62 1/8 X 20 1/8" Chain Ladder Split PG-ST-0011 43"...
  • Page 10 SPLIT LADDER FOR 6’ DECK: PART NUMBER DESCRIPTION QTY. PG-4X6-084-STP-CHN-R 83 3/4" Step - Chain Ladder Rail Right 43" ROUND RUNG PG-4X6-082-STP-CHN-L 81 3/4" Step / Chain Ladder Rail Left PG-ST-0011 PG-ST-0011 43" Round Rung PG-4X6-084-RNG-CHN-L 83 3/4" Rung - Chain Ladder Rail Left ST-CHLAD76-SP 62 1/8 X 20 1/8"...
  • Page 11 SPLIT LADDER FOR 7’ DECK: PART NUMBER Description QTY. PG-4X6-099-STP-CHN-R 98 1/2" Step - Chain Ladder Rail Right 43" ROUND RUNG PG-4X6-097-STP-CHN-L 97 1/4" Step- Chain Ladder Rail Left PG-ST-0011 PG-ST-0011 43" Round Rung PG-4X6-099-RNG-CHN-L 98 1/2" Rung - Chain Ladder Rail Left ST-CHLAD99-SP 86 7/8 X 20 1/8 Chain Ladder PG-2X8-018-STP...
  • Page 12 CLIMBING WALL FOR 5’ DECK: QTY. PART NUMBER Description PG-4X4-069-CWR 69" Climbing Wall Rail PG-546-047-CWB-A 47" X 1 X 5 1/2 Climbing Wall Board PG-546-047-CWB-B 47" X 1 X 5 1/2 Climbing Wall Board PG-546-047-CWB-C 47" X 1 X 5 1/2 Climbing Wall Board PG-546-047-CWB-D 47"...

  • Page 13: 1/4" Flat Washer

    CLIMBING WALL FOR 6’ DECK: PART NUMBER Description QTY. PG-4X6-084-CWRR 83 3/4" Climbing Wall Rail Right PG-4X6-084-CWRL 83 3/4" Climbing Wall Rail Left PG-546-047-CWB-A 47" X 1 X 5 1/2 Climbing Wall Board PG-546-047-CWB-B 47" X 1 X 5 1/2 Climbing Wall Board PG-546-047-CWB-D 47"...
  • Page 14 CLIMBING WALL FOR 7’ DECK: QTY. PART NUMBER Description PG-4X6-099-CWRR 98 1/2" Climbing Wall Rail Right PG-4X6-099-CWRL 98 1/2" Climbing Wall Rail Left PG-546-047-CWB-E 47" X 1 X 5 1/2 Climbing Wall Board PG-546-047-CWB-A 47" X 1 X 5 1/2 Climbing Wall Board PG-546-047-CWB-B 47"...

  • Page 15: 8X2 1/2 Ph Flat Hd Wdscr

    ASSEMBLY OF CLIMBING WALL FOR 5’ DECK: 1" PG-HW-S013 #14 X 1.5" Round Phil Head Screw PG-HW-W002 SIDE VIEW 1/4" Flat Washer PG-HW-N002 PG-HW-B002 3/8"-16 X 1/2" T-NUT 3/8- 16 x 1.5" Socket Head Screw PG-HW-S009 #8X2 1/2 PH FLAT PG-HW-W012 HD WDSCR 3/8”...
  • Page 16 ASSEMBLY OF CLIMBING WALL FOR 6’ DECK: 2" PG-HW-B002 3/8-16 x 1.5" Socket PG-HW-N002 Head Screw 3/8"-16 X 1/2" T-NUT SIDE VIEW PG-HW-W012 3/8” Narrow Flat Washer PG-HW-S009 PG-546-047-CWB-A #8X2 1/2 PH FLAT PG-546-047-CWB-B HD WDSCR PG-HW-S013 PG-546-047-CWB-D #14 X 1.5" Round PG-546-047-CWB-C Phil Head Screw PG-546-047-CWB-B...
  • Page 17 ASSEMBLY OF CLIMBING WALL FOR 7’ DECK: 2-3/8" PG-HW-N002 3/8"-16 X 1/2" T-NUT SIDE VIEW PG-546-047-CWB-C PG-546-047-CWB-D PG-HW-S009 PG-546-047-CWB-B #8X2 1/2 PH FLAT PG-546-047-CWB-C HD WDSCR PG-HW-S013 PG-546-047-CWB-A #14 X 1.5" Round PG-546-047-CWB-B Phil Head Screw PG-546-047-CWB-D PG-546-047-CWB-C PG-HW-W002 1/4" Flat Washer PG-546-047-CWB-B PG-4X6-099-CWRL PG-546-047-CWB-A...
  • Page 18 3/8" X 4" Lag Screw 3/8" X 5 1/2" Lag Screw 3/8" Flat Washer PG-4X4-020-BRR 20" - 45 Degree 3/8" Flat Washer Angle Brace Right PG-4X4-069-BS 69" Base Support 3/8" X 4" Lag Screw 2" SIDE VIEW...
  • Page 19 ASSEMBLY OF SPLIT LADDER FOR 5’ DECK: PG-2X6-018-STP 18 1/4 Ladder Step PG-4X4-069-STP-CHN-R 69" Step Chain Ladder Rail Right PG-HW-W002 1/4" Flat Washer PG-ST-0011 43" ROUND PG-HW-L002 RUNG 1/4" x 4.5" LAG SCREW Center Step within Ladder ST-CHLAD76-SP 62 1/8 x 20 1/8" Chain Ladder Split SIDE VIEW PG-4X4-069-STP-CHN-L...
  • Page 20 ASSEMBLY OF SPLIT LADDER FOR 6’ DECK: PG-4X6-084-STP-CHN-R PG-2X8-018-STP 83 3/4" Step - Chain Ladder Rail Right 18 1/4" Ladder Step PG-HW-W002 PG-ST-0011 1/4" Flat Washer 43" ROUND RUNG PG-HW-L002 1/4" x 4.5" LAG SCREW PG-4X6-084-RNG-CHN-L 83 3/4" Rung - Chain Ladder Rail Left Center Step within Ladder...
  • Page 21 ASSEMBLY OF SPLIT LADDER FOR 7’ DECK: PG-4X6-099-STP-CHN-R PG-2X8-018-STP 98 1/2" Step - Chain Ladder Rail Right 18 1/4" Ladder Step PG-HW-W002 1/4" Flat Washer PG-HW-L002 PG-ST-0011 1/4" x 4.5" LAG SCREW 43" ROUND PG-4X6-099-RNG-CHN-L RUNG 98 1/2" Rung - Chain Ladder Rail Left ST-CHLAD99-SP Center Step...
  • Page 22 NOTE: Hole on this end 3/8" X 4" Lag Screw 3/8" X 5 1/2" Lag Screw 3/8" Flat Washer PG-4X4-020-BRR 20" - 45 Degree Angle Brace Right 3/8" Flat Washer PG-4X4-106-BSRL 106" Base Support 3/8" X 4" Lag Screw Rope Ladder 2"...
  • Page 23 PG-4X6-108-DS 1/2" FLAT WASHER 108" Deck Support 1/2" FLAT WASHER 1/2" NYLON LOCKNUT 1/2"-13 ACORN NUT 1/2"-13 x 6" HEX BOLT NOTE: Tighten Hardware but leave loose enough so parts move freely. PG-4X6-138-DS 138" Deck Support...
  • Page 24 3/8" X 4" Lag Screw 3/8" Flat Washer PG-4X6-017-BRL 17" - 30 Degree Angle Brace Left NOTE: Tighten Hardware from previous page once all Angle Braces are installed.
  • Page 25 PG-4X4-092-VRS PG-4X4-040-CP Vertical Roof 40 1/4" - Corner Post Support PG-4X4-092-VRS Vertical Roof Support 1/2”-13 X 6” Hex Bolt PG-4X4-040-VPD-A 1/2” Washer 40 1/4" - Vertical PG-4X4-040-CP Panel Divider 1/2” Nylon Locknut 40 1/4" - Corner Post 1/2” Acorn Nut PG-4X4-040-CP 40 1/4"...
  • Page 26 NOTE: If your Model did not come with assembled Decks follow these instructions. If your model has pre-assembled Decks continue to the next page. PG-HW-S009 #8X2 1/2 PH FLAT HD WDSCR PG-2X4-028-BB 27 1/2" Deck Backboard TOP VIEW PG-2X6-030-BB 30" Deck Backboard PG-2X6-054-DEK 53 5/8"...
  • Page 27 RW-DEK-054-030 Deck 30 1/8” Wide 1/4" x 4.5" LAG SCREW 1/4" FLAT WASHER RW-DEK-054-029 Deck 29” Wide RW-DEK-054-030 Deck 30 1/8” Wide...
  • Page 28 PG-4X4-126-HRS-A 126" Horizontal Roof Support OB XL 1/2" FLAT WASHER 1/2"-13 x 6" HEX BOLT PG-4X4-126-HRS-A 126" Horizontal Roof Support OB XL 1/2"-13 ACORN NUT 1/2" NYLON LOCKNUT 1/2" FLAT WASHER...
  • Page 29 PG-4X4-020-BRR 20" - 45 Degree Angle Brace Right PG-4X4-020-BRL 20" - 45 Degree Angle Brace Left PG-4X4-020-BRL 20" - 45 Degree Angle Brace Left 3/8" Flat Washer 3/8" X 4" Lag Screw PG-4X4-020-BRR 20" - 45 Degree Angle Brace Right...
  • Page 30 1/2" FLAT WASHER 1/2"-13 x 6" HEX BOLT 1/2" FLAT WASHER 1/2" NYLON LOCKNUT 1/2"-13 ACORN NUT 1/2"-13 ACORN NUT 1/2" NYLON LOCKNUT 1/2" FLAT WASHER PG-4X4-106-RLAA 106" Rope 3/8" FLAT WASHER Ladder 3/8" X 5 1/2" Lag Screw PG-4X4-106-AA 106"...
  • Page 31 As required repeat for all panels. #8X2 1/2 PH FLAT HD WDSCR #8X2 1/2 PH FLAT HD WDSCR PG-2X4-025-PBT 25" PANEL TOP PG-2X4-011-PBT 10 5/8" PANEL TOP 1/4 x 3" Hex Lag Screw 1/4" Flat Washer 1/4" x 3" Hex Lag Screw PG-2X4-025-PBB-A 25"...
  • Page 32 1/4" Flat Washer 1/4" x 4.5" Lag Screw 1/4 x 3" Hex Lag Screw 1/4" Flat Washer...
  • Page 33 3/8" X 4" Lag Screw 3/8" Flat Washer 26 1/2" 45 Degree Angle Brace Right PG-4x4-020-BRL 26 1/2” 45 Degree Angle Brace Left 3/8" X 4" Lag Screw 3/8" Flat Washer PG-4x4-020-BRR 26 1/2” 45 Degree Angle Brace Right...
  • Page 34 BACK VIEW Attaching Rope Block 1. Attach Rope Block with two 3/8” Lag Screws and two 3/8” Washers as shown. ROPE MUST BE TIGHT ENOUGH THAT IT CANNOT BE LOOPED BACK ON ITSELF, AND NO MORE THAN 12" OF ROPE SHOULD BE LEFT AFTER TYING KNOTS AT THE TOP AND BOTTOM OF ROPE.
  • Page 35 PG-2X4-061-HRS 60 5/8" Horizontal Roof Support 3/8" X 3" Lag Screw 3/8" Flat Washer PG-2X4-068-HRS 67 3/8" Horizontal Roof Support PG-2X4-068-HRS 67 3/8" Horizontal Roof Support 3/8" Flat Washer 3/8" X 3" Lag Screw...
  • Page 36 If installing the optional Wood Roof, stop here and follow the instructions in the Wood Roof Manual. Wrap one end of the Vinyl Roof around to the inside of the End Tarp Board and center it on the Support. Tap the snaps gently with a hammer to leave an indentation in the End Tarp Board (as shown in the Roof Snap Inset).
  • Page 37 Consumer Information Sheet for Playground Surfacing Materials The U.S. Consumer Product Safety Commission maintained at depths of 6", 9", and 12". However, it (CPSC) estimates that about 100,000 playground should be recognized that all injuries due to falls equipment-related injuries resulting from falls to the cannot be prevented no matter what surfacing mate- ground surface are treated annually in the U.S.
  • Page 38 2016 WARRANTY 5 Year Warranty Subject to proper installation and normal residential use, Woodplay warrants, subject to the limitations stated below, to the original retail purchaser, all chain, seats, swing hangers, hardware, metal braces, ropes and accessories to be free from defects in material and workmanship for a period of five years from date of purchase.
