Summary of Contents for Super SOCO TC-MAX
- Page 1 Follow us USER MANUAL SUPER SOCO World Scan QR code to www.supersoco.com download e-user manual...
- Page 2 All parameters have been permanently set according to national standards before delivery, our company is not responsible for anything change like the original electrical circuit ,wire harness and maximumspeed. Please contact the SUPER SOCO Customer Service Center 400-021-2008 if you have any questions about this bike. We are at our service at any time. Wish you safe and pleasant riding experience!
- Page 3 SAFETY INSTRUCTIONS To ensure the safety of you and others, please make sure to observe the following matters: Please do not lend your vehicle to someone who can not control it to avoid injury Minors under 16 years old is not allowed to ride our bike on the road. Please ride your bike in the bicycle lane, do not exceed the maximum speed (Keep right on the road if there is no bicycle lane) Do not ride after you take medications which may effect your riding ability, drink alcohol or when you feel physically upset.
- Page 4 SAFETY INSTRUCTIONS Check before riding. In case of any abnormality, please timely repair or go to official dealer’s service center. a. Check the power circuit, lighting circuit statues etc. b. Check whether the front and rear brakes workproperly c. Check the handlebar and the front and rear wheels fixing d.
- Page 5 QUICK START PARTS INSPECTION Quick Start Mirrrors User manual Keys Spanner for mirrors Charger...
- Page 6 QUICK START INSTALL BATTERYPACK Open storage,take out cover. Put battery package in. Connect powerplug. Switch off kill switch,put seat back.Put storage cover back and close storage.
- Page 7 QUICK START IGNITE TC-MAX Get on TC-MAX, kick side stand Press ‘UNLOCK’ onremote Put helmeton. out. control, “POWER” buttonon. Turn accelerator gently, TC- Press ‘Power’ , poweron. Press ‘Parking’ button, unpacking TC-MAX, parking MAX run. symbol off.
- Page 8 DOWNLOAD APP TC-MAX smart electric bikes has GPRS function,can connect with your smart phone. By APP,you can use smart phone to manage and query your TC-MAX. Only IOS and Android are currently available now, please confirm your smart phone operating system in advance.
-
Page 9: Table Of Contents
CONTENTS Description of Components and Parts Operation guide Riding guider Battery use instruction App instruction Maintenance FAQ & Trouble shooting... -
Page 10: Description Of Components And Parts Operation
DESCRIPTION OF COMPONENTS AND PARTS SCHEMATIC DIAGRAM OF COMPONENTS AND PARTS SIDE VIEW TOP VIEW Rear mirror Storage box Frontbrake Brake cylinder lever Accelerator Right-handlebar switch assy Speedometerassy Headlamp Battery Winker compartment Tall lamp Motor Saddle Electronic side stand FOC vector controller Rear brake Spoke-type aluminum rimlever Brakedisc Left-handlebar switchassy... - Page 11 DESCRIPTION OF COMPONENTS AND PARTS DIAGRAM OF SPEEDOMETER Speed Temperature & distance Distance per Controller temperature Total mileage charge/ trip distance/ rotating speed, ambient Display current speed Display the totalmileage Display the temperature under current temperature operating conditions Power display bar Battery percentage display Gear Display Display current battery power Display the current battery power level...
- Page 12 DESCRIPTION OF COMPONENTS AND PARTS DIAGRAM OF SPEEDOMETER Data connecting NORMAL Mode ECO Mode Charging Batteryerror High beam indicator Prompt fault code Winker indicator lighton ParkingLight M bottom instruction Displacement switching Range/Temperature Change between KM/Mile and KM/P & MPH In normal mode, press it longer than 8 seconds, then release. Innormalmode，press theswitchfor onesecond,turned into Press it less than 2 seconds, change indications, and keep thestatus.
-
Page 13: Guide
OPERATION GUIDE LEFT SWITCH High/low beam switch Winkerswitch Right switch Up position, high beam on; Down Turn to left, left winker on; Turn to right, Press, horn on; release, horn off. position, low beam on. right winkeron. - Page 14 Front Light switch Parkingswitch Up position, front light on; Down position, front light Press,light on, TC-MAX at parking position; TC-MAX is set with3 modes: automatically on. (Front light adjust the lightness 1: ECO mode 2: NORMAL mode 3: SPORT mode.
- Page 15 OPERATION GUIDE C.REMOTO CONTROL TC-MAX use second generation smart remote control, within 50 meter radius, press the button, can lock or unlock yourTC-MAX. F.POWER D.LOCK After unlocking TC-MAX via remote control, press the “POWER”,poweron,press again, power off. LOCK, when TC-MAX in resting state, press “LOCK”, “POWER”...
- Page 16 LOCK TC-MAX in parking position, turn handlebar to the extreme left position, put key in handlebar lock, and turn the key to right position, handlebar locked. Put the key in handlebar lock, turn the key to left position, handlebar unlocked.
- Page 17 OPERATION GUIDE g.KILL SWITCH Kill switch, protect power, when current over than set range cause by abnormal situation or short circuit, kill switch will stop the connection between battery and TC-MAX automatically, for safety reason. TIPS: For your own safety, please put kill switch at “OFF”position: A.
-
Page 18: Riding Guider
Whether the mirrors are clean and adjust them to the appropriateangle. Whether the brake oil is enough, whether the brake lever and brake system work properly ornot. Any exceptions or operational doubts, please contact Super SOCO official dealer’s service center. - Page 19 RIDING GUIDE b. POWER ON Press “UNLOCK” on remote control, Put on helmet. Riding TC, kick out side stand. “POWER” continuously on. Press ‘Parking’ button, unpacking TC- Turn throttle gently, TC-MAX run Press “POWER”, poweron. MAX, parking symboloff.
- Page 20 TC-MAX need to power on under steady standing status. In case any unusual situation, please move the bike to side of the road, in case any dangerous,please don’t restart the bike when it still running or in the middle of the road.
-
Page 21: Battery Use Instruction
BATTERY USE INSTRUCTION a.CHARGING ON-BOARD Connect the charger to TC-MAX charging port. Connect the charger with power supply, during normal charging, red light keeps on. When fully charged, green light keeps on. Battery Charging Display Charging: Red lighton. Full Charged: Green light on. Error: Red light,... - Page 22 BATTERY USE INSTRUCTION b.External charging Open seat,switch off kill switch; Open storage,take out storage cover,disconnect the power plug. Put key in battery lock, turn to right, then can take out the battery packfrom bike. Connect charger with battery, then connect charger with power supply, charger working, red light keepson. TIPS：...
- Page 23 BATTERY USE INSTRUCTION c.Storage、maintenance、transport Incase long time no use battery, please charge it till 50% (in case battery is empty, charge the battery pack 5 hours is enough). Disconnect the batteryfrombikewhenstoringthem.Storeindryventilatedplace, at least charge 4 hourseach 2 months. Batterypackandchargerneedtobestoredinclean,dryventilatedplace, avoidconnect withcorrosive material,stayawayfrompower,fire,heat place.
-
Page 24: App Instruction
The mobile community can be turned on and interpersonal communication can be realized in a new way. The functionality of the SUPER SOCO APP might be updated, difference will be happened due to different model and APP update. Please refer to the latest version. -
Page 25: Maintenance
The new bike must do the first inspection and maintenance in the official SUPER SOCO Service Center when it reaches 1,000 km or two months (whichever comesfirst). The motorcycle is recommended to do a regular inspection and maintenance in the official SUPER SOCO Service Center when it reaches each 3,000 km or six months (whichever comes first). -
Page 26: Faq & Trouble Shooting
5. Battery aging or normal scrap 5. Change battery Battery cannot be charged 1. Poor contact of charger plug 1. Check whether the battery plug is at right position or not 2. Used wrongcharger 2. Use SUPER SOCO charger 3. Battery aging or normal scrap 3. Change battery... - Page 27 FAQ & TROUBLE SHOOTING Error Causes Solutions Error 99 on speedometer Controller communication error Please contact after sales service or dealeraler Error 98 on speedometer Controller stop working(Possible over Please stop riding and wait for a while then restart or current,motor blocking,under voltage,over contact after sales service or dealer temperature) Error 97 on speedometer...
- Page 28 FAQ & TROUBLE SHOOTING Error Causes Solutions Error 90 on speedometer Battery discharging over current error Please stop riding if keep showing and contact after sales service or dealer Error 89 on speedometer Battery charging low temperature error Please move the bike to warm indoor place and wait for a while Error 88 on speedometer Battery discharging low temperature Please move the bike to warm indoor place and wait for a while...
- Page 29 FAQ & TROUBLE SHOOTING b.BELT WEAR ANALYSIS Error Causes Solutions In the case of internal tooth crack(in the shape of hair): Running under supervision; In the case of out tooth crack: Replace the belt; In the case of missingtooth: Replace the belt In the case of blurred coreedge: Running under supervision;...
- Page 30 FAQ & TROUBLE SHOOTING c.BATTERY FAULT REMOVAL Battery Status Issues Causes Solution Before using Battery runs out, unable to activate Battery nopower Please charge the battery the bike InOperation In battery low power mode. Battery Battery runs out, low-voltage protection Please charge the battery below 10% ,bike power-off...
- Page 31 FAQ & TROUBLE SHOOTING Battery Status Issues Causes Solution Storage Press “Start” , no power The battery is stored too long time, battery Please charge the battery. If it is not runs out possible to charge,please contact after sales service or dealer In Charge Display 89 error code Charging at lowtemperature...
- Page 32 CHECK LIST RANGE 1000 3000 6000 9000 12000 15000 18000 21000 24000 Torque（N·m） Brake fluid" Tire pressure and wear" Brake shoe wear degree before and after" Before and after the disc brake wear" Front axle nut fastening" Tighten the rear flat fork nut" Rear wheel axelnut Upper:22 Front shock boltfastening...
- Page 33 SOCO wish you a happyvoyage Bind APP Download APP 请粘贴 二维码...
