- Page 1 2507 Ring Detector Installation Guide Order Codes 2507 Ring Detector Document 90-00116A Algo Communication Products Ltd (604) 454-3792 2021-06-01 4500 Beedie St Burnaby BC Canada V5J 5L2 support@algosolutions.com Page 1 www.algosolutions.com...
- Page 2 Algo SIP endpoint. Only one compatible Algo SIP Endpoint can be connected directly to the 2507 Ring Detector at a time, however, any of the endpoint devices can send a signal to additional devices via the relay output connections on the back, or via multicast.
- Page 3 2507. This connection is not polarity dependant. 7. Plug one end of the handset cord into the RJ jack on the 2507 and the other end into the HEADSET jack on the phone.
- Page 4 10. Set the sensitivity on the 2507 to maximum, by gently rotating the adjustment knob all the way clockwise. If a continuous alert is triggered or the alerting device is activated when the phone isn’t, lower the sensitivity. 11. Test by calling the phone. If the Algo Speaker or Visual Alerter does not activate, read the Troubleshooting section below.
- Page 5 Troubleshooting Wiring Connections To verify that the Algo SIP Endpoint is powered and configured correctly, short the wire pair on the input of the alerting device and see if an audio/visual alert is triggered. If not, verify the PoE connection and web configuration options as described in the Algo SIP Endpoint Web Interface Configuration of this guide.
- Page 6 Document 90-00116A Algo Communication Products Ltd (604) 454-3792 2021-06-01 4500 Beedie St Burnaby BC Canada V5J 5L2 support@algosolutions.com Page 6 www.algosolutions.com...
- Page 7 Document 90-00116A Algo Communication Products Ltd (604) 454-3792 2021-06-01 4500 Beedie St Burnaby BC Canada V5J 5L2 support@algosolutions.com Page 7 www.algosolutions.com...
