Getting Started

With its default settings, the DI-704P, when activated, will connect with

other D-Link Express Ethernetwork products, right out of the box.

Please refer to the following

sections of this manual for

additional information about

setting up a network:

Networking Basics - learn

how to check and assign your

IP Address; share printers and

files.

Using the Configuration

Menu - learn the settings for

the DI-704P, using the web-

based interface.

For a typical network setup at home (as shown above), please do the

following:

You will need broadband Internet access (a Cable or DSL subscription line into

your home or office)

Consult with your Cable or DSL provider for proper installation of the modem

Connect the Cable or DSL modem to the DI-704P wireless broadband router

(see the Quick Installation Guide included with the DI-704P.)

If you are connecting a desktop computer to your network, you can install the

D-Link DFE-530TX+ ethernet adapter into an available PCI slot. (See the

Quick Installation Guide included with the DWL-530TX+.)

If you are connecting a laptop computer to your network, install the drivers for

the Ethernet Cardbus adapter (e.g., D-Link DFE-690TXD) into a laptop

computer.(See the Quick Installation Guide included with the DFE-690TXD.)

Connect your printer to the printer port on the DI-704P. Please refer to the

quick installation guide for loading the print server software.
