Bryant 395CAV Specifications

ENERGY-EFFICIENT
INDUCED-COMBUSTION
DELUXE UPFLOW FURNACE
With a unique approach to induced-combustion design, a 40-in.
tall cabinet, 4-pass heat exchanger, an inshot burner system,
and its safety features, this furnace is without peer. The model
395CAV Deluxe Induced-Combustion Upflow Furnace achieves
one of the highest Annual Fuel Utilization Efficiency (AFUE) rat-
ings available in a noncondensing, induced-combustion furnace.
Its ease and economy of installation, ease of serviceability, eco-
nomical initial cost, and short payback time put it in a class well
ahead of the competition. The model 395CAV Gas Furnace has
the kind of overall performance needed in today's homes. All
models are GAMA efficiency rating certified and certified for use
in California Air Quality Management Districts.
FEATURES
EFFICIENCY —The 395CAV Deluxe Induced-Combustion Gas
Furnace provides the efficiency customers want with 80.0 per-
cent AFUE.
MEDIA FILTER CABINET —Enhanced indoor air quality in your
home is made easier with our media filter cabinet—a standard
accessory on all deluxe upflow furnaces. When installed as a
part of your system, this cabinet allows for easy and convenient
addition of a Bryant high-efficiency air filter.
HOT SURFACE IGNITION —This field proven ignition system
will save energy and improve reliability.
ALUMINIZED HEAT EXCHANGER —The patented 4-pass heat
exchanger is made of aluminized steel and backed by a 20-year
Limited Warranty.
INTELLIGENT CONTROL BOARD —The 395CAV Furnace has
an intelligent control board with an LED status indicator light to
ensure top furnace performance. This control board also has a
self-test feature that enables the servicing technician to verify
operation of the board itself, the inducer, the hot surface ignitor,
both high- and low-speed blower operation, and the humidifier.
The board also features a 3-amp fuse that protects the trans-
former and board. We guarantee the reliability of the control
board with a 3-year Limited Warranty.
40-IN. HEIGHT —The 395CAV Deluxe Induced-Combustion
Furnace with a 40-in. cabinet height simplifies installation in al-
coves, attics, basements (ideal for short basement), closets, and
utility rooms, especially with a high-efficiency cooling coil.
PREPAINTED CABINET —The 395CAV uses prepainted sheet
metal for the cabinet. This is the same high-quality finish found
on refrigerators and other appliances today. We ensure its dura-
bility by using a galvanized steel substrate to provide superior
rust protection.
PATENTED BLOCKED VENT SAFEGUARD —Our induced-
combustion furnace has a patented blocked vent safeguard. The
safeguard will stop furnace operation if the vent system be-
comes blocked or is not operating properly. An exclusive with the
395CAV Furnace.
EASY INSTALLATION —The model 395CAV has many fea-
tures that make installation easier: left or right gas and electrical
connections, Molex blower speed selector, matching coil sizes,
accessory low-voltage connections, and many more.
QUIET OPERATION —A soft mount inducer assembly and slow
opening gas valve improves sound level.
Form No. PDS 395CAV.40.8
395CAV
Sizes 045 thru 155
Series H and J
