Kohler Cimarron K-6419 Quick Start Manual

Features
•
Round-front bowl.
•
Comfort Height .
•
AquaPiston flushing system.
•
Touchless Technology allows hands-free operation to actuate
the flush.
•
1.28 (4.8 lpf)
•
2-1/8" (54 mm) glazed trapway.
•
11-1/2" (292 mm) x 9-1/4" (235 mm) water area.
Material
•
Vitreous china.
Installation
•
12" (305 mm) rough-in.
•
27-1/4" (692 mm) x 17-5/8" (448 mm) x 30-1/2" (775 mm)
Recommended Accessories
K-4639 Cachet Quiet-Close™ Round-Front Toilet Seat
K-5589 Purefresh Round-Front Toilet Seat
K-76923 Puretide™ Quiet-Close™ Round-Front Manual
Cleansing Toilet Seat
K-5420 Low-Profile Bolt Caps
1023457 Wax Ring/Hardware Kit
1265114 Connector Hose
Components
Product includes:
K-4347 Comfort Height Round-front Bowl
K-5693 Toilet Tank Round-Front Touchless
Additional included component/s: Touchless Flush Kit.
1-800-4KOHLER (1-800-456-4537)
Kohler Co. reserves the right to make revisions without notice to product specifications.
For the most current Specification Sheet, go to www.kohler.com.
9-28-2018 13:01
Comfort Height Touchless Toilet
CSA B651 OBC
Codes/Standards
ASME A112.19.2/CSA B45.1
DOE - Energy Policy Act 1992
EPA WaterSense
California Energy Commission (CEC)
ADA
ICC/ANSI A117.1
CSA B651
OBC
KOHLER One-Year Limited Warranty
See website for detailed warranty information.
Available Color/Finishes
Color tiles intended for reference only.
Color Code Description
0 White
96 Biscuit
47 Almond
NY Dune
95 Ice™ Grey
G9 Sandbar
7 Black Black™
Cimarron
K-6419
